State of DevOps: Quality Assurance

For most software a bug means something breaks. For State of DevOps a bug usually means a wrong number, and nothing breaks at all. The dashboard renders, the chart looks fine, and an executive could conclude that CODEOWNERS coverage dropped overnight when only a parser changed. So the test strategy for this project is less about “does it run” and more about “can we trust what it says”.

Unit testing

Every component has a tests/ folder (the repo analyzer has test_main.py, the shared clients in cronjobs/common/ have their own, and the dashboard backend tests its config), and CI points SonarQube at those tests per component.

The unit tests worth having in this codebase are the ones around decisions:

• each sub-analyzer’s pass/fail logic against small hand-written repo payloads;
• date-folder path building, including UTC day boundaries and ISO weeks;
• the stale-repo threshold and exemption wildcards;
• GitHubAppTokenManager refreshing tokens before the 5-minute expiry buffer.

def test_repo_without_codeowners_fails():
    client = FakeGitHub(files={"README.md"})
    result = CodeownersAnalyzer(client, config={}).analyze("org-a", {"name": "svc-x"})
    assert result["has_codeowners"] is False

TODO: What is unit test coverage per component today? The frontend has no test files yet, so react-scripts test currently has nothing to run.

Integration testing

The project already has a well-defined integration ladder in its testing docs, and it’s the right one:

Layer	Answers	Speed
1. Local Python	Does the logic work against the real GitHub, Jira or JFrog APIs?	Seconds
2. Local k3d	Do the image, Helm chart, configYaml, secrets, mounts, RBAC and schedule work?	Minutes
3. AKS	Does the real path (ExternalSecrets, ArgoCD, Azure Files) work?	Slower

The rule is to pick the lowest layer that answers your question. Layer 1 runs src/main.py directly with PYTHONPATH pointing at cronjobs/common/ and, crucially, with dry-run turned on in config.yaml, so Jira and Teams side effects are logged instead of sent.

Contract testing

The contracts in this system are files, so contract tests check files. For every folder a job writes, a JSON Schema (or a Pydantic model shared between writer and readers) describes the shape:

# Shared model, imported by the analyzer (writer) and the dashboard backend (reader)
class CodeownersResult(BaseModel):
    repo: str
    has_codeowners: bool
    path: str | None = None

The analyzer’s tests validate what it writes against the model; the backend’s tests load a sample file through the same model. A renamed field then fails a test in CI instead of blanking a column in production. The Jira create-story endpoint deserves one contract test against Jira’s API shape too.

End-to-end testing

The end-to-end path is: collector → analyzer → aggregators → dashboard. In k3d it can be run on demand instead of on the schedule:

task state-of-devops-deploy-local
kubectl create job --from=cronjob/github-data-collector e2e-collect -n cronjobs
kubectl create job --from=cronjob/devops-repo-analyzer  e2e-repo    -n cronjobs
kubectl create job --from=cronjob/devops-summary-generator e2e-sum  -n cronjobs
curl -s http://127.0.0.1:8000/api/home-overview | jq '.generated_at'

Against a small test org with known gaps, this is the one test that proves the whole chain. It’s worth wrapping as a task e2e-state-of-devops so it’s one command, in keeping with the “everything is a task” rule.

Regression testing

The regression that matters is a number changing when nothing in GitHub changed. A golden-file test catches it: keep a frozen snapshot of collector output for a test org, run every analyzer against it, and compare the results with stored expected outputs. Any diff is either an intended rule change (update the golden files in the same PR, and announce the change) or a regression.

Performance and load testing

Two very different performance questions:

• Jobs: do all daily jobs finish inside their window (02:00 to 07:00 UTC) as orgs and repos grow? Track run duration per job and alert when one takes more than half its slot.
• Dashboard: does it stay fast with many users? Home reads one file, so load is mostly the analysis tabs. A short k6 or Locust run against /api/organizations/{org}/repositories with a cold and a warm Redis cache gives the numbers needed to size the autoscaling settings.

TODO: How long does each daily job take today, and how many concurrent dashboard users are typical (for example around an executive review)?

Security testing

CI runs SonarQube per component and CodeQL on changes plus a weekly full scan. On top of that, the security tests specific to this app are:

• path traversal attempts on every {org} and {repo} path parameter (..%2F..%2F, absolute paths);
• calling POST /api/jira/create-story without the required group membership once SSO is in place;
• confirming no secret values or file contents appear anywhere under /data (a grep in the e2e test);
• the JFrog Xray image scan that every CI build already runs, with an agreed severity threshold.

Accessibility testing

An automated axe or Lighthouse accessibility run against the built React app in CI catches the basics (contrast, labels, keyboard focus). Charts need a manual check: can the trend be read without colour, and is there a table view? Details are in User Experience and Design.

Compatibility testing

The audience uses managed corporate laptops, so the browser matrix is short: current Edge and Chrome. The compatibility that actually breaks things here is on the API side:

• GitHub API changes (deprecated fields, new rate-limit headers): pin API versions where GitHub supports it (X-GitHub-Api-Version).
• Python base image upgrades (3.11 to 3.12): run the golden-file regression suite on both.
• Kubernetes upgrades on AKS: CronJob API and Helm chart compatibility, checked in k3d first.

User acceptance testing

For a measurement tool, user acceptance means a domain owner agrees the numbers are right. Before a new analyzer’s tab is switched on through /api/sidebar-config, someone who knows that domain (security for GHAS, finance or the platform owner for cost) checks five repos or line items against the source system and signs off.

TODO: Who signs off new analyzers today, and was there a UAT step before the cost or GHAS tabs went live?

Test data and test environment management

• Test org: a small GitHub organization (or a set of repos) with deliberate gaps: no CODEOWNERS, no branch protection, an archived repo, a stale repo, a fork. Every check has a repo that fails it.
• Golden snapshots: frozen collector output for that org, versioned in the repo.
• Environments: local Python, then k3d (values-local.yaml), then AKS, as in the ladder above.
• Secrets: a git-ignored .env per cronjob for layer 1; never real production tokens in tests.

Checklist

• Unit tests for every sub-analyzer’s pass/fail logic
• Frontend tests started (at least the API client and the Jira modal)
• Dry-run on by default for local runs
• Shared models validate every file contract on both sides
• task e2e-state-of-devops runs the whole chain against a test org
• Golden-file regression suite in CI
• Job durations tracked against their schedule windows

• Domain owner sign-off before any new tab is switched on
