OpenTelemetry End to End: Understand and Review

You’ve followed a click through four services, broken the backend on purpose and watched it recover. This last part puts the pieces back together: the full signal path once more, what each experiment proved, the shortcuts this lab takes, and what you’d change before running anything like it for real.

The Full Signal Path

Here is the architecture animation from Part 1 again. Every hop in it has now shown up in a screenshot, so step through it and name the evidence for each one.

1. A click starts a trace: otel.js wraps the fetch to /api/demo in a span and adds a W3C traceparent header carrying the trace ID.
2. Traefik continues it: The ingress reads traceparent and records a gateway span as a child, in the same trace.
3. Pages come from nginx: Traefik routes / to nginx, which serves the static page. nginx traces and logs its own requests, separately.
4. /api goes to FastAPI: opentelemetry-instrument wraps the API, so the request becomes a server span with no tracing code in main.py.
5. The API calls the backend: The HTTPX client span injects traceparent again, so the backend's spans join the same trace.
6. Check Redis first: The backend's Redis GET span is renamed GET (cache miss) or GET (cache hit) by a response hook.
7. SQLite on a miss (miss): On a miss the backend runs a manually created sqlite SELECT records span, then SETEX writes Redis for 60 s.
8. Spans are pushed: Every service exports spans over OTLP to the Collector. The browser's go through nginx at /v1/traces.
9. Metrics and logs are pulled: The Collector scrapes the nginx exporter every 15 s and tails JSON log lines from the pod log files.
10. One pipeline per signal: Traces go to Tempo, logs to Loki, metrics to Mimir, all in the homelab's mon cluster, tagged with the lab's cluster, lab-otel.
11. One place to look: Grafana queries all three. The shared trace ID is what lets you jump from a log line to its trace.

Read top to bottom, one click on Call /api/demo does this:

1. The browser SDK starts a span and sends traceparent with the fetch.
2. Traefik continues the trace with a gateway span and routes /api to the API.
3. FastAPI’s auto-instrumentation opens a server span; HTTPX opens a client span and forwards traceparent to the backend.
4. The backend’s spans join the same trace: the Redis GET (cache hit|miss), and on a miss the manual sqlite SELECT records span and SETEX.
5. Every service pushes its spans over OTLP to the Collector; the browser’s go through nginx’s /v1/traces proxy.
6. The API prints one JSON line with the trace_id; the Collector tails it from /var/log/pods and copies the ID into the log record’s trace context.
7. Traefik pushes request metrics over OTLP; nginx’s counters are scraped from the exporter sidecar.
8. Tempo, Loki and Prometheus store the three signals; Grafana queries all of them.

The single idea underneath is context propagation. Nothing in the backend knows about the browser, and nothing in Loki knows about Tempo. A 32-character trace ID, passed along in a header and written into a log line, is what ties them together.

What the Experiments Showed

Experiment	What it proved
1. Reload the page	Metrics and logs count different things: three files in the access log, 15 requests on nginx’s counter, because probes and exports are counted but not logged
2. Cache miss	One trace ID carried through four services and two languages: 13 spans, 18 ms, with SQLite (0.37 ms) the cheapest part
3. Cache hit	A trace’s shape shows which code path ran: 11 spans, no SQLite or SETEX; the backend got 3× faster, the request only 2 ms faster
4. Traffic burst	Pushed metrics arrive in batches: Traefik’s counter jumped by about 150 in one step, 30 to 60 seconds after the burst
5. Log to trace	Correlation is just a shared ID: the API’s log line and its trace both carry e6dc49ed…
6. Backend outage	A failure shows in all three signals, and the trace tells how it failed: a 2 ms ConnectError here, a 5 s ConnectTimeout in another run

Between them, those six cover the three ideas this lab set out to teach: propagation (2, 3, 5), transport and timing (1, 4), and correlation during failure (6).

Limits of This Setup

This lab optimises for being easy to run and easy to read. Taken from its own config, here is what it gives up:

Shortcut	Where	Why it’s fine here	Why it isn’t in production
One shared backend (mon) for every homelab cluster	Collector exporter, resource/cluster	No storage to run inside the lab	Every query needs the lab’s cluster filter, and one noisy lab can crowd the others
One OTLP token shared by every lab	Secret observability/otlp-token	Labs come and go without platform changes	Revoking it cuts off every lab at once, and a lab could claim another lab’s cluster name
/grafana-api/* proxied by nginx with a Viewer token	nginx.conf, Secret demo/grafana-proxy	Lets the page show its own telemetry; the site is on localhost only	Read access to every homelab cluster’s logs, traces and metrics for anyone who can load the site
OTLP receivers with no auth or TLS	Collector config	Cluster-internal only (the hop to mon uses TLS and a token)	Anything in the cluster could send (or flood) telemetry
parentbased_always_on sampling	Python Dockerfiles	Every trace is kept, so experiments are repeatable	At real traffic volumes, storing 100% of traces gets expensive
One replica of everything, one node	manifests, cluster.yaml	Simple and cheap	Any pod restart is an outage (experiment 6 is that outage)
Redis without persistence, SQLite in /tmp	api-backend.yaml	The data is one seeded row	Real data needs a real database and backups
No alerting	none configured	You are watching the screen	Nobody watches the screen at 3 a.m.

None of these are bugs. They are the reason the lab starts with one command on the homelab.

Taking It to Production

If this were a real service, these are the changes I’d make first, in roughly this order:

1. Separate, durable backends. Replace a bundled all-in-one backend with Loki, Tempo and Mimir (or managed equivalents) with object storage and retention policies. The applications don’t change at all: they only know the Collector’s address, which is the point of having one. This lab has taken that step: until 2026-10-14 it bundled grafana/otel-lgtm, and moving to the homelab’s mon cluster changed the Collector’s exporter and nothing in the API or backend.
2. Two Collector tiers. Keep a DaemonSet agent per node for logs and local OTLP, and add a gateway Deployment that does the heavy work (tail-based sampling, filtering, routing to backends) and can scale independently.
3. Sample deliberately. Switch to tail-based sampling at the gateway so every error trace and slow trace is kept, and only a fraction of the fast, successful ones.
4. Lock it down. Grafana behind single sign-on, no telemetry proxy on the public site, TLS and authentication on OTLP endpoints, and NetworkPolicies so only the Collector talks to the backends.
5. Alert on symptoms. Error rate and latency SLOs from the metrics that already exist (Traefik’s traefik_entrypoint_requests_total by code, and the request-duration histograms), with a link from each alert to example traces.
6. Survive one failure. At least two replicas of the API and backend, a PodDisruptionBudget, and a Redis that can lose a pod. Experiment 6 should then show a blip, not an outage.

Tear Down

make down

That first runs lab.sh unregister lab-otel, which takes the cluster out of Argo CD, removes the lab’s dashboard from mon and revokes its Grafana token, then k3d cluster delete lab-otel, which removes the cluster container and every pod. The telemetry it sent stays in mon until mon’s 15-day retention ages it out. The images you built stay in your local Docker image cache; remove them with docker image rm static-site:dev trace-lab-api:dev trace-lab-backend:dev if you want the space back. make up brings everything back from scratch.

Go Further

Each of these needs only a small change, and each produces a signal you can predict:

• Add a latency panel. The API and backend already export http_server_duration_milliseconds histograms (and Traefik exports http_server_request_duration_seconds), but no panel uses them. Add histogram_quantile(0.95, sum by (le, service_name) (rate(http_server_duration_milliseconds_bucket[5m]))) and run experiment 4 again. Expect: the backend’s p95 well below the API’s, since the API waits on it.
• Make SQLite slow. Add a time.sleep(0.2) inside the SQLite span and redeploy (make build deploy). Expect: misses about 200 ms longer than hits, and the gap visible in the waterfall at a glance.
• Stop Redis instead of the backend. kubectl -n demo scale deploy/redis --replicas=0. Expect: no 502 at all. The backend catches RedisError, sets app.cache.result=unavailable and reads SQLite every time; find those spans with { span.app.cache.result = "unavailable" }.
• Add a custom metric. Count cache hits and misses with an OpenTelemetry counter in the backend. Expect: a new metric in Prometheus with a result label, with no Collector change, because it arrives through the existing otlp receiver.
• Drop the browser SDK. Remove the <script> that loads /otel.js and click again. Expect: the trace now starts at Traefik, and state-site-browser disappears from it.

Check Your Understanding

If you replaced grafana/otel-lgtm with separate Tempo, Loki and Mimir services, what would change in the API and backend?

Nothing. They export to the Collector. Only the Collector’s exporter configuration would point somewhere new. That’s exactly what happened when this lab moved from grafana/otel-lgtm to the homelab’s mon cluster.

Why is the /grafana-api/ proxy a security problem outside a laptop?

It lets anyone who can load the site query Loki, Tempo and Mimir through nginx, with nginx’s Viewer token and no Grafana login of their own. Since the lab moved to mon, that’s every homelab cluster’s data, not just the lab’s. Logs and traces often contain user data, internal hostnames and error details. That’s why the site listens on 127.0.0.1 only.

With tail-based sampling keeping 10% of successful traces, would experiment 6 still be easy to investigate?

Yes, if the policy keeps all error traces, which is the usual reason to sample at the tail: the decision is made after the whole trace is seen, so failures can always be kept.
