Y-IaC: User Experience and Design

Y-IaC doesn’t have a single screen, and it still has a user experience. It’s the YAML a consumer writes, the banner the CLI prints before it touches anything, the error message at 6 pm when a plan fails, and the summary a reviewer reads before approving an apply. If any of those is confusing, people route around the platform, and a shared platform that people route around isn’t shared any more.

Information architecture

There are two structures a user has to learn: the consumer repository layout and the docs.

The consumer layout is the more important one, because folder names are configuration. The path environments/<cloud>/<environment>/<stack>/ is parsed by root.hcl (the cloud folder picks the backend namespace) and by the CLI (the three --cloud, --environment, --stack arguments map one to one):

infra-aws/
├── config.yaml                    # backend + workflow settings for this repo
├── entrypoint.py                  # identical stub in every consumer
└── environments/
    └── aws/
        ├── root.hcl               # written by bootstrap, never edited
        └── dev/
            ├── common_vars.yaml   # account, providers, tags, gates
            └── hello-world/
                └── resources.yaml # what to create

The docs follow personas, through docs/getting-started/README.md: choose a persona, then follow numbered guides (01 onboard a consumer, 02 add a module, 03 modify a module, 04 CI/CD, 05 and 06 Python internals, 09 consumer config reference, 12 the CLI init flow). That numbering is good; I’d keep new guides in it rather than adding loose files to docs/.

User flows

The main flows, as the user experiences them:

Persona	Flow
Consumer	Edit resources.yaml → local plan → PR → read summary → merge → approve apply
Contributor	Add module + unit template → run validator → add tests → PR
Maintainer	Change Python or workflow → pytest, ruff → compatibility run → release note
Operator	Read failed run → error report suggests a fix → rerun, release lock, or import

The consumer flow is the one to keep short. Today a consumer never writes HCL, never touches a backend block and never edits a pipeline. The animated walkthroughs in Technical Architecture show everything that happens behind that one command, and the point of the design is that the consumer doesn’t need to know it.

Wireframes and prototypes

There’s nothing to wireframe in the usual sense, but there are two artifacts I’d prototype before changing them, because they’re what users actually look at:

1. The execution banner (cli/banner.py). It shows the command, cloud, environment, stack, backend, providers, cache decision and working directory before anything runs. A mock-up in a PR description is enough to review a change to it.
2. The plan summary (reporting/plan_summary.py and the summary workflow). A per-unit table of add/change/destroy plus gate outcomes.

For a new YAML shape, the prototype is a sample resources.yaml in the PR. If the sample is awkward to write, the shape is wrong, whatever the module looks like.

Visual design and design system

The “design system” here is consistency of terminal output and docs:

• Status words and symbols together. ✅ passed, ❌ failed, ⚠️ skipped. The symbol helps scanning; the word carries the meaning.
• Box-drawn error panels for configuration errors. root.hcl already does this for a missing backend entry: a framed message with the repo name, what’s missing and four numbered fixes.
• Colour for emphasis only, through core/console.py. Output must still read correctly in a CI log with colours stripped.
• One terminology list: stack, unit, resource type, consumer, shared module. “Stack” means the folder under an environment, never a Terraform workspace.

The module reference site (generated docs on GitHub Pages) is the one visual surface, and it uses the generator’s default theme. That’s fine; nobody chooses an IaC platform for its fonts.

Interaction patterns

• Safe by default. Plan is the default action for a manual CI run. Destroy plans first, prints a warning naming what it will remove, and only proceeds when you type yes in full.
• Opt-in for risky automation. Releasing a stale state lock only happens with AUTO_RELEASE_LOCK set, and only for locks older than LOCK_MIN_AGE_MINUTES.
• Passthrough, not reinvention. Unknown flags such as -reconfigure or -upgrade go straight to Terraform after Terragrunt’s -- separator, so Terraform knowledge still applies.
• Predictable generation. Generated files carry an “AUTO-GENERATED, do not edit” header, and the user’s own files (resources.yaml, common_vars.yaml) are only read, never rewritten.
• Fail before acting. Validation (paths, provider-stack fit, subscription mapping, duplicate resources) runs before authentication and before Terragrunt starts.

Responsive behavior

For a CLI, “responsive” means two things. First, output must work in an 80-column terminal and in a GitHub Actions log, which wraps differently. Wide tables belong in the job summary (Markdown), not in the console. Second, the CLI should behave the same on a laptop and on a runner. It does, by design: entrypoint.py only differs in where it looks for the shared module (GITHUB_ACTIONS=true means ./terragrunt_shared_module, otherwise the sibling folder).

Accessibility design

• No information by colour or emoji alone, as above.
• Diagrams in the docs have accompanying text. The animated diagrams in this playbook have a caption per step and a no-JavaScript fallback list.
• Error messages are plain sentences with a concrete next action, which helps screen-reader users and everyone else equally.
• Markdown docs use real headings and tables, not screenshots of tables.

Usability testing

The guide suggests three test participants, and I agree with the choice:

1. A new consumer onboards a scratch repo from 01-onboard-consumer-repo.md alone.
2. A module contributor adds a small module from 02-add-new-module.md.
3. An operator diagnoses a deliberately broken plan (wrong subscription, stale lock, missing backend).

Watch, don’t help, and write down every time someone needs to ask a person. Each of those moments is tribal knowledge that becomes a backlog item in the Documentation track.

So far onboarding has gone through the DevOps team, so nobody has yet onboarded a consumer from the docs alone. That makes session 1 the most valuable one to run first.

Content and messaging

Every message the CLI prints should answer three questions: what happened, why, and what to do next. The missing-backend error in root.hcl is the model:

❌ ERROR: Backend Configuration Missing
Repository: infra-example
⚠️  Backend configuration not found in config.yaml
📝 Action Required:
   1. Open: terragrunt_shared_module/config/config.yaml
   2. Add backend configuration for repo: infra-example
   ...

The error catalog (config/error_message_and_solutions.yaml) extends this to known Terraform and provider errors. I’d treat each support question as a candidate catalog entry.

Checklist

• Consumer folder layout is documented with a single annotated tree
• Banner and plan summary changes are reviewed with a mock-up in the PR
• Every status symbol in CLI output sits next to a status word
• A terminology list (stack, unit, consumer, shared module) is in the docs
• Three usability sessions are run and findings logged as backlog items
• Every new error path prints what happened, why and what to do next

• Recurring support questions are added to the error catalog
