eBPF Lab: Understand and Review

You’ve now seen each eBPF tool do its job, and two of them do less than their configuration promised. This part puts the whole path back together, lists what each experiment proved, is honest about where this nested, shared-kernel setup stops, and suggests what you’d change for production. It ends with how to tear the lab down and five things to try on your own.

The Full Signal Path

1. A visit: curl or the Count a visit button calls /api/visits on 127.0.0.1:8091, which k3d maps to NodePort 30091 on the server node.
2. No kube-proxy: Cilium's eBPF programs translate the NodePort to the web pod. k3s runs with no kube-proxy and no iptables Service rules.
3. nginx proxies /api: nginx sends it to the api Service on HTTP :8080. Cilium picks one of two api pods on the pod's veth, sometimes on the other node, over VXLAN.
4. INCR in Redis: The Go API opens a connection, sends INCR visits to Redis :6379 in its own protocol and returns the count. It has no tracing, metrics or logging library.
5. Data on a static PV: Redis appends every write to its AOF on a PVC bound to a static local PV, so the counter outlives the whole cluster.
6. eBPF sees it all: Four eBPF tools watch from the kernel the k3d nodes share: packets (Cilium), HTTP and Redis calls (OBI), process executions (Tetragon, Falco).
7. Flows in Hubble: Cilium records every flow with its source and destination identity and verdict. Hubble Relay gathers both nodes for the UI.
8. OBI to mon, directly: OBI turns the traffic into RED metrics and spans and sends OTLP straight to mon's gateway, because a host-network pod can't reach the agent here.
9. Security events: Tetragon and Falco write JSON events to stdout; the platform's agent tails them like any pod log. Falcosidekick also shows Falco's in its UI.
10. The monitoring pack: The agent collector, installed by Argo CD when make up registered the lab, ships logs and metrics to the gateway with the labs token.
11. One cluster label: The gateway turns k8s.cluster.name into cluster=lab-ebpf; Mimir, Loki and Tempo keep the lab's data next to every other cluster's.
12. The lab's dashboard: Grafana on mon shows the eBPF lab dashboard in folder Labs, every query filtered on lab-ebpf.

One visit, end to end, now that you’ve seen every hop:

1. curl 127.0.0.1:8091/api/visits reaches NodePort 30091. Cilium’s eBPF translates it to the web pod; there is no kube-proxy (Experiment 1).
2. nginx connects to the api Service. Cilium picks one of two API pods on the web pod’s veth, and about half the time the packet leaves through VXLAN to the other node. Hubble records each flow with both identities.
3. The API sends INCR visits to Redis, if the policy from Experiment 2 allows its identity (it does; web’s doesn’t).
4. Redis appends the write to a file on a static PV, outside the cluster (Experiment 7).
5. OBI times the HTTP and Redis calls from the kernel and pushes metrics once a minute and spans in batches to mon’s gateway, directly, because it lives on the host network (Experiments 3 and 4).
6. If anyone runs a shell or a download tool in a demo pod, Tetragon and Falco write JSON events to stdout; the monitoring pack’s agent tails them to Loki (Experiments 5 and 6).
7. In mon, everything carries cluster="lab-ebpf", and the lab’s dashboard reads all of it.

What the Experiments Showed

Experiment	What it proved
1. See every flow without kube-proxy	Cilium load-balances Services in eBPF with zero iptables Service rules, and Hubble shows every hop, including which ones crossed nodes (to-overlay)
2. Drop a connection by identity	A policy keyed on labels drops web’s SYN to Redis while the API’s connections still work; Hubble names the verdict and the reason
3. RED metrics from an app with no instrumentation	OBI produces per-route rate, status and p95 latency and per-command Redis metrics for a Go service with no metrics code; they arrive once a minute
4. A trace across web, api and redis	OBI joins services into one trace only when they run on the same node; a cross-node request splits into two traces
5. Catch a shell in a container	A custom Falco rule catches a non-interactive kubectl exec that the stock rule misses, with pod and image metadata
6. Kill a download before it starts	Tetragon kills a process inside execve(); because wget never runs, Falco has nothing to report about it
7. Delete the cluster and keep the data	A static local PV with a fixed name, path and claimRef brings the same data back after a full rebuild, with no hostPath in any pod

Limits of This Setup

• One shared kernel. Both k3d nodes, the other homelab clusters and the host itself share one kernel. Tetragon and Falco see all of it, which is why they need namespace filters, and why Falco’s stock rules filled the Falcosidekick UI with tens of thousands of alerts that have nothing to do with the lab.
• Nested networking. Inside k3d’s node containers, host-network pods can’t use Service addresses, so Cilium, Tetragon and OBI are pointed at the API server’s node address, and OBI exports straight to the gateway instead of through the agent collector.
• Cilium’s L7 policy doesn’t work here. The first design of Experiment 2 was an HTTP-aware policy allowing only GET on the API’s read paths. Denied requests got Envoy’s 403 and showed in Hubble as L7 drops, but allowed requests timed out at Envoy’s upstream connection (503). Steering the replies in eBPF (TPROXY) and running Envoy inside the agent didn’t fix it, so the policy is parked in docs/l7-api-policy.k3d-limitation.yaml and the experiment uses an L3/L4 policy. On real nodes this is a standard Cilium feature.
• Traces split across nodes. OBI’s trace context didn’t cross nodes in this setup (Experiment 4). Half the requests are two traces instead of one.
• Hubble metrics aren’t collected. They’re enabled, but their ServiceMonitor is off because Cilium installs before the monitoring pack brings the CRD. Flows stay inside the cluster.
• The Tetragon policy matches a name. busybox wget or a renamed copy gets past it.
• Default credentials. The Falcosidekick UI uses the chart’s admin:admin. It’s only reachable on 127.0.0.1, which is the only reason that’s acceptable.
• Single instances. One Redis, one Falcosidekick, one OBI per node, one copy of every data store. Redis’s AOF is durable across rebuilds but there’s no backup.
• Viewer-only Grafana. The lab’s tooling uses a read-only token, so there’s no Explore; the dashboard’s Trace variable is the workaround.
• No alerts. Nothing pages on a Falco alert or a Tetragon kill; you have to look.

Taking It to Production

These are recommendations, not things this lab tested:

• Run Cilium on real nodes (VMs or bare metal) where L7 policy, socket-level load balancing and host-network Service access behave normally, and turn on Hubble’s ServiceMonitor once the CRDs exist. Consider Cilium’s own Hubble exporter if you need flow logs centrally.
• Default-deny network policy per namespace, then allow by identity, as Experiment 2 did for Redis.
• Scope runtime security to your workloads and tune the stock rules. Falco’s out-of-the-box rules are a starting point; in this lab they produced far more noise than signal. Route Falco alerts through Falcosidekick to your alerting (Alertmanager, Slack) instead of a UI nobody watches.
• Enforce on more than names. For Tetragon, match on file identity or restrict executables with something designed for it, and start new policies in observe-only mode (no Sigkill) before you enforce.
• Verify cross-node tracing before relying on it. If OBI’s context doesn’t cross your network path, add OpenTelemetry SDKs (or an injection point such as the ingress) to the services where trace joins matter; keep OBI for the coverage it gives everything else.
• Storage: replace static local PVs with a replicated storage class or managed data stores, with backups. Static PVs are good for a lab that must survive a rebuild on one host, not for losing a node.
• Resource limits on the eBPF agents. They run privileged in every node; their memory counts against every node in the cluster.

Tear Down

make down

make down runs lab.sh unregister lab-ebpf (Argo CD forgets the cluster and removes its apps, and the dashboard leaves mon), deletes the k3d cluster, removes any node containers k3d left behind and the image volume, and fails if anything is still there.

What it keeps:

• /srv/homelab/labs/ebpf-lab/redis and falco-ui-redis: the next make up finds the same data. Delete the folders yourself for a clean start.
• The lab’s data in mon: metrics, logs and traces with cluster="lab-ebpf" stay for mon’s retention (15 days).

make rebuild is down followed by up.

Go Further

1. Find where the INCR time goes. Experiment 4’s traces show INCR, one in-memory increment, taking almost 10 ms, and in another run 0.42 ms. Pin both API pods to the server node (Redis’s node), then to the agent node, and compare histogram_quantile(0.95, sum by (le) (rate(db_client_operation_duration_seconds_bucket{cluster="lab-ebpf"}[5m]))). Look at Hubble’s flows for the DNS lookup and TCP handshake that each new connection makes.
2. Make every trace whole. Delete one API pod and scale to one replica on web’s node; run make exp-obi-traces and check that the split query in Part 5 finds nothing new.
3. Get past the Tetragon policy, then close it. With the policy from Experiment 6 applied, run kubectl exec deploy/web -- busybox wget -q -O /dev/null http://api:8080/healthz. Expect no Tetragon kill, because the path passed to execve ends in /busybox. Then check whether Falco’s Network tool rule fired and which process name it reports, and extend the Tetragon policy to catch it.
4. Watch a DNS policy. Write a CiliumNetworkPolicy that allows the API to reach only redis and DNS. Expect DROPPED flows in Hubble for anything else it tries, such as nc from a debug pod with the API’s labels.
5. Alert on enforcement. Add a Loki alert rule in mon for {k8s_cluster_name="lab-ebpf", k8s_container_name="export-stdout"} |= "SIGKILL" and run Experiment 6 again. Expect the alert in Grafana’s alert list within a minute or two.

Check Your Understanding

Which of the four eBPF tools could you remove without losing any signal on the dashboard?

Cilium’s Hubble isn’t on the dashboard at all, but Cilium itself can’t go: it’s the cluster’s network. Of the others, each feeds its own panels (OBI the metrics and traces, Tetragon and Falco a log panel each), so none can go without emptying a panel.

Why is Falco alone not enough to stop the download in Experiment 6, and Tetragon alone not enough to tell you about Experiment 5?

Falco detects and reports; it doesn’t block. Tetragon’s policy in this lab only kills network tools; it records every process in demo pods (Experiment 5’s shell is in its events too), but it has no rule that flags a shell as suspicious and no UI or alert that would tell you.

A colleague says "OBI gives us distributed tracing for free". What would you add, based on this lab?

That it gives you spans for free, but whether they join into one trace depends on the path: in this lab, only same-node calls joined. Test it on your network before you rely on it, and add SDK instrumentation where whole traces matter.

After make down, which data survives, and where?

The Redis counter and the Falcosidekick UI’s events, in /srv/homelab/labs/ebpf-lab on the host; and the lab’s metrics, logs and traces in mon for its 15-day retention. Hubble’s flows and everything else inside the cluster are gone.
