State of DevOps: Infrastructure and Environments

State of DevOps runs the same Helm charts in three places: a k3d cluster on a laptop, a development AKS cluster where open pull requests can be previewed, and production AKS behind ArgoCD. Keeping those three close is what lets one person change a cronjob on a Tuesday evening and trust it in production on Wednesday morning.

Development environment

The development environment is k3d (k3s in Docker) with a bundled local registry:

task local-start                      # k3d/create-cluster.sh: cluster k8cron-cluster, secrets, file share
task build-state-of-devops-all        # docker build every component
task import-state-of-devops-all       # k3d image import (no local registry)
task state-of-devops-deploy-local     # shared infra + one helm upgrade --install per cronjob

The k3d/ folder holds the scripts behind those tasks: create, restart and clean up the cluster, set up local secrets, and set up the file share resources so /data is a host bind mount. That last part is underrated: you can open last night’s analyzer output on the laptop with ls and jq instead of kubectl exec.

Test or QA environment

There’s no separate QA cluster. Testing follows the ladder from Quality Assurance: local Python with dry-run, then k3d, then the development AKS cluster.

The development cluster is also where PR preview deploys run, currently piloted on devops-cost-analyzer. When CI is green on a PR that changes a preview-enabled service, a “Review deployments” approval appears on the run (with a 15-minute watchdog that cancels it if nobody answers). Once approved, the image is built as <svc>:pr-<number> and ArgoCD is pointed at it with a Helm parameter override, without committing to the GitOps repo. Closing the PR removes the override, and a nightly sweep catches anything missed. It’s a neat way to get a QA environment per PR without maintaining one.

Staging environment

For a read-only reporting tool, a full staging copy of production is hard to justify: the jobs read the same real GitHub orgs, so a staging cluster would mostly duplicate API traffic. The development cluster with PR previews covers most of what staging would.

The one thing staging would add is a place to run a new analyzer version against production-sized data before its numbers go on the dashboard. A cheaper equivalent is running the new version in the development cluster writing to a separate path (for example /data/devops-state-canary/) and diffing against production for a few days.

TODO: Is there a staging environment today, or is it development cluster then production?

Production environment

Resource	Production setting
Cluster	AKS, managed by ArgoCD (one application per component)
Namespaces	cronjobs (13 jobs), state-of-devops (dashboard)
Images	JFrog Artifactory, tagged with the 7-character Git SHA and :latest on main
Ingress	nginx with SSL redirect, internal hostname
Storage	Azure File Share; jobs via cron-jobs-data-pvc, dashboard via its own PV and PVC (ReadWriteMany, mounted read-write)
Cache	Azure Cache for Redis (TLS port 6380)
Identity	Workload Identity on cron-jobs and state-of-devops ServiceAccounts
Secrets	External Secrets Operator from Azure Key Vault

TODO: Is production on a dedicated AKS cluster or a shared platform cluster, and which team owns the cluster itself?

Infrastructure as code

Kubernetes resources are fully in code: Helm 3 charts per component, the cronjob-library library chart for shared templates, and cronjob-shared-infra for the ServiceAccount, ExternalSecrets and the shared PVC. Promoted values live in a separate GitOps apps repository that ArgoCD watches.

The Azure resources underneath (storage account and file share, Redis, Key Vault, Workload Identity federated credentials) are a different story. For the enterprise scorecard phase they should be in Terraform too, and the project’s own infra analyzer already checks other repos for Terraform; it should pass its own check.

TODO: How are the Azure resources (storage account, Redis, Key Vault, identities) provisioned today: Terraform, portal, or a platform team’s modules?

Networking and DNS

• One internal DNS name for the dashboard, pointing at the nginx ingress controller’s internal load balancer, with TLS and SSL redirect.
• No inbound traffic to cronjobs; they only need egress to GitHub, JFrog, Azure management endpoints, Teams and Jira.
• Locally, traefik in k3d plus a port-forward to 127.0.0.1:8000.

Egress is worth writing down as an allow-list, because it doubles as documentation of every external dependency (see Security and Privacy).

Compute, storage, and databases

Workload	Requests → limits	Pattern
Analyzers	200m / 512Mi → 1000m / 1Gi	Short-lived pods, once a day
Collectors, summary generator	100m / 256Mi → 500m / 512Mi	Short-lived pods
Dashboard	100m / 128Mi → 500m / 512Mi	One long-running pod (to become 2 to 3)

Storage is one Azure File Share mounted as /data, which suits this workload: many small JSON files, written once, read many times, by pods in two namespaces. There’s no relational database; Redis is a cache only, so losing it costs speed, not data.

Configuration and secret management

Configuration is config.yaml in the image, overridden by a ConfigMap from the chart’s configYaml value; environment differences are in values.yaml versus values-local.yaml. Secrets come from Key Vault through External Secrets in AKS, and from values-local.yaml or kubectl create secret (via the setup-local-secrets.sh script) in k3d.

The rule that keeps this manageable: no environment-specific values in config.yaml. Org lists, thresholds and toggles are the same everywhere; only endpoints, identities and hostnames differ, and those belong in the values files.

Environment parity

Parity is good where it’s cheap and deliberately broken where it isn’t:

Aspect	k3d	AKS	Parity
Helm charts and templates	Same	Same	Full
Images	Same Dockerfiles, local tags	JFrog tags	Full (build), different registry
Storage	Host bind mount	Azure Files	Different driver, same paths
Secrets	Local secrets	External Secrets	Different source, same secret names
Ingress	traefik	nginx	Different, rarely matters
Redis	redis:7-alpine pod	Azure Cache for Redis	Different, TLS only in AKS

The Redis row is the one most likely to bite: TLS on 6380 in AKS and plain 6379 locally means the TLS code path is only exercised in the cloud.

Capacity and quota planning

The binding constraint isn’t CPU or storage, it’s GitHub API rate limits. Each GitHub App installation has its own hourly budget, so per-org Apps spread the load, and the central collector with ETags keeps repeated calls cheap (a 304 Not Modified response to a conditional request does not count against the rate limit).

Other quotas to plan for:

• Schedule window: all daily jobs must finish between 02:00 and 07:00 UTC; job duration should be tracked against that window as orgs grow.
• Azure Files: capacity grows linearly with daily outputs kept forever (see retention in Data and Integration).
• Dashboard: replicas and requests sized from the load test, once autoscaling is on.

Checklist

• k3d environment created with one task, data visible on the host
• PR preview deploys extended beyond the cost analyzer pilot
• Decision recorded on staging (or the canary-path alternative)
• Azure resources defined in Terraform
• Egress allow-list documented and enforced
• No environment-specific values in any config.yaml
• Redis TLS path tested locally

• GitHub rate-limit usage per App tracked, with headroom
