State of DevOps: CI/CD and Release Management

The release pipeline for State of DevOps follows one principle: build once, deploy many by re-tagging. A merge to main builds each changed component’s image and chart exactly once. A release is a version bump in versions.yaml that re-tags that same image as vX.Y.Z and opens a promotion pull request in the GitOps repository. Nothing is rebuilt between development and production, so what was tested is what ships.

Build automation

CI is one GitHub Actions workflow (ci.yaml) built mostly from the organization’s reusable workflows:

prepare ─▶ detect-components ─▶ build-components (matrix: one job per changed component)
                              ├▶ sonarqube-scan (matrix)
                              └▶ tag-latest (main only)
detect-helm-charts ─▶ helm-charts (package + publish changed charts)
codeql-scan (on changes + weekly full scan, Mondays 06:00 UTC)
preview-approval / release-approval (+ 15-minute expiry watchdogs)

Change detection is what makes the monorepo affordable: a change in devops-ghas-analyzer/ builds only that image and chart. Manual dispatch inputs allow building one specific component, or forcing a build of everything, which is useful after a change to cronjobs/common/ that every image copies in.

Automated test execution

Tests run in the SonarQube job per component (test_path: tests), so coverage is reported where the quality gate can see it. The suites described in Quality Assurance slot in by layer:

Stage	Tests
Every PR	Unit tests, contract tests on file models, golden-file regression
PR preview (development cluster)	The changed job run once against the dev data path
After release to dev	End-to-end chain against a test org

Gates block; they don’t just report. The merge policy for main:

Check	Blocks the merge when
Build and unit, contract and golden-file tests	Any test fails
SonarQube quality gate (sonar.qualitygate.wait=true, so the job fails with the gate)	New bugs or vulnerabilities, unreviewed security hotspots, coverage on new code under 80%, or duplication on new code over 3%
CodeQL on the PR	A new high or critical alert
Review	No approval from the component’s CODEOWNER, or the branch is behind main

These are required status checks in a ruleset on main, with stale approvals dismissed on new pushes, so nothing reaches the build-once step without passing them. The weekly full CodeQL scan is the one check that only reports, since it runs on main rather than on a PR; its findings become issues.

Static analysis and security scanning

• SonarQube per component, with its own project key, for code quality, coverage and Python security rules.
• CodeQL through a reusable workflow, configured with a projects file, on changes and as a weekly full scan.
• Image scanning is in place: the CI build job calls the shared Docker and JFrog workflow with xray_scan: true, so JFrog Xray scans every built image, and the release workflow sets it again when it publishes. PR previews set xray_scan: false to stay fast. What’s left is an agreed severity threshold that fails the build, which is the bar the pipeline analyzer checks other repos against.

Artifact and container management

Artifact	Where	Tags
Container images	JFrog Artifactory	<short-sha> on every build, :latest on main, vX.Y.Z on release
Helm charts	JFrog (chart repo)	Chart version = release version
Local images	k3d registry (localhost:5000/k8cron/…)	:latest

The JFrog step that re-tags an image for a release (jf rt docker-promote) authenticates with GitHub OIDC, so no long-lived JFrog credential is stored in the repo for releases. Image tags per component are tracked in versions.yaml, which is the single manifest of “what version is what”.

Deployment automation

Deployment is GitOps with two repositories: this one (code, Dockerfiles, charts, workflows, versions.yaml) and a GitOps apps repository that ArgoCD watches.

merge versions.yaml bump
  └▶ auto-release.yaml ─▶ release.yaml (per bumped service)
        retag-image     <service>:<sha> ─▶ <service>:vX.Y.Z      (no rebuild)
        publish-chart   chart <service> @ X.Y.Z
        github-release  tag <service>-vX.Y.Z + GitHub Release
        open-dev-pr     promotion PR in the apps repo (dev)  ─▶ merge ─▶ ArgoCD syncs dev

make promote SERVICE=<svc> VERSION=vX.Y.Z   (approve the production environment)
  └▶ promotion PR in the apps repo (prod) ─▶ merge ─▶ ArgoCD syncs prod

Starting a release is one action: approve the post-merge release prompt (patch bump), run the “Version Bump” workflow from the Actions tab, or make release SERVICE=<svc> [BUMP=minor]. For quick iteration in the cloud, task dev-pause / task dev-push short-circuit the loop for one app and resume ArgoCD sync afterwards.

Database deployment strategy

There’s no database to migrate. The equivalent concern is output format changes: when a new analyzer version changes its JSON shape, readers (dashboard, trends, summary) must handle both shapes before the analyzer is released, because history keeps the old shape forever. The safe order is:

1. Release readers that accept both the old and new shapes (keyed on the version in metadata.json).
2. Release the analyzer that writes the new shape.
3. Leave the old-shape support in place for as long as old files are read.

Redis needs no migration: cache keys include the date, and a flush only costs a slower first request.

Approval gates

Gates use GitHub environments with required reviewers:

Environment	Gates	Expiry
development	PR preview deploy to the development cluster	15-minute watchdog cancels the run
release	Post-merge “create a patch release?” prompt	15 minutes; ignore it to release later
production	promote.yaml, the prod promotion	Until approved

Plus the ordinary gates: branch protection on main (the only guard on the build-once step) and the review of each promotion PR in the apps repository.

Versioning and release notes

Each service has its own semantic version in versions.yaml; shared charts (cronjob-shared-infra) are versioned through their own Chart.yaml. A release creates a <service>-vX.Y.Z tag on the source commit and a GitHub Release.

For this project, release notes have a second audience besides engineers: anyone who reads the trend charts. Any release that changes what is measured (a new check, a threshold, a parsing fix) should say so in plain words, with the date it takes effect, so a jump on the chart isn’t mistaken for progress.

Rollback and roll-forward procedures

Because images are immutable and every release is a tag, rollback is a promotion of the previous version:

make promote SERVICE=devops-repo-analyzer VERSION=v1.0.0   # previous good version

ArgoCD syncs it, and the next scheduled run uses it. For a bad run rather than a bad release, roll forward on data: fix the analyzer, then re-run it for the affected day; since outputs are idempotent per date, the rerun overwrites the bad folder. Bad numbers already shown to people need a note on the dashboard, not just a fix.

Release calendar

There’s no fixed release train, and a project like this doesn’t need one. Two windows matter instead:

• Don’t promote analyzers during the nightly run window (02:00 to 07:00 UTC), or a job can start on one version and its dependants on another.
• Freeze measurement changes before audits and executive reviews, so the numbers people are about to discuss don’t move for reasons unrelated to the work.

TODO: Are there recurring dates to freeze around (quarterly business reviews, audit fieldwork)?

Checklist

• Only changed components are built; a forced full build is available
• Failing tests and quality gates block the merge
• Xray image scan fails the build on an agreed severity
• Releases re-tag the tested image; nothing is rebuilt after merge
• Production promotion requires an approved production environment
• Release notes call out every change to what is measured
• Rollback by promoting the previous version rehearsed once

• No promotions inside the 02:00-07:00 UTC run window
