Y-IaC: Operations and Observability

When Y-IaC is healthy, nobody notices it. When it isn’t, the first symptom is a consumer’s plan failing, and the first question is always the same: is this my YAML, my cloud, or the platform? Operations for Y-IaC is about answering that question fast, which means watching the platform separately from the workloads it builds. The drift loop does most of the watching today.

Application and infrastructure monitoring

Two layers, deliberately kept apart:

Layer	Signals	Owner
Platform health	Workflow success rate, duration, queue time, cancellations, failure category; gate outcomes; compatibility results; lock errors; backend availability	Platform team
Workload health	Resource metrics, diagnostic logs, alerts on the infrastructure the modules created	Consumer team

A spike in failed plans across five consumers on the same day is a platform signal. One consumer’s failing plan after a portal change is a workload signal. The failure category is what tells them apart, which is why the error catalog matters operationally, not just for support.

Not centrally yet: each failure surfaces in the consumer that hit it, and the DevOps team sees it there. Collecting workflow run data from the GitHub API is the first step toward the dashboard below.

Logging and log retention

What’s logged and where:

• CLI logs through core/logging_config.py, to the console and the workflow log.
• Terragrunt output, streamed through the log processor (reporting/log_processor.py), which shortens timestamps, abbreviates unit names ([.terragrunt-stack/azurerm_windows_virtual_machine] becomes [azwvm]) and prefixes, so a 30-unit stack log stays readable.
• Workflow logs in GitHub Actions, kept for the repository’s log retention setting.
• Reports (summary, error report, final report) as job summaries and artifacts.

Two rules: never print credentials or sensitive provider attributes (the redaction module handles plan JSON; the CLI must not echo ARM_* values), and set log retention to match the evidence decision from Security and Privacy.

Metrics and dashboards

The dashboard I’d build first, from GitHub Actions run data across consumers:

Panel	Metric
Plan success rate	Successful / total plan jobs per day, per consumer
Apply success rate	Same for apply jobs
Plan-after-apply clean rate	Runs with zero changes after apply
Failure categories	Count by error catalog entry (auth, lock, provider, YAML, gate)
Gate outcomes	Pass, advisory finding, blocked, overridden
Drift	Stacks with drift, tickets open, ticket age
Duration	p50 and p95 plan time per changed stack
Adoption	Consumers per Y-IaC ref (how many are on the latest release)

Grafana is already a Y-IaC provider target, so the dashboard itself can be declared as code in a consumer.

Distributed tracing

There’s no request path to trace; a run is one process tree on one runner. The closest equivalent is correlation: every run already exports Git runtime metadata (reporting/git_info.py), and the summary links the commit, the run and the artifacts. I’d add one run ID that appears in the CLI banner, the Terragrunt log prefix, the plan summary, the Jira comment and the Teams message, so one search finds everything about a run. Full OpenTelemetry tracing would be overkill here.

Health checks

The platform’s health checks are pre-flight checks the CLI already runs before any Terraform call: Terragrunt installed and reporting a version, credentials resolvable for the backend and the target subscription, the stack folder present, a backend entry found. A scheduled “canary” run would turn these into a health signal: plan one tiny stack in each cloud every day, against the latest release, and alert if it fails. infra-aws’s hello-world stack is a ready-made canary for AWS.

Alerting and escalation

Drift is the main alert today, and it’s a loop rather than a one-off notification. Step through it:

1. Scheduled run: The consumer workflow's cron fires weekly (or someone runs it manually with drift_scan set). No YAML has changed.
2. Plan every stack: Every stack in the consumer is planned with the same CLI and gates. A plan with changes means the cloud no longer matches the YAML on main.
3. Analyze: drift-detection-analyze counts stacks with changes and stacks that failed to plan.
4. Notify and ticket: Teams gets a message, and Jira gets one ticket per repository. An open ticket gets a comment instead of a duplicate; priority rises on destroys.
5. Fix the cause: The owner either reverts the manual change with an apply, or adopts it by updating the YAML through a normal PR.
6. Next scan: The loop never ends. The following scheduled run plans every stack again.
7. Analyze again: Same analysis on fresh plans.
8. In sync: No drift and no failed stacks, so nothing is sent. Unchanged drift on an open ticket is also suppressed by its fingerprint.

Two details worth knowing. The consumer template’s comment says “Daily drift detection”, but the cron is 0 6 * * 0, which is weekly, Sundays at 06:00 UTC. One of them should change. And the Jira integration keeps one ticket per repository, adds comments rather than duplicates, and uses a fingerprint to stay quiet when drift hasn’t changed, which keeps alert fatigue down.

Escalation path I’d propose:

Signal	First responder	Escalate to
Drift ticket	Consumer owner	Platform if the cause is a module or provider
Failed plan in one consumer	Consumer owner	Platform if the error is in the shared path
Failed plans across consumers	Platform maintainer	Platform owner; announce a pin-back ref
Gate blocked	Change author	Security for an exception

Availability and performance targets

Classic availability doesn’t fit a CLI. These are the targets that do, as proposals:

SLI	Proposed SLO
Plans failing because of the platform (not YAML or cloud)	Under 2% of plan runs per month
Time to a pin-back ref after a bad release	Under 1 hour
Plan-after-apply clean rate	99%
Drift ticket age (median)	Under 10 working days
p95 plan time for a single-stack change	Agreed per largest stack

These are my proposed starting targets for the DevOps team; review them after one quarter of real data.

Operational runbooks

The runbooks operators need most, with what exists:

Situation	Starting point
State lock stuck	docs/features/auto-release-state-lock.md; --auto-release-lock with an age guard
Backend config missing	The root.hcl error message lists the four fixes
Wrong subscription or missing credentials	docs/features/provider-credential-resolution.md
Provider lookup or dependency mock errors	.github/skills/diagnose-terragrunt-failure/ and the troubleshoot prompt
Terragrunt errors in general	docs/troubleshooting/terragrunt.md
Drift ticket	Revert by apply, or adopt by PR
Import an existing resource	docs/importing_resources.md

What’s missing is a runbook for the platform’s own incidents: a bad release reaching consumers.

Incident and problem management

Severity for platform incidents:

Sev	Example	Response
1	A release causes destructive plans or blocks all applies	Announce pin-back ref immediately; revert; review applies since the release
2	Plans fail for many consumers; no destructive effect	Pin-back or hotfix within the day
3	One provider family or module broken	Fix in the next patch release
4	Cosmetic, docs	Backlog

Problem management means the recurring causes: each recurring failure becomes an error catalog entry, a validation rule, or a test, so the same incident can’t happen twice in the same way.

Capacity and cost monitoring

Platform cost is mostly CI minutes, multiplied by consumers and by the weekly drift scan. Watch minutes per consumer per month and runner queue time; if the drift scan dominates, scan production weekly and non-production fortnightly.

Workload cost is the bigger number, and Infracost is the tool already wired in, but disabled by default. Turning it on in advisory mode for every consumer would at least put a monthly cost delta on every plan summary, which is cheap insight. Thresholds and blocking can come later.

Checklist

• Platform and workload signals are on separate dashboards
• Workflow run data is collected centrally across consumers
• A daily canary plan runs per cloud against the latest release
• The drift cron and its comment agree
• SLOs are agreed and published
• A bad-release runbook exists with a pin-back procedure
• Infracost is enabled in advisory mode

• A single run ID appears in logs, summaries, Jira and Teams
