Dunderly HR System: Interview Questions

This is the Dunderly HR System as I’d talk about it in an interview, answered from the architect, developer, DevOps and SRE seats. One thing to say upfront, because interviewers respect it: Dunderly is a design case study I took from a 2023 architecture exercise to a full 18-area playbook. It hasn’t run in production, so these answers describe the design and the planned code, and they say so where it matters.

“I designed an HR system on Azure and .NET for a 250-person paper supplies company: employee records, salary approvals, leave and a monthly payroll file to a legacy C++ system, and the most interesting decision was merging the original three microservices into one modular API.”

Project Overview and Your Role

Walk me through a frontend or backend application you designed and built end to end.

Dunderly sells paper supplies and needed an HR system for 250 employees (500 within five years): employee records with scanned documents, a salary-change workflow where a manager asks and the HR manager approves, vacation balances, and a monthly payment file for a legacy C++ system that only accepts files.

I’d be upfront that it’s a design case study, not something I ran in production. The design: a Blazor WebAssembly app on Static Web Apps, one modular ASP.NET Core API on App Service, Azure SQL for records, Blob Storage for ~25 GB of documents, an Azure Functions app for the monthly payroll run, and an on-premises agent that pulls the file. Entra ID does sign-in and roles; everything else uses managed identities.

The story I tell is the evolution: the 2023 version had six services and an $848/month estimate. Revisiting it, I merged three APIs into a modular monolith, dropped a $352/month WAF, and made the payroll hand-off verifiable.

Deeper: System context, ADRs

On the code side it’s a .NET 10 solution in one repo:

• Blazor WebAssembly (Dunderly.Hr.Web): routable components (@page), [Authorize(Roles=…)], EditForm with FluentValidation, Fluent UI components, a typed HttpClient generated from OpenAPI.
• ASP.NET Core minimal APIs (Dunderly.Hr.Api): endpoints grouped per module with MapGroup, DI for services, RequireAuthorization with role policies, problem details for errors.
• Modules (Employees, Salary, Leave, Payroll, Audit): each has Domain, Application, Infrastructure (EF Core config, its own schema) and Contracts.
• EF Core with temporal tables and migration bundles.
• Azure Functions (isolated worker): queue, timer and Event Grid triggers for payroll and scans.

dotnet run --project src/Dunderly.Hr.AppHost   # Aspire: SQL container, Azurite, API, Functions, web
dotnet test
dotnet ef migrations add <Name> --project src/Dunderly.Hr.Api --context SalaryDbContext

The gap I’d name: there’s no production code behind this yet; the snippets are from the design.

Deeper: Project structure

Three deployables plus infrastructure, all from one GitHub repo:

• Infrastructure: Bicep with Azure Verified Modules, one main.bicep and a .bicepparam per environment (dev, test, prod).
• API: zip deploy to App Service Linux, to the staging slot in prod, then a swap.
• Functions: zip deploy to a Flex Consumption app.
• Web: Static Web Apps, with PR preview environments.
• Database: an EF Core migration bundle run before the code.

Pipelines are GitHub Actions with OIDC to Azure, so there are no stored cloud secrets. Main builds once and promotes the same artifacts dev → test → prod, with a required reviewer on prod and a payroll-week freeze.

az deployment sub what-if -l westeurope -f infra/main.bicep -p infra/env/prod.bicepparam
az webapp deployment slot swap -g rg-dunderly-hr-prod -n app-dunderly-hr-api-prod --slot staging --target-slot production

Deeper: CI/CD

What business problem did it solve, and how did you know it was working?

The business problem: HR records in spreadsheets (an assumption I flag, the case study didn’t say), salary changes approved by email, and a payment file built by hand for a system that gives no feedback. The risks were wrong pay, no audit trail, and salary data readable by anyone with share access.

How I’d know it works, as KPIs:

KPI	Target
Payroll files delivered and confirmed before cutoff	12 of 12 months
Salary changes with a complete four-eyes trail	100%
Leave requests handled in the app	> 90% after 3 months
Payroll corrections from HR data errors	Down vs baseline
Monthly Azure cost	Under budget, and under the 2023 estimate

The honest part: the baselines don’t exist yet.

TODO: Baseline payroll corrections per month and time to close payroll, from Dunderly’s current process. Without them, “down vs baseline” can’t be reported.

The real acceptance test is a parallel payroll month: old and new process side by side, matching line by line.

Deeper: Success metrics

What was your role, and which architectural decisions did you own?

I was the architect, end to end: requirements clarification, the architecture, and the playbook that takes it to delivery. The decisions I owned, each written as an ADR:

• ADR-001 one modular API instead of three services sharing one database.
• ADR-003 Azure Functions instead of a WebJob for the payment interface.
• ADR-004 no Application Gateway WAF in v1, with explicit revisit triggers.
• ADR-005 private endpoints and managed identity instead of IP firewall rules.
• ADR-007 a pull-based payroll file with a manifest and a receipt.
• ADR-008 Azure SQL serverless with temporal tables.

I’d also say what I didn’t own: business rules belong to the HR manager, and the file format belongs to the payment system’s owner. Knowing which decisions aren’t yours is part of the role.

Deeper: ADRs, Decision authorities

As a developer on this design I’d own a module end to end, for example Salary: the request state machine (Draft → Submitted → Approved/Rejected/Withdrawn → Paid), its rules (direct report only, one open request, no closed periods, four eyes), the minimal API endpoints, the Blazor form and the tests.

Concepts I’d point to:

• Domain logic in the domain layer, returning result types instead of throwing for business outcomes.
• Authorization in two layers: the role policy on the endpoint, and the reporting-line check in code.
• Optimistic concurrency with a rowversion and If-Match, returning 412 or 409.
• TimeProvider injected, so “after cutoff” is testable.

g.MapPost("/{id:int}/approval", Approve).RequireAuthorization(p => p.RequireRole("HR.Manager"));

dotnet test tests/Salary.Tests --filter "Category=Rules"

Deeper: API and UI implementation

I’d own the platform: Bicep for three environments, the GitHub Actions pipelines, OIDC federated credentials, private networking and DNS, and the release mechanics (migration bundle, slot swap, smoke tests, swap-back).

Decisions in my lane:

• Build once, promote the same artifacts; never rebuild per environment.
• Use prod’s staging slot instead of a fourth environment.
• DDL rights only for the pipeline identity; the API gets DML.
• A payroll-freeze check in the release workflow.
• Weekly drift detection with what-if.

az bicep lint --file infra/main.bicep
gh workflow run release.yml
az webapp log tail -g rg-dunderly-hr-prod -n app-dunderly-hr-api-prod

Deeper: Infrastructure as code

Who were the users and stakeholders, and how did their needs shape the design?

Six user groups, and two shaped the design most:

User	Need	Design impact
Employees (250 → 500)	Check leave, request it	Mobile-friendly, three-click leave booking
Managers	Approve leave, raise salary changes	Reporting-line authorization
HR admins	Maintain records and documents	One employee hub page with tabs
HR manager	Approve salaries and payroll runs	Strongest controls; four-eyes rules
Payroll operator	Close the month	Variance review, delivery status strip
IT (payment system owner)	Stable file interface	Pull model, interface agreement

The HR manager drove security: a few accounts that can see everyone’s salary are the main target, so they get compliant-device Conditional Access. The payment system owner drove integration: their system can’t change, so we adapt to it and don’t ask for an inbound hole into their server farm.

TODO: Headcounts for managers and HR staff, which size role assignments and UAT.

Deeper: Personas

System Design and Architecture

If you had to design this application from scratch on a whiteboard, with a frontend, a backend and a data store, how would you approach it?

I’d start with the questions, not boxes, exactly as the case study did: how many users (10 concurrent), how much data (25.5 GB at 500 employees), how critical (not very), and what the external system needs (one file a month).

Then three boxes and an arrow:

1. Frontend: a SPA served statically (Static Web Apps), because there’s no server rendering need.
2. Backend: one API, with modules for employees, salary, leave and payroll. At this scale a single deployable is the right default.
3. Data: relational for records (Azure SQL), object storage for documents (Blob), never documents in the DB.
4. The arrow: the payroll file, drawn separately because it’s the time-critical, failure-prone part.

Then I’d layer identity (Entra ID), async work (Functions, queues) and observability, and finish with the trade-offs I’d revisit: WAF, region strategy, RPO.

Deeper: System context

From a developer’s whiteboard, I’d draw the request path and the code seams:

• Browser: Blazor WASM. Components render from state; HttpClient with an MSAL message handler adds the bearer token.
• API: middleware pipeline (exception handling → authentication → authorization → rate limiting → endpoints), minimal API groups per module, DI-registered services.
• Domain: plain C# with rules and state transitions; no EF or HTTP types.
• Data: EF Core DbContext per module schema, with retries on transient SQL errors.

var builder = WebApplication.CreateBuilder(args);
builder.Services.AddMicrosoftIdentityWebApiAuthentication(builder.Configuration);
builder.Services.AddEmployees(builder.Configuration).AddSalary(builder.Configuration);
var app = builder.Build();
app.UseAuthentication(); app.UseAuthorization();
app.MapGroup("/api/v1").MapEmployees().MapSalary();
app.Run();

Deeper: Technology selection

What are the main components, and how are responsibilities split between them?

Component	Responsibility
Blazor app (Static Web Apps)	UI only; no business rules it alone enforces
HR API (App Service)	All business logic, authorization, audit
Payroll Functions	Draft runs, write files, process receipts and scan results, send the outbox
Azure SQL	Records, salary history, leave ledger, payroll snapshots, audit
Blob (documents)	Scanned contracts and reviews, quarantine then clean
Blob (payroll outbound)	Files, manifests, receipts; immutable
Pickup agent (on-prem)	Pull, verify, hand to the payment system, write receipt
Entra ID / Key Vault / App Insights	Identity, the few secrets, telemetry

The split rule: synchronous user work in the API, anything that must survive failure or runs on a schedule in Functions, and anything that touches the server farm on-premises. The API never talks to the payment system directly.

Deeper: Component table

Inside the API, the split is by module, and the boundary is enforced:

• Each module owns a SQL schema (salary, leave…) and its EF configuration.
• Modules talk through Contracts interfaces, for example IReportingLine from Employees, used by Salary.
• A NetArchTest rule fails the build if one module references another’s internals.
• Shared validators live in Dunderly.Hr.Shared, used by both Blazor and the API.

[Fact]
public void Salary_does_not_depend_on_leave_internals() =>
    Types.InAssembly(typeof(SalaryModule).Assembly)
        .ShouldNot().HaveDependencyOn("Dunderly.Hr.Modules.Leave.Domain")
        .GetResult().IsSuccessful.Should().BeTrue();

The point of this structure is to keep “we could split it later” true without paying for it now.

Deeper: Coding standards

Operationally there are four deployable units, each with its own lifecycle:

Unit	Target	Deploy
Web	Static Web Apps	SWA deploy action, previews per PR
API	App Service (P0v3)	Zip to staging slot, smoke, swap
Functions	Flex Consumption	Zip deploy after the API swap
Pickup agent	Arc-enabled on-prem server	Versioned package, installed with IT

Plus the database (migration bundle) and the infrastructure (Bicep). Ordering matters: Bicep → migrations → API → Functions → web, so the UI never calls an API older than itself.

az functionapp deployment source config-zip -g rg-dunderly-hr-prod -n func-dunderly-hr-prod --src artifacts/func.zip

Deeper: Deployment automation

Which non-functional requirements drove the architecture the most?

Three NFRs drove it, and two of them pushed in the “smaller” direction:

1. Scale (10 concurrent users, 500 employees, 25.5 GB). It ruled out anything distributed for its own sake. That’s the reason for a modular monolith, a serverless database and one App Service plan.
2. “Not mission critical”, with one exception. The web app can be down for an afternoon, the payroll file can’t be late. So single region and no warm standby, but a verified, alerted payroll path.
3. Data sensitivity. Salary and personal data meant identity-first security: Entra ID, role plus reporting-line checks, private endpoints, no personal data in telemetry.

The file-only payment interface was the constraint that shaped integration: pull, manifest, receipt.

Assumption: RTO one business day and RPO 15 minutes; the case study only said “not very critical”.

Deeper: Non-functional requirements

From the reliability seat, the NFR that matters is the one the case study didn’t quantify: what “not critical” means. I’d turn it into SLOs:

SLI	Proposed SLO
Availability test success, business hours	99.5% / 30 days
API p95 latency	< 500 ms
Payroll file confirmed before cutoff + 1 day	100%, every month

The third one shapes operations: alerts for “approved but no file” (Sev 1 after an hour) and “file but no receipt” (Sev 1 after four hours), each with a runbook. The first two get an error budget; burning half of it moves reliability work up the backlog.

requests | where timestamp > ago(30d) | summarize p95=percentile(duration,95) by name | order by p95 desc

The gap: these targets are proposals until the sponsor agrees them.

Deeper: Targets

Which architectural options did you consider and reject, and why?

Option	Why rejected
Three services (2023 design)	Shared database, one UI page needs all three, 10 users: a distributed monolith
Application Gateway WAF v2	41.5% of the 2023 cost for an SSO-only internal app; revisit triggers recorded
App Service WebJob for payroll	No built-in redundancy, tied to the API’s deployment
Push the file into the server farm	Needs inbound connectivity and credentials into a system we don’t own
Service Bus	Storage queues and an outbox cover the volume; Service Bus is the step up if needed
AKS / containers	No team need and no scale need; App Service is simpler to run
Provisioned SQL, 3-year reserved	Pays for idle capacity; serverless fits a spiky, low load
Custom logging service	Application Insights already batches asynchronously
Power BI in v1	Licensing and another copy of salary data; CSV exports first

The pattern: I rejected things because they cost more than the risk they removed, and I wrote down when each rejection should be revisited.

Deeper: ADRs

Monolith, modular monolith or microservices, what did you choose and why?

Modular monolith. The 2023 case study split it into Employee, Salary and Vacation services, then correctly chose a single shared data store because the data is shared. Three services on one database is the worst of both: three pipelines and three App Services (~$219/month in 2023), but no independent deployability, because a schema change touches all of them.

What I kept from the microservice idea is the boundary: modules with their own schema, a contracts project, and an architecture test that enforces it. The signals that would justify splitting a module out: a separate team, a separate release cadence, or a separate scaling need. At Dunderly’s size none is expected, but if the payroll module ever had to integrate with a new payroll SaaS on its own cadence, it’s the first candidate.

This is the answer I’d lead with, because it shows I can disagree with an earlier design, my own included.

Deeper: ADR-001

Day to day, a modular monolith means one solution, one debugger session, one transaction when I need one, and no network calls between modules. The cost is discipline:

• Schema per module: modelBuilder.HasDefaultSchema("salary") in each DbContext.
• No cross-module joins in EF; read another module’s data through its contract interface.
• In-process events for side effects (salary approved → audit event) via a simple dispatcher, and the outbox for anything leaving the process.
• Architecture tests keep it honest.

public sealed class SalaryDbContext(DbContextOptions<SalaryDbContext> o) : DbContext(o)
{
    protected override void OnModelCreating(ModelBuilder b)
    {
        b.HasDefaultSchema("salary");
        b.Entity<SalaryRecord>().ToTable("SalaryRecord", t => t.IsTemporal());
    }
}

Deeper: Data models

For DevOps the monolith is a clear win: one API artifact, one App Service plan, one slot swap, one set of alerts. With three services I’d have three pipelines, three slots and a coordination problem every time a shared schema changed, because they all shared the database.

What I’d still keep separate is what has a genuinely different lifecycle:

• Functions: event and schedule driven, scale to zero, different trigger model.
• Web: static hosting with PR previews.
• Pickup agent: deployed on-premises with IT, released rarely.

dotnet publish src/Dunderly.Hr.Api -c Release -o artifacts/api && (cd artifacts/api && zip -r ../api.zip .)

Deeper: Artifacts

Technology Choices

Which technologies did you use across the stack, and why those?

Layer	Choice	Why
Frontend	Blazor WebAssembly + Fluent UI	.NET team, shared validators, Microsoft 365 look
Hosting (web)	Static Web Apps Standard	Static files, PR previews; kept from 2023
API	ASP.NET Core minimal APIs on App Service Linux P0v3	Slots, VNet integration, one plan
Background	Azure Functions, Flex Consumption	Timer, queue, Event Grid triggers; scale to zero
Data	Azure SQL serverless; Blob Storage	Relational + temporal; documents out of the DB
Identity	Entra ID, managed identities, Arc for on-prem	No passwords anywhere
Observability	Application Insights via OpenTelemetry	Replaces the custom logging service
IaC / CI	Bicep + AVM; GitHub Actions with OIDC	Azure-only estate; no state file

The client asked for Azure and .NET, so the real choices were inside that box, and most of them were “which managed service is the smallest that does the job”.

Deeper: Technology selection

The developer-facing stack and why each piece earns its place:

• .NET 10 LTS: support window covers the first years.
• Minimal APIs: less ceremony than controllers; MapGroup per module and endpoint filters for cross-cutting concerns.
• EF Core: migrations, temporal tables, retries; raw SQL via FromSql for reports.
• FluentValidation: one validator class used in Blazor (<FluentValidationValidator />) and the API.
• Microsoft.Identity.Web / MSAL: token validation on the API, acquisition in the browser.
• Fluent UI Blazor: accessible components.
• xUnit, Testcontainers, bUnit, Playwright: tests at every level.

dotnet add src/Dunderly.Hr.Api package Microsoft.Identity.Web
dotnet list package --vulnerable --include-transitive

Deeper: Dependency management

• GitHub Actions with reusable workflows and environments (dev, test, prod with reviewers).
• OIDC federated credentials with azure/login, no client secrets.
• Bicep with Azure Verified Modules and .bicepparam files; what-if on every PR.
• Zip deploy to App Service and Functions; no containers, no registry to run.
• EF Core migration bundles as a self-contained executable.
• Azure Monitor: action groups, alerts, workbooks.
• Azure Arc to give the on-prem agent a managed identity.

az deployment sub create -l westeurope -f infra/main.bicep -p infra/env/test.bicepparam
./artifacts/efbundle --connection "<connection string using Active Directory Default auth>"

The gap: Flex Consumption has no deployment slots, so Functions deploy without a swap. Their jobs are idempotent, which is the mitigation.

Deeper: Build automation

How do you evaluate and choose between competing technologies?

I score options against the requirements that actually bind, then check the cost of being wrong.

For Dunderly the binding constraints were: Azure and .NET (client), a small team (assumption), 10 users, sensitive data, a file-only integration. So my questions per choice were:

1. Does the team already know it? (Blazor over React for a .NET team.)
2. Is it the smallest managed service that does the job? (Functions over Batch or Logic Apps.)
3. What does it cost per month at this scale? (SQL serverless over reserved provisioned.)
4. How hard is it to reverse? (Bicep vs Terraform: both reversible; a WAF can be added later.)

Then I write an ADR with a “revisit when” line. The Functions decision shows the method: 2023 rejected Functions as “lightweight”; re-scoring on reliability (queue retries, triggers) rather than weight flipped it.

Deeper: ADRs

I’d evaluate with a spike, not a slide. For Dunderly the one I’d actually run is Blazor WebAssembly vs a React SPA:

• Build the same leave request form both ways in a day.
• Compare: shared validation (Blazor reuses the API’s FluentValidation classes; React would duplicate them in TypeScript), first-load size, accessibility of the component library, and the team’s speed.
• Blazor won on shared code and team fit; React would win on first-load size and the hiring pool.

For libraries, I check license, maintenance (recent releases, issues answered), and whether the platform already covers it (TimeProvider instead of a clock library, System.Text.Json instead of Newtonsoft).

dotnet new blazorwasm -o spike/BlazorLeave && dotnet run --project spike/BlazorLeave

Deeper: Technology selection

Where did you build, and where did you buy or reuse?

Bought (as managed services): hosting, database, storage, identity, malware scanning (Defender for Storage), monitoring, CI. None of these differentiate an HR system, and the team is too small to run them.

Built: the HR domain (salary workflow, leave ledger, payroll run), because the rules are Dunderly’s; and the payroll integration (file writer and pickup agent), because the legacy system’s format is unique.

Considered and not chosen: a SaaS HR suite. It’s the honest alternative, and I’d raise it with the sponsor: a SaaS HR product could cover most of this. The case for building was the legacy file interface and the client’s explicit request for an Azure/.NET system; if those changed, I’d re-run that decision. I also kept the exit path clean: no proprietary formats, export via API and SQL.

Deeper: Decommissioning

On the platform side I reuse rather than build:

• Azure Verified Modules for Bicep instead of hand-written resource modules.
• GitHub’s own actions (azure/login, azure/webapps-deploy, SWA deploy) instead of custom scripts.
• AzCopy in the pickup agent instead of writing a transfer client.
• Azure Monitor alerts and action groups instead of a separate paging tool.
• Dependabot, CodeQL, secret scanning built into GitHub.

What I’d build is thin glue: the reusable deploy workflow, the payroll-freeze check, and the drift what-if job.

azcopy copy "https://<payroll-account>.blob.core.windows.net/payroll-outbound/2027-03/*" "D:\payroll\incoming" --include-pattern "*.dat;*.json"

Deeper: Integration development

Frontend Architecture

How is the frontend (or user-facing interface) structured, in terms of framework, routing, components and state?

A Blazor WebAssembly single-page app on Static Web Apps, with navigation shaped by role: everyone gets “Me”, managers add “My team”, HR roles add the HR section, and items a role can’t use aren’t rendered at all.

• Routing: @page routes per feature, grouped by area (/me/leave, /team/salary-requests, /hr/employees/{id}).
• Components: Fluent UI Blazor for the design system; feature components per module.
• State: mostly server state, fetched per page; small in-memory caches for reference data; filters in the URL so views can be bookmarked.
• Auth: MSAL with PKCE; AuthorizeView and [Authorize(Roles=…)] hide what a role can’t use. The API enforces it; the UI only avoids showing dead ends.

The employee detail page is the hub for HR (tabs for profile, salary, leave, documents, history), which is also the UX argument for one API rather than three.

Deeper: Information architecture

Blazor concepts, tied to this app:

• Routable components: @page "/team/salary-requests/new/{EmployeeId:int}" with a typed route parameter.
• Parameters and state: [Parameter] public int EmployeeId; form model in a private field; StateHasChanged rarely needed because events re-render.
• Lifecycle: OnInitializedAsync loads data; OnParametersSetAsync reloads when the route parameter changes.
• Forms: EditForm + FluentValidationValidator with the shared validator; OnValidSubmit posts.
• Auth: CascadingAuthenticationState, AuthorizeView Roles="HR.Manager".
• HTTP: typed client generated from OpenAPI, BaseAddressAuthorizationMessageHandler-style handler adds the token.
• DI: services registered in Program.cs of the WASM host.

<AuthorizeView Roles="HR.Manager">
    <Authorized><FluentButton OnClick="ApproveAsync" Disabled="@isOwnRequest">Approve</FluentButton></Authorized>
</AuthorizeView>

dotnet watch --project src/Dunderly.Hr.Web

Deeper: API and UI implementation

How does the user interface handle loading, errors and large data sets?

Large data sets barely exist here (500 employees, an audit log that grows slowly), so the patterns are simple and consistent:

• Loading: skeletons on first load, inline progress on actions; buttons disable while submitting so a double click can’t approve twice (and the API is idempotent anyway).
• Errors: problem details from the API map to plain messages (“March payroll is already closed”), shown inline until fixed. A correlation ID is shown on unexpected errors so support can find the trace.
• Large lists: server-side paging, search and filters for employees and the audit log, with filters in the URL. Virtualization only for the audit view.
• Concurrency: a 412 from the API shows “someone changed this record” with the differences.

Deeper: Interaction patterns

• Conditional rendering: @if (employees is null) { <FluentSkeleton /> } else if (error is not null) { … }.
• Paging: FluentDataGrid with an ItemsProvider that calls GET /employees?page=&pageSize=.
• Virtualization: <Virtualize ItemsProvider="LoadAuditAsync"> for the audit log.
• Errors: a DelegatingHandler turns problem details into a typed ApiError; an ErrorBoundary catches render failures.
• Navigation state: NavigationManager and [SupplyParameterFromQuery] keep filters in the URL.

private async ValueTask<GridItemsProviderResult<EmployeeRow>> LoadAsync(GridItemsProviderRequest<EmployeeRow> req)
{
    var page = await api.GetEmployeesAsync(search, req.StartIndex / PageSize + 1, PageSize, req.CancellationToken);
    return GridItemsProviderResult.From(page.Items, page.TotalCount);
}

The gotcha: Blazor WASM’s first download is larger than a JS SPA’s; on office networks it’s fine, on a phone over 4G the first load needs watching.

Deeper: Responsive behavior

How do you keep the frontend fast and accessible?

Fast: static hosting at the edge, AOT or trimmed WASM bundles, lazy-loaded assemblies for the HR-only sections so employees never download them, and an API that answers in under 500 ms at p95. The one real risk is first load on phones, so I’d measure it.

Accessible: WCAG 2.2 AA designed in: Fluent UI components with keyboard and ARIA support, visible focus, 4.5:1 contrast, labels and linked error messages, a list alternative to the leave calendar, session-timeout warnings, 24 px targets. Then axe in every E2E run, and a manual keyboard and screen-reader pass per release. Automated tools catch only part of the problems, so the manual pass isn’t optional.

Deeper: Accessibility design, Accessibility testing

• Trimming and compression: PublishTrimmed (default for WASM), Brotli served by Static Web Apps.
• Lazy loading: HR and payroll pages in separate assemblies loaded with LazyAssemblyLoader on navigation.
• Avoid re-renders: @key on list items, ShouldRender for heavy components, no work in OnAfterRender.
• Accessibility in markup: Label on every Fluent input; aria-describedby for errors; focus the first invalid field on submit.

<ItemGroup>
  <BlazorWebAssemblyLazyLoad Include="Dunderly.Hr.Web.Hr.wasm" />
  <BlazorWebAssemblyLazyLoad Include="Dunderly.Hr.Web.Payroll.wasm" />
</ItemGroup>

npx playwright test --project=chromium   # E2E with axe checks

Deeper: Visual design

I’d watch the frontend as users feel it:

• Client telemetry: Application Insights JS SDK for page views and failed calls only; page load times by route and device type.
• Availability test: a standard test from three locations hitting /health, plus the static site root.
• Signals: p95 first-load time for the home page, client error rate, and API p95 for the calls each page makes.

pageViews | where timestamp > ago(7d)
| summarize p95=percentile(duration,95), n=count() by name, client_Type

The gap: synthetic tests can’t sign in with MFA, so they check the static site and health endpoints, not a real signed-in journey. Real-user page timings cover that.

Deeper: Monitoring

How is the frontend built, configured per environment and served?

dotnet publish produces static files (wwwroot), deployed to Static Web Apps. Per-environment settings are only public values (API base URL, client ID, scope), written into wwwroot/appsettings.json by the pipeline. Nothing secret can go there: everything in a WebAssembly app is downloadable.

Static Web Apps gives a custom domain with a managed certificate, HTTP security headers via staticwebapp.config.json, a fallback route so deep links reach the SPA, and a preview environment per pull request, which is how HR reviews UI changes before they merge.

Deeper: Environment configuration

• Program.cs reads builder.Configuration["Api:BaseUrl"]; wwwroot/appsettings.{Environment}.json per environment.
• The environment comes from the Blazor-Environment header, which Static Web Apps can set per environment.
• MSAL settings (Authority, ClientId, DefaultScopes) bind from config.

{
  "navigationFallback": { "rewrite": "/index.html", "exclude": ["/_framework/*", "/css/*"] },
  "globalHeaders": {
    "Content-Security-Policy": "default-src 'self'; connect-src 'self' https://hr-api.<company domain> https://login.microsoftonline.com",
    "X-Content-Type-Options": "nosniff"
  }
}

dotnet publish src/Dunderly.Hr.Web -c Release -o artifacts/web

Deeper: Build automation

The web deploy is the last step of a release, so the UI never calls an API older than itself:

- uses: Azure/static-web-apps-deploy@v1
  with:
    azure_static_web_apps_api_token: ${{ secrets.SWA_TOKEN }}
    action: upload
    app_location: artifacts/web/wwwroot
    skip_app_build: true

• On PRs the same action creates a preview environment with its own URL; it’s deleted on close.
• The appsettings.json rewrite per environment is a small jq step on the artifact.
• The deployment token is the one credential I can’t replace with OIDC here, so it’s an environment secret, rotated yearly.

Deeper: Deployment automation

Backend and API Design

How do CRUD operations work in the backend, from request to persisted data?

Take “update employee”: the request carries the row version in If-Match. The endpoint checks the role (HR.Admin), validates the body with the shared validator, loads the aggregate, applies the change through domain methods that enforce rules, and saves in one transaction that also writes an audit event. EF Core’s concurrency token turns a stale row version into 412. The response returns the new version.

Three design rules make CRUD safe for HR:

• Delete is deactivation (POST …/deactivation), because records have retention periods.
• History is automatic: EMPLOYEE and SALARY_RECORD are temporal tables.
• Audit in the same transaction, so a change can’t happen without its record.

Deeper: API architecture

• Routing: MapPut("/employees/{id:int}", Update) with a route constraint.
• Binding: body to a record DTO; [FromHeader(Name = "If-Match")] for the version.
• Validation: an endpoint filter runs FluentValidation and returns 400 with problem details.
• DI: EmployeesDbContext and IAuditWriter injected.
• Concurrency: Property(e => e.RowVersion).IsRowVersion(); catch DbUpdateConcurrencyException.

static async Task<IResult> Update(int id, UpdateEmployee dto, [FromHeader(Name = "If-Match")] string etag,
    EmployeesDbContext db, IAuditWriter audit, ClaimsPrincipal user, CancellationToken ct)
{
    var e = await db.Employees.FindAsync([id], ct);
    if (e is null) return Results.NotFound();
    db.Entry(e).Property(x => x.RowVersion).OriginalValue = Convert.FromBase64String(etag);
    var before = e.Snapshot(); e.Apply(dto);
    audit.Add("EmployeeUpdated", id, before, e.Snapshot(), user.GetObjectId());
    try { await db.SaveChangesAsync(ct); } catch (DbUpdateConcurrencyException) { return Results.StatusCode(412); }
    return Results.Ok(e.ToDto());
}

Deeper: Feature development

How did you design the API, in terms of style, resources, versioning, pagination and errors?

• Style: REST over HTTPS, JSON, OpenAPI generated from code. Commands that aren’t CRUD are modelled as sub-resources: POST /salary-requests/{id}/approval, …/rejection, …/withdrawal. It keeps the 2023 case study’s shape and makes each action separately authorizable and auditable.
• Resources: plural nouns everywhere (/employees, /salary-requests, /payroll-runs). The 2023 tables mixed employee and employees; I normalized them.
• Versioning: path (/api/v1). With one client in the same repo, a v2 should never be needed.
• Pagination: page and pageSize (max 100), with totalCount in the response.
• Errors: RFC 9457 problem details with a stable type per business rule, so the UI can show a specific message.

Deeper: API table, REST API

• builder.Services.AddOpenApi() and app.MapOpenApi() for the document; typed results (Results<Ok<T>, NotFound>) so the schema is accurate.
• AddProblemDetails() plus an exception handler; business failures return Results.Problem(type: "https://errors.<domain>/period-closed", …).
• Paging as a reusable record: record Page<T>(IReadOnlyList<T> Items, int TotalCount).
• WithTags, WithSummary and Produces on endpoints for docs.

g.MapGet("/", async ([AsParameters] EmployeeQuery q, EmployeesDbContext db, CancellationToken ct) =>
{
    var query = db.Employees.AsNoTracking().Where(e => q.Name == null || e.LastName.StartsWith(q.Name));
    var total = await query.CountAsync(ct);
    var items = await query.OrderBy(e => e.LastName).Skip((q.Page - 1) * q.PageSize).Take(q.PageSize)
        .Select(e => new EmployeeRow(e.EmployeeId, e.FirstName, e.LastName)).ToListAsync(ct);
    return TypedResults.Ok(new Page<EmployeeRow>(items, total));
});

Deeper: Developer documentation

How is the backend structured internally, and where does background work run?

Internally it’s a modular monolith: modules for Employees (with Documents), Salary, Leave, Payroll and Audit, each with domain, application and infrastructure layers and a contracts project. Cross-module calls go through contracts; the architecture test enforces it.

Background work never runs in the API process. It runs in the Functions app:

Job	Trigger
Draft payroll run	Timer, on cutoff day
Write payroll file	Storage queue payroll-approved
Mark run delivered	Event Grid, receipt blob created
Promote scanned document	Event Grid, Defender scan result
Send notifications	Timer, reads the outbox
Retention purge	Timer, monthly

Why not hosted services in the API? Deployment slots: during a swap, two copies of the API run, and a BackgroundService would run twice.

Deeper: System context

• Layers per module: Domain (entities, rules), Application (use cases like SalaryService.ApproveAsync), Infrastructure (EF config, Blob client), Contracts (interfaces other modules may use).
• Registration: each module exposes AddSalary(IServiceCollection, IConfiguration) and MapSalary(RouteGroupBuilder).
• Functions (isolated worker): [QueueTrigger], [TimerTrigger("0 0 6 * * *")], [EventGridTrigger]; they reference the same module projects, so business rules aren’t duplicated.

[Function("CreatePayrollRun")]
public Task Run([TimerTrigger("0 0 6 * * *")] TimerInfo t, CancellationToken ct)
    => payroll.CreateDraftIfCutoffTodayAsync(ct);   // no-op on other days; idempotent per period

The gotcha: the Functions app and the API must deploy compatible versions of the shared modules, which is why they come from the same build.

Deeper: Integration development

Two hosts, two plans, one build:

• API: App Service plan P0v3, Linux, healthCheckPath: /health/live, VNet integration, staging slot.
• Functions: Flex Consumption with VNet integration; storage queue and Event Grid subscriptions in Bicep.
• Identities: system-assigned managed identity each, with role assignments in Bicep (Storage Queue Data Contributor for the API on payroll-approved, Storage Blob Data Contributor for Functions on outbound).

az functionapp function list -g rg-dunderly-hr-prod -n func-dunderly-hr-prod -o table
az storage message peek --queue-name payroll-approved-poison --account-name <acct> --auth-mode login

The thing I’d check after each deploy: Event Grid subscriptions still point at the right function, because a renamed function silently breaks them.

Deeper: Compute, storage, and databases

How do you validate input and keep operations safe to repeat?

Validate at the edge with shared FluentValidation rules, in the domain for business rules (period closed, four eyes), and in the database as the last line (check constraints, unique keys, foreign keys). Uploads add type checks by magic bytes, a size limit and malware scanning.

Safe to repeat:

• Commands are state transitions: approving an already-approved request returns 409, not a second salary row.
• If-Match row versions stop lost updates.
• The payroll file name includes the run ID, the container is immutable, and the writer exits early if the blob exists; queue retries can’t produce a second file.
• The outbox marks messages sent; a re-run won’t email twice.
• The migration tool upserts by employee number, so rehearsals can run repeatedly.

Deeper: Input validation

• Endpoint filter for validation, so handlers only see valid input.
• State machine in the domain: Approve() throws a domain error unless Status == Submitted.
• Idempotent consumer in Functions: check-then-write with the blob’s existence, and blob immutability as the backstop.

public sealed class ValidationFilter<T>(IValidator<T> validator) : IEndpointFilter
{
    public async ValueTask<object?> InvokeAsync(EndpointFilterInvocationContext ctx, EndpointFilterDelegate next)
    {
        var arg = ctx.Arguments.OfType<T>().Single();
        var result = await validator.ValidateAsync(arg);
        return result.IsValid ? await next(ctx) : Results.ValidationProblem(result.ToDictionary());
    }
}

The gotcha: “exists then upload” isn’t atomic; two concurrent executions could race. The immutable container (and If-None-Match: * on upload) makes the second one fail instead of overwriting.

Deeper: Integration development

What I’d watch so “safe to repeat” stays true in production:

• Poison queue depth on payroll-approved-poison: any message is a Sev 2.
• 409 rate on approval endpoints: a spike means a UI double-submit bug or a race.
• Duplicate detection query: more than one file per payroll period, which should be impossible.
• Retry behaviour: Functions queue retries with backoff (max dequeue 5), SQL retry on transient errors.

requests | where name has "approval" and resultCode == "409"
| summarize count() by bin(timestamp, 1h)

Deeper: Alerting

Database and Data Modeling

Which data store did you choose, and why?

Azure SQL Database (serverless, General Purpose) for records, and Blob Storage for documents.

Why relational: the data is relational (employees, managers, salaries, requests, payroll lines), the rules need transactions (approve + new salary row + audit in one commit), and HR history needs temporal tables, which Azure SQL gives natively. Why serverless: 10 users and a spiky month-end don’t justify the 2023 estimate’s reserved provisioned database ($256.63/month); serverless bills per second of use. Why Blob for documents: ~25 GB of scans would bloat backups and cost more in the database.

Trade-off I’d name: serverless can auto-pause, and a one-minute resume on Monday morning is a bad first impression, so auto-pause is off in production and on in dev and test.

Deeper: ADR-008

• EF Core with the SQL Server provider, one DbContext per module schema.
• Entra-only auth: connection string with Authentication=Active Directory Default; the managed identity in Azure, my own account locally against a dev database, or SQL auth only to the local container.
• Resiliency: EnableRetryOnFailure() for transient errors.
• Temporal queries: TemporalAsOf to answer “what was the salary on date X”.

var march = await db.SalaryRecords.TemporalAsOf(new DateTime(2027, 3, 31))
    .Where(s => s.EmployeeId == id).ToListAsync(ct);

dotnet ef dbcontext info --context SalaryDbContext

Deeper: Data architecture

Provisioned in Bicep:

• Logical server with Entra-only authentication and an Entra admin group; no SQL logins.
• Database GP_S_Gen5 serverless, max 2 vCores; autoPauseDelay: -1 in prod, 60 in dev/test.
• Public network access disabled; private endpoint in snet-pe; private DNS zone linked.
• Backups: PITR 35 days, LTR policy, geo-redundant backup storage.
• Auditing to Log Analytics.
• Contained users for the API (DML) and the pipeline (DDL), created by a deployment script.

az sql db show -g rg-dunderly-hr-prod -s sql-dunderly-hr-prod -n sqldb-hr --query "{sku:sku.name,autoPause:autoPauseDelay}"

Deeper: Compute, storage, and databases

How is the data modeled, and how did the access patterns shape the model?

Three access patterns shaped the model:

1. “What was X paid on date Y?” → salaries as effective-dated rows, never updated, plus temporal tables.
2. “How many leave days are left, and why?” → a leave ledger (entitlements, bookings, adjustments); the balance is a sum, every number explainable.
3. “What exactly did we send in March?” → payroll runs snapshot their lines; later edits can’t change a file that’s gone.

Plus the reporting line (ManagerId self-reference) because authorization depends on it, and an append-only audit table. Each module owns a schema. Indexes on every foreign key and on (EmployeeId, EffectiveFrom).

The ER diagram is in the playbook; the case study’s “1 MB per employee” means the whole relational store stays under 1 GB for years, so modelling for clarity beats modelling for performance here.

Deeper: Data models

• Entities and value objects: Money(decimal Amount, string Currency) as an owned type; DateOnly for dates.
• Self-reference: HasOne(e => e.Manager).WithMany().HasForeignKey(e => e.ManagerId).
• Ledger balance: a query, not a stored column.
• Temporal: ToTable("Employee", t => t.IsTemporal()).

public Task<decimal> GetBalanceAsync(int employeeId, int year, CancellationToken ct) =>
    db.LeaveEntries.Where(l => l.EmployeeId == employeeId && l.Year == year && l.Status != LeaveStatus.Rejected)
        .SumAsync(l => l.Type == LeaveType.Entitlement ? l.Days : -l.Days, ct);

The gotcha: storing the balance would be faster, but then it can drift from the ledger. At 500 employees the sum is cheap.

Deeper: Data validation

How were schema changes and data migrations handled?

EF Core code-first migrations, one history per module schema, reviewed in PRs, shipped as a migration bundle that the pipeline runs before deploying code. The rule that makes it safe is expand, then contract: a release only adds; removals come a release later. That’s what lets the old and new API versions both run during a slot swap.

Data migration from the old records (assumed spreadsheets and a file share, ~2,500 documents at 250 employees) is a separate idempotent tool, rehearsed three times on a locked-down copy, with reconciliation of headcount, salary totals, leave totals and document hashes.

Deeper: Schema and migrations, Data migration

dotnet ef migrations add AddLeaveCarryOver --project src/Dunderly.Hr.Api --context LeaveDbContext
dotnet ef migrations script --idempotent --context LeaveDbContext -o out/leave.sql   # to review the SQL
dotnet ef migrations bundle --project src/Dunderly.Hr.Api --self-contained -r linux-x64 -o artifacts/efbundle

• Review the generated SQL, not just the C#: a rename can be generated as drop + add, which loses data.
• Expand-only: new columns nullable or with defaults; a column drop waits for the next release.
• Data fixes go in the migration with migrationBuilder.Sql(...) only if they’re small and idempotent; otherwise a one-off tool.
• Temporal tables need care: altering a temporal table’s columns updates the history table too, which EF handles, but review it.

Deeper: Database deployment

In the release workflow: record the time (for point-in-time restore), run the bundle as the pipeline’s identity (the only principal with DDL), then deploy the API to the staging slot.

date -u +%Y-%m-%dT%H:%M:%SZ > restore-point.txt
./artifacts/efbundle --connection "Server=tcp:<server>.database.windows.net;Database=sqldb-hr;Authentication=Active Directory Default"

If a migration fails, nothing has been deployed yet, so production keeps running the old code against a schema that’s either unchanged or only expanded. For the rare bad data change, PITR to a new database at the recorded time, then repair.

Deeper: Rollback

How do you handle data retention, backup and restore?

Retention is data-driven: a monthly job anonymizes personal fields and deletes documents once a leaver’s records pass their retention date, keeping minimal payroll facts if tax law needs them longer. Payroll files sit in an immutable container for the retention period.

TODO: Retention periods per data set from Dunderly’s legal advisor; under GDPR (assumption A2), “keep forever” isn’t an option.

Backup: SQL automatic backups with 35-day PITR and long-term retention, geo-redundant; Blob versioning, soft delete and GRS. Restore is tested quarterly, which is when a backup becomes a real thing.

Deeper: Retention, Backup and restore

Configured in Bicep, not the portal:

• SQL: shortTermRetentionPolicies 35 days; longTermRetentionPolicies (monthly 12 months, yearly for the legal period); requestedBackupStorageRedundancy: 'Geo'.
• Blob: isVersioningEnabled, deleteRetentionPolicy 30 days, lifecycle rule to cool after 180 days.
• Payroll container: time-based immutability policy.

az sql db restore -g rg-dunderly-hr-prod -s sql-dunderly-hr-prod -n sqldb-hr \
  --dest-name sqldb-hr-restoretest --time "2027-03-14T09:00:00Z"
az storage blob list --account-name <docs-acct> -c documents --include v --prefix <docId> --auth-mode login

Deeper: Backup verification

Backups only count once restored. The SRE routine:

• Quarterly PITR restore into an isolated resource group, row-count and checksum checks, then delete. The time it takes is our measured RTO for data loss.
• Quarterly restore of a deleted document version.
• Yearly DR drill: geo-restore in North Europe and rebuild compute from Bicep; measure against the one-business-day RTO (assumption A7).

RPO: SQL log backups every 5 to 10 minutes give a PITR RPO of minutes; geo-restore across regions is looser (up to about an hour).

TODO: Is a 15-minute RPO firm for a regional outage? If so, an auto-failover group is needed, at the cost of a second database.

Deeper: Disaster recovery testing

Frontend, Backend and Database Communication

How does the frontend connect to the backend?

The Blazor app calls the API directly over HTTPS at its own hostname (hr-api.<company domain>), with an Entra ID access token in the Authorization header. CORS on the API allows only the web app’s origin.

I considered the Static Web Apps linked-backend feature (proxy /api to App Service, same origin, no CORS). I chose direct calls with MSAL because the API’s authorization is built on Entra app roles in the JWT, which is standard and well supported by Microsoft.Identity.Web, while Static Web Apps’ built-in auth would put its own principal header in between and need extra role mapping. The cost is a CORS policy and a second public hostname, both easy to get right.

No WAF in front (ADR-004): the API requires a valid token on every endpoint except health, and has rate limiting.

Deeper: Identity and access

• MSAL in Blazor: AddMsalAuthentication with the API scope as a default scope.
• Message handler: an AuthorizationMessageHandler configured for the API base URL attaches tokens and handles AccessTokenNotAvailableException by redirecting to sign-in.
• Typed client: generated from OpenAPI, registered with AddHttpClient<HrApiClient>.
• CORS on the API: one named policy, the web origin only.

builder.Services.AddHttpClient<HrApiClient>(c => c.BaseAddress = new Uri(apiBase))
    .AddHttpMessageHandler(sp => sp.GetRequiredService<AuthorizationMessageHandler>()
        .ConfigureHandler(authorizedUrls: [apiBase], scopes: [$"api://{apiClientId}/HR.Access"]));

builder.Services.AddCors(o => o.AddPolicy("web", p => p.WithOrigins(webOrigin).AllowAnyHeader().AllowAnyMethod()));

Deeper: Authentication and authorization

• Two custom domains, both with managed certificates: hr.<company domain> (Static Web Apps) and hr-api.<company domain> (App Service).
• The API’s allowed CORS origin and the web app’s API base URL both come from Bicep outputs, so they can’t disagree between environments.
• App Service: httpsOnly, minimum TLS 1.2, HTTP/2 on.

az webapp config hostname add -g rg-dunderly-hr-prod --webapp-name app-dunderly-hr-api-prod --hostname hr-api.<company domain>
az staticwebapp hostname set -n swa-dunderly-hr-prod --hostname hr.<company domain>

TODO: Dunderly’s domain and who manages its DNS.

Deeper: Networking and DNS

Trace a single user request from the browser to the data store and back.

“HR manager approves a salary request”:

Hop	What happens
Browser	Blazor posts POST /api/v1/salary-requests/42/approval with the row version and a bearer token
API middleware	TLS ends at App Service; JWT validated (issuer, audience, signature); role HR.Manager checked
Endpoint	Validation filter; SalaryService.ApproveAsync loads request 42
Domain	Status must be Submitted; approver ≠ requester; effective date not in a closed period
SQL (private endpoint)	One transaction: request → Approved, new SALARY_RECORD, audit event, outbox row; row version checked
Response	200 with the updated request; or 403, 404, 409, 412 as problem details
Later	Outbox Function emails the manager (no amount in the email)

One trace ID follows it through, visible in Application Insights.

Deeper: Salary journey

In code, the same request:

// Application layer
public async Task<OneOf<SalaryRequestDto, NotFound, SelfDecision, Conflict>> ApproveAsync(
    int id, Guid approver, byte[] rowVersion, CancellationToken ct)
{
    var req = await db.Requests.SingleOrDefaultAsync(r => r.Id == id, ct);
    if (req is null) return new NotFound();
    if (req.RequestedBy == approver) return new SelfDecision();
    db.Entry(req).Property(r => r.RowVersion).OriginalValue = rowVersion;
    var record = req.Approve(approver, time.GetUtcNow());          // domain rules
    db.SalaryRecords.Add(record);
    audit.Add("SalaryApproved", req.Id, approver); outbox.Add(Notify.Requester(req));
    try { await db.SaveChangesAsync(ct); } catch (DbUpdateConcurrencyException) { return new Conflict(); }
    return req.ToDto();
}

One SaveChangesAsync means one transaction for the request, the new salary row, the audit event and the outbox message.

Deeper: API and UI implementation

I’d follow the trace, not guess. The UI shows the correlation ID on errors, and from there:

union requests, dependencies, exceptions, traces
| where operation_Id == "<trace id>"
| project timestamp, itemType, name, duration, resultCode, message
| order by timestamp asc

Where time goes on this path: token validation (cached signing keys, microseconds), the SQL round trips (two or three, single-digit milliseconds over the private endpoint), and the commit. If p95 drifts above 500 ms, the first suspects are SQL serverless scaling or an N+1 in a list endpoint, not this write.

Deeper: Distributed tracing

How does the backend connect to the data store, and how are connections, timeouts and concurrency handled?

The API connects to Azure SQL through a private endpoint using its managed identity (Entra-only authentication), so there’s no password and no public path.

• Connections: ADO.NET connection pooling via EF Core; one DbContext per request (scoped). At 10 concurrent users, the default pool is far more than enough.
• Timeouts: command timeout 30 s by default; reports get their own higher timeout; HTTP requests honour cancellation tokens so an abandoned request stops its query.
• Transient faults: EnableRetryOnFailure with backoff, which matters for serverless scaling events.
• Concurrency: optimistic, with rowversion on aggregates that people edit; SQL’s default READ COMMITTED SNAPSHOT isolation in Azure SQL avoids readers blocking writers.

Deeper: Hosting

builder.Services.AddDbContext<SalaryDbContext>(o => o.UseSqlServer(
    builder.Configuration.GetConnectionString("Hr"),   // Authentication=Active Directory Default
    sql => { sql.EnableRetryOnFailure(5, TimeSpan.FromSeconds(10), null); sql.CommandTimeout(30); }));

• Scoped DbContext, never shared across threads.
• AsNoTracking for reads; projections to DTOs so only needed columns are fetched.
• Cancellation tokens passed into every EF call.
• Retry + transactions: with a retrying strategy, explicit transactions go through db.Database.CreateExecutionStrategy().ExecuteAsync(...), otherwise EF throws.

That last one is the gotcha that bites people the first time they combine retries with a manual transaction.

Deeper: Coding standards

• Dependency telemetry for every SQL call (duration, success) from OpenTelemetry.
• SQL metrics: CPU %, app CPU billed, and resume events for serverless; connections count.
• Alert on dependency failure rate rather than raw SQL CPU, because users feel failures, not CPU.

dependencies | where type == "SQL" and timestamp > ago(1d)
| summarize p95=percentile(duration,95), failures=countif(success == false) by bin(timestamp, 15m)

The gotcha: on a serverless database with auto-pause (dev and test), the first request after a pause waits for resume. That’s why auto-pause is off in production, and why perf tests don’t run against a paused DB.

Deeper: Health checks

Where do you cache, and how do you keep cached data correct?

Very little, on purpose, because stale HR data is worse than slow HR data:

What	Where	TTL	Why it’s safe
Reference data (departments, leave types, public holidays)	API in-memory	10 min	Changes rarely; HR edits evict it
Entra signing keys	Microsoft.Identity.Web	Library default	Standard
Static web assets	Static Web Apps / browser	Fingerprinted, long	New build = new file names

Not cached: salaries, balances, anything user-specific. With 10 users and a sub-1 GB database, SQL answers those fast enough. No Redis: it would add a service, a cost and a place where salary data could linger.

If two API instances run, each has its own memory cache; a reference-data edit evicts locally and the other instance catches up within the TTL, which is acceptable for public holidays.

Deeper: Scalability

public Task<IReadOnlyList<LeaveType>> GetLeaveTypesAsync(CancellationToken ct) =>
    cache.GetOrCreateAsync("leave-types", async e =>
    {
        e.AbsoluteExpirationRelativeToNow = TimeSpan.FromMinutes(10);
        return (IReadOnlyList<LeaveType>)await db.LeaveTypes.AsNoTracking().ToListAsync(ct);
    })!;

public async Task UpdateLeaveTypeAsync(LeaveType t, CancellationToken ct)
{
    db.Update(t); await db.SaveChangesAsync(ct);
    cache.Remove("leave-types");                          // evict on write
}

IMemoryCache (or HybridCache if we ever add a distributed layer). Keys are constants per data set; no user-specific keys, so there’s no risk of serving one person’s data to another.

Deeper: Technology selection

With so little cached, the cache can’t cause an outage, which is the point. Two things I’d still check:

• After an HR edit to public holidays, the leave calendar can be up to 10 minutes stale on the other instance. If HR reports “my change didn’t show”, that’s the first answer.
• Memory: reference data is tiny, so the App Service memory metric shouldn’t move. If it does, something is caching what it shouldn’t.

az monitor metrics list --resource <app-service-plan-id> --metric MemoryPercentage --interval PT1H

Deeper: Troubleshooting guides

Where did you use synchronous and where asynchronous communication, and why?

Synchronous for everything a user waits on: browser to API, API to SQL and Blob. The user needs the answer (“approved”, “403”, “period closed”) now, and at this scale the calls are fast.

Asynchronous where work must survive a failure, runs on a schedule, or reacts to an event:

Flow	Mechanism	Why async
Payroll file after approval	Storage queue	Retries and a poison queue; the HR manager doesn’t wait for a file
Notifications	Outbox in SQL + Function	Same transaction as the change; no “approved but nobody told”
Document scan result	Event Grid from Defender	Scanning takes seconds; the upload returns 202
Receipt from on-prem	Event Grid on blob created	The agent runs on its own schedule

The 2023 design made logging async via a queue. That instinct was right, and the OpenTelemetry exporter already does it in-process, so no queue is needed.

Deeper: Event and messaging contracts

• Upload returns 202 Accepted with a Location for the document, whose status is PendingScan; the UI polls the status every two seconds for up to a minute.
• Outbox pattern: OutboxMessage rows added in the same SaveChangesAsync; a timer Function claims rows with UPDATE TOP (20) … OUTPUT inserted.* and sends them.
• Queue message: PayrollRunApproved.v1 JSON with IDs only, also written to the outbox in the approval’s transaction; the dispatcher relays it to the payroll-approved queue.

run.Approve(approver, time.GetUtcNow());
outbox.Add(new PayrollRunApproved(run.Id, run.Period));   // same transaction as the approval
await db.SaveChangesAsync(ct);

The gotcha this avoids: sending to the queue straight after the commit leaves a gap where a crash loses the message, and payroll silently never gets its file. The relay can deliver twice, which is why the file writer is idempotent.

Deeper: Integration development

Integrations and Background Processing

Which external systems does the application integrate with, and how?

Four integrations, and one of them is the reason the system exists:

System	Direction	How
Legacy payment system (C++, on-prem, file-only)	Out, monthly	Function writes file + manifest to an immutable container; Arc-enabled agent pulls, verifies, delivers, writes a receipt
Microsoft Entra ID	In	OIDC sign-in, app roles; later, HR-driven provisioning
Microsoft Graph (email)	Out	Notifications from a shared mailbox, managed identity, restricted by application access policy
Defender for Storage	In	Malware verdicts via Event Grid

The payment system can’t call us or return errors, so I designed for verification: what was approved is snapshotted, the file is checksummed, delivery is confirmed by a receipt, and a missing receipt alerts days before payday. Pull, not push, so nothing in Azure needs a route into the server farm.

TODO: The payment system’s file specification and a sample file.

Deeper: External systems

• File rendering: a pure function LegacyPayrollFormat.Render(run) returning the bytes and a manifest; no I/O, so it’s golden-file testable.
• Writer Function: queue trigger, checks status, writes once (see snippet in the playbook).
• Pickup agent: a .NET console app run by a scheduled task; Azure.Identity’s ManagedIdentityCredential works with Azure Arc, so it authenticates without a secret.
• Receipt: a small JSON blob { runId, sha256, pickedUpAt, host }.

var credential = new ManagedIdentityCredential();      // Azure Arc on the payment server
var container = new BlobContainerClient(new Uri(outboundUri), credential);
await foreach (var blob in container.GetBlobsAsync(prefix: period))
    if (blob.Name.EndsWith(".dat") && !await ReceiptExistsAsync(blob.Name)) await PullAndVerifyAsync(blob);

Deeper: Integration development

How do you handle rate limits, retries and partial failures from external APIs?

The integrations here aren’t rate-limited APIs, so I’d reframe: the failure modes are a file not written, not picked up, corrupted, or picked up twice.

Failure	Handling
Function fails writing	Queue retry with backoff (5 attempts), then poison queue → Sev 2 alert
Agent offline	No receipt → Sev 1 alert after 4 hours; runbook has a manual fallback
Corrupted / tampered file	Agent’s SHA-256 check fails → quarantined, never delivered
Picked up twice	Agent skips files with a receipt; the payment system never sees duplicates
Partial file	Written as one blob upload; the manifest is written after, so a file without a manifest is ignored

For the real API calls we do make (Graph email), the Azure SDK’s retry policy handles 429s and 5xx with exponential backoff, and the outbox keeps unsent messages until they succeed.

Deeper: Payroll run

• Queue retries: host.json maxDequeueCount: 5, visibility timeout with backoff.
• SDK retries: BlobClientOptions.Retry (exponential, max 5) and Graph’s built-in retry handler for 429 with Retry-After.
• Which errors to retry: transient (timeouts, 5xx, 429) yes; 4xx validation or “run not approved” no, log and stop.
• Ordering: manifest uploaded after the data file, so the agent only acts on complete pairs.

{ "version": "2.0", "extensions": { "queues": { "maxDequeueCount": 5, "visibilityTimeout": "00:00:30" } } }

Deeper: Event and messaging contracts

The payroll path gets the strictest alerting in the system, because its SLO is 100%:

Signal	Alert
Run approved, no file after 1 h	Sev 1
File written, no receipt after 4 h	Sev 1
Poison message on payroll-approved	Sev 2
Agent heartbeat missing in the payroll window	Sev 2

customEvents | where name in ("PayrollFileWritten", "PayrollReceiptReceived")
| summarize written=maxif(timestamp, name=="PayrollFileWritten"), received=maxif(timestamp, name=="PayrollReceiptReceived") by tostring(customDimensions.runId)
| where isnotempty(written) and (isempty(received) or received < written) and written < ago(4h)

TODO: Is there a manual fallback for delivering the file if the agent can’t run?

Deeper: Operational runbooks

How are scheduled and background jobs designed and coordinated?

All scheduled and background work lives in one Functions app, separate from the API, so slot swaps can’t run jobs twice and jobs don’t compete with user requests. Each job is idempotent and keyed by a natural ID (payroll period, run ID, document ID), which is what makes retries safe.

Coordination is by state in SQL, not by job chaining: the timer creates a draft run for the period if none exists; approval is a human step in the UI; approval enqueues the write; the receipt event marks delivery. A job that finds the state isn’t what it expects logs and exits. No orchestrator (Durable Functions) is needed, because the human approval in the middle is already the coordinator.

Deeper: Backend structure

• Timer triggers with NCRONTAB: "0 0 6 * * *" daily at 06:00 UTC, checking “is today cutoff?” in code (cutoff dates depend on working days, which CRON can’t express).
• Queue trigger for the file writer; Event Grid triggers for receipts and scan results.
• Idempotency keys: unique index on PayrollRun(Period) so a second draft insert fails cleanly.
• Testing: job logic lives in application services, so tests call CreateDraftIfCutoffTodayAsync with a FakeTimeProvider.

public async Task CreateDraftIfCutoffTodayAsync(CancellationToken ct)
{
    var today = DateOnly.FromDateTime(time.GetLocalNow().Date);
    if (!calendar.IsCutoff(today)) return;
    if (await db.Runs.AnyAsync(r => r.Period == calendar.PeriodFor(today), ct)) return;   // idempotent
    db.Runs.Add(PayrollRun.Draft(calendar.PeriodFor(today), await snapshot.TakeAsync(ct)));
    await db.SaveChangesAsync(ct);
}

Deeper: Unit testing

• Functions app on Flex Consumption with VNet integration, deployed after the API swap.
• Timer schedule and app settings from Bicep; WEBSITE_TIME_ZONE isn’t supported on Flex Consumption, so schedules are UTC and the code converts.
• Queues and Event Grid system topics plus subscriptions defined in Bicep.
• To run a job by hand (for a runbook), an admin-only HTTP-triggered wrapper or the Functions admin API.

az functionapp function show -g rg-dunderly-hr-prod -n func-dunderly-hr-prod --function-name CreatePayrollRun
az storage message put --queue-name payroll-approved --content '{"runId":41,"period":"2027-03"}' --account-name <acct> --auth-mode login

The gotcha: the pickup agent is outside this pipeline. Its versions are tracked in the repo, but installing it is an IT change on their server.

Deeper: Deployment instructions

Security and Identity

How do users authenticate, and how is authorization enforced?

Authentication: Microsoft Entra ID only. The SPA uses authorization code flow with PKCE via MSAL; the API validates JWTs. Conditional Access requires MFA for everyone and a compliant device for HR, payroll and auditor roles. No local accounts or passwords in the HR database.

Authorization, in two layers that must both pass:

1. Role (Entra app roles via groups): Employee, Manager, HR.Admin, HR.Manager, Payroll.Operator, Auditor.
2. Data scope in the API: a manager acts only on their direct reports (from ManagerId in the HR data); an employee sees only themselves.

Plus separation of duties in code: nobody approves their own salary request or a payroll run they prepared. An authorization matrix test covers every endpoint × role.

Deeper: Authentication and authorization

• AddMicrosoftIdentityWebApiAuthentication validates issuer, audience and signature.
• App roles arrive in the roles claim; RequireRole("HR.Manager") on endpoint groups.
• Data scope in code via IReportingLine.IsDirectManagerAsync(caller, employeeId).
• user.GetObjectId() (the oid claim) is the stable identity stored in audit records, not the email.
• On the client, AuthorizeView only hides UI; it is never the control.

api.MapGroup("/payroll-runs").RequireAuthorization(p => p.RequireRole("Payroll.Operator", "HR.Manager"));

# inspect a token's roles during development
az account get-access-token --scope api://<api-client-id>/HR.Access --query accessToken -o tsv | cut -d. -f2 | base64 -d 2>/dev/null

Deeper: Identity

• App registrations (dunderly-hr-web, dunderly-hr-api) and app roles defined as code (Microsoft Graph Bicep extension or a script in the repo), per environment.
• Role assignment to groups, not users; group membership owned by HR via access reviews.
• Conditional Access policies owned by the tenant admins; documented in the repo.
• Workload identities: system-assigned managed identities, role assignments in Bicep.

az ad app show --id <api-client-id> --query "appRoles[].{role:value,enabled:isEnabled}" -o table
az role assignment list --assignee <api-principal-id> --all -o table

Deeper: Access reviews

How are secrets and credentials managed?

By not having them. Every workload uses a managed identity: the API and Functions to SQL (Entra-only auth), storage, queues and Key Vault; the on-premises agent through an Azure Arc managed identity; GitHub Actions through OIDC federated credentials. Email goes through Graph with the Functions app’s identity, restricted by an application access policy to one mailbox.

What’s left goes in Key Vault (RBAC mode, private endpoint), referenced from app settings. The one credential I couldn’t remove is the Static Web Apps deployment token, kept as a GitHub environment secret and rotated yearly.

TODO: Does Dunderly’s policy require customer-managed keys for HR data? That would add key rotation as an operational task.

Deeper: Secrets and key management

• DefaultAzureCredential locally (my developer login) and ManagedIdentityCredential in Azure, through the Azure SDK clients registered with AddAzureClients.
• SQL connection string has no password: Authentication=Active Directory Default.
• Options bound from configuration with ValidateOnStart; Key Vault references resolve before the app sees them.
• Secret scanning with push protection stops accidental commits.

builder.Services.AddAzureClients(c =>
{
    c.AddBlobServiceClient(new Uri(builder.Configuration["Storage:DocumentsUri"]!));
    c.AddQueueServiceClient(new Uri(builder.Configuration["Storage:QueuesUri"]!));
    c.UseCredential(new DefaultAzureCredential());
});

Deeper: Environment configuration

permissions: { id-token: write, contents: read }
steps:
  - uses: azure/login@v2
    with:
      client-id: ${{ vars.AZURE_CLIENT_ID }}
      tenant-id: ${{ vars.AZURE_TENANT_ID }}
      subscription-id: ${{ vars.AZURE_SUBSCRIPTION_ID }}

• One federated credential per GitHub environment (repo:<org>/dunderly-hr:environment:prod), so only the prod environment’s jobs can get a prod token.
• Key Vault references in app settings: @Microsoft.KeyVault(SecretUri=https://<vault>.vault.azure.net/secrets/<name>).
• No Azure secrets in GitHub; the variables above are IDs, not secrets.

az ad app federated-credential list --id <deploy-app-id> -o table

Deeper: Configuration and secrets

How is sensitive data protected, and which compliance constraints applied?

The data is personal and some of it is highly confidential (salary, payroll, documents, sick leave). Under assumption A2 (EU employees, GDPR):

• Classification per data set decides where it may appear; salary never in emails, notifications or logs.
• Encryption: TDE and storage encryption at rest (AES-256), TLS 1.2+ in transit, SHA-256 integrity on payroll files.
• Access: roles plus reporting line; quarterly access reviews on sensitive groups.
• Network: private endpoints; public access disabled on SQL and Key Vault.
• Privacy: minimisation (possibly no bank data at all), retention enforced by a job, DPIA before go-live, data kept in EU regions.
• Audit: append-only audit table, temporal history, SQL auditing.

TODO: Which national employment laws and retention periods apply, and who is the DPO?

Deeper: Privacy

Enforced by Azure Policy rather than by hoping:

• Allowed regions: West Europe and North Europe.
• Deny public network access on SQL and Key Vault; require TLS 1.2; deny shared key access on storage.
• Require diagnostic settings to the Log Analytics workspace.
• Defender for Cloud (CSPM) and Defender for Storage malware scanning.

az policy state summarize --resource-group rg-dunderly-hr-prod
az sql server show -g rg-dunderly-hr-prod -n sql-dunderly-hr-prod --query publicNetworkAccess

Deeper: Policy enforcement

Which threats did you design against?

A STRIDE pass over the system, with two threats specific to HR:

Threat	Control
Insider browsing salaries via the API	Role + reporting-line check on every call; authorization matrix tests
Manager approving their own raise	Four-eyes rule in code
Phished HR manager account	MFA, compliant-device Conditional Access
Payroll file tampered between Azure and on-prem	SHA-256 manifest, immutable container, agent verification
Malicious upload into HR	Type allow-list, magic bytes, quarantine, Defender scan
“I never approved that”	Append-only audit with Entra object IDs
Scripted API abuse	Rate limiting; not mission critical

What I’d say openly: there’s no WAF in v1 (ADR-004). The trade-off is cost against an SSO-only internal app, with explicit triggers to add Front Door WAF.

Deeper: Threat modeling

• Broken object-level authorization is the top risk in an HR API: every endpoint with {id} checks the caller’s scope, and the matrix test proves it.
• Injection: EF Core parameterizes; raw SQL only via FromSql with interpolation.
• Uploads: magic bytes, size, random names, Content-Disposition: attachment on download.
• Mass assignment: DTOs per command; never bind to entities.
• Rate limiting: AddRateLimiter with a per-user fixed window.

builder.Services.AddRateLimiter(o => o.AddPolicy("per-user", ctx =>
    RateLimitPartition.GetFixedWindowLimiter(ctx.User.GetObjectId().ToString(),
        _ => new FixedWindowRateLimiterOptions { PermitLimit = 120, Window = TimeSpan.FromMinutes(1) })));

Deeper: Input validation, API Security

The pipeline’s part of threat defence:

• CodeQL, dependency review, secret scanning with push protection on every PR.
• OWASP ZAP baseline against test on every deploy.
• No standing admin: PIM for Azure roles; deploys only through OIDC from main.
• Branch protection plus CODEOWNERS so payroll code needs a payroll reviewer: a supply-chain control against one person changing how money is calculated.
• Resource locks on prod.

docker run --rm -t ghcr.io/zaproxy/zaproxy:stable zap-baseline.py -t https://hr-api-test.<company domain>/health

Deeper: Static analysis

Performance and Scalability

What load does the system handle, where are the bottlenecks, and how does it scale?

The case study’s numbers: 10 concurrent users, 250 employees growing to 500, ~1 MB of records and ~50 MB of documents per employee. That’s a small load; I’d say so plainly in an interview rather than invent scale.

Possible bottleneck	Why it’s fine	What would show it
SQL vCores	Serverless max 2 handles month-end reports	CPU %, query duration
API instance	P0v3, autoscale 1 → 2 on CPU > 70%	CPU, p95
Document downloads	5 MB streamed through the API	Response time on download endpoints
First load of the WASM app	Lazy loading of HR sections	Page view duration on phones

Scaling is “change a SKU” in Bicep. The tested headroom is 50 concurrent users, 5× the stated load.

Deeper: Scalability

• Golden signals: traffic (requests/min), latency (p95 per endpoint group), errors (5xx and dependency failures), saturation (App Service CPU and memory, SQL app CPU billed).
• Capacity is mostly a cost question here; budget alerts are the saturation signal for money.
• Autoscale rule: scale out at 70% CPU for 10 minutes, in at 30% for 20 minutes, min 1, max 2.

az monitor autoscale show -g rg-dunderly-hr-prod -n autoscale-hr-api --query "profiles[0].capacity"
az monitor metrics list --resource <sql-db-id> --metric app_cpu_percent --interval PT15M

Deeper: Capacity and cost monitoring

How would the design change at ten times the users or data?

At 5,000 employees and 100 concurrent users, honestly, very little changes:

• SKUs: App Service to P1v3 with 2 to 3 instances; SQL serverless max 4 to 8 vCores.
• Reporting: a read replica or a reporting view refreshed nightly, so reports don’t compete with writes.
• Documents: ~250 GB; still Blob, lifecycle to cool tier matters more.
• Payroll: 5,000 lines is still a small file; the Function might need streaming writes.
• Resilience: at that size the business probably calls it more critical, so zone redundancy (P1v3+, SQL zone-redundant) becomes worth it.

What wouldn’t change: the modular monolith. Ten times the users doesn’t create a reason to split it. Ten times the teams might.

Deeper: Architecture reviews

All parameterized in the .bicepparam files, so it’s a PR:

param appServiceSku = 'P1v3'
param apiMinInstances = 2
param apiMaxInstances = 3
param sqlMaxVCores = 8
param zoneRedundant = true

• Zone redundancy needs the right SKUs and at least 2 to 3 instances; check regional support first.
• Re-run the k6 load test with the new targets before and after.
• Re-price in the calculator and update the budget alert.

az deployment sub what-if -l westeurope -f infra/main.bicep -p infra/env/prod.bicepparam

Deeper: Capacity and quota planning

• Re-baseline SLOs: at 100 concurrent users, latency SLOs per endpoint group make more sense than one global p95.
• Add saturation alerts (SQL CPU sustained > 80%, connection count) that don’t matter today.
• Load-test the Monday 9 am peak and month end at the new size.
• Revisit RTO/RPO with the business; a bigger company may not accept a business day of downtime.

k6 run -e USERS=100 -e DURATION=30m tests/load/monday-peak.js

Deeper: Performance and load testing

How did you measure and improve performance?

I’d measure first and keep the bar honest: p95 < 500 ms for API calls and first page load under 3 s (both assumptions until agreed).

1. Baseline with k6 in test: a normal day (10 users), a Monday peak (50), a month-end payroll draft for 500 synthetic employees.
2. Find the slowest endpoints from Application Insights and the slowest queries from Query Store.
3. Fix the cause: missing index, N+1, over-fetching, an un-lazy-loaded WASM assembly.
4. Re-measure, and stop when the SLO is met with headroom.

There’s no recorded performance improvement yet, because nothing has run; this is the method I’d follow and the numbers I’d hold it to.

Deeper: Performance optimization

• N+1: listing employees with their manager name → one query with a projection, not lazy loading.
• AsNoTracking for read paths; projections to DTOs.
• Indexes from the access patterns: (EmployeeId, EffectiveFrom) on salary records, (EmployeeId, Year) on leave.
• Streaming downloads with Results.Stream(blobStream, contentType) instead of buffering 5 MB in memory.
• Blazor: @key, Virtualize, lazy-loaded assemblies.

var rows = await db.Employees.AsNoTracking()
    .Select(e => new EmployeeRow(e.EmployeeId, e.FirstName, e.LastName, e.Manager!.LastName))
    .ToListAsync(ct);   // one SQL statement with a join

dotnet-counters monitor -n Dunderly.Hr.Api System.Runtime Microsoft.AspNetCore.Hosting

Deeper: API and UI implementation

requests | where timestamp > ago(7d) and name !has "documents"
| summarize p95=percentile(duration,95), n=count() by name
| top 10 by p95 desc

• Track p95 per endpoint week over week on the engineering workbook.
• Query Store top queries by duration after each release.
• k6 results stored with each release so regressions are visible.
• An error budget: if latency burns it, the next sprint spends time on performance.

The honest gap: the 500 ms target and the 50-user test are mine, not agreed with the business.

Deeper: Metrics and dashboards

Reliability and Resilience

What are the failure modes, and how does the system degrade when a part fails?

Failure	User impact	Degradation
One API instance restarts	Seconds of errors	Second instance during scale-out; reads retried
SQL transient fault or scaling	A failed request	EF Core retry
Blob unavailable	No document upload/download	Rest of the app works; uploads fail clearly
Defender scan delayed	Documents stay “pending”	Visible status; alert after an hour
Graph email down	Notifications late	Outbox keeps them; sent when it recovers
Functions failing	No payroll file	Queue retries, poison queue, Sev 1 alert
Pickup agent offline	File not delivered	Missing-receipt alert days before payday
Region outage	System down	Rebuild in North Europe within a business day

The design principle: the web app may degrade or go down for hours; the payroll path must never fail silently. Most failures are contained to one feature because the dependencies are separate services.

Deeper: Resilience

• Health checks split by purpose: /health/live (process only, so SQL trouble doesn’t make App Service churn instances), /health/ready (dependencies), /health for the availability test.
• Timeouts and retries: SQL retry with backoff; SDK retries for Blob, queues and Graph; no retry on 4xx.
• No circuit breaker today: at this traffic, retries with backoff are enough; Polly’s circuit breaker via AddStandardResilienceHandler is ready if an outbound HTTP dependency appears.
• Graceful degradation in the UI: document features show “temporarily unavailable” instead of breaking the page.

curl -s https://hr-api.<company domain>/health/ready
az webapp log tail -g rg-dunderly-hr-prod -n app-dunderly-hr-api-prod

Deeper: Health checks

What are the availability and recovery targets, and how are backup and disaster recovery handled?

Assumption: Availability 99.5% in business hours, RTO one business day, RPO 15 minutes (assumption A7). The case study only said “not very critical”.

• Backup: SQL automatic backups (PITR 35 days, LTR, geo-redundant); Blob versioning, soft delete, GRS; immutable payroll containers.
• DR: rebuild compute in North Europe from Bicep, geo-restore SQL, repoint DNS. No warm standby: for a one-day RTO it would double the cost for little benefit.
• The RPO tension: geo-restore gives up to about an hour of possible loss for a regional outage. If 15 minutes is firm, an auto-failover group is the answer.

TODO: Confirm RTO/RPO with the sponsor, especially whether 15 minutes is firm.

Deeper: Backup and restore

DR is a pipeline run with a different parameter file, rehearsed yearly:

az deployment sub create -l northeurope -f infra/main.bicep -p infra/env/dr.bicepparam
az sql db geo-backup restore --dest-database sqldb-hr --dest-server sql-dunderly-hr-dr -g rg-dunderly-hr-dr \
  --geo-backup-id <recoverable-database-id>

Then redeploy the current release artifacts to the DR app names, update DNS CNAMEs, and switch the pickup agent’s container URI (a config value on the agent).

The first drill will find something hard-coded to West Europe. That’s what drills are for.

Deeper: Disaster recovery testing

Target	Value	How it’s measured
Availability	99.5% business hours	Availability test success rate
RTO	1 business day	Timed in the yearly DR drill
RPO	15 min (to confirm)	PITR granularity; geo-restore is looser
Payroll SLO	100% confirmed before cutoff + 1 day	Receipt events

The measured RTO comes from the quarterly restore tests and the DR drill, not from the design document; the runbook records how long each one took.

availabilityResults | where timestamp > ago(30d)
| summarize availability = 100.0 * countif(success == true) / count()

Deeper: Availability targets

How do you make jobs and deployments safe to retry?

Jobs and deployments are safe to retry because each is either idempotent or a state transition that refuses to happen twice:

Thing	Why a retry is safe
Payroll file write	Keyed by run ID; immutable container; exits if the file exists
Draft payroll run	Unique index on period
Notifications	Outbox rows marked sent
Document promotion	Moves by document ID; second attempt finds it already promoted
Migration tool	Upserts by employee number
EF migrations	Bundle applies only pending migrations
Bicep	Declarative; re-running converges
API deploy	Same artifact to the slot; swap is reversible

Deeper: Input safety

• Natural keys for idempotency: PayrollRun.Period unique, file name from run ID.
• Conditional writes: BlobUploadOptions { Conditions = new BlobRequestConditions { IfNoneMatch = ETag.All } } so a concurrent second write fails rather than overwrites.
• Status checks at the start of every job: “is the run Approved and without a file?”

try
{
    await blob.UploadAsync(content, new BlobUploadOptions { Conditions = new() { IfNoneMatch = ETag.All } }, ct);
}
catch (RequestFailedException e) when (e.Status == 409)
{
    log.LogInformation("Run {RunId} file already exists; nothing to do", run.Id);
}

Deeper: Integration development

• Build once, deploy the same artifact: re-running a deploy job is harmless.
• Bicep is declarative: re-running converges; what-if shows the delta first.
• Migration bundle applies pending migrations only, so a re-run after success does nothing.
• Slot swap is reversible; re-running a failed swap is safe.
• GitHub environments with concurrency groups so two prod deploys can’t overlap.

concurrency: { group: deploy-${{ inputs.environment }}, cancel-in-progress: false }

Deeper: Rollback

Testing and Quality

What is your testing strategy across the frontend, backend and data?

Lopsided on purpose: thorough where a bug moves money or exposes data, pragmatic elsewhere.

Layer	What	Why
Unit	Salary, leave and payroll rules with FakeTimeProvider	Where money is decided
Integration	API + real SQL (Testcontainers) + Azurite	Migrations, temporal tables, grants as deployed
Authorization matrix	Every endpoint × role	The top HR risk is data exposure
Contract	OpenAPI client generation; payroll golden files	The two contracts that matter
E2E	Five Playwright journeys with axe	The flows users depend on
Performance	k6: normal day, Monday peak, month end	Headroom, not scale
UAT + parallel run	One real payroll month in both systems	The real acceptance test

Frontend logic is thin (the API enforces the rules), so Blazor components get bUnit tests only where they have logic, plus E2E.

Deeper: Quality Assurance

public class AuthorizationMatrix(ApiFactory api) : IClassFixture<ApiFactory>
{
    public static TheoryData<string, string, string, int> Cases => MatrixLoader.From("authz-matrix.csv");

    [Theory, MemberData(nameof(Cases))]
    public async Task Endpoint_enforces_role(string method, string path, string role, int expected)
    {
        var client = api.CreateClientAs(role, objectId: TestUsers.For(role));
        var res = await client.SendAsync(new HttpRequestMessage(new HttpMethod(method), path));
        ((int)res.StatusCode).Should().Be(expected);
    }
}

• xUnit + FluentAssertions; Testcontainers for SQL; WebApplicationFactory with a test auth handler.
• bUnit for components with logic (the leave day counter).
• Bogus for synthetic data.

dotnet test --filter "Category!=E2E"

Deeper: Integration testing

How do you test integrations with external systems?

The payment system can’t be called and may not have a test instance, so the strategy is layered:

1. Golden files: known payroll runs rendered and compared byte for byte with samples approved by the payment system’s owner. This is the contract test.
2. Agent tests against Azurite and a fake input folder: checksum mismatch, duplicate file, missing manifest.
3. End-to-end in test with the payment system’s test instance, if one exists; otherwise the owner checks sample files manually.
4. Parallel run: one real month in both systems, compared line by line.

TODO: Does the payment system have a test instance?

For Entra ID and Graph: real dev-tenant app registrations in test, fakes in unit tests.

Deeper: Contract testing

[Fact]
public async Task March_run_matches_approved_golden_file()
{
    var run = GoldenRuns.March2027();                         // 12 employees: joiner, leaver, unpaid leave
    var (content, manifest) = LegacyPayrollFormat.Render(run);
    content.Should().Equal(await File.ReadAllBytesAsync("Golden/payroll-2027-03.dat"));
    manifest.RecordCount.Should().Be(12);
}

• Golden files live in tests/Payroll/Golden/, owned by payroll-reviewers in CODEOWNERS.
• Changing one requires the payment system owner’s sign-off recorded in the PR.
• Edge cases each get a golden run: mid-month joiner, leaver, unpaid leave, salary change effective mid-period.

The gotcha: encodings and line endings. A golden test catches a stray \r\n that a “looks the same” review never would.

Deeper: Integration development

• Azurite as a service container in CI for Blob and queues; SQL Server via Testcontainers.
• A test payroll storage account and a test pickup agent in the test environment, pointed at the payment system’s test instance or a stub folder.
• Golden-file tests run on every PR; the agent integration test runs on deploy to test.

services:
  azurite:
    image: mcr.microsoft.com/azure-storage/azurite
    ports: ["10000:10000", "10001:10001"]

docker run -d -p 10000:10000 -p 10001:10001 mcr.microsoft.com/azure-storage/azurite

Deeper: Test environment

Which quality gates does code pass before it merges and ships?

Gate	Blocks
Build, analyzers as errors, dotnet format	Merge
Unit, integration, authorization matrix, architecture tests, golden files	Merge
CodeQL, dependency review, secret scanning	Merge
Bicep lint and what-if	Merge (review)
One review; two for payroll paths	Merge
E2E + axe, ZAP baseline in test	Promotion to prod
Named reviewer; payroll-freeze check	Prod deploy
Smoke tests on the staging slot	Swap

The gate I’d point to as specific to this system is the second reviewer on payroll code: it’s a control against one person changing how money is calculated.

Deeper: Approval gates

In practice, before I push:

dotnet format --verify-no-changes
dotnet build -warnaserror
dotnet test --filter "Category!=E2E"
dotnet list package --vulnerable --include-transitive

And the reviewer checklist I’d expect my PR to pass: rule tested at the edges, role and data scope checked, audit event for every write, migration expand-only, no personal data in logs, docs updated. PRs over about 400 lines get split.

Deeper: Code reviews

• Branch protection: required checks, one review, linear history, no force push.
• CODEOWNERS: payroll paths need payroll-reviewers; infra/ needs devops.
• GitHub environment prod: required reviewer, deploy only from main.
• A freeze check job that reads payroll cutoff dates and fails prod deploys in the window unless labelled payroll-fix.

gh api repos/<org>/dunderly-hr/branches/main/protection --jq '.required_status_checks.contexts'

Deeper: Development workflow

Infrastructure and Environments

Where and how is the application hosted, and why there?

Azure PaaS in West Europe (assumption A1, as in the 2023 estimate), DR in North Europe:

Piece	Service	Why
Web	Static Web Apps Standard	Static files, previews
API	App Service Linux P0v3	Slots, VNet integration, one plan
Jobs	Functions Flex Consumption	Event and schedule driven, scale to zero
Data	Azure SQL serverless, Blob GRS	Pay per use; documents out of the DB
On-prem	Arc-enabled server running the agent	Next to the payment system

Why PaaS and not containers or VMs: no team need, no scale need, and every hour not spent patching servers goes to the HR domain. Why EU regions: employee data (assumption A2, GDPR).

Deeper: Hosting

az resource list -g rg-dunderly-hr-prod --query "[].{name:name,type:type}" -o table

• Resource groups: rg-dunderly-hr-{dev,test,prod} plus rg-dunderly-hr-shared (Log Analytics, action groups).
• VNet per environment: snet-app (delegated, VNet integration) and snet-pe (private endpoints) with private DNS zones.
• Prod resource group lock CanNotDelete.
• Tags app, env, owner on everything for cost reports.

Deeper: Production environment

From a reliability view, the hosting gives me:

• App Service health check replaces unhealthy instances; autoscale 1 → 2.
• Platform-managed patching (no OS to patch), so maintenance shows up as brief instance restarts, covered by the second instance or retries.
• A single region: an accepted risk given the one-business-day RTO, with a rehearsed rebuild.

The thing I’d watch: one instance most of the time means platform maintenance can cause short blips. If availability SLO burn shows it, min instances goes to 2.

az webapp show -g rg-dunderly-hr-prod -n app-dunderly-hr-api-prod --query "siteConfig.healthCheckPath"

Deeper: Resilience

Which environments exist, and how close is local development to production?

Three Azure environments plus local, and a deliberate absence:

Env	Purpose	Data
Local	Development with .NET Aspire (SQL container, Azurite)	Synthetic
Dev	Proves Bicep, identities, private networking	Synthetic
Test	E2E, performance, ZAP, UAT	Synthetic
Prod (+ staging slot)	Production; the slot is staging	Real

No separate staging environment: prod’s staging slot runs on production infrastructure and configuration, which is closer to prod than any copy. Test and prod come from the same Bicep with different parameter files.

The gap I’d admit: local uses containers instead of PaaS and can’t run Defender scanning, so dev and test catch what local can’t.

Deeper: Environment parity

git clone <repo-url>/dunderly-hr && cd dunderly-hr
dotnet tool restore
dotnet run --project src/Dunderly.Hr.AppHost

• .NET Aspire AppHost starts SQL Server and Azurite containers, the API, Functions and the Blazor app, and wires connection strings; its dashboard shows logs and traces.
• Seed data: a fake company of 50 employees on startup in Development.
• Auth: a dev Entra app registration with test users per role, so authorization runs for real.
• Fakes: a dev-only scanner marks uploads clean after two seconds.

var sql = builder.AddSqlServer("sql").AddDatabase("hr");
var storage = builder.AddAzureStorage("storage").RunAsEmulator();
builder.AddProject<Projects.Dunderly_Hr_Api>("api").WithReference(sql).WithReference(storage.AddBlobs("blobs"));

Deeper: Local development

Setting	Dev	Test	Prod
App Service	B1, no slots	P0v3 + slot	P0v3 + slot, 1–2
SQL max vCores / auto-pause	1 / 60 min	2 / 60 min	2 / off
Storage	LRS	LRS	GRS
Defender scanning	Off	On	On

Everything else (network, identities, role assignments, diagnostics, policy) is identical, and the parameter files are short enough to diff by eye.

diff infra/env/test.bicepparam infra/env/prod.bicepparam

Deeper: Test environment

How is the infrastructure provisioned and configured?

Bicep with Azure Verified Modules (ADR-009), applied only by the pipeline, with what-if on every PR and a weekly drift check. The 2023 design was configured in the portal (access restrictions, firewall rules set by hand); infrastructure as code is what makes the three environments match and DR possible.

Why Bicep over Terraform: an Azure-only estate run by a .NET team, no state file to protect, and new Azure features available immediately. Terraform would be an equally valid choice if Dunderly already used it.

Configuration (app settings, flags) is a Bicep output, so code and infrastructure agree per environment.

Deeper: Infrastructure as code

infra/
├── main.bicep          # subscription scope: RG + modules
├── modules/            # network, data, app, functions, monitoring (AVM wrappers)
└── env/{dev,test,prod}.bicepparam

az bicep lint --file infra/main.bicep
az deployment sub what-if  -l westeurope -f infra/main.bicep -p infra/env/prod.bicepparam
az deployment sub create   -l westeurope -f infra/main.bicep -p infra/env/prod.bicepparam

• AVM modules pinned to versions in the br/public:avm/... references.
• Role assignments and private DNS zone links in Bicep, so a rebuild has the same permissions.
• SQL contained users via a deployment script (needs Entra auth to the database).

The gotcha: app registrations live in Entra, not ARM, so they need the Graph Bicep extension or a script, and tenant-level permissions the pipeline shouldn’t have in prod.

Deeper: Database and infrastructure implementation

CI/CD and Deployment

Walk me through the pipeline from commit to production.

The animated pipeline is in the playbook; the shape:

1. PR: build, unit and integration tests, authorization matrix, golden files, CodeQL, dependency and secret scanning, Bicep what-if, a Static Web Apps preview for HR to click through.
2. Merge to main: build once (API and Functions zips, Blazor bundle, migration bundle), versioned.
3. Dev: Bicep, migrations, deploy.
4. Test: same artifacts; Playwright E2E with axe, ZAP baseline; UAT on release candidates.
5. Prod approval: named reviewer; blocked in payroll week unless it’s a payroll fix.
6. Prod: Bicep → migrations → API to staging slot → smoke tests → swap → Functions → web.

The principle: what reaches prod is byte-for-byte what test approved.

Deeper: CI/CD pipeline

jobs:
  build:   { uses: ./.github/workflows/build.yml }
  dev:     { needs: build, uses: ./.github/workflows/deploy.yml, with: { environment: dev } }
  test:    { needs: dev,   uses: ./.github/workflows/deploy.yml, with: { environment: test, e2e: true } }
  prod:    { needs: test,  uses: ./.github/workflows/deploy.yml, with: { environment: prod, slot: staging } }

• Reusable deploy.yml with OIDC login, Bicep, efbundle, zip deploy, smoke, swap.
• Artifacts uploaded once in build, downloaded by each deploy job.
• prod is a GitHub environment with a required reviewer and a main-only branch rule.

gh run list --workflow release.yml --limit 5
gh run watch

Deeper: Deployment automation

Which deployment strategy do you use, and how do you roll back?

Blue-green via App Service deployment slots. The new build goes to the staging slot, warms up, passes smoke tests, then swaps into production. Rolling back is swapping again: the previous build is still in the slot, so it takes minutes.

What makes it safe is the database rule: migrations run first and are expand-only, so both versions work against the schema during and after the swap.

Situation	Action
Smoke fails	Don’t swap; fix forward
Problem after swap	Swap back
Bad Functions or web deploy	Redeploy the previous artifact
Bad data change	PITR to a new database, repair

Default is roll forward unless users are being hurt right now.

Deeper: Rollback and roll-forward

az webapp deployment source config-zip -g rg-dunderly-hr-prod -n app-dunderly-hr-api-prod --slot staging --src artifacts/api.zip
curl -fsS https://app-dunderly-hr-api-prod-staging.azurewebsites.net/health/ready
az webapp deployment slot swap -g rg-dunderly-hr-prod -n app-dunderly-hr-api-prod --slot staging --target-slot production
# rollback
az webapp deployment slot swap -g rg-dunderly-hr-prod -n app-dunderly-hr-api-prod --slot staging --target-slot production

• Slot-sticky settings (Hr__IsStagingSlot) stay with the slot so the waiting build doesn’t run once-only work.
• App Service’s swap warm-up hits applicationInitialization paths before the swap completes.
• Functions on Flex Consumption have no slots, so they deploy after the swap; jobs are idempotent.

Deeper: Staging environment

• Watch after every swap for 30 minutes: 5xx rate, p95, exceptions by version (the build version is a telemetry dimension).
• Swap back if the 5xx alert fires within that window, before diagnosing.
• Release timing: Tuesday to Thursday mornings, never Friday afternoon, never in payroll week.

requests | where timestamp > ago(1h)
| summarize failures=countif(success == false), total=count() by application_Version, bin(timestamp, 5m)

Deeper: Release calendar

How do data and schema changes ship alongside application changes?

Migrations ship in the same release as the code, but run before it, and only expand. A destructive change takes two releases: N stops using a column, N+1 drops it. That’s the whole strategy, and it’s what lets the slot swap and swap-back work without schema rollbacks.

Data changes (backfills) are small, idempotent migrations or a one-off tool, never manual SQL in prod. The pipeline records a timestamp before migrating so point-in-time restore has a clean target.

Payroll-impacting changes get a re-render of the last three months’ approved runs, compared with what was sent: they must be identical.

Deeper: Database deployment strategy

A two-step column rename, as I’d actually do it:

1. Release N: add PreferredName, write both columns, read the new one with fallback.
2. Backfill in the same migration: UPDATE … SET PreferredName = KnownAs WHERE PreferredName IS NULL.
3. Release N+1: stop writing KnownAs, then drop it.

protected override void Up(MigrationBuilder mb)
{
    mb.AddColumn<string>("PreferredName", schema: "employees", table: "Employee", maxLength: 100, nullable: true);
    mb.Sql("UPDATE employees.Employee SET PreferredName = KnownAs WHERE PreferredName IS NULL");
}

The gotcha: EF will happily scaffold a rename as drop + add. Always read the generated migration.

Deeper: Schema and migrations

dotnet ef migrations bundle --project src/Dunderly.Hr.Api --self-contained -r linux-x64 -o artifacts/efbundle
./artifacts/efbundle --connection "$SQL_CONN"     # Active Directory Default auth, pipeline identity

• The pipeline identity is the only principal with DDL in prod; the API’s identity has DML only.
• The bundle runs before the slot deploy; a failure stops the release with prod untouched.
• The SQL firewall is closed, so the runner reaches SQL over the private endpoint (a self-hosted runner in the VNet or a deployment script inside Azure).

That last point is the real-world gotcha: GitHub-hosted runners can’t reach a private-only database.

Deeper: Database deployment strategy

How do you manage configuration and versions across environments?

• Configuration: layered .NET configuration; per-environment values are Bicep outputs written to app settings; secrets (few) are Key Vault references; feature flags in configuration.
• Versions: one semantic version for the whole system, stamped on every artifact and on telemetry; /api/v1 changes only for breaking API changes, which with one in-repo client should be never.
• Promotion: the same artifacts move through environments; only configuration differs.

This makes “what’s running in prod?” a one-line answer: a version, and a parameter file in git.

Deeper: Versioning

• IOptions<T> with ValidateDataAnnotations().ValidateOnStart() so a missing setting fails at startup.
• Microsoft.FeatureManagement: [FeatureGate("LeaveApprovalWorkflow")] on endpoints, <FeatureGate> in Blazor.
• Version from <Version> set by the pipeline (-p:Version=1.4.0), exposed via /health and as the telemetry application_Version.

builder.Services.AddOptions<StorageOptions>().BindConfiguration("Storage").ValidateDataAnnotations().ValidateOnStart();
builder.Services.AddFeatureManagement();

Deeper: Feature flags

dotnet publish src/Dunderly.Hr.Api -c Release -p:Version=$VERSION -o artifacts/api
az webapp config appsettings list -g rg-dunderly-hr-prod -n app-dunderly-hr-api-prod -o table

• Version: from the git tag on release, 0.0.0-<sha> otherwise; attached to the GitHub Release with artifacts.
• App settings come only from Bicep; a manual portal change is drift, caught by the weekly what-if.
• Feature flags per environment in the .bicepparam files, so turning one on in prod is a reviewed PR.

Deeper: Configuration and secret management

Monitoring and Observability

How do you know the system is healthy in production?

Three questions, three signals:

1. Can people use it? An availability test on /health from three locations, plus the 5xx rate.
2. Is it fast enough? p95 latency per endpoint group against 500 ms.
3. Will payroll land? The payroll workbook: run status, file written, picked up, receipt, days to payday.

The third is what makes this system’s observability different. CPU can be green while payroll is quietly failing, so payroll has its own events and its own Sev 1 alerts. All telemetry goes to Application Insights and Log Analytics through OpenTelemetry, which replaced the 2023 design’s custom logging service (ADR-006).

Deeper: Monitoring

All of it is Bicep:

• Workspace-based Application Insights per environment, one Log Analytics workspace in rg-dunderly-hr-shared.
• Diagnostic settings on every resource (SQL, storage, App Service, Key Vault, Functions).
• Standard availability test and metric/log alerts with action groups (Teams, email, SMS for Sev 1).
• Azure Monitor Agent with a data collection rule on the Arc-enabled payment server for the agent’s event log.

az monitor scheduled-query list -g rg-dunderly-hr-shared -o table
az monitor app-insights component show -g rg-dunderly-hr-prod -a appi-dunderly-hr-prod --query connectionString

Deeper: Monitoring and alert validation

SLI	SLO	Source
Availability (business hours)	99.5% / 30 days	availabilityResults
API p95	< 500 ms	requests
Payroll confirmed before cutoff + 1 day	100% monthly	customEvents (receipts)

Health endpoints split by purpose (live, ready, full), and every alert was fired on purpose in test before go-live, with someone confirming it arrived.

availabilityResults | where timestamp > ago(1d) | summarize success=avg(todouble(success)) by location

TODO: SLO agreement with the sponsor; the numbers above are proposals.

Deeper: Targets

What do you log, measure and alert on?

Log: structured events with correlation IDs; IDs only (EmployeeId, RunId), never names or salary amounts. Business audit (who changed what) goes to SQL, not telemetry, because it contains personal data and has a different retention.

Measure: request rate, latency and failures per endpoint group; SQL and Blob dependency health; custom metrics for salary decisions and payroll file duration; documents pending scan; queue and poison depth.

Alert on symptoms: availability, 5xx rate, payroll file not written (Sev 1), receipt missing (Sev 1), run not approved near the deadline, document stuck in scan, poison messages, budget. Every alert links to a runbook.

Deeper: Alerting and escalation

log.LogInformation("Salary request {RequestId} approved by {ApproverId}", req.Id, approver);   // no amount
SalaryDecisions.Add(1, new("outcome", "approved"));

• Message templates, never string interpolation, so properties are queryable.
• Correlation: OpenTelemetry propagates the trace through HTTP; for queues and the outbox I write the traceparent into the message and restore it in the Function.
• Personal data guard: a review rule plus a scheduled KQL check for email or currency patterns in traces.
• Custom meter Dunderly.Hr registered with AddMeter.

dotnet add src/Dunderly.Hr.Api package Azure.Monitor.OpenTelemetry.AspNetCore

Deeper: Logging and log retention

Alert design rules I’d hold to:

• Alert on what users or payroll feel; dashboards for everything else.
• Each alert has a severity, an owner and a runbook link, or it doesn’t exist.
• Business-hours alerts for the app; the payroll alerts page out of hours in payroll week.
• Monthly review: delete or tune any alert that fired without needing action.

traces | where timestamp > ago(1d)
| where message matches regex @"[\w.+-]+@[\w-]+\.\w+" or message matches regex @"\b\d{2,3}[,.]\d{3}\b"
| take 20      // personal-data leak check: should return nothing

Deeper: Reliability reviews

Walk me through how you would troubleshoot a production issue in this system.

Picture a manager reporting “I can’t approve leave” with an error screen. I’d go:

1. Scope: one user or everyone? Availability test and 5xx rate answer that in seconds.
2. Trace: the error screen shows a correlation ID → the end-to-end transaction in Application Insights.
3. Classify: 403 (role or reporting line, a data problem in HR), 409 (state changed), 5xx (our bug or a dependency).
4. Mitigate before root-causing if many are affected: swap back the last release, turn off a feature flag.
5. Fix and review: a test that would have caught it; a blameless review for Sev 1 and 2.

Most “bugs” in an HR system turn out to be data: a missing manager, an expired role. The troubleshooting guide starts there.

Deeper: Troubleshooting guides

az webapp log tail -g rg-dunderly-hr-prod -n app-dunderly-hr-api-prod
az monitor activity-log list -g rg-dunderly-hr-prod --offset 24h --query "[].{op:operationName.value,who:caller,when:eventTimestamp}" -o table
az webapp deployment slot swap -g rg-dunderly-hr-prod -n app-dunderly-hr-api-prod --slot staging --target-slot production

First question from the DevOps seat: what changed? The activity log shows infrastructure changes, GitHub shows the last deployment, and telemetry is split by application_Version. If the problem started with a release, swap back first.

Deeper: Rollback

exceptions | where timestamp > ago(2h)
| summarize count() by type, outerMessage, application_Version | order by count_ desc

dependencies | where timestamp > ago(2h) and success == false
| summarize count() by target, resultCode

My order: user impact → recent changes → errors by version → dependency failures → resource saturation. For a payroll alert, the order is different: run status in SQL → Function executions and poison queue → agent event log on the payment server (via Log Analytics) → the network path. The payroll runbooks encode that.

Deeper: Incident response

Cost, Maintenance and Support

What drives the cost of running the system, and how do you keep it under control?

The 2023 estimate was $848.07/month: Application Gateway WAF $352.15 (41.5%), SQL reserved $256.63 (30.3%), three App Service S1s $219 (25.8%), with monitoring, Static Web Apps and storage under $21 combined.

The modernized design attacks the top three: no WAF in v1 (ADR-004), one App Service plan instead of three (ADR-001), SQL serverless instead of reserved provisioned (ADR-008). It adds small lines: Defender malware scanning, private endpoints, Key Vault, Functions, GRS.

TODO: Re-price the target design in the Azure pricing calculator. I expect it well under $848, but that’s an expectation, not a number I’d quote in an interview.

Control: budgets with alerts per environment, tags for cost by app and environment, auto-pause in dev and test, a quarterly cost check, and people cost (the real cost) kept low by PaaS.

Deeper: Budget

az consumption budget list -g rg-dunderly-hr-prod -o table
az costmanagement query --type ActualCost --timeframe MonthToDate \
  --scope /subscriptions/<sub>/resourceGroups/rg-dunderly-hr-prod --dataset-grouping name=ResourceType type=Dimension

• Budgets and alerts (80%, 100%) in Bicep per environment.
• Dev: B1, SQL auto-pause after an hour, LRS, no Defender scanning.
• Tags app, env, owner enforced by Azure Policy.
• Lifecycle rule moves old documents to cool tier.

Deeper: Capacity and cost monitoring, Cloud FinOps in Azure

The cost lines that can surprise you here, and how I’d watch them:

• Log Analytics ingestion: grows quietly with chatty logs. Watch Usage by table monthly.
• SQL serverless: billed vCore-seconds; a runaway report query costs money as well as latency.
• Defender for Storage: per-GB scanned; the migration’s bulk upload is a one-off spike.

Usage | where TimeGenerated > ago(30d) | summarize GB=sum(Quantity)/1024 by DataType | order by GB desc

Deeper: Cost optimization

How is the system maintained and supported after go-live?

After go-live the team shrinks to roughly one developer at 20% plus the architect for escalations (assumption). The model:

Level	Who
L0	User guides, KB, in-app help
L1	HR service desk: how-to, access, data fixes
L2	App team rota (business hours, payroll-week cover)
L3	Microsoft support for platform faults

Maintenance is small and routine: weekly Dependabot merges, monthly runtime patches verified in test, quarterly restore tests, a yearly DR drill, a .NET LTS upgrade every two to three years, and about 20% of maintenance time on debt. The boundary with IT is the payment system’s input folder.

TODO: Which Azure support plan does Dunderly have? Without one, L3 doesn’t exist.

Deeper: Support model

Routine maintenance I’d automate or calendar:

• Dependabot grouped weekly; merged when green.
• Runtime version bumps via a Bicep parameter, tested in test first.
• Weekly drift what-if; quarterly evidence export; yearly SWA token rotation.
• Pickup agent and AzCopy updates quarterly, installed with IT.

gh pr list --label dependencies
az webapp config show -g rg-dunderly-hr-prod -n app-dunderly-hr-api-prod --query linuxFxVersion

Deeper: Patch and upgrade management

• Incident response: declare, contain, diagnose, recover, communicate, review. Sev 1 for payroll in payroll week.
• Toil watch: if a runbook is run by hand more than twice a month, automate it.
• Restore and DR tests produce the real RTO numbers.
• Problem management: recurring incidents get a root cause and a tracked fix (for example moving the payment server’s patch window out of the pickup window).

gh issue list --label problem --state open

Deeper: Incident and problem management

Leadership, Stakeholders and Governance

How did you communicate the architecture and progress to stakeholders and executives?

Different views for different people:

• Sponsor and steering group: a one-page status every two weeks: milestones, top risks, decisions needed, budget. Every red item comes with a proposed decision.
• HR: sprint demos in the PR preview environment, and the plain-language release note (“You can now withdraw a salary request”).
• Engineers: the architecture doc, ADRs and the animated flows.
• IT and the payment system owner: the interface agreement and the file format doc.

For executives, the story was cost and risk: the 2023 estimate, where 41.5% was a WAF for ten users, and a payroll file that can’t fail silently. The animated system diagram did more work in reviews than any slide.

Deeper: Project governance

How do you document and govern architectural decisions?

ADRs in docs/adr/, one per decision: context, decision, consequences, and a “revisit when” line. An ADR is never edited after acceptance; a new one supersedes it. That’s how the 2023 decisions and their replacements both stay readable, with the reasons for each change.

Governance around them:

Decision type	Who decides
Architecture and technology	Architect, via ADR, reviewed monthly (quarterly after go-live)
Business rules	HR manager
File format	Payment system owner + payroll operator
Risk acceptance	Sponsor

ADR-004 (no WAF) is my favourite example: the “revisit when” triggers (exposure beyond employees, a pen-test finding, a regulator or insurer) go on the yearly security review agenda.

Deeper: ADRs

How did you bring other engineers onto the project?

With a first-week path rather than a document dump: run it locally with one command on day one, read the architecture doc and ADRs on day two, walk the three key flows (salary approval, payroll run, document upload) in the debugger, pick a good-first-issue, shadow a production deploy, and read the payroll runbooks (shadowing the run if it’s payroll week).

The structure helps: module boundaries mean a new developer can own one module without understanding all of them, and the architecture tests stop them from accidentally crossing a boundary.

Deeper: Onboarding documentation

What I’d give a new developer, concretely:

git clone <repo-url>/dunderly-hr && cd dunderly-hr
dotnet tool restore && dotnet run --project src/Dunderly.Hr.AppHost
gh issue list --label good-first-issue

• Pair on the first PR; the reviewer checklist is in the PR template.
• Test users per role in the dev tenant, so they can see the app as a manager or HR manager.
• docs/how-to/ for common tasks: add an endpoint, add a migration, add a feature flag.
• A rule: anything they found confusing in week one becomes a doc fix in week two.

Deeper: Developer documentation

Lessons Learned and Trade-offs

What was the hardest technical problem, and how did you solve it?

The hardest problem is an integration with a system that can’t talk back: a legacy C++ payment system that accepts one file a month and gives no response. You can’t get an error code, so you have to design certainty.

My solution: snapshot the run so what’s approved is what’s paid; four-eyes approval; a file plus a manifest (record count, control total, SHA-256); an on-prem agent that pulls (no inbound path into the server farm), verifies before delivering, and writes a receipt; an alert if the receipt is missing, days before payday.

The second-hardest was a people problem: disagreeing with the original design, my own 2023 one, about three services. Writing it as ADR-001 with the reasons made it a decision rather than a reversal.

Deeper: Payroll run

The hardest code problem is date logic: effective-dated salaries, mid-month joiners and leavers, unpaid leave, closed periods, and leave carry-over across years. It’s where off-by-one bugs pay someone the wrong amount.

How I’d tame it:

• DateOnly everywhere, no times; an injected TimeProvider.
• Rules as pure functions, tested with [Theory] tables of edge dates.
• Golden payroll runs for each edge case.

[Theory]
[InlineData("2027-03-15", 17, 31)]   // joiner on 15 March: 17 of 31 days
public void Prorates_joiner(string start, int paidDays, int daysInMonth)
    => Proration.PaidDays(DateOnly.Parse(start), new(2027, 3, 31)).Should().Be(paidDays);

TODO: Does Dunderly prorate by calendar days or working days? It changes the rule, and the payment system may already do it.

Deeper: Unit testing

What would you do differently if you started again?

Three things:

1. Start from one deployable. The 2023 design started from services and had to discover the shared database. I’d start with a modular monolith and earn any split.
2. Ask about the payroll file in week one, not as a box on a diagram. The case study treated the payment interface as one component; it’s actually the riskiest part of the project.
3. Price the design before choosing it. The WAF line was 41.5% of the 2023 total. Seeing the bill early would have prompted the “is it worth it?” conversation.

And one I’d keep: asking the awkward NFR questions first (users, data, criticality). That habit made the whole design right-sized.

Deeper: ADRs

Since this is a design, “differently” means what I changed from the 2023 version and what I’d insist on from the first sprint:

• Background jobs in Functions from day one, not BackgroundService in the API: during a slot swap two copies of the API run, and a hosted service would run twice.
• Every post-commit message through the outbox, including the payroll queue message. Sending to the queue straight after SaveChangesAsync leaves a gap where a crash loses the message.
• The API client generated from OpenAPI from sprint 1, so the contract is enforced by the compiler.

outbox.Add(new PayrollRunApproved(run.Id, run.Period));   // relayed to the queue by the dispatcher
await db.SaveChangesAsync(ct);                             // same transaction as the approval

Deeper: Event and messaging contracts

• Plan for private networking in CI from the start. A database with public access disabled can’t be migrated from a GitHub-hosted runner; it needs a VNet-connected runner or a deployment script inside Azure.
• Put Entra app registrations in code early. They live outside ARM and drift easily.
• Rehearse DR in the first quarter, not the first year: the first drill always finds a hard-coded region.

az deployment sub what-if -l northeurope -f infra/main.bicep -p infra/env/dr.bicepparam

Deeper: Infrastructure as code

What technical debt exists today, and how would you pay it down?

Known and accepted debt, each with a trigger:

Debt	Trigger to pay it down
No WAF (ADR-004)	Exposure beyond employees, pen-test finding, insurer or regulator
Single region, no warm standby	RTO tightens below a business day
CSV-only reports	HR asks for dashboards → Power BI dataset with RLS
Email-only notifications	After go-live → Teams adaptive cards
Manual Entra provisioning	Roadmap: HR-driven joiner/mover/leaver

How I pay it down: about 20% of maintenance time, a quarterly check of whether any trigger has fired, and flags removed first because they’re cheap. Plus the honest one: this is still a design. The first real debt will be whatever the first sprint teaches us.

Deeper: Technical debt management

Code-level debt I’d expect and track as type:debt issues:

• Outbox rows that are never purged after sending (a table that only grows).
• Feature flags past their rollout date.
• Reports written as raw SQL that should become views with tests.
• Any FromSql without a test that covers its parameters.

gh issue list --label type:debt --state open
grep -rn "TODO(debt)" src/ | wc -l

Deeper: Technical debt tracking

• Static Web Apps deployment token: the one remaining long-lived secret; rotate yearly until SWA deployment via OIDC replaces it.
• Functions without slots (Flex Consumption): mitigated by idempotent jobs; revisit if a job ever isn’t.
• CI reaching private SQL: needs a VNet-connected runner or an in-Azure deployment script.
• Pickup agent deployment is manual with IT; package it (winget or an Arc extension) once it’s stable.

gh secret list --env prod

Deeper: Patch and upgrade management

Where does the system go next, and how does the architecture support that?

In my order of value:

1. HR-driven Entra ID provisioning (joiner, mover, leaver). The HR system becomes the source of truth for who works here; leavers lose access the day they leave. The API and reporting-line model already support it.
2. Leave approval and self-service, behind flags today.
3. Teams notifications and approvals, through the existing outbox.
4. E-signature for contracts, which the document pipeline (quarantine, scan, promote) already accommodates.
5. Reporting via a Power BI dataset over SQL views.

And the big one: when the legacy payment system is replaced, only the file writer and the pickup agent change. The run, the snapshot and the approvals stay. That isolation was deliberate, and it’s the part of the architecture I’d point to as built for the future.

Deeper: Roadmap, Decommissioning
