State of DevOps: Implementation

Most of State of DevOps was implemented by one person, over 8 to 10 months, before the DevOps team started contributing. Keeping that going for months depends on making the second analyzer cheaper than the first, and the tenth cheaper still. This post is about the patterns that did that, and the debt they left behind.

Sprint or iteration planning

Solo development doesn’t need ceremonies, but it needs a cadence. The one I’d recommend for a project like this is a two-week iteration with a single rule: every iteration ends with a number someone can see change. A new check in the repo analyzer counts, a refactor alone doesn’t.

With a team, the natural split follows the component boundaries: one person per analyzer per iteration, and shared code changes reviewed by whoever owns cronjobs/common/.

TODO: What cadence did the solo phase actually follow, and does the team now run sprints in Jira for this project?

Feature development

Most features are a new check. The repo analyzer is built from sub-analyzers (branching, documentation, codeowners, secrets, environments, properties, pr-health, rulesets, pull_request, repository), and each one answers one family of questions for one repository. A new check slots into that structure. In outline:

# Sketch of the sub-analyzer shape; names simplified
class CodeownersAnalyzer:
    name = "codeowners"

    def __init__(self, client: GitHubAPIClient, config: dict):
        self.client, self.config = client, config

    def analyze(self, org: str, repo: dict) -> dict:
        paths = ["CODEOWNERS", ".github/CODEOWNERS", "docs/CODEOWNERS"]
        found = next((p for p in paths if self.client.file_exists(org, repo["name"], p)), None)
        return {"repo": repo["name"], "has_codeowners": found is not None, "path": found}

The orchestration around it (iterate orgs, read the collector cache, call the sub-analyzers, write /data/devops-state/repo-analysis/{org}/{YYYY}/{MM}/{DD}/codeowners/) is shared, so a new check is mostly the analyze method plus a test.

A whole new domain (an analyzer per area of the future enterprise scorecard) repeats the same steps at a larger scale: copy a component folder, change the domain name, add an output folder and a tab.

API and UI implementation

The backend is a FastAPI app with services behind the routes:

Service	Responsibility
storage_client	Reads files from the local filesystem (k3d) or Azure Files (AKS)
cache_client	Redis memoization of expensive aggregations
applications_service	Application to Jira epic mappings from applications/config/
ghas_service	GHAS analyzer output
cache_warmer	Pre-fetches popular endpoints at startup

The pattern that does most of the performance work is memoizing an aggregation by its inputs, which here are the domain, org and date:

# Sketch of the memoization idea; key includes the analysis date, so a new day is a new key
async def org_summary(domain: str, org: str, date: str) -> dict:
    key = f"summary:{domain}:{org}:{date}"
    if (hit := await cache.get(key)) is not None:
        return hit
    summary = await build_summary(domain, org, date)   # reads many JSON files; off the event loop via asyncio.to_thread
    await cache.set(key, summary, ttl=6 * 3600)
    return summary

Because data only changes once a day, the date in the key does the invalidation for free.

On the frontend, each domain gets an org list page and a repo detail page, wired through React Router, with Axios calls wrapped in one API client and shared table chrome (Pagination, refresh buttons, the Jira modal).

Database and infrastructure implementation

There’s no database to implement; storage is Azure Files, and the “schema” is the path layout built by each job’s storage client (see Data and Integration).

The infrastructure implementation is Helm, in three layers:

• cronjob-library: a library chart with the CronJob and ConfigMap templates every job uses.
• cronjob-shared-infra: provisions the cron-jobs ServiceAccount, the ExternalSecrets and the shared PVC cron-jobs-data-pvc in the cronjobs namespace.
• One chart per component: mostly values, including the schedule, resources (analyzers request 200m / 512Mi and limit at 1000m / 1Gi; lighter jobs 100m / 256Mi to 500m / 512Mi) and configYaml.

The dashboard chart adds the Deployment, Service, Ingress, Redis, the Azure Files PV/PVC and its own ServiceAccount for Workload Identity.

Integration development

Each external system got one shared client in cronjobs/common/, written once and reused everywhere:

Module	Integration
github_api_client.py	GitHub REST + GraphQL, rate-limit aware, retries
github_app_auth.py	GitHubAppTokenManager: per-org App JWT, cached installation tokens
fileshare_storage_client.py	Azure Files with the credential chain
jira_api_client.py, jira_story_creator.py	Jira stories from the dashboard
teams_notifier.py	Teams webhook messages

The biggest integration change was the move to a central collector: github-data-collector fetches the shared repository data once with ETags, and the analyzers read it from /data/github-data/ before calling the API for anything domain-specific. If I were starting again, I’d build the collector first.

Technical debt tracking

Debt in this project is known and listable, which is the best kind. The current list:

Debt	Why it matters	Where it’s addressed
Dashboard runs 1 replica; autoscaling values exist but no HPA template	No redundancy during node drains or upgrades	Operations
Jobs ordered by clock, not by dependency	Trends can read yesterday’s repo data	Continuous Improvement
No pruning of daily outputs	Storage grows forever	Data
Create React App is unmaintained	Build tooling will age out	Continuous Improvement
Storage key fallback in production	Broad credential that isn’t needed	Security
Docs drifted (CRA vs Vite)	Contributors get wrong instructions	Documentation

I’d keep this table as a Jira epic with a label, and spend roughly one iteration in five on it.

Code reviews

During the solo phase there was nobody to review, which is the normal reality of one-person projects. The substitutes are CI (SonarQube, CodeQL, tests) and a self-review pass the next day. With the team on board, the repo’s CODEOWNERS file gives every component a reviewer.

For this codebase, the review question that matters most isn’t style: “could this change move a number on the dashboard?” If yes, the PR needs a before/after comparison for at least one org, because executives will notice the jump before the reviewer does.

Developer documentation

The developer docs that pay for themselves here are short and specific:

• cronjobs.md: one table per job with schedule, source, reads, writes and env.
• storage.md: the /data tree, so nobody invents a new path.
• deployment.md: the build / import / deploy trio and the roll-up tasks.
• Docstrings on the shared clients in cronjobs/common/, since everyone calls them.

What’s missing is a “how to add an analyzer” page that walks the steps in Feature development end to end. It’s the most common task and the one a new team member is most likely to get subtly wrong.

Checklist

• Each iteration ends with a visible change on the dashboard
• New checks follow the sub-analyzer shape with a test fixture
• Expensive endpoints memoized in Redis with the date in the key
• Every external call goes through a shared client in cronjobs/common/
• Tech-debt table kept as a labelled Jira epic and reviewed each iteration
• PRs that can move a number include a before/after comparison

• “How to add an analyzer” guide written
