Dunderly HR System: Requirements Gathering

The 2023 case study had a short requirements list and one excellent habit: it asked the awkward questions before designing anything. How many users? How much data? What do we know about the payment system? The answers (“10”, “25.5 GB” and “legacy C++, files only, once a month”) shaped the whole design more than any feature did. This post keeps those answers, expands the five functional bullets into something a team can build and test, and marks where the case study stopped.

Functional requirements

The client gave five requirements: web based, CRUD on employees, manage salaries (manager asks, HR manager approves or rejects), manage vacation days, and use the external payment system. Here they are broken down, with an ID each so stories and tests can point at them:

ID	Requirement	Source
FR-1	Browser-based UI; nothing to install	Case study
FR-2	HR can create, read, update and deactivate employees	Case study
FR-3	HR can attach, list, download and remove scanned documents per employee	Case study (API table)
FR-4	A manager can request a salary change for a direct report	Case study
FR-5	The HR manager can approve or reject a salary request, with a reason	Case study
FR-6	HR sets each employee’s annual vacation entitlement	Case study
FR-7	Employees request vacation; managers approve; balances update	Expanded (see below)
FR-8	Once a month, approved pay data goes to the payment system as a file	Case study
FR-9	HR can see whether this month’s payroll file was delivered	New
FR-10	Every change to salary, leave and personal data is audited	New
FR-11	Employees can view (not edit) their own profile, leave and documents	New

Two of these change the original design on purpose. The case study had employees “reduce vacation days” directly; in practice that means anyone can book leave without their manager knowing, so FR-7 adds a request and approval step. And “delete employee” becomes deactivate, because HR records have legal retention periods (see retention).

Non-functional requirements

These are the case study’s answers, kept exactly, plus the ones it didn’t ask:

Area	Requirement	Source
Concurrency	10 concurrent users	Case study
Population	250 employees today, 500 in five years	Case study
Data per employee	~1 MB structured + ~10 scanned documents × ~5 MB = ~51 MB	Case study
Total data	51 MB × 500 = ~25.5 GB, relational and unstructured	Case study
Criticality	Not mission critical	Case study
Integration	File-based, one file a month, legacy C++ system on-premises	Case study
Availability	99.5% in business hours	Assumption A7
Recovery	RTO one business day, RPO 15 minutes	Assumption A7
Latency	p95 under 500 ms for API calls; first page load under 3 s	Assumption
Security	SSO with MFA; salary data visible only to HR roles and the line manager	Assumption
Retention	Personnel records kept for the legally required period after leaving	TODO

“Not mission critical” needs a caveat. The web app isn’t: if it’s down for an afternoon, nobody’s harmed. The payroll file is: if it’s late, 250 people aren’t paid. So I treat the system as non-critical with one time-critical job, and design the payroll run to be verified and alerted on, rather than making the whole platform highly available.

TODO: What does “not very critical” mean in hours? Is a full business day of downtime acceptable outside payroll week? This confirms or changes assumption A7.

User journeys and use cases

The journey that carries the most risk is the salary change, because it’s the one that ends in money. Tick the box to see a rejection instead:

1. A manager starts it: Only a manager can propose a salary change, and only for their own direct reports. HR can raise one on anyone's behalf.
2. Raise the request: The manager enters the new amount, the effective date and a justification. The request is saved as Draft until they submit it.
3. Validate the rules: The API checks the pay band, that the effective date isn't in a payroll period that's already closed, and that no other request is open for that employee.
4. Submitted to HR: The request becomes Submitted and the HR manager is notified. Increases above the threshold are flagged for extra scrutiny.
5. Approved (approve): Approval writes a new effective-dated salary row. The old row stays in history (temporal table), and an audit event records who approved what and when.
6. Paid from the next run (approve): The first payroll run whose period covers the effective date includes the new salary. After that run is approved, the request is read-only.
7. Rejected (reject): A rejection needs a written reason, which the manager sees. Nothing changes in the salary data, and the manager can raise a new request later.

The other core journeys, written as user stories:

• Onboard an employee. As an HR admin, I create the employee, set their manager, salary and leave entitlement, and upload their signed contract, so they’re paid from the next run.
• Book leave. As an employee, I see my remaining days, request five days in August, and get a notification when my manager approves.
• Approve leave. As a manager, I see my team’s requests and calendar, and approve or decline with a comment.
• Close payroll. As the payroll operator, I review the draft run, explain the variances, and send it for approval; as the HR manager, I approve it, and the file goes out.
• Leaver. As an HR admin, I set a leaving date; the employee is included in the final run, then deactivated, and their records start the retention clock.

Acceptance criteria

I’d write acceptance criteria as Given/When/Then for the risky rules and keep the rest short. For FR-4 and FR-5:

Scenario: A manager can only request changes for direct reports
  Given Priya manages Sam and not Alex
  When Priya requests a salary change for Alex
  Then the request is refused with 403
  And an audit event "SalaryRequestForbidden" is recorded

Scenario: Approval creates an effective-dated salary
  Given a submitted request for Sam to 52,000 effective 1 March
  When the HR manager approves it
  Then Sam's salary history shows 52,000 from 1 March
  And the previous salary is still visible in history
  And the March payroll run includes 52,000 for Sam

Scenario: No changes into a closed period
  Given the February payroll run is approved
  When a manager requests a change effective 1 February
  Then the request is refused with "period closed"

Every FR in the table above gets at least one scenario like these before it’s “ready” for a sprint (see Backlog structure).

Business rules

The salary request is a small state machine, and writing it down caught two rules the case study didn’t mention (withdrawal, and locking once paid):

stateDiagram-v2
    [*] --> Draft: manager starts
    Draft --> Submitted: submit
    Draft --> Withdrawn: withdraw
    Submitted --> Approved: HR manager approves
    Submitted --> Rejected: HR manager rejects (reason)
    Submitted --> Withdrawn: manager withdraws
    Approved --> Paid: included in an approved payroll run
    Rejected --> [*]
    Withdrawn --> [*]
    Paid --> [*]

The rules around it:

Rule	Detail
BR-1	Only the employee’s current line manager (or HR) can raise a request
BR-2	One open request per employee at a time
BR-3	Effective date can’t fall in a payroll period that’s already approved
BR-4	A requester can’t approve their own request (four eyes)
BR-5	Increases above a threshold are flagged for the HR manager
BR-6	Leave balance can’t go negative without HR override
BR-7	Unpaid leave is passed to payroll as a deduction line
BR-8	The payroll run is approved by someone other than the person who prepared it

TODO: What is the salary increase threshold that needs extra scrutiny (BR-5), and does Dunderly allow carrying unused vacation into the next year? If so, how many days?

Reporting and analytics requirements

HR at this size needs a handful of reports, not a BI platform:

• Headcount by department and month (joiners, leavers).
• Leave taken and remaining, per team.
• Salary changes in a period, with requester and approver.
• Payroll run history: totals, variances, delivery status.
• Audit extract for a given employee (also used for data subject access requests).

All of these run as SQL views behind API endpoints and export to CSV. I’d resist Power BI in v1: it adds licensing, another place salary data lives, and another set of permissions to review. If HR asks for dashboards after go-live, a read-only reporting replica or a Power BI dataset with row-level security is a clean add-on (see Product analytics).

Accessibility and localization requirements

Accessibility: WCAG 2.2 level AA. An HR system is used by every employee, including people using screen readers or keyboard-only navigation, and in many jurisdictions an employer’s internal tools are expected to be accessible. The details are in Accessibility design.

Localization: English only in v1.

Assumption: One country, one currency, one language. Dates and numbers follow the browser locale.

TODO: Does Dunderly employ people in more than one country? Multiple countries means multiple public holiday calendars, leave rules and possibly currencies, which changes the leave and payroll model.

Regulatory, legal, and compliance requirements

HR data is personal data, and salary, bank and health-related absence data are about as sensitive as an ordinary company holds. Under assumption A2 (EU employees), GDPR applies:

• Lawful basis is the employment contract and legal obligation; no consent banners needed for core HR.
• Data subject rights: access and rectification must be supportable (the audit extract helps).
• Data minimisation: don’t store what payroll or HR law doesn’t need.
• Records of processing and, given the sensitivity, a DPIA before go-live.
• Data stays in the EU (West Europe and North Europe regions).

TODO: Which national employment and record-keeping laws apply, and what are the retention periods for personnel files, payroll records and leave records? These set the retention policy.

Prioritization and release scope

I’d use MoSCoW, with the payroll path as a must because it’s the reason the system exists:

Must (MVP)	Should (MVP if time)	Could (later)	Won’t (v1)
FR-1, 2, 3, 4, 5, 6, 8, 9, 10	FR-7 leave approval, FR-11 self-service	Reports as dashboards, Teams notifications	Payroll calculation, recruitment, mobile app

FR-7 is a “should” only because the case study’s simpler version (HR sets days, employees reduce them) is enough to launch; the approval step can follow a sprint later without migration pain, since both write to the same leave ledger.

Checklist

• Walk FR-1 to FR-11 with the HR manager and record changes.
• Confirm the NFR table, especially what “not very critical” means in hours.
• Get the salary-increase threshold and the vacation carry-over rule.
• Confirm countries, currencies and languages in scope.
• Get retention periods for personnel, payroll and leave records from legal.
• Write Given/When/Then for every “must” requirement.

• Agree the MoSCoW split with the sponsor.
