Dunderly HR System: Data and Integration

Dunderly’s legacy payment system is written in C++, lives in the company’s server farm, accepts only files, and gets one a month. It will never call an API, return an error code or tell us it’s unhappy. That makes the payroll file the most important contract in the system and the one with the least feedback, so this post designs it the way you’d design a bank transfer: snapshot, approve, checksum, deliver, confirm.

Data ownership and classification

HR owns the data; the application team are custodians. Each data set has a classification that drives who sees it and where it may appear:

Data	Owner	Classification	Examples
Employee directory	HR	Internal	Name, job title, department, manager
Personal details	HR	Confidential	Address, date of birth, emergency contact
Salary and payroll	HR manager	Highly confidential	Salary history, payroll lines, files
Leave	HR	Confidential	Balances, bookings; sick leave is special-category health data
Documents	HR	Highly confidential	Contracts, reviews
Audit	HR + IT	Confidential	Who changed what

Highly confidential data never leaves the HR system except in the payroll file (to the payment system) and in exports by HR roles. It never appears in telemetry, emails or notifications.

Data retention and deletion

Employees aren’t deleted, they leave. A leaver’s record moves through states, and retention is enforced by a monthly job, not by someone remembering:

Data	Kept while employed	After leaving
Personnel record and documents	Yes	TODO (legal)
Salary and payroll history	Yes	TODO (legal; often several years for tax)
Leave records	Yes	TODO
Audit events	Same as the record they describe	Same
Payroll files and receipts (Blob)	Immutable for the retention period	Then deleted by lifecycle policy

TODO: Retention periods per data set from Dunderly’s legal or HR advisor. Under assumption A2 (GDPR), keeping data “just in case” isn’t allowed, so the system needs real numbers.

Mechanics: when a record passes its retention date, the job anonymizes personal fields in SQL (name, contact, date of birth), deletes the documents from Blob, and keeps the minimal payroll facts if a longer tax period applies. Temporal history is purged for the same rows. Blob soft delete (30 days) means a mistaken purge can be undone briefly, then it’s gone.

Database schema and migrations

EF Core code-first migrations, one migrations history per module schema, generated in PRs and reviewed like code. The model is in Data architecture.

Rules:

• Expand, then contract. A release only adds (columns nullable or with defaults, new tables). Removals happen in a later release, once no running code uses them. This is what makes the slot swap safe.
• Migrations ship as a bundle (dotnet ef migrations bundle), one executable per release, run by the pipeline with the deploy identity.
• Temporal tables are declared in the model (ToTable(t => t.IsTemporal())), so history tables are part of the migration, not hand-made.

dotnet ef migrations add AddLeaveCarryOver --project src/Dunderly.Hr.Api --context LeaveDbContext
dotnet ef migrations bundle --project src/Dunderly.Hr.Api --context LeaveDbContext -o artifacts/efbundle-leave

Data validation and quality

Validation at the edge (shared FluentValidation rules), constraints in the database as the last line: CHECK (Amount > 0), unique EmployeeNumber, foreign keys everywhere, EndDate >= StartDate.

Data quality checks that run weekly and show on the HR dashboard:

• Active employees without a manager (except the CEO).
• Active employees without a current salary or leave entitlement.
• Managers who have left but still have direct reports.
• Documents stuck in PendingScan for more than an hour.

These matter most just before the payroll cutoff: an employee without a salary is a payroll line that can’t be built. The draft run lists them as blocking issues.

Import and export requirements

• Import: the one-off migration (below) plus a CSV import for bulk changes HR occasionally needs (annual entitlement for everyone at year start). The import validates every row and applies all or nothing.
• Export: CSV for the reports, available to HR roles only, audited (who exported what, when).
• The payroll file, which is an export with much stricter rules, described next.

External systems and third-party integrations

The case study’s facts: legacy system, C++, hosted in the company’s server farm, input is files only, one file a month. Here’s the monthly run, end to end. Tick the box to see what happens when the file doesn’t verify:

1. Cutoff day: On the payroll cutoff day a timer-triggered Function starts the month's run. Salary changes approved after this point wait for next month.
2. Draft the run: It snapshots active employees, effective-dated salaries and unpaid leave into a draft run, so later edits can't change what gets paid.
3. Payroll review: The payroll operator compares totals and headcount with last month. Any line that moved more than the variance threshold needs an explanation.
4. Four-eyes approval: The HR manager approves the run. Whoever prepared it can't approve it, and once approved the run is read-only.
5. Write the file: A queue-triggered Function renders the legacy file layout plus a manifest (record count, control total, SHA-256). Re-running it for the same run ID is a no-op.
6. Pull from the farm: The on-premises pickup agent polls the outbound container and downloads new files over HTTPS. Nothing in Azure can reach into the server farm.
7. Verify: The agent recomputes the SHA-256 and the record count and compares them with the manifest before it touches the payment system.
8. Hand to the payment system (ok): The file lands in the payment system's input folder, the only interface the legacy C++ system offers.
9. Upload a receipt (ok): The agent writes a small receipt blob back with the run ID, hash and pickup time.
10. Delivered (ok): An Event Grid trigger marks the run Delivered in the HR system, so HR sees it on the payroll page instead of phoning IT.
11. Quarantine (bad): A mismatch means the file is moved aside and never reaches the payment system. No receipt is written.
12. Alert before payday (bad): With no receipt by the deadline, an Azure Monitor alert pages the payroll on-call, days before payday, while there's still time to fix it.

Why it’s built this way:

• Snapshot, then approve. The draft run copies figures into PAYROLL_LINE. What HR approves is exactly what gets written.
• Pull, not push (ADR-007). The pickup agent on-premises fetches the file. Nothing in Azure needs a route, a firewall hole or credentials into the server farm.
• Manifest and receipt. The manifest lets the agent check integrity; the receipt lets the HR system know delivery happened. A missing receipt is an alert days before payday, not a phone call on payday.
• Idempotent. The file name includes the run ID (payroll-2027-03-run-41.dat). Re-running the Function overwrites nothing (the container is immutable) and the agent skips files it has receipts for.

Assumption: Payroll cutoff is five working days before payday (assumption A6), and the pickup agent polls every 15 minutes during the payroll window.

TODO: The payment system’s file specification: fixed-width or delimited, encoding, field list, how amounts and dates are formatted, and whether it needs one file per month or can accept a correction file. A sample file from a previous month would answer most of it.

Event and messaging contracts

The 2023 design used a queue for logs. The modernized design uses messaging only where work must survive a failure, and keeps contracts small and versioned:

Message	Transport	Producer → consumer	Payload
PayrollRunApproved.v1	Outbox, relayed to Storage queue payroll-approved	API → Payroll Functions	{ runId, period, approvedBy, approvedAt }
PayrollReceiptCreated	Event Grid (Blob created)	Storage → Functions	Blob URL of the receipt
ScanResult	Event Grid (Defender for Storage)	Defender → Functions	Blob URL, verdict
Notification.v1	Outbox table in SQL	API → outbox dispatcher Function	{ template, recipientId, data }

The outbox matters for anything that leaves the API after a commit: the API writes the business change and the message row in the same transaction, and a Function relays it afterwards (to the mailbox, or to the payroll-approved queue). Either both happen or neither does, with no “approved but nobody was told” gap and no approved payroll run whose queue message was lost. The relay can deliver twice, so every consumer is idempotent. Messages carry IDs, never salary amounts.

Why no Service Bus? At this volume, Storage queues give us retries and poison queues for almost nothing. If we ever need topics, sessions or ordering, Service Bus is a drop-in step up.

Backup and restore strategy

Store	Backup	Retention	Restore test
Azure SQL	Automatic: full weekly, differential, log every 5 to 10 minutes; geo-redundant	PITR 35 days; LTR monthly for 12 months, yearly for the legal period	Quarterly, to a new database in test
Documents (Blob)	Versioning + soft delete (30 days); GRS	Retention policy	Quarterly, restore a deleted version
Payroll files	Immutable container; GRS	Retention policy	Yearly, read back a past file and verify hash
Bicep, code, config	Git	Forever	Every deploy

Restores are only real once they’ve been tested, which is why the restore column exists (and why backup verification is a recurring task).

Data migration and reconciliation

Assumption: The source is spreadsheets plus scanned documents on a file share (see Business problem).

At 250 employees and ~10 documents each, that’s roughly 2,500 documents and about 12.5 GB to move, small enough for a careful, repeatable tool rather than a migration product. The tool:

1. Reads the source CSVs and a document manifest (path, employee number, type, SHA-256).
2. Maps and validates every row; anything that fails goes into a rejects file for HR to fix at source.
3. Loads through the same domain code as the API, so business rules and audit events apply.
4. Uploads documents through the quarantine and scan path.
5. Is idempotent: re-running it updates rather than duplicates, so we can rehearse it as often as needed.

Reconciliation proves it worked: headcount, sum of current salaries, sum of leave balances and document count and hashes, source vs target, all must match or be explained. The cutover itself is in Go-Live.

Checklist

• Get the payroll file specification and a sample file.
• Get retention periods per data set from legal.
• Confirm whether bank details are needed in the HR system.
• Build and test the pickup agent with the payment system’s owner.
• Set up SQL LTR and Blob immutability policies to match retention.
• Write the migration tool and run the first rehearsal on a copy of real data.

• Agree the reconciliation checks with HR and finance.
