Productivity Dashboard: Data and Integration

Everything the Productivity Dashboard knows lives in a folder tree shaped like the organization chart: department, team, person, date. That makes it easy to browse and easy to reason about, and it has one consequence that’s easy to miss until it happens: when a person changes team, their history doesn’t move with them. This post covers the data, who owns it, how it flows, and the edge cases that come with modelling people as paths.

Data ownership and classification

Data	Writer	Classification
…/{user}/daily/{date}/github.json, jira.json	GitHub and Jira collectors	Confidential: employee activity
…/Epics/{EPIC}/epic-metadata.json, jira-updates.json	Epic data collector	Internal
…/Users/{user}/{period}/…/summary.md	User generator	Confidential: about a named person, used in reviews
…/{team}/{period}/…/summary.md	Team generator	Internal
…/Epics/{EPIC}/…summary.md	Epic generator	Internal
{org_prefix}/PODS/{pod}/…	POD generator	Internal (per-member files: confidential)

Each path has exactly one writer; the UI only reads. Per-person data is the sensitive category: not because of what’s in it (work activity, no PHI) but because of how it’s used.

Data retention and deletion

Today there’s no automated pruning: every dated file is kept indefinitely. For an engineering dashboard that would be fine; for personal data used in performance reviews it needs a decision:

• How long are per-person collector files and summaries kept? (A review cycle plus a margin is a common answer.)
• What happens to a person’s data when they leave?
• Are team, epic and POD summaries, which are less personal, kept longer?

A pruning job is simple once the rules exist, for example a CronJob running find /data/<dept>/<team>/<user>/daily -mtime +N -delete per rule. The rules are the hard part, and they’re HR’s and legal’s, not engineering’s.

TODO: What retention did the HR, legal and privacy review set for per-person data, and what happens to it when someone leaves?

Database schema and migrations

The schema is the folder layout plus three file shapes:

File	Shape
github.json	metadata, commits[], pull_requests[], reviews[], summary{}
jira.json	metadata, issues_created[], issues_updated[], comments[], sprint_issues[], summary{}
summary.md	Markdown with the sections the prompt asks for

Fields collected are configurable per collector (for example comment_fields in the Jira collector), which makes the data scope a config change rather than a code change. That’s useful, and also exactly why the data scope should be reviewed whenever that config changes.

Data validation and quality

• No activity is explicit: the GitHub collector writes no_activity: true for a day with nothing, so “no data” and “collector didn’t run” are different states.
• Coverage: every configured person should have both files for each working day; a missing file is usually a wrong GitHub username or Jira email in the identity config.
• Output check: every PR number and Jira key in a summary should appear in that day’s source files. This one check catches most hallucinations that matter.

The CollectorStats component already shows whether collector data exists for a date; turning that into a daily coverage report per team would surface identity mistakes the day they happen.

Import and export requirements

• Import: none; all data comes from GitHub and Jira.
• Export: summaries can be printed or exported from the UI (PrintExport), which is how they reach review documents and stakeholder emails.
• Source export: raw collector data for a user and date range (/api/collector-data/aggregated), which is the evidence behind any summary.

External systems and third-party integrations

System	Direction	Auth	Used by
GitHub REST and GraphQL	Read	Per-org GitHub App; PAT fallback	GitHub and epic collectors
Jira Cloud REST	Read	Email + API token	Jira and epic collectors
Azure OpenAI	Read / write (prompts)	API key	All generators (production)
OpenAI, LM Studio	Same	API key / none	Alternatives; LM Studio for local development
Kubernetes API	Write (Jobs)	ServiceAccount + Role	UI refresh
Azure Files	Read / write	Workload Identity	All components

The epic collector also links GitHub branches to Jira story keys, so code work shows up under the right epic even when the PR doesn’t mention the ticket in its title.

Event and messaging contracts

There’s no message bus; the contracts are files and time:

UTC	Job	Reads	Writes
02:00	Epic data collector	Jira, GitHub	Epic data
03:00	Epic summary generator	Epic data	Epic summaries
04:00	User summary generator	Previous run’s github.json / jira.json	User summaries
04:00	POD summary generator	User data filtered by Jira label	POD summaries
05:00	Team summary generator	User summaries (waits up to 300 s)	Team summaries
06:00	GitHub and Jira collectors	GitHub, Jira	Today’s collector files

Generators run before the collectors on the same day on purpose: they summarize the previous run’s collection, so yesterday’s summaries are ready before the Americas’ working day, and the 06:00 collection feeds tomorrow. The team generator’s wait is the one explicit dependency; the others rely on the clock.

TODO: Which calendar day does the 06:00 UTC collection cover: the day that just ended, or the current UTC day? If it’s the current day, a “daily” summary only sees activity before 06:00 UTC, which would miss most of the Americas’ working day. Worth stating precisely in the docs.

Backup and restore strategy

Data	Regenerable?	Backup need
Collector files	Partly; GitHub and Jira search windows and edits change history	Yes
Summaries	Only approximately; a new prompt or model writes different text	Yes, if used in reviews
Code, prompts, config	From Git	No

Azure Files share snapshots through Azure Backup cover this, with a retention that matches the agreed data retention (and no longer, since backups are also personal data).

Data migration and reconciliation

The migration that happens all the time is people changing teams. Paths include the department and team, so after a move, new data lands under the new team while history stays under the old one. A monthly summary in the month of the move only sees part of the month, and a user page for the new team starts empty.

Two fixes, from cheapest to cleanest:

1. A small migration script run with each team change that moves the person’s folders to the new path.
2. Key per-person data on a stable ID (for example the Jira account ID) instead of team-based paths, with the team as metadata.

Reconciliation for accuracy is a weekly sample: pick a few people and days, compare the summary with the raw data view, and record the result as the accuracy KPI.

TODO: How are team moves handled today?

Checklist

• Per-person data classified confidential, with readers agreed
• Retention and leaver rules from HR, legal and privacy implemented as a pruning job
• Collector field lists reviewed whenever they change
• Daily coverage report per team for identity mistakes
• Output key check against source on every summary
• Collection day boundary documented precisely
• Team moves handled by a script or stable IDs

• Share backups with retention equal to the data retention
