State of DevOps: Development Preparation

The development setup for State of DevOps was built for a team of one, and it had to survive the DevOps team joining 8 to 10 months later. The conventions that make that possible are simple. Every component has the same folder shape, every operation is a task, and the whole platform runs on a laptop in k3d with the same Helm charts as production. A new contributor learns one component and knows how all the others work.

Repository and branching strategy

State of DevOps lives in a monorepo with one top-level folder per component, next to shared code (cronjobs/common/), shared Helm charts (cronjob-library/, cronjob-shared-infra/), local cluster setup (k3d/) and docs. The same repo also hosts a sibling productivity dashboard, which reuses the same shared code.

A monorepo fits because the components change together more often than you’d expect: a change to github_api_client.py affects every job. CI detects which components changed and builds only those, so the monorepo doesn’t cost build time.

Branching is short-lived feature branches off main, named after the Jira issue (<JIRA-KEY>-<number>-<short-description>), merged by pull request. main is what CI tags :latest and promotes.

TODO: Which rulesets protect main (required reviews, required checks, linear history)? The repo should pass every check its own repo analyzer enforces.

Coding standards

The standards that matter most in this codebase are the ones that keep thirteen jobs consistent:

• Use the shared clients. GitHub calls go through GitHubAPIClient (rate limits, retries, GraphQL); storage through FileShareStorageClient and analyzer_storage_client, whose format_date_path builds the dated folders. A job that calls requests.get on GitHub directly is a review comment.
• Config, not constants. Thresholds, org lists, exemptions and toggles live in config.yaml.
• Logging through setup_logging, with the org and job name in every line.
• Python type hints and Pydantic models at the API boundary.
• SonarQube’s Python rules in CI are the enforced baseline.

TODO: Is a formatter or linter (ruff, black) enforced locally or in CI? If not, adding ruff with a pre-commit hook is a one-hour change that ends style discussions in review.

Project structure

Every cronjob has the same shape:

<component>/
├── Dockerfile
├── requirements.txt
├── config.yaml          # defaults; overridden by a ConfigMap in the cluster
├── helm/                # Chart.yaml, values.yaml, values-local.yaml, templates/
├── src/
│   └── main.py          # entrypoint
└── tests/

Each chart depends on the cronjob-library Helm library chart for the CronJob and ConfigMap templates, so a component’s helm/ folder is mostly values. The dashboard follows the same idea with backend/, frontend/, helm/ and one Dockerfile that builds the React app and serves it from FastAPI.

The payoff of a fixed shape is that scaffolding a new analyzer is a copy and a rename, which matters for the enterprise scorecard phase.

Local development setup

Two loops, for two kinds of change:

# Whole platform in a local cluster
task local-start
task build-state-of-devops-all
task import-state-of-devops-all
task state-of-devops-deploy-local
task port-forward-devops-state-dashboard    # http://127.0.0.1:8000

# Dashboard only, with hot reload
task local-development                      # backend :8000 (uvicorn --reload), frontend :3000

The frontend dev server is the Create React App one (react-scripts start), which proxies /api to the backend through the proxy field in package.json. The docs carry a hard-won tip: always use 127.0.0.1, not localhost, because IPv6 resolution keeps causing failures. The CRA proxy is still set to http://localhost:8000, so it’s worth changing it to 127.0.0.1 to follow the project’s own advice.

To look at real data locally, the k3d server container exposes the share:

docker exec k3d-k8cron-cluster-server-0 ls /data/devops-state/

Environment configuration

Configuration has three layers, from least to most specific:

1. config.yaml baked into the image (defaults).
2. A ConfigMap from the chart’s configYaml value, mounted over it in the cluster.
3. Environment variables for secrets and endpoints: GITHUB_APP_<ORG_SLUG>_APP_ID / _PRIVATE_KEY / _INSTALLATION_ID, GITHUB_TOKEN (fallback), AZURE_STORAGE_ACCOUNT_NAME, JFROG_URL and JFROG_ACCESS_TOKEN, STORAGE_PATH, CONFIG_PATH.

Per environment, each chart has values.yaml (AKS) and values-local.yaml (k3d). The rule is that a change to one is reflected in the other, except deliberately cloud-only fields such as ingress hosts and Workload Identity client IDs. Drift between the two is a classic source of “works locally”.

Dependency management

• Python dependencies are pinned per component in requirements.txt, so one job’s upgrade can’t break another.
• The frontend has package.json plus a lockfile.
• Image tags per component are recorded in versions.yaml; chart versions in each Chart.yaml.

Per-component pinning has a cost: a security fix in requests or urllib3 has to be applied in thirteen files. Dependabot grouped updates (one PR per ecosystem per week) handle that well.

Feature flags

The dashboard has one simple, effective flag system: GET /api/sidebar-config tells the frontend which tabs to render. A new analyzer’s tab can ship to production hidden, be switched on once its data has been checked, and be switched off again if its numbers look wrong, all without a frontend release.

On the job side, the flags are config.yaml toggles, for example turning code scanning, secret scanning or Dependabot on or off in the GHAS analyzer. That’s enough; a feature-flag service would be overkill for this project.

Documentation standards

The docs live in the repo, next to the code, and are built with MkDocs. The State of DevOps section has one page per concern: README (30-second tour), architecture, cronjobs, deployment, storage, UI and tech stack. Each table links to the source path it describes, so a reader can check any claim against code.

Two standards I’d keep: a cronjob isn’t done until its row in cronjobs.md (schedule, reads, writes, env) exists, and docs are updated in the same PR as the behaviour. The CRA-vs-Vite mismatch that existed in the docs is exactly what happens otherwise.

The repo also carries instructions for AI coding agents (AGENTS.md, Copilot instructions, prompts and skills under .github/), which act as executable documentation for repetitive tasks such as release versioning.

Development workflow and code review process

1. Create a branch named after the Jira issue.
2. Develop against k3d (task state-of-devops-<component> builds, imports and deploys one component).
3. Open a PR; CI builds changed components, runs SonarQube, and CodeQL.
4. Review by a code owner (the repo has a CODEOWNERS file).
5. Merge to main; CI pushes images to JFrog; the chart is promoted and ArgoCD syncs to AKS.

For review, the checklist I’d pin to the PR template: uses shared clients, config not constants, tests for new checks with a fixture repo, values.yaml and values-local.yaml in sync, docs updated.

Checklist

• Every component follows the standard folder shape and uses cronjob-library
• Every operation available as a task; nobody needs raw docker, helm or kubectl
• CRA proxy switched to 127.0.0.1:8000
• Linter and formatter enforced with pre-commit and in CI
• values.yaml / values-local.yaml drift check in review
• Dependabot grouped updates on for pip, npm and Docker

• PR template with the review checklist; CODEOWNERS covers every component
