State of DevOps: Data and Integration

The most useful lesson from building State of DevOps was a data lesson. At first every cronjob collected its own GitHub data, and much of it was the same data. Later I moved the common collection into one job, and the other cronjobs now read that data and fetch only the extra detail their domain needs. Less redundancy, faster jobs, fewer API calls. This post is about that shared data: where it lives, who owns it, and the contracts that keep thirteen independent jobs and a dashboard in agreement.

Data ownership and classification

Every folder under /data has exactly one writer, and that writer owns its format:

Data	Owner (only writer)	Classification
/data/github-data/	github-data-collector	Internal: repo metadata
devops-state/repo-analysis/, pipeline-analysis/, infra-analysis/	The matching analyzer	Internal
devops-state/ghas-analysis/, enterprise/	GHAS and enterprise analyzers	Confidential: security findings
devops-state/cost-analysis/	devops-cost-analyzer	Confidential: spend
devops-state/trends/, summaries/	The two aggregators	Internal
github-{new,stale}-repositories/, weekly-routine/	Collectors and scanners	Internal

None of it is PHI, and that’s a rule rather than an accident (see Security and Privacy). The “one writer per folder” rule is what lets jobs run independently without locks.

Data retention and deletion

Data	Retention
Daily analyzer outputs	Indefinite (the trends analyzer reads history)
Trends and home overview	Indefinite (small)
New and stale repository reports	90 days
Container and package registry scans	90 days
/data/github-data/ cache	Overwritten on every collection

The 90-day values are applied at write time; there’s no automated pruning job. “Indefinite” is fine for trends, but full daily outputs for every repo in four orgs grow forever. I’d keep the trends forever and prune raw daily outputs after a period long enough for audits and trend recomputation.

TODO: How long must daily outputs be kept as audit evidence (one year, the audit cycle, longer)? That number decides the pruning job.

Database schema and migrations

There’s no database, so the “schema” is the folder layout plus the JSON shape of each file:

/data/devops-state/<domain>/{org}/{YYYY}/{MM}/{DD}/<sub-analyzer>/<stable-name>.json
                                                    metadata.json   # version + generated_at

Conventions that act as the schema:

• Dated folders are YYYY/MM/DD, zero-padded, UTC; weekly buckets are YYYY/W{WW} (ISO week).
• Filenames inside a dated folder are stable, so “today” is a deterministic path.
• Paths are built in code, not configured: the collector uses AnalyzerStorageClient.format_date_path, and each analyzer’s own storage_client formats {org}/{YYYY}/{MM}/{DD}/{repo}.json. One shared helper for every job (and the dashboard) is the change I’d make, so the layout lives in one place.

Migrations are cheap because old files are never rewritten: when a JSON shape changes, the analyzer version in metadata.json changes, and readers handle both shapes until the old ones age out. That only works if readers check the version, which is worth enforcing with Pydantic models in the backend.

Data validation and quality

Wrong numbers are the fastest way to lose an executive audience, so data quality needs explicit checks:

• Completeness: every org in config has today’s folder for every daily domain by 07:30 UTC.
• Freshness: generated_at in metadata.json is from today.
• Plausibility: repo counts per org don’t change by more than a set percentage day over day without a known cause (for example a mass archive).
• Distinguish no data from zero: an analyzer that failed must not look like a perfect score.

The summary generator is the natural place to enforce these, since it reads everything anyway. It can write a quality section into home-overview.json that the Home page shows as a warning banner.

Import and export requirements

There’s no import path; all data comes from APIs. Export is mostly about audits and executives:

• Every analyzer output is already a JSON file that can be handed over as evidence for a given date.
• The most-requested export for a tool like this is CSV of a repo table, for example “all repos without CODEOWNERS in org X”, which is a small endpoint over data the API already returns.

TODO: Is there an export feature today, and what format do auditors ask for?

External systems and third-party integrations

System	Direction	Protocol and auth	Used by
GitHub REST and GraphQL	Read	HTTPS, per-org GitHub App tokens	Collectors and analyzers
GitHub Enterprise API	Read	HTTPS, enterprise App	Cost analyzer (seat usage)
GitHub Container Registry, Packages API	Read	HTTPS / OCI	Registry scanners (SBOM lookup)
JFrog Artifactory	Read	HTTPS, access token or basic auth	Cost analyzer
Azure Cost Management	Read	HTTPS, azure-identity	Cost analyzer
Microsoft Teams	Write	Incoming webhook	New and stale repository reports
Jira	Write	HTTPS, API token	Dashboard create-story
Azure Files	Read / write	SMB via PVC, Workload Identity	Every component

Every integration goes through tenacity retries with exponential backoff, because rate limits and transient 5xx responses are normal. The registry scanners also throttle explicitly (a 5 s per-repo delay in the container scanner, 1 s between SBOM calls to stay under 100 requests per minute).

Event and messaging contracts

There’s no message bus. The contracts are:

1. File contracts. Each folder’s path pattern and JSON shape is an interface. The dashboard, the trends analyzer and the summary generator are consumers, so a field rename is a breaking change.
2. Time contracts. The schedule is an implicit event order: the GHAS analyzer at 02:00 reads the collector cache from the previous day’s 04:00 run, and the summary generator at 07:00 assumes every analyzer has finished. Nothing enforces this.
3. Teams messages. The new and stale repository reports post a webhook payload with a fixed title (“New Repos Report”, “OSPO Stale Repository Report”) that people filter on.

The time contract is the weakest. The trends analyzer and the repo analyzer both start at 05:00, so trends may read yesterday’s repo analysis instead of today’s. A completion marker (for example a _SUCCESS file next to metadata.json) and a dependency-aware trigger would turn the implicit order into an explicit one.

Backup and restore strategy

Everything except /data can be rebuilt from Git. Within /data, the categories are different:

Data	Can be regenerated?	Backup need
github-data/ cache	Yes, next collector run	None
Today’s analyzer outputs	Yes, rerun the job	None
Historical daily outputs and trends	No: GitHub only shows current state	Required

Azure Backup is configured on the share, and a restore has been tested. Share snapshots cover this well, as long as their retention matches the audit requirement for daily outputs.

Data migration and reconciliation

The centralized-collector change was the project’s real data migration. Moving shared collection into github-data-collector meant every consumer had to switch from its own API calls to the cache without changing its output. The safe way to do a change like that is to run old and new side by side for a few days and diff the outputs per org before cutting over.

The same idea gives an ongoing reconciliation check worth automating: pick a few repos per org each week and compare the dashboard’s values (branch protection, CODEOWNERS, alert counts) against the GitHub UI or API directly. If they disagree, the dashboard is wrong until proven otherwise.

TODO: How was the switch to the central collector rolled out (all jobs at once, or one by one), and did it change any numbers?

Checklist

• One writer per /data folder, documented in the storage docs
• Classification set for each domain; GHAS and cost marked confidential
• Audit retention period agreed and a pruning job built for raw daily outputs
• metadata.json version checked by every reader
• Data quality checks (completeness, freshness, plausibility) shown on Home
• Completion markers written by each analyzer; dependent jobs wait for them
• Azure Backup on the share, with a tested restore

• Weekly reconciliation of sample repos against GitHub
