Y-IaC: Documentation and Knowledge Transfer

Y-IaC is already better documented than most internal platforms: there are twelve numbered getting-started guides, a generated module reference site and a function-by-function trace of one CLI command. The risk isn’t missing docs. It’s docs that drift from the code, because on a shared platform a wrong guide is copied into every consumer’s habits. So this post is mostly about keeping what exists true, and filling a few specific gaps.

Product documentation

The layers, from the top:

Layer	Document	Status
What and why	Readiness and delivery guide; this playbook	Exists
Repo overview	README.md with module tables by category	Exists; links to the docs site
Persona entry point	docs/getting-started/README.md	Exists
Feature docs	docs/features/ (state-lock release, duplicate detection, module validation, credential resolution, visualization)	Exists
Release history	CHANGELOG.md	Exists; one “Unreleased” section
Service catalog entry	catalog-info.yaml (Backstage)	Exists, but still has sample annotations from a template (artist-website slug)

The catalog entry is a quick fix with a real payoff: in Backstage, it’s how people find the platform’s owner, docs and repo.

User guides

Users are consumer engineers, and their guides are the numbered series:

• 01 Onboard a consumer repo: template, layout, prerequisites, a worked azurerm_resource_group, local plan, branch to PR to gated apply, imports.
• 09 Consumer repo config reference: every key in config.yaml and common_vars.yaml.
• 04a to 04j One page per reusable workflow.

The one I’d add is a “cookbook” of short YAML recipes: a resource group with tags, a Key Vault with a private endpoint, a GitHub repository with environments, an S3 bucket. People copy examples far more than they read references.

API documentation

The “APIs” are module interfaces and YAML shapes. Each module README documents inputs, outputs, a YAML example and the import command, and the module validator fails a module without the required sections. docs/site/build_docs.py turns the READMEs into a searchable MkDocs site published to GitHub Pages by docs-pages.yaml.

Two improvements: generate the inputs table from variables.tf (so it can’t drift from the code), and publish the Python package’s docstrings as a reference for maintainers.

Architecture documentation

• This playbook’s Technical Architecture post, with the animated system context and the two-part run walkthrough.
• 12-cli-init-reconfigure-flow.md, a top-down Mermaid trace of every function one command calls, plus a sequence diagram. It’s the most precise architecture document in the repo.
• entrypoint.md, the step-by-step execution outline.
• ADRs, which don’t exist yet; the list to write is in Architectural decision records.

There’s also an older flow_digram.mmd at the repo root that describes the pre-package flow; it should be removed or replaced by a link to guide 12, so nobody learns the old flow.

Deployment instructions

Y-IaC isn’t deployed, so its “deployment instructions” are two documents:

1. How a consumer adopts a release: change iac_shared_module_ref, run a plan, read the release notes. Short, and it belongs in guide 01.
2. How a maintainer releases: tag, CHANGELOG section, compatibility run, announcement. This doesn’t exist yet and should, before the release process in CI/CD is adopted.

Operations runbooks

The operator runbooks are listed in Operations. The documentation rule for them: each runbook starts with the symptom as the operator sees it (the error text), then the diagnosis, then the fix, then how to confirm. A runbook that starts with background gets skipped in the middle of an incident.

Troubleshooting guides

Troubleshooting knowledge lives in four places today:

• docs/troubleshooting/terragrunt.md;
• config/error_message_and_solutions.yaml, the machine-readable error catalog the CLI matches against;
• .github/skills/diagnose-terragrunt-failure/ and the troubleshoot prompt, for assisted diagnosis;
• this blog’s Terragrunt errors post, for general Terragrunt failures.

The error catalog should be the source, and the Markdown guide generated from it, so a fix added for the CLI is also documented for people.

Support procedures

What a consumer should do when something breaks, in order:

1. Read the error report the CLI printed; it may already name the fix.
2. Check the troubleshooting guide and the CHANGELOG for a recent change.
3. Pin the previous Y-IaC ref and re-run, if the failure started after a release.
4. Ask in the platform channel with the run link, the command and the consumer repo.
5. For a security finding or blocked gate, request an exception through the governance process.

Help comes from the DevOps team. I’d recommend a single intake: issues on the Y-IaC repo for bugs and requests, and the DevOps team’s existing channel for quick questions, so nothing is lost in direct messages.

Onboarding documentation

Two onboarding paths, and only one is complete:

• New consumer: guide 01, then 09. Complete.
• New maintainer: guides 05, 06 and 12 explain the Python package, but there’s no “your first week” path. I’d add one: set up the sibling checkouts, run the tests, trace one command with guide 12 in a debugger, add a trivial module with guide 07, and shadow one release.

The usability sessions in UX are the test for both paths.

Training materials

There’s a platform presentation deck in docs/ (around 1,100 lines of Markdown slides) that covers the platform end to end. Paired with the animated diagrams in this playbook, it’s a solid one-hour introduction. What I’d add:

• a 30-minute hands-on lab: onboard a scratch consumer and plan one resource;
• a 30-minute lab for contributors: add a module and pass the validator;
• a recorded walkthrough of a failed plan diagnosed with the error report.

Checklist

• catalog-info.yaml sample annotations are replaced with real owner, slug and links
• A YAML cookbook of common recipes is added
• Module input tables are generated from variables.tf
• flow_digram.mmd is removed or replaced by a link to guide 12
• A maintainer release guide exists
• The error catalog generates the troubleshooting page
• A “first week” path exists for new maintainers

• Hands-on labs exist for consumers and contributors
