Cloudutsuk Platform: Infrastructure and Environments

Every environment in this project lives on one machine: the DGX Spark under my desk, with 121 GB of unified memory that the GPU shares with everything else. So “environments” here isn’t a row of cloud accounts; it’s four long-lived k3d clusters, some short-lived ones, and a lot of care about what each is allowed to cost. This post describes what Phase 0 actually built on 2026-10-11, not a plan.

Development environment

There’s no separate development cluster for the platform, and I don’t want one yet. Development happens in three places, each cheaper than a permanent environment:

Where	What runs there	Lifetime
My workstation (the DGX itself)	Service code under test: the lab runner’s 29 tests, the portal’s Labs plugin with yarn dev	Per session
Throwaway k3d clusters	Spikes: the GPU-in-k3d test, chart experiments	Minutes to hours, then k3d cluster delete
Lab clusters (lab-<slug>)	The blog’s hands-on labs, each with its own make up / make down	Until the lab’s TTL

A throwaway cluster costs about 0.5 to 1 GB just for its k3s server, so I create one when a change can break a long-lived cluster (a new CRD, a new kind of storage) and delete it the same day. Everything a spike proves goes back into code: the GPU spike became the custom k3s image the ai cluster now runs on, and its findings are in ADR 0010.

Test or QA environment

Testing of the platform’s own services runs in CI, not in a standing QA cluster. From Phase 1 the self-hosted GitHub Actions runners (ARC, in platform) run unit, integration and API tests, then the security gates, before an image reaches Zot. Phase 3a adds Playwright journeys, Schemathesis, a nightly ZAP scan and Locust load scenarios (Product Planning).

For infrastructure, the “test” step is the plan. Every Terragrunt stack is planned before it’s applied, and the plan is read: for a k3d cluster it shows the rendered k3d config, and any change to it means the cluster is rebuilt (ADR 0006). That one rule caught the difference between adding a load-balancer port (in place) and adding a host alias (a rebuild) more than once today.

Staging environment

There’s no staging environment, and that’s a deliberate trade-off rather than an oversight. A copy of the four long-lived clusters would need roughly another 20 to 30 GB of memory, which the memory budget doesn’t have while a chat model is loaded.

What stands in for staging:

• Plan first, always (Terragrunt and Argo CD’s diff).
• Changes that can’t be undone in place go to a throwaway cluster first, as described above.
• Backups before risky changes: Velero can take an on-demand backup of any cluster in under a minute (Production environment).

TODO: Is a single platform-next k3d cluster worth its memory once the portal has users other than me? It would let Backstage upgrades and new plugins run against real Keycloak and OpenBao before platform gets them.

Production environment

Production is the four long-lived clusters, all created by infra-local and all on the homelab Docker network:

Cluster	Holds	Memory cap	Ingress address	API
core (boots first)	OpenBao, Keycloak and its Postgres, PowerDNS, Zot, cert-manager, External Secrets, ExternalDNS	6 GB	172.30.0.1	172.30.0.1:6441
platform	Argo CD, the Velero UI; later Backstage, the lab runner, the SRE agent	12 GB	172.30.0.2	172.30.0.1:6442
mon	Its bootstrap only; LGTM and Alertmanager arrive in Phase 2	10 GB	172.30.0.3	172.30.0.1:6443
ai (GPU image)	4 time-sliced GPUs; vLLM, the gateway and the RAG stack in Phase 5	16 GB	172.30.0.4	172.30.0.1:6444

Nothing in production is reachable from the internet. My own devices reach it over a private Tailscale network (ADR 0037), and every UI signs in through Keycloak.

Two host services keep production honest. A boot unit starts core first, unseals OpenBao, starts the rest and re-adds the k3d host aliases Docker drops on restart (lesson L026). A heartbeat pings healthchecks.io every five minutes while OpenBao answers healthy, so a silent DGX emails me. Backups run nightly with Velero (Compute, storage, and databases).

Infrastructure as code

Everything is code, split by what owns its lifecycle:

Repo	Owns	Tooling
infra-local	The homelab network, the four clusters, each cluster’s bootstrap Helm releases, host units and scripts	Terragrunt on the shared module (docker_network, k3d_config_cluster, helm_release)
homelab-gitops	Everything after bootstrap, through Argo CD’s app-of-apps; the ADRs	Argo CD ApplicationSets
infra-azure	The backup storage account	Terragrunt, the same shared module
infra-github	The platform’s GitHub repos	Terragrunt

Bootstrap releases are what must exist before Argo CD, or what restoring core can’t wait for: OpenBao, External Secrets, cert-manager, PowerDNS, Keycloak, Zot, Velero (ADR 0036). Each is one folder with a resources.yaml, its values and its ExternalSecrets, applied with:

venv/bin/python entrypoint.py --cloud k3d --environment homelab --provider helm \
  --stack core --resource openbao --terragrunt plan     # then apply

State lives in an Azure storage account, so losing the DGX’s disk doesn’t lose the record of what built it. Charts are pinned by version and digest, at least 14 days old, and third-party charts that aren’t published as OCI are pushed into Zot after their digest is checked (lesson L031).

Networking and DNS

The network plan is fixed and boring on purpose (ADR 0030):

• One bridge, homelab, 172.30.0.0/24. The gateway 172.30.0.1 belongs to core (DNS, the registry and its ingress); platform, mon and ai each get their own address (.2, .3, .4), added to the bridge by a host unit. Docker hands out container addresses only from .128 upward.
• Unique pod and service ranges per cluster (10.10/10.11 for core, 10.20/10.21 for platform, 10.30/10.31 for mon, 10.40/10.41 for ai), so routes between clusters are never ambiguous.
• Internal DNS: PowerDNS in core is authoritative for home.cloudutsuk.com. ExternalDNS in each cluster writes its own names, such as velero.platform.home.cloudutsuk.com. The DGX uses split DNS; pods reach PowerDNS through CoreDNS forwarding to 172.30.0.1:1053, because k3d redirects port 53 on the gateway to Docker’s own resolver inside every node.
• Certificates: real Let’s Encrypt certificates through a Cloudflare DNS-01 challenge; Cloudflare holds only the public zone and the challenge records.
• Remote access: the DGX advertises 172.30.0.0/24 to my tailnet, and the tailnet sends home.cloudutsuk.com lookups to PowerDNS, so my phone sees the same names and certificates as the DGX.

The network diagram walks the request path step by step.

Compute, storage, and databases

Compute is k3d nodes as Docker containers, one server per cluster, each with a memory cap. The ai cluster runs on a custom k3s image with the NVIDIA container toolkit and shares the GB10 GPU four ways by time-slicing; there’s no MIG on this GPU.

Storage is host paths under /srv/homelab, one folder per stateful component, so rebuilding a cluster keeps its data: OpenBao’s raft store, PowerDNS’s SQLite zone, Zot’s images, core-db for Keycloak, and folders ready for Mimir, Loki, Tempo and Grafana in mon.

Databases: one Postgres 17.10 in core (core-db, Keycloak’s realm). platform-db and ai-db arrive with Backstage and the RAG stack.

Backups (ADR 0039): Velero runs in core, platform and ai and writes nightly (kept 30 days) and weekly (kept 12 weeks) to an Azure Blob container on the Cool tier. Velero can’t copy host-path volumes, so in core a small dump pod takes application-consistent copies first: a pg_dump of every database, through a read-only role, and an OpenBao snapshot, through the pod’s own Kubernetes login and a snapshot-only policy. Velero then uploads those, encrypted with a password only OpenBao and my offline kit hold. The first run saved 714 objects and 328 KB of dumps from core. A web UI at velero.platform.home.cloudutsuk.com shows every cluster’s backups, when they ran and how big they are.

Configuration and secret management

No secret value is in git (ADR 0023). OpenBao in core holds them all in one KV store, one folder per cluster plus shared/. Every cluster runs External Secrets with its own Kubernetes-auth mount and a policy that reads only its own folder; I checked that mon gets a 403 on core/*.

The rest is careful plumbing:

• Unseal keys sit in a root-only file on the DGX, with an encrypted offline copy. The boot unit unseals from that file.
• Day-to-day changes use a periodic admin token, and since today an OpenBao sign-in through Keycloak. The root token is break-glass only.
• Scripts never print a secret: values move through pipes and 0600 temp files. For example, the storage account key goes from Azure straight into OpenBao, and the Keycloak client secrets are generated once and never rotated by a re-run.
• Configuration is values files in infra-local and manifests in homelab-gitops, reviewed as plans and diffs.

TODO: When should the OpenBao root token be revoked? It’s blocked on switching configure-core.sh from the root token to the admin token.

Environment parity

With one production per cluster, parity is about the clusters matching each other, and the labs matching what they’ll run on:

• The same k3s version everywhere (v1.35.5), with ai adding only the GPU toolkit to that image.
• The same bootstrap set in every cluster: External Secrets, its secret store, DNS forwarding, sign-in through Keycloak (oidc-rbac) and Velero. After bootstrap, Argo CD’s ApplicationSets install cert-manager and ExternalDNS the same way on platform, mon and ai.
• The same image path: every node pulls public images through the Zot mirror from one shared registries.yaml.
• Labs join the same network and send telemetry to mon (lab contract v2, below), instead of each lab bundling its own Grafana stack.

The deliberate exception is core: Argo CD doesn’t manage it, so it keeps working when platform is down (ADR 0038).

Lab contract v2

A hands-on lab is a short-lived k3d cluster that its own repo’s make up creates and make down deletes. Until Phase 2, every lab also ran its own Grafana, Loki, Tempo and Prometheus. The contract v2 (Phase 2 step 5) is what a lab does to use the platform’s monitoring instead, and what the platform does in return:

The lab	The platform
Creates its cluster on the shared homelab Docker network, named lab-<short>	A host script registers the cluster with Argo CD, labelled for labs
Keeps its own pod and service ranges, one pair per lab from 10.100 up, so two labs can run side by side	Argo CD installs only cert-manager and the monitoring pack there: the OpenTelemetry Operator, the agent and cluster collectors, kube-state-metrics
Lists every host port it publishes, the Kubernetes API’s included, and the memory it needs, in its card’s deploy: block	The lab runner refuses a deploy that clashes on a port or would leave the host short of memory (ADR 0017)
Pulls public images through the Zot mirror and resolves the internal zone through PowerDNS	Same mirror and DNS as every other cluster
Sends its apps’ OTLP to the in-cluster agent collector	The collectors label everything with the cluster’s name and forward it to mon with the shared labs token
Ships its dashboards as JSON in its repo	They’re loaded into mon’s Grafana, folder Labs, at registration and removed when the lab leaves
Publishes its UIs as NodePort Services on localhost ports	A labs gateway gives each one a name and a certificate on the tailnet, such as https://hubble-ui.ebpf.labs.home.cloudutsuk.com (ADR 0045)
Leaves the platform first in make down, then deletes the cluster	Argo CD stops managing the cluster before it disappears

Every query in a lab’s dashboards and checks filters on its cluster, because mon holds every cluster’s signals: cluster on metrics, k8s_cluster_name on logs, resource.k8s.cluster.name on traces. The screenshot tooling and the labs’ verify targets read mon’s Grafana with a read-only service-account token, since Grafana there needs a Keycloak sign-in.

As built (2026-10-14): the eBPF lab runs on it, and its metrics, logs and traces reach mon. A lab scaffolded from the learning-lab skill’s new template went from make up to its first verified metric in mon in about 8 minutes, most of it the monitoring pack’s first install. Its make down left nothing behind in Argo CD or Grafana. A lab that has to run without the homelab still uses the v1 template, with its own Grafana stack.

Capacity and quota planning

Memory is the only quota that matters on this box. The DGX doubles as my desktop, which left about 81 GB free, so the platform plans for about 75 GB (the mid-range budget in ADR 0010):

Consumer	Budget
Chat model (vLLM, starting size)	~30 GB planned; ~21 GB built (gpt-oss-20b, ADR 0046); ~44 GB since 2026-10-16 (Qwen3.5-35B-A3B, ADR 0049)
Embeddings, gateway, RAG stack	~7 to 11 GB
core, platform, mon	~16 to 21 GB
Lab clusters, in total	~10 GB
CI builds, in bursts	~4 to 8 GB

Two catches shape how I measure it. GPU memory on the GB10 is unified system memory that isn’t charged to any container, so per-cluster figures undercount ai by the size of its vLLM slices; the host’s free -g is the real total. And a k3d cluster costs 0.5 to 1 GB before any workload runs, which is why labs need admission control in the lab runner rather than good intentions.

Disk isn’t a constraint (3.3 TB free), and the cloud side is cents a month for backups.

Measured 2026-10-15, chat model loaded (Phase 5 step 1). gpt-oss-20b in a 0.17 slice: host MemAvailable fell by about 22 GB when it loaded, and with it running the DGX had 26 GB available. That was with the embeddings model, every long-lived cluster, the eBPF lab and the desktop running. Free memory is well below the 81 GB this plan assumed, which is why the chat slice started smaller.

TODO: Set the lab runner’s admission limit from this measurement, once the rest of Phase 5 (Qdrant, Redis, the RAG services, Phoenix) is running and measured.

Checklist

• homelab network and the four long-lived clusters created from infra-local (2026-10-11)
• Every cluster syncs its own secrets from OpenBao and is refused another cluster’s
• Internal names resolve on the DGX, in every cluster and over the tailnet, with valid certificates
• Boot unit and heartbeat installed; nightly Velero backups in core, platform and ai
• Reboot test: everything comes back unsealed, with host aliases and the tailnet route
• First restore test of core’s dumps into a throwaway cluster
• OpenBao root token revoked after configure-core.sh moves to the admin token
• Memory budget confirmed with the chat model loaded

• Decision on a platform-next cluster before the portal gets other users
