Dunderly HR System: Operations and Observability

The 2023 design had a Logging service fed by a queue, with logs queried for dashboards and alerts. The instinct was right: you need to know what the system is doing. But the alert that matters most for Dunderly isn’t about CPU or error rates. It’s “the payroll file hasn’t been confirmed as delivered, and payday is in four days”. Operations here is built around that kind of signal.

Application and infrastructure monitoring

Everything lands in one Log Analytics workspace, with a workspace-based Application Insights resource per environment (ADR-006 replaces the custom logging service):

Source	How	What we get
HR API	Azure Monitor OpenTelemetry Distro	Requests, dependencies (SQL, Blob), exceptions, traces, custom metrics
Payroll Functions	OpenTelemetry in the isolated worker	Executions, failures, queue retries
Blazor app	Application Insights JS SDK (page views, failed calls only)	Client errors, slow loads
Azure SQL, Storage, App Service, Key Vault	Diagnostic settings	Platform metrics and logs, SQL auditing
Pickup agent	Azure Monitor Agent on the Arc server	Event log entries for each pull
Availability	Standard availability test on /health every 5 min from 3 locations	Uptime as users see it

Sampling is off: at this volume it would only lose the rare events we care about.

Logging and log retention

Structured logs with message templates, always with a correlation ID (the W3C trace ID), which the UI shows on error screens so a support ticket can carry it.

The hard rule: no personal data or salary amounts in telemetry. Logs carry IDs (EmployeeId 1042, RunId 41), never names or numbers. An analyzer-backed review check and a scheduled KQL query that looks for patterns like currency amounts or email addresses in traces enforce it.

Data	Retention	Why
Application telemetry	90 days interactive	Enough to investigate; personal-data-free
Platform logs, SQL audit	90 days interactive, then archive to 1 year	Security investigations
Business audit (SQL)	Retention of the HR record	Legal, see Audit logging

Assumption: 90 days of interactive telemetry retention. The 2023 estimate assumed 1 month for Log Analytics and 3 months for Application Insights.

Metrics and dashboards

Two workbooks (see Azure Workbooks), each answering a different person’s question:

“Is it working?” (engineering): availability, request rate, p95 latency and failure rate per endpoint group, SQL CPU and resume events, Function failures, queue depth, documents pending scan.

“Is payroll on track?” (HR and engineering): one row per month: run status, prepared/approved timestamps, file written, picked up, receipt received, and days to payday. Green, amber, red.

Custom metrics emitted by the API and Functions:

private static readonly Meter Meter = new("Dunderly.Hr");
private static readonly Counter<long> SalaryDecisions = Meter.CreateCounter<long>("hr.salary.decisions");
private static readonly Histogram<double> PayrollFileSeconds = Meter.CreateHistogram<double>("hr.payroll.file.duration", "s");

SalaryDecisions.Add(1, new KeyValuePair<string, object?>("outcome", "approved"));

Distributed tracing

A request is traced from the browser through the API into SQL and Blob, and asynchronous work keeps the trace going: the API writes the trace context into queue messages and outbox rows, and the Functions continue it. So “HR approved March payroll at 10:02” and “the file was written at 10:02:07” are one trace in the transaction search.

The pickup agent is outside Azure and doesn’t join the trace, but it logs the run ID and file hash, which are enough to join its events to the trace in a KQL query.

Health checks

ASP.NET Core health checks, split by purpose:

Endpoint	Checks	Used by
/health/live	Process is up	App Service health check (instance replacement)
/health/ready	SQL reachable, Blob reachable, config valid	Smoke tests, slot warm-up
/health	Ready + a cheap read query	Availability test

/health/live deliberately doesn’t check SQL: if SQL is down, replacing API instances won’t help, and the platform would churn instances for nothing. Health endpoints are anonymous but return only status, no details.

Alerting and escalation

Alert on symptoms users or payroll feel, not on every metric. The whole catalogue:

Alert	Condition	Severity	Goes to
Availability	/health fails from 2 of 3 locations for 10 min (business hours)	Sev 2	App team rota
API errors	5xx rate > 5% over 15 min	Sev 2	App team rota
Payroll file not written	Run approved > 1 hour, no file	Sev 1	App team + payroll operator
Payroll receipt missing	File written > 4 hours, no receipt	Sev 1	App team + payroll operator + IT
Run not approved	2 days before file deadline, run still draft	Sev 3	Payroll operator
Document stuck in scan	Pending > 1 hour	Sev 3	App team
Poison queue message	Any	Sev 2	App team
Budget	80% and 100% of monthly budget	Info	Architect, finance

Alerts post to a Teams channel and email via action groups; Sev 1 also sends SMS. Escalation follows the support model. Every alert links to its runbook.

Availability and performance targets

Assumption: These targets follow assumption A7 and the latency assumption in Requirements. They need the sponsor’s agreement before they’re real SLOs.

SLI	SLO	Window
Availability (availability test success, business hours)	99.5%	30 days
API latency (p95, excluding uploads)	< 500 ms	30 days
Payroll file delivered and confirmed before cutoff + 1 day	100%	Every month

The third one is the SLO that matters; missing it once is a serious incident even if the others are perfect. The first two get an error budget: if availability burns more than half its budget in a month, the next sprint prioritizes reliability work over features.

Operational runbooks

One Markdown file per task in docs/runbooks/, each with: when to use it, prerequisites, steps with exact commands, how to verify, how to roll back.

Runbook	Trigger
payroll-monthly.md	Every month: draft, review, approve, confirm receipt
payroll-receipt-missing.md	Alert: check agent, re-trigger pull, manual delivery fallback
payroll-rerun.md	Wrong file sent: correction process agreed with the payment system owner
restore-sql.md	Data loss or bad data change
restore-document.md	HR deleted a document by mistake
access-request.md	Assign or remove app roles
dr-failover.md	Region outage
rotate-and-revoke.md	Suspected credential compromise

TODO: Is there a manual fallback for delivering the payroll file (for example IT copies it by hand)? The receipt-missing runbook needs a last resort that doesn’t depend on the agent.

Incident and problem management

Incidents follow a simple cycle: detect, triage (severity), mitigate, resolve, review. The detailed flow and escalation are in Support and Maintenance.

Problem management is the slower loop: recurring incidents or near misses get a problem record (a GitHub issue labelled problem), a root cause, and a fix tracked to completion. Example: if the agent misses pulls twice because the payment server restarts for patching on the same night, the problem fix is to move the patch window, not to keep re-triggering pulls.

Capacity and cost monitoring

Capacity is not a concern at this size (see Capacity and quota planning), so cost is the capacity metric:

• A Cost Management budget per environment with alerts at 80% and 100%.
• Tags on every resource (app=dunderly-hr, env, owner) so cost reports group cleanly.
• A monthly look at the cost by resource: SQL vCore-seconds, App Service plan, Defender scanning, storage, Log Analytics ingestion. Ingestion is the line that grows quietly if someone logs too much.

TODO: The monthly budget figure, once the target design is re-priced (see Budget).

More on Azure cost practices: Cloud FinOps in Azure.

Checklist

• Wire the OpenTelemetry distro into the API and Functions; turn off sampling.
• Add the KQL check for personal data patterns in telemetry.
• Build the two workbooks.
• Create every alert in the catalogue with its runbook link.
• Agree the SLOs with the sponsor.
• Write the eight runbooks, starting with the payroll ones.

• Set budgets and tags per environment.
