Dunderly HR System: Security and Privacy

An HR system’s most valuable data isn’t valuable to hackers in the usual sense: nobody resells Dunderly’s leave balances. It’s valuable to insiders. A curious employee who can see colleagues’ salaries, or a manager who can approve their own raise, does more damage here than most external attacks. So this post spends as much time on “who can see what” as on firewalls, and replaces the 2023 design’s IP-based rules with identity.

Threat modeling

STRIDE over the system context, run as a one-hour workshop with the team and HR:

Threat	Example at Dunderly	Main controls
Spoofing	Phished HR manager credentials	Entra ID MFA, Conditional Access (compliant device for HR roles)
Tampering	Payroll file altered between Azure and the payment system	SHA-256 manifest, immutable container, verification by the agent
Repudiation	“I never approved that raise”	Append-only audit events with the Entra object ID, temporal tables
Information disclosure	Employee browses others’ salaries via the API	Role plus reporting-line check on every call; tests for it
Denial of service	Scripted calls exhaust the API	Rate limiting per user; App Service autoscale; not mission critical
Elevation of privilege	Manager approves own salary request	Four-eyes rule in code (BR-4); role separation

Two threats get extra attention because they’re specific to this system: a malicious document uploaded into HR (below, with its own flow), and the payroll file, which is the one artifact where tampering turns directly into money.

Authentication and authorization

Authentication: Entra ID only. The Blazor app uses MSAL with authorization code + PKCE, gets an access token for dunderly-hr-api, and the API validates it with Microsoft.Identity.Web. No local accounts, no passwords in the HR database. Conditional Access requires MFA for everyone, and a compliant or hybrid-joined device for the HR.*, Payroll.Operator and Auditor roles.

Authorization has two layers, and both must pass:

// Salary module: raise a request
app.MapPost("/api/v1/salary-requests", async (CreateSalaryRequest cmd, ClaimsPrincipal user,
        IReportingLine lines, ISalaryRequests requests) =>
{
    var caller = user.GetObjectId();
    var isHr = user.IsInRole("HR.Admin") || user.IsInRole("HR.Manager");
    if (!isHr && !await lines.IsDirectManagerAsync(caller, cmd.EmployeeId))
        return Results.Problem(statusCode: 403, title: "Not your direct report");
    return Results.Created($"/api/v1/salary-requests/{(await requests.CreateAsync(cmd, caller)).Id}", null);
})
.RequireAuthorization(p => p.RequireRole("Manager", "HR.Admin", "HR.Manager"));

The role check is declarative; the data check is explicit and tested. Approval adds a third rule: DecidedBy must differ from RequestedBy.

Role	Employees	Salary	Leave	Payroll	Audit
Employee	Own profile (read)	Own (read)	Own	—	—
Manager	Direct reports (read)	Request for reports	Approve for reports	—	—
HR.Admin	All (write)	Request	All	—	—
HR.Manager	All (read)	Approve / reject	All	Approve run	—
Payroll.Operator	All (read)	Read	Read	Prepare run	—
Auditor	All (read)	Read	Read	Read	Read

Secrets and key management

The best secret is the one that doesn’t exist. With managed identities, the list of real secrets is short:

Credential	Approach
API → SQL, Blob, queues, Key Vault	System-assigned managed identity, Entra-only auth on SQL
Functions → SQL, storage, Graph	Managed identity
Pickup agent → payroll storage	Azure Arc-enabled server managed identity
GitHub Actions → Azure	OIDC federated credential, no client secret
Email via Microsoft Graph	Managed identity with Mail.Send, restricted by an application access policy to one mailbox
Anything left over	Key Vault (RBAC mode, private endpoint), referenced from app settings

Key Vault also holds nothing exotic: TDE and storage encryption use Microsoft-managed keys.

TODO: Does Dunderly’s policy require customer-managed keys for HR data? If yes, Key Vault holds the SQL TDE protector and the storage keys, and key rotation becomes an operational task.

Encryption requirements

The case study had this right: Azure SQL and Storage encrypt at rest with AES-256 by default, and traffic uses TLS. On top of that:

• TLS 1.2 minimum on every endpoint, HTTPS only, HSTS on the web app.
• Payroll files are protected in transit (HTTPS) and integrity-checked (SHA-256 manifest). If the payment system’s owner wants confidentiality at rest on the file share too, the agent can decrypt from a PGP-encrypted file, but that adds key handling on-premises. I’d only do it if their policy requires it.
• Backups inherit encryption.
• No salary data in logs (see Audit logging); telemetry is not an encryption boundary.

Network security

The 2023 design proposed App Gateway WAF in front of the APIs, access restrictions from the gateway’s VNet, and firewall rules on SQL and Storage allowing the App Service outbound IPs. The modernized design keeps the intent and changes the mechanism:

2023	Now	Why
App Gateway WAF v2	None in v1 (ADR-004)	Cost vs risk for an SSO-only internal app
Access restrictions from gateway VNet	Entra token required on every API call; rate limiting	Staff use it from anywhere, so IP rules don’t fit
SQL/Storage firewall with App Service outbound IPs	Private endpoints; public access disabled	Outbound IPs are shared with other tenants and can change

The payroll storage account is the exception that touches the outside world: the on-premises agent must reach it.

TODO: Does Dunderly have a site-to-site VPN or ExpressRoute to Azure? If yes, the agent uses the private endpoint and the account has no public access at all. If not, the account allows only the server farm’s egress IP, and the Arc managed identity is still required.

Input validation and secure coding

Validation runs twice with one set of rules: FluentValidation validators live in a shared project, so the Blazor forms and the API enforce the same rules. The API is the authority. EF Core parameterizes queries; any raw SQL for reports uses FromSql with interpolated parameters, never string concatenation.

Uploads deserve their own flow, because HR will be handed files from outside the company (signed contracts, certificates). Tick the box to see a malicious file:

1. HR attaches a scan: An HR admin attaches a signed contract or review to an employee record. Only HR roles can upload, and files are capped at 10 MB.
2. Validate first: The API checks the role, an allow-list of types (PDF, JPEG, PNG) and the file's magic bytes, not just the name and content type the browser sent.
3. Quarantine: The file is stored under a random GUID name in a quarantine container. Its SQL metadata row says PendingScan, so nobody can download it yet.
4. Malware scan: Microsoft Defender for Storage scans the blob on upload and publishes the verdict as an Event Grid event.
5. Promote (clean): A small Function moves clean files to the documents container and marks the row Available. Versioning and soft delete protect it from then on.
6. Contain (malicious): A malicious verdict deletes the blob, marks the row Rejected and raises a security alert. The file was never readable by anyone.

The rules: allow-list of types checked by magic bytes, 10 MB limit, random blob names (never the user’s file name in a path), quarantine until scanned, Content-Disposition: attachment on download so a browser never renders an uploaded file inline. See API Security for the general checklist this follows.

Vulnerability and dependency management

• Dependabot for NuGet, npm (build tooling only) and GitHub Actions, grouped weekly.
• dotnet list package --vulnerable --include-transitive fails the build on high or critical.
• CodeQL on every PR; secret scanning with push protection on the repo.
• Defender for Cloud (foundational CSPM free tier at least) for Azure misconfigurations, plus Defender for Storage for malware scanning.
• Patch window: platform patching is Microsoft’s (PaaS); our patching is dependency updates and the .NET runtime, merged weekly, emergency fixes within the remediation SLA.

Privacy and data-protection requirements

Under assumption A2 (GDPR applies), privacy is designed in:

• Minimisation. Store what HR and payroll need. No national ID scans unless the law requires them; bank details only if the payment system needs them from us.
• Purpose limitation. HR data is used for HR and payroll. Reports for other purposes need the DPO’s okay.
• Access by need. The role table above; salary data never in notifications, emails or logs.
• Subject rights. An audit extract per employee answers access requests; rectification goes through HR.
• Retention. Enforced by data, not memory (see retention).
• DPIA before go-live, because the data includes salary and health-related absence.

TODO: Does the payment system need bank account details from the HR system, or does it hold them already? If it holds them, the HR system never stores bank data, which is a significant privacy win.

Audit logging

Two different kinds of logs, kept apart on purpose:

	Business audit	Technical telemetry
What	Who changed what, when, before and after	Requests, errors, traces
Where	SQL audit.AuditEvent (append-only) + temporal tables	Application Insights / Log Analytics
Contains personal data	Yes, by necessity	No: IDs only, no names or amounts
Retention	Same as the HR record it describes	90 days (assumption)
Who can read	Auditor role, HR manager	Engineering

The audit table is append-only: the API’s database user has INSERT but not UPDATE or DELETE on it. Azure SQL auditing also goes to the Log Analytics workspace, to catch anyone reading tables directly.

Security testing and incident response

Testing: authorization tests for every endpoint and role (the cheapest high-value security test here), OWASP ZAP baseline scan against test in the pipeline (see the OWASP ZAP post), and one external penetration test before go-live, scoped to the API, uploads and the payroll path.

Incident response: a short security playbook that extends the incident process:

1. Contain: disable the affected Entra account or app role assignment; rotate anything relevant.
2. Preserve: export the audit and sign-in logs for the window.
3. Assess: whose data, which fields. Salary and health data raise the severity.
4. Notify: DPO immediately; under GDPR, the supervisory authority within 72 hours if it’s a reportable breach, and affected employees where required.
5. Review and fix.

TODO: Who is Dunderly’s DPO (or privacy contact), and who decides whether a breach is reportable?

Checklist

• Run the STRIDE workshop with HR and record new threats.
• Configure Conditional Access: MFA for all, compliant device for HR and payroll roles.
• Write authorization tests for every endpoint × role combination.
• Confirm VPN/ExpressRoute and the payroll storage network rules.
• Decide on customer-managed keys (policy question).
• Confirm whether the HR system needs bank details at all.
• Complete the DPIA before go-live.

• Book the external penetration test for week 13 or 14.
