Dunderly HR System: CI/CD and Release Management

The 2023 case study ended at “Write Architecture Document” and “Support the Team”; it never said how code reaches Azure. For a team of four, the pipeline is the team’s most productive member: it builds, tests, scans, deploys and rolls back without needing a meeting. The one thing it isn’t allowed to do on its own is ship during payroll week.

Build automation

GitHub Actions, two workflows: pr.yml on pull requests and release.yml on pushes to main. The whole path, from PR to production. Tick the box to see failing smoke tests stop a release:

1. Open a pull request: Every change, whether code, Bicep or a migration, starts as a short-lived branch and a pull request against main.
2. Build and test: GitHub Actions builds the API, the Functions and the Blazor app and runs unit tests, plus integration tests against SQL Server in a container.
3. Scan: CodeQL, dependency review, secret scanning and Bicep linting run on every PR. A high-severity finding fails the check.
4. Preview: Static Web Apps creates a preview environment for the PR, so the HR product owner can click through a UI change before it merges.
5. Review and merge: Branch protection needs one approving review and green checks. Merging to main is the only way into the release path.
6. Build once: Main builds the release artifacts once (API and Functions zips, the Blazor bundle, an EF Core migration bundle), all stamped with one version.
7. Deploy to dev: The workflow signs in to Azure with OIDC, so there's no stored secret. Bicep applies first, then the artifacts deploy.
8. Promote to test: The same artifacts go to test, where Playwright end-to-end tests run and HR does acceptance testing on release candidates.
9. Production approval: The production environment needs a named reviewer. Payroll week is a change freeze unless the fix is for payroll itself.
10. Migrate, then deploy to the slot: The migration bundle applies backward-compatible schema changes, then the new build goes to the staging slot while production keeps serving.
11. Smoke test the slot: Health, sign-in, an employee read and a document download run against the warmed-up staging slot.
12. Swap (pass): The slot swap is the release. Rolling back is swapping again, within minutes, because the previous build is still sitting in the slot.
13. Don't swap (fail): Production never saw the bad build. The team fixes forward on main, and the expand-only migration is harmless to the version still running.

The build is plain dotnet CLI with locked restores, so a CI build and a local build are the same build:

dotnet restore --locked-mode
dotnet build -c Release --no-restore
dotnet test -c Release --no-build --collect:"XPlat Code Coverage"
dotnet publish src/Dunderly.Hr.Api -c Release -o artifacts/api
dotnet publish src/Dunderly.Hr.Web -c Release -o artifacts/web
dotnet publish src/Dunderly.Hr.Functions -c Release -o artifacts/func
dotnet ef migrations bundle --project src/Dunderly.Hr.Api --self-contained -r linux-x64 -o artifacts/efbundle

More on .NET builds in CI in DotNet Build and on Actions basics in GitHub Actions - Introduction.

Automated test execution

Stage	Tests	Blocks
PR	Unit, integration (Testcontainers SQL + Azurite), authorization matrix, architecture tests, payroll golden files	Merge
Deploy to test	Playwright E2E journeys with axe, ZAP baseline	Promotion to prod
Nightly on test	Full E2E on Chromium, Firefox, WebKit	Nothing (reports)
Prod staging slot	Smoke tests	Swap

Test results publish as a check summary; coverage goes to the PR as a comment. A flaky test is quarantined with an issue, never retried silently into green.

Static analysis and security scanning

• CodeQL (C#) on every PR and weekly on main.
• Dependency review action blocks PRs adding packages with known high/critical vulnerabilities or disallowed licenses.
• Secret scanning with push protection.
• .NET analyzers as errors (TreatWarningsAsErrors), dotnet format --verify-no-changes.
• Bicep: az bicep lint and a what-if against the target environment, posted to the PR.
• OpenAPI diff flags breaking API changes for an explicit decision.

Artifact and container management

No containers in production: App Service and Functions run zip deployments, and Static Web Apps takes the built wwwroot. The release workflow builds once and uploads the artifacts (api.zip, func.zip, web/, efbundle) to the workflow run, stamped with the version (1.4.0+<short sha>). Every environment deploys those exact files. Rebuilding per environment would mean prod runs something test never saw.

Artifacts are kept for 90 days in GitHub; tagged releases also attach them to the GitHub Release, so any version can be redeployed.

Deployment automation

One reusable job deploys any environment, signed in with OIDC:

deploy:
  environment: ${{ inputs.environment }}          # dev | test | prod (prod has required reviewers)
  permissions: { id-token: write, contents: read }
  steps:
    - uses: azure/login@v2
      with:
        client-id: ${{ vars.AZURE_CLIENT_ID }}
        tenant-id: ${{ vars.AZURE_TENANT_ID }}
        subscription-id: ${{ vars.AZURE_SUBSCRIPTION_ID }}
    - run: az deployment sub create -l westeurope -f infra/main.bicep -p infra/env/${{ inputs.environment }}.bicepparam
    - run: ./efbundle --connection "${{ steps.conn.outputs.sql }}"   # Entra auth, no password
    - uses: azure/webapps-deploy@v3
      with:
        app-name: app-dunderly-hr-api-${{ inputs.environment }}
        slot-name: ${{ inputs.environment == 'prod' && 'staging' || 'production' }}
        package: artifacts/api.zip

For prod the sequence is: Bicep → migrations → API to the staging slot → smoke tests → swap → Functions → Static Web Apps. The web app goes last so the UI never calls an API older than itself. PRs get a Static Web Apps preview environment automatically, which is where HR reviews UI changes.

Database deployment strategy

Migrations run before the new code, and are expand-only (see migrations). That ordering is what makes the slot swap safe: during the swap, both the old and the new API version run against a schema that suits both.

A destructive change (dropping a column) takes two releases: release N stops using it, release N+1 drops it. The migration bundle runs as the pipeline’s identity, which is the only principal with DDL rights in prod; the API’s identity has DML rights only. One practical catch: SQL has public network access disabled, so a GitHub-hosted runner can’t reach it. The bundle runs either on a small self-hosted runner in the VNet or as an Azure deployment script attached to the VNet; I’d pick the deployment script, because there’s no runner to patch.

Before any migration in prod, the pipeline records the current time. Point-in-time restore to that moment is the escape hatch if a data migration goes wrong, which is rare when migrations only add.

Approval gates

Gate	Who	Where
PR merge	One reviewer; two for payroll paths	Branch protection + CODEOWNERS
Deploy to test	Automatic	—
Deploy to prod	A named reviewer (tech lead or architect)	GitHub environment prod
Payroll-impacting release	Also the payroll operator	PR label risk:payroll + checklist
Payroll week	Blocked unless the fix is for payroll	Release calendar check

The prod environment also has a wait timer of zero and a deployment branch rule: only main can deploy.

Versioning and release notes

Semantic versioning for the system as a whole (MAJOR.MINOR.PATCH). The API’s URL version (/api/v1) only changes for breaking API changes, which, with one client in the same repo, should be never.

Release notes are generated from PR titles (conventional commit prefixes: feat:, fix:, chore:) into the GitHub Release, then a human writes a two-line summary for HR in plain language: “You can now withdraw a salary request before HR decides.” That second part is what users actually read.

Rollback and roll-forward procedures

Situation	Action	Time
Smoke tests fail in the slot	Don’t swap; fix forward	0 user impact
Problem found after swap	Swap back (old build is in the slot)	Minutes
Bad Functions deployment	Redeploy the previous func.zip from the release	Minutes
Bad web deployment	Redeploy the previous web artifact	Minutes
Bad data change	Point-in-time restore to a new database, repair data	Hours

Because migrations only add, swapping back never needs a schema rollback. Default is roll forward for anything that isn’t actively hurting users; swap back when it is.

az webapp deployment slot swap -g rg-dunderly-hr-prod -n app-dunderly-hr-api-prod --slot staging --target-slot production

Release calendar

Small releases, often, outside payroll week:

• Normal cadence: weekly, Tuesday to Thursday mornings, when the team is around to watch.
• Freeze: from the payroll cutoff to payday, every month (assumption A6). Payroll fixes only.
• No Friday afternoon releases. Not a superstition: nobody’s watching at the weekend.
• Year end: freeze around leave carry-over and the first payroll of the year.

The calendar is a shared Outlook calendar plus a check in the workflow that reads the payroll cutoff dates from a config file and fails a prod deploy in the freeze window unless the PR has the payroll-fix label.

Checklist

• Create pr.yml and release.yml with the reusable deploy job.
• Configure OIDC federated credentials and GitHub environments with reviewers.
• Add the smoke test suite and wire it to the swap decision.
• Grant DDL to the pipeline identity only; DML to the API identity.
• Add the payroll-freeze check with this year’s cutoff dates.
• Rehearse a swap-back in test.

• Write the plain-language release note template for HR.
