Y-IaC: Data and Integration

Y-IaC has no database, and that makes it easy to forget that it’s full of data. Every unit has a state file, every run produces plans and reports, and every consumer’s YAML is a declaration of what should exist. Lose a state file and Terraform thinks a production resource doesn’t exist. This post is about who owns each piece of that data, how it moves, and how we get it back.

Data ownership and classification

Data	Owner	Classification (recommended)
Module source, unit templates, root.hcl, CLI, workflows	Platform team	Internal
Config catalog (config/: providers, policies, scanners, error catalog)	Platform team	Internal
Consumer YAML (config.yaml, common_vars.yaml, resources.yaml)	Consumer team	Internal; may reveal topology
Terraform state, one file per unit	Consumer team, stored in the consumer’s backend	Confidential: can hold secrets
Plan files, plan JSON, summaries, logs	Consumer team, produced by shared workflows	Confidential
Drift tickets, Teams messages	Consumer team; platform owns the integration	Internal
The resources themselves	Cloud and service owners	Per workload

The split matters when something goes wrong. If a state file is damaged, the consumer owns the recovery decision, but the platform team owns the tooling and the runbook. That shared ownership should be in the operating agreement, not discovered during the incident.

Data retention and deletion

Data	Default today	Recommendation
State	Kept while the resource exists	Keep, with backend versioning; delete only after destroy and a grace period
State versions	Depends on backend settings	30 to 90 days of versions, then lifecycle-delete
Workflow artifacts (plans, reports)	7 days (retention-days: 7)	Keep short for plans (sensitive diffs); export summaries if needed for audit
Local .terragrunt-cache/, .terragrunt-stack/	Until the next run cleans it	Treat as disposable; never commit
Local state under ~/tf-backend (labs)	Forever	Developer’s responsibility
Jira drift tickets	Jira project retention	Follow the project’s policy

Deletion has one sharp edge: removing a stack folder from a consumer doesn’t destroy anything. The resources and their state stay where they are, now unmanaged. Decommissioning a stack is always destroy first, folder second.

Following the regulatory baseline, production evidence records are kept for six years; non-production for one year. Raw plan files stay at seven days in both cases.

Database schema and migrations

The “schemas” in Y-IaC are the YAML shapes and the Terraform state format. Both migrate:

• YAML shapes. When a module’s input changes shape, the unit template should accept both the old and the new shape for at least one release (try() with a fallback is the usual pattern) and the CHANGELOG should say when the old shape stops working.
• Resource addresses in state. When a module renames or restructures a resource, use a moved block in the module so existing state follows without a destroy and create. Without it, every consumer’s next plan shows a replacement.
• State format. Terraform upgrades the state format on write; a consumer that plans with a newer Terraform than another can’t go back. Pin Terraform per consumer and upgrade deliberately.
• Layout migrations. The move from python/lib/ to the src/ package kept a fallback import in the stub, so consumers that hadn’t re-synced kept working. That’s the pattern to repeat.

Data validation and quality

Validation happens before any data reaches Terraform:

• Duplicate declarations. YAML silently keeps the last of two identical keys, so two azurerm_federated_identity_credential: blocks in one file would quietly drop the first. The resources linter (generators/resources_lint.py) catches that before the stack is generated.
• Empty or config-only files. The stack generator rejects a resources.yaml that contains only scalars and no resource lists, with an example of what it expected.
• Unit-level defaults. Unit templates use try() with sensible defaults for optional fields, so a minimal YAML entry still produces a valid module input.
• Module schema checks. The module validator compares a module’s resource arguments against the provider schema (validation/schema.py), catching arguments the pinned provider doesn’t support.
• Policy on the result. OPA checks the plan, so even valid YAML that produces a non-compliant resource is caught.

What’s missing is a formal schema per resource type. A JSON Schema generated from each module’s variables.tf would let editors validate resources.yaml as people type.

Import and export requirements

Import brings existing resources under management without recreating them. Y-IaC supports it two ways:

1. Manual import through the CLI’s import action, with provider paths normalized by import_id_normalization in config/config.yaml (Azure returns microsoft.insights in some IDs; Terraform expects Microsoft.Insights).
2. Auto-import (config/auto-import.yaml, handlers/terragrunt/auto_import.py). For each supported type it describes how to find the real resource (for example az group show --name {target.name}), how to build the import ID, and when to ask for confirmation (each, all or none).

Either way, the acceptance test is the same: the next plan shows no changes. If it shows changes, the YAML doesn’t match reality yet and must be fixed before any apply.

Export is mostly plan JSON (for gates and reports) and the resource inventory visualization (--python visualize, which writes architecture.py and an SVG under docs/<name>/ without calling any cloud API).

External systems and third-party integrations

System	Direction	Auth	Failure behavior
Azure, AWS, GCP APIs	Out	Service principal or user login, keys, ADC	Plan fails; transient errors retried by root.hcl
GitHub API (github provider)	Out	GH_TOKEN	Plan fails
JFrog, Grafana, Zscaler ZPA, ArgoCD, Helm, Kubernetes	Out	Tokens and URLs from env	Plan fails for that unit
State backends	Both	BACKEND_* or same identity	Init fails; backend timeouts retried
Terraform registry	In	None	Init fails; plugin cache helps
Wiz	Out	WIZ_CLIENT_ID, WIZ_CLIENT_SECRET	Missing binary or credentials: warn and skip
Infracost	Out	API key	Gate skipped if disabled (default)
Microsoft Teams	Out	Webhook URL	Notification job fails, apply unaffected
Jira	Out	JIRA_USERNAME, JIRA_API_TOKEN, JIRA_URL	Job fails red; skips if config absent

The “warn and skip” behavior for Wiz is worth a decision. It’s friendly in development, but in a production pipeline a missing scanner silently turns a mandatory gate into no gate.

Event and messaging contracts

Three outbound messages have contracts that other people rely on:

• Drift ticket (Jira). One ticket per repository, summary IaC Drift: <owner>/<repo>, label iac-drift. A new finding comments on the open ticket; a closed ticket means a new one. Each body carries a fingerprint marker ({{iac-drift-fingerprint:<hash>}}) so unchanged drift doesn’t add duplicate comments. Priority escalates on destroys or failed stacks.
• Teams notification. Sent when drift is found or stacks fail to plan, from the same analysis outputs as the ticket.
• GitHub to Jira webhook. Runs after a PR plan (on open) and after an apply on main, linking the change to its ticket.

These contracts change when the workflow changes, so their shape belongs in the workflow docs (04g and 04j in docs/getting-started/) and changes belong in the CHANGELOG.

Backup and restore strategy

State is the only data that can’t be regenerated. YAML lives in Git; generated files are rebuilt on every run; plans can be recomputed. So backup is about state:

Backend	Backup mechanism	Restore
azurerm	Blob versioning and soft delete on the storage account	Promote a previous blob version, then plan to confirm
s3	Bucket versioning	Restore the previous object version
gcs	Object versioning	Restore the previous generation
local	None (lab use only)	Rebuild or re-import

Restore runbook outline: stop pipelines for that consumer, take a copy of the current state, restore the previous version, run a plan, and expect it to show only the changes made since that version. If it shows more, import or fix before any apply.

Versioning is on for the Azure Blob state storage, and a restore has been rehearsed. Repeating it on a schedule keeps it that way (see Backup verification).

Data migration and reconciliation

Migrations Y-IaC has to support:

• Moving resources between stacks (terragrunt state mv across state files, or remove and import).
• Changing a consumer’s backend (for example from local to azurerm): init -migrate-state per unit, then confirm every unit plans clean.
• Renaming a stack folder, which changes every state key under it because the key includes the unit path. Treat it as a backend migration, not a rename.
• Adopting existing infrastructure through import or auto-import.

Every migration ends with reconciliation: a plan per affected unit showing no unexpected changes, a record of the original resource IDs, and the consumer and platform teams both signing off. The cutover and rollback steps are owned jointly, as the guide says, and I’d write them per migration rather than pretend one template fits all.

Checklist

• Data classification for state, plans and artifacts is agreed and documented
• Versioning is on for Azure Blob state storage; S3 and GCS to match
• A state restore has been rehearsed; repeat it on a schedule
• Stack decommissioning is documented as destroy first, folder second
• Modules that restructure resources use moved blocks
• Wiz “warn and skip” is turned into a failure for production pipelines
• Drift ticket and Teams payload shapes are documented with the workflows

• A JSON Schema per resource type is on the backlog
