Cloudutsuk Platform: Product Planning

The trap with a platform like this is building the fun part first: the chatbot, the agent. Without SSO, GitOps and monitoring underneath, they’d be demos I’d have to rebuild. So the plan goes bottom up, and every phase ends with something I actually use. The other rule is that this playbook gets updated at the end of every phase, so the blog never describes a platform that doesn’t exist.

Living playbook. Phase status is tracked below and on the project index. Areas that need facts from the build (security, infrastructure, CI/CD, operations and the rest) are added as their phase completes.

Product roadmap

Phase	Delivers	Depends on	Status
0. Foundation	This playbook, animated diagrams (design gate), ADRs (0001 onward), 3 new repos, core cluster (Keycloak, OpenBao, PowerDNS, Zot registry), mon, platform and ai clusters, External Secrets everywhere, internal DNS and TLS, GPU spike, DNS on Cloudflare, private remote access through Tailscale, boot unit, heartbeat, backup bucket	none	Done 2026-10-11
1. GitOps + CI/CD	Central Argo CD, homelab-gitops app-of-apps, ARC runners, BuildKit, the Zot registry in core, reusable build workflow with security gates (Gitleaks, Semgrep, Trivy, Checkov, Hadolint, SBOM, Cosign), Kyverno, PostSync smoke tests	0	Done 2026-10-13 (Argo CD and Zot came early, in Phase 0)
1a. Multi-cluster management	Karmada trial, then the Karmada control plane in platform (installed by Argo CD), pull-mode agents on every cluster, the shared add-ons moved from ApplicationSets to Karmada propagation and override policies, lab runner registers and removes labs	1	Not started
3a. Quality baseline	Playwright journeys, Schemathesis on every service, nightly OWASP ZAP, Locust load scenarios, Performance and Security dashboards, open-source DefectDojo as the central findings store, OWASP Dependency-Track for SBOMs, first performance baseline	3	Not started
2. Central monitoring	mon with LGTM and Alertmanager; host exporters (node, GPU, Docker, blackbox); a monitoring pack on every cluster (OTel collectors, kube-state-metrics, ServiceMonitors); ready-made dashboards and mixin alerts; labs moved onto it	0	Done 2026-10-15
2a. Chaos engineering	Open-source LitmusChaos: ChaosCenter and its MongoDB in core, chaos agents on target clusters by an ApplicationSet (labs first), the experiment library in homelab-gitops, a Chaos dashboard in Grafana, first game day	1, 2	Not started
3. Portal + labs	Backstage custom image through CI, SSO, Labs plugin, lab runner, deploy: blocks, Dashboard tab on the blog	1, 2	In progress (started 2026-10-13, alongside Phase 2)
4. Inventory + cost	Four collectors, lab tag, AWS cost allocation tags, OpenCost on every k3d cluster with custom DGX prices, Inventory & Cost plugin, budget alerts	2, 3	Not started
5. Local LLM + RAG + chat	ai cluster: vLLM chat and embeddings behind a LiteLLM gateway; KEDA scaling on-demand models to zero when idle; Qdrant, Redis cache, rag-ingest, rag-api, Chat plugin	3	In progress (started 2026-10-15)
6. Alert agent	sre-agent webhook, multi-cluster access, RAG and mon tools, eval suite from lab experiments (faults injected with LitmusChaos)	2, 2a, 5	Not started

Phase steps

These tables are the source of truth for the build. A step is added to its phase before any work on it starts, and its status changes in the same change as the work. Step numbers are never reused or renumbered (a step slotted in later gets a letter, such as 9a); lessons, ADRs and commits refer to them as “Phase N, step M”. Phases 1 to 6 are broken down from the plan. Their steps will be refined as each phase starts, but the numbers stay.

Phase 0 steps

Before step 1: playbook areas 1, 2, 3 and 5 were written with the system, network and commit-to-deploy diagrams and the data model (2026-10-10), and infra-local, homelab-gitops and homelab-services were created through infra-github (2026-10-11).

Step	Does	Repos	Done when	Status
1	Repo skeletons (READMEs, pre-commit, layouts) and ADRs 0001–0035	infra-local, homelab-gitops, homelab-services	Files are in place and the ADR front-matter check passes	Done (2026-10-11)
2	ADRs on the blog: sync script, ADR post, log table, index tile	this blog	The ADR post renders, htmlproofer passes, the sync --check is clean	Done (2026-10-11)
3	DGX prerequisites: k3d, Helm, Argo CD CLI, OpenBao CLI, age, SOPS, cloudflared; host folders; overlapping containers stopped	infra-local	Every tool prints its version; free memory matches the budget (moved to mid-range, ADR 0010)	Done (2026-10-11)
4	GPU-in-k3d spike: k3s image with the NVIDIA toolkit, device plugin with time-slicing, vLLM chat and embeddings side by side	infra-local	ADR 0010 is accepted	Done (2026-10-11)
5	Move DNS from GoDaddy to Cloudflare: export every record, change nameservers, compare	Cloudflare	curl -I https://cloudutsuk.com is 200 and every record matches	Done (2026-10-11)
6	homelab network (172.30.0.0/24) and the core cluster through the new docker_network and k3d_config_cluster units; Headlamp and Popeye “doctor”	infra-local, shared Terragrunt module	k3d cluster list shows core and its load balancer publishes on 172.30.0.1	Done (2026-10-11)
6a	Doctor link inventory: one page listing every cluster’s Ingress, IngressRoute and HTTPRoute URLs and published ports, each checked once, regenerated with run.sh refresh	infra-local	The page lists every route in every k3d cluster as a clickable link with its status	Done (2026-10-11)
7	OpenBao in core: Helm release, init, unseal from a root-only key file, KV v2, offline key copy	infra-local	bao status is unsealed after a cluster restart	Done (2026-10-11)
8	cert-manager (Let’s Encrypt through Cloudflare DNS-01), PowerDNS, ExternalDNS, split DNS on the DGX	infra-local	bao.core.home.cloudutsuk.com resolves on the host and in a pod and serves a valid certificate	Done (2026-10-11)
9	External Secrets in core and the ClusterSecretStore pattern	infra-local	An ExternalSecret reports SecretSynced	Done (2026-10-11)
10	Zot registry in core: HTTPS, anonymous pull-through mirror, push and pull accounts, retention	infra-local	A node pulls a public image through the mirror; a pushed test image pulls with the pull account	Done (2026-10-11)
11	Keycloak in core: Google and Entra as identity brokers, realm, groups, one client per UI and per service	infra-local	Login works with both brokers	Done 2026-10-11 (Keycloak, realm, groups and the Entra broker; I signed in with Entra to kubectl on mon and to OpenBao; deferred: Google, core’s own OIDC until its next rebuild, one client per app as each arrives, revoking OpenBao’s root token)
12	mon, platform and ai clusters, each with External Secrets, its OpenBao Kubernetes-auth mount, CoreDNS forwarding and k3s OIDC flags	infra-local	Each cluster syncs an ExternalSecret; a lab-scoped store can’t read platform/*	Done 2026-10-11 (mon, platform, and ai on the GPU image with 4 time-sliced GPUs; each syncs its own secrets and is refused the others’, pulls through Zot, trusts Keycloak)
13	Argo CD in platform: repo credentials from OpenBao, every cluster registered, app-of-apps from homelab-gitops, ApplicationSets for External Secrets, ExternalDNS and cert-manager	infra-local, homelab-gitops	Every app is Synced and Healthy	Done 2026-10-11 (Argo CD in platform with Keycloak sign-in; mon and ai registered from OpenBao; the app-of-apps on main installs cert-manager, ExternalDNS and their settings on platform, mon and ai: 11 apps Synced and Healthy)
14	Private remote access through Tailscale (ADR 0037): the DGX as a subnet router for the homelab bridge, split DNS for home.cloudutsuk.com, an access policy for my devices only. Replaces the Cloudflare tunnel and Access, whose Zero Trust team asks for a payment method	infra-local, Tailscale	From my phone on mobile data, an internal UI loads with a valid certificate after a Keycloak sign-in; kubectl works from my laptop; another Tailscale user can’t reach the bridge	Done 2026-10-11 (my phone on mobile data reaches the internal UIs with valid certificates; deferred until the laptop is back: kubectl from it, and the other-user denial test)
15	Resilience basics: boot unit (start core, unseal, start the rest, re-apply the k3d host aliases that Docker drops on restart), heartbeat, and nightly backups with Velero (ADR 0039): database and OpenBao dumps taken by pre-backup hooks, encrypted by Velero’s file-system backup and kept in an Azure Blob container. R2 is out because it asks for a payment method	infra-local, infra-azure	A reboot brings everything back unsealed; a missed heartbeat alerts; a nightly backup succeeds in every cluster and last night’s core dumps restore into a throwaway cluster	Done 2026-10-11 (boot unit installed and run; heartbeat pinging healthchecks.io; Velero in core, platform and ai, first backups complete, a web UI over them; deferred: the reboot test and the first restore test)
16	Phase 0 exit: verification list, roadmap ticked, playbook updated (areas 11 and 13 scaffolded), card moved to In progress	this blog	M0’s exit check passes	Done 2026-10-11 (verification list run; card moved to In progress)

Phase 1 steps

Step	Does	Repos	Done when	Status
1	ARC in platform through Argo CD: the scale-set controller (chart 0.14.2) and two runner scale sets. homelab is registered with the org (private repos only, ephemeral pods, no host access). homelab-iac is registered with infra-local alone and gets Docker and cluster access for its IaC jobs (ADR 0040)	homelab-gitops, infra-local	A workflow job runs on each scale set, including one of infra-local’s queued IaC jobs	Done (2026-10-12: homelab ran build-set jobs; homelab-iac ran all 15 Terragrunt plans of infra-local PR #2, 14 with no changes and 1 expected change. The shared module needed three fixes for arm64 self-hosted runners (L042). Controller image pinned by digest for Kyverno)
1a	GitHub App for ARC (repo Administration read/write, Metadata read, org Self-hosted runners read/write), installed on the org; its ID, installation ID and private key in OpenBao at platform/ci	GitHub, infra-local	The ExternalSecret in arc-runners reports SecretSynced and both scale sets show as online runners in GitHub	Done (2026-10-11: cloudutsuk-arc-runners, created through the manifest flow with infra-local/host/github/create-app.py, installed on the org; the ExternalSecret is SecretSynced)
1b	Docker access through a mutual-TLS endpoint (ghostunnel on the homelab bridge, ADR 0040) and cluster access for homelab-iac, plus the IaC jobs’ own secrets: Azure login for the state backend and the shared-module read token; config.yaml runner set to homelab-iac	infra-local	A plan job for a k3d stack finishes on homelab-iac	Done (2026-10-12: in infra-local PR #2 all 15 Helm plans ran on homelab-iac with the kubeconfig and the homelab-iac-state principal, and the network stack’s plan refreshed the Docker network through the mTLS endpoint, CN=homelab-iac in ghostunnel’s log, no changes)
1c	OpenBao JWT auth for GitHub OIDC: a push role bound to main and a read-only role for pull requests (ADR 0019, ADR 0034, ADR 0043)	infra-local	A main job logs in and gets the Zot push credentials; a PR job is refused them	Done (2026-10-12: host/openbao/configure-ci.sh. Role main is bound to the org, self-hosted runners, refs/heads/main and the reusable workflow itself, so no other workflow can read the push key. Role pr reads only the pull key; secrets sit in a new ci/ area no cluster store can read. A throwaway PR was refused role main on job_workflow_ref and got 403 for the push key; the first main build signed in as main and pushed)
2	BuildKit and the reusable build workflow: build, push to Zot, commit the new digest to homelab-gitops	homelab-gitops, homelab-services	A workflow run pushes an image and opens the digest commit	Done (2026-10-12: one rootless BuildKit v0.33.0 in platform, reachable only from the runner namespace, used through docker buildx with the remote driver; build-image.yaml in homelab-gitops builds on every run, pushes and commits the digest with kustomize edit set image on main (ADR 0043). hello-world in homelab-services went through it: image pushed to platform/hello-world, digest committed to apps/hello-world by the writer App. The first push got 401 from a newline in the credential (L044))
2a	Write access for the digest commit: a second GitHub App limited to Contents read/write on homelab-gitops, its key in OpenBao	GitHub, infra-local	A workflow job mints a short-lived token and pushes a commit to homelab-gitops	Done (2026-10-12: cloudutsuk-gitops-writer, created with create-app.py (manifests/gitops-writer.json) and installed on homelab-gitops only; key at ci/gitops-writer. The promote job signs the App JWT with openssl, asks for a token limited to homelab-gitops and contents: write, pushes the commit and revokes the token)
3	Hello-world service through the whole path	homelab-services, homelab-gitops	A commit ends with an Argo CD app Synced and Healthy on the new SHA	Done (2026-10-12: FastAPI hello-world in homelab-services, deployed to platform from homelab-gitops/apps/hello-world, pulled with a zot-pull secret that External Secrets builds from shared/zot-pull. A code commit to main was built and pushed in 64 s; the digest commit followed, and Argo CD rolled it out 5.5 minutes after the push (its 3-minute poll). The app was Synced and Healthy and the pod answered with that commit’s SHA. Kyverno’s six Audit policies all pass for it)
4	Security gates in the reusable workflow: Gitleaks, Semgrep, Bandit, Trivy, Checkov, Conftest, Hadolint, Syft SBOM, Cosign signing	homelab-gitops, homelab-services	The hello-world service passes every gate and its image is signed	Done (2026-10-12: every run of build-image.yaml, pull requests included, passes Gitleaks (full history), Semgrep, Bandit, Trivy (dependencies, config), Checkov, Conftest with shared Dockerfile rules and Hadolint before building. BuildKit exports an OCI layout that Trivy scans and Syft turns into a CycloneDX SBOM, and on main crane pushes those same bytes, Cosign signs them and attests the SBOM. hello-world passes every gate, and its deployed image’s signature and SBOM attestation verify with the committed public key. A deliberately bad commit (unpinned base image, root user, shell=True) was blocked by six gates before anything was built. Reports: job summary and a security-reports artifact (ADR 0032, 0033 as built)
4a	Cosign key in OpenBao’s transit engine and a signing policy only main builds can use (ADR 0033)	infra-local	cosign sign with the transit key works from a main job and fails from a PR job	Done (2026-10-12: transit key cosign (ECDSA P-256, not exportable) set up by configure-ci.sh; only the main role, bound to the reusable workflow, may sign. build-image.yaml signs every main image with Cosign v3.1.3 (hashivault://cosign, no transparency log); the signature is a Sigstore bundle stored as an OCI referrer in Zot and verifies with the committed public key. In a throwaway PR, role main was refused and role pr got 403 from the transit sign call. First try failed: Cosign signs at transit/sign/cosign/sha2-256, so the policy needs the sub-path)
4b	homelab runner image with the CI tools baked in (ADR 0044): stock actions-runner plus the pinned scanners, built and signed by build-image.yaml, rolled out by hand	homelab-gitops	Gate jobs on the homelab runners use the baked tools and skip the downloads	Done (2026-10-12: tool set in ci/tools (sha256-pinned binaries, hash-locked Python tools, one installer); platform/actions-runner builds through build-image.yaml, signed with an SBOM attestation, and runs the homelab scale set, pulled from Zot. The tools step went from 2 to 7.5 minutes to under a second; a gated pull request build takes 45 s and a full main build with deploy commit about 70 s. The image gate only reports for this image: 255 fixable CVEs in the stock runner and in the newest tool releases can only be fixed upstream (ADR 0044)
4c	Unit tests and lint in each service’s pull request gate (ADR 0031): a test job runs ruff and pytest from the locked workspace before the image job, which needs it	homelab-services	A failing test or lint finding fails the PR before anything is built	Done (2026-10-13: hello-world’s workflow runs Ruff (lint and format) and pytest from uv.lock in a test job that the image job needs. In a throwaway pull request a deliberately broken assertion failed the job in 13 s and the image job never started; on main the job takes 13 s. Found while writing the CI/CD area: the tests existed, but nothing in CI ran them)
5	Kyverno in every Argo CD-managed cluster (platform, mon, ai; labs once they register) through an ApplicationSet, and ADR 0033’s policies in Audit mode first; each moves to Enforce once its policy reports are clean or its exceptions are written down. Signature checks wait for step 4a, the registry rule for step 3	homelab-gitops	Kyverno is Healthy everywhere and the hello-world app passes its policies	Done (2026-10-12: Kyverno 1.19.1 Synced and Healthy on platform, mon and ai; seven CEL policies. disallow-latest-tag, restrict-image-registries and verify-image-signatures deny at admission; the last checks the Cosign signature and the signed SBOM of every platform/* and labs/* image. hello-world passes all seven. Tested by dry runs: :latest, an unmirrored registry, an unsigned image and an image signed without an SBOM were denied, and a signed image was admitted; CI jobs still start on the signed runner image. One written exception (Argo CD’s Redis registry). Kyverno resolves an image index to amd64, so images are now built as single arm64 manifests. The other four policies stay in Audit, with their third-party violations listed in the chart’s README (step 5a))
5a	Move the four Audit policies (require-image-digest, pod-security-restricted, require-read-only-root-fs, require-requests-limits) to Deny: chart values for digests, security contexts and resources, written exceptions for what can’t comply (BuildKit, Velero’s node agent), and Argo CD’s Redis image through Zot in infra-local	homelab-gitops, infra-local	Every Kyverno policy is in Deny and its reports are clean or excepted	Done (2026-10-13: all seven policies deny on platform, mon and ai, and the reports are clean. Every add-on meets them through its chart values: public images pinned by their upstream digest, restricted security contexts, read-only roots and requests with a memory limit, Helm hook jobs included. Argo CD’s Redis comes from Docker Hub through Zot, and Mimir’s data reaches its pod through a PV instead of a hostPath. Four written exceptions: rootless BuildKit, the log-tailing agent collector, Velero’s node agent, and the runners’ writable home. Server-side dry runs on all three clusters denied an unpinned image, root, a hostPath, a writable root and missing limits (also in a Deployment) and admitted a compliant pod. Kyverno’s chart ships with exceptions off at admission while reports still honour them, so CI runners were refused for 19 minutes until the feature was turned on (L051). Every Argo CD app now retries with refresh (ADR 0033 as built))
6	PostSync smoke-test pattern	homelab-gitops	The hello-world PostSync test runs, and a failing test fails the sync	Done (2026-10-12: apps/hello-world/smoke-test.yaml, a PostSync hook Job with a pinned curl image, checks /readyz, / and that the revision is a commit SHA, and passes every Kyverno policy. A Service pointed at a wrong port left the Deployment Healthy but failed the test and the sync. Argo CD then kept retrying the broken commit and ignored the fix, until syncPolicy.retry.refresh made the next retry sync the fix a minute after it was pushed. No automatic rollback: a failed test fails the sync, and the rollback is a revert (ADR 0031 as built))
7	Phase 1 exit: ADRs synced, CI/CD area written with the commit-to-deploy diagram and the testing and security matrix, roadmap ticked	this blog	M1’s exit check passes	Done (2026-10-13: M1 passed again on the live system: a hello-world commit was Healthy on its SHA 8 min 25 s after the push. The CI/CD and Release Management area is written with the commit-to-deploy diagram (now as built) and the testing and security matrix; ADRs synced; the Phase 1 readiness review is in Deployment and Go-Live)

Phase 2 steps

Phase 2 runs alongside Phase 1 (decided 2026-10-11): its third-party charts install through the Argo CD that Phase 0 already runs and need no CI, so it depends on Phase 0 only.

Step	Does	Repos	Done when	Status
1	mon workloads through Argo CD: LGTM, gateway collector, Alertmanager	homelab-gitops	Grafana on mon serves a valid certificate and its data sources are healthy	Done (2026-10-12: Mimir with its Alertmanager, Loki, Tempo, Grafana with Keycloak sign-in and the OTLP gateway on mon, ADR 0041; valid certificates, all four data sources healthy, a metric, log and trace sent to otlp.mon.home.cloudutsuk.com arrived with their cluster label)
2	Host exporters: node-exporter, DCGM, cAdvisor, blackbox	infra-local	Every exporter target is up in mon	Done (2026-10-12: node-exporter, DCGM, Docker cAdvisor and blackbox as a Compose project in infra-local host/exporters, on 172.30.0.1; all 10 targets up in mon as cluster dgx. The GB10 reports 11 DCGM fields, no framebuffer, XID or row-remap fields)
3	Monitoring-pack ApplicationSet for every cluster, labs included: OTel Operator, collectors, kube-state-metrics, ServiceMonitor CRDs	homelab-gitops	The kubernetes-mixin dashboards show every cluster in the cluster drop-down	Done (2026-10-12: OTel Operator, kube-state-metrics, Prometheus CRDs and two collectors with a target allocator on platform, mon and ai, each sending with its own token, ADR 0042; the cluster drop-down lists all three and the mixin’s recording rules fill. Labs join with contract v2, step 5)
4	Fleet, Kubernetes and Platform dashboard folders and the mixin alert rules, as code (ADR 0027)	homelab-gitops	No “No data” panels for deployed components; fleet memory per cluster matches docker stats; killing a pod fires an alert	Done (2026-10-13: Kubernetes, Fleet and Platform folders in Grafana. The Platform folder holds Argo CD, External Secrets, Kyverno, Traefik and cert-manager at the versions that run, plus Velero backups and the OpenTelemetry collectors written here; their metrics come from ServiceMonitors switched on in each chart, a Traefik PodMonitor and the collectors’ own. 195 alert rules, including Argo CD drift, ExternalSecret failures, OpenBao sealed, Velero backups and a cluster that stops reporting. Alertmanager sends warnings and critical alerts to Slack and the Watchdog to healthchecks.io, both tested. scripts/panel_check.py ran 925 panel queries across every cluster: none empty without a listed reason. Per-cluster memory matches the host’s Docker view within 1-2%; a crash-looping pod raised KubePodCrashLooping (2026-10-12). Database alerts wait for the first database. 2026-10-15: an alertmanager-sync Job also loads the Alertmanager config through Mimir’s API after each sync and hourly, so Grafana’s Alerting pages show the contact points and policies (L070))
4a	AI dashboard folder and alert rules, as code (ADR 0027): DCGM GPU, vLLM and LiteLLM dashboards vendored and pinned, GPU and vLLM alert rules	homelab-gitops	The AI folder shows data for the ai cluster’s GPUs and models; a stopped vLLM pod fires an alert	Done (2026-10-13: the embeddings model from ADR 0010 (Qwen3-Embedding-0.6B on vLLM 0.24) runs in ai, the first app of the new cluster-ai, and passes all seven Kyverno policies without an exception. Under light traffic every AI / vLLM panel has data and the host’s DCGM exporter shows the GPU working (the ai cluster’s GPU is the DGX’s one GB10, ADR 0026). A model server that isn’t running fires VLLMNotServing: on the first deploy the pod couldn’t pull its 22 GB image for 15 minutes while Zot mirrored it, the alert fired after its 10 minutes and reached Slack, and it resolved when the pod became ready. VLLMTargetDown missed it once the pod was gone (L059). LiteLLM’s dashboard fills in Phase 5)
5	Lab contract v2: the lab cluster joins the homelab network, the lab card gets deploy.memory_gb and deploy.ports, OTLP goes to mon with no bundled LGTM; learning-lab skill updated	this blog	The contract is documented and new labs are created to it	Done (2026-10-14: the contract is written in the learning-lab skill and in Infrastructure and Environments, and the skill’s new default template k3d-platform scaffolds labs to it. A lab made from the template went through make up, its first metrics were verified in mon, and make down left nothing behind. The eBPF lab runs on it, with metrics, logs and traces in mon. The host scripts wait on an infra-local PR)
6	Migrate the two existing labs to contract v2 and update their posts’ setup steps	lab repos, this blog	make up on each lab gets the monitoring pack and its signals appear in mon	Done (2026-10-14: both labs ran make up from scratch on the homelab network and registered themselves with infra-local/host/labs/lab.sh; Argo CD installed cert-manager and the monitoring pack, and make down unregisters first. The OpenTelemetry lab is now cluster lab-otel with no bundled LGTM: its Collector sends to mon’s gateway with the shared labs token, its dashboard is in Grafana’s Labs folder, the Trace Lab page queries mon through nginx with a Viewer token, and all six verify targets pass against mon. The eBPF lab’s metrics, pod logs and OBI traces and RED metrics arrive under cluster lab-ebpf; OBI sends straight to the gateway because host-network pods in nested Cilium reach neither Services nor mon’s names (L065). Every query in both cards, the posts and the lab repos is filtered on the lab’s cluster (L067). The OpenTelemetry lab’s posts describe the new setup; the eBPF lab’s posts aren’t written yet. Lab repos left uncommitted for review)
7	Phase 2 exit: ADRs synced, Operations and Observability area started with real dashboard screenshots, roadmap ticked	this blog	M2’s exit check passes	Done (2026-10-15: M2 passed. The eBPF lab’s metrics, logs and traces reach mon with nothing lab-specific on the platform: it joins through its own make up. A crash-looping test pod on ai raised KubePodNotReady after its 15 minutes, then KubePodCrashLooping, both routed to Slack, and both cleared within 6 minutes of deleting it. The Operations and Observability area is written with real dashboard screenshots; ADRs synced)

Phase 3 steps

Step	Does	Repos	Done when	Status
1	Backstage custom image built through CI and deployed by Argo CD, with its database: platform-db (Postgres 17, database backstage, ADR 0035) and Velero’s nightly dump of it	self-service-portal, homelab-gitops	A portal commit redeploys Backstage	Done (2026-10-13: a portal commit was live on its new digest, with the smoke test passed, 9 min 44 s after the merge. The portal runs on platform at its internal address with a valid certificate, and Kyverno admits the signed image by digest. platform-db holds its 21 plugin schemas, and its backup dump was tested by hand. The Labs page lists the blog’s three labs. Tests run in a Dockerfile stage on BuildKit, because the runners have no compilers)
2	Keycloak sign-in for the portal (needs Phase 0 step 11): a confidential portal client, groups in the Backstage identity, a permission policy (reads for everyone signed in, changes and lab deploys for platform-admins), guest removed	self-service-portal, infra-local, homelab-gitops	Sign-in works through Keycloak with both brokers	In progress (2026-10-13: sign-in works through Keycloak and the Entra ID broker; guest is off; the permission policy gives changes and lab deploys to platform-admins only. Left: the Google broker, deferred since Phase 0)
3	Labs plugin (frontend and labs-backend) on the lab-runner API contract	self-service-portal	The Labs page lists every lab and drives the lab runner	Done (2026-10-14: deployed in the portal; it lists the blog’s labs and drives the lab runner. Deploy and Destroy worked from the portal. A pull request keeps a job’s log across page reloads)
4	Lab runner: deploy and destroy, admission control, TTL, Argo CD cluster registration, streamed logs	homelab-services	Deploy and Destroy from the portal create and delete the cluster and register and unregister it in Argo CD	Done (2026-10-14: installed on the DGX as a host service on the homelab bridge, with the portal connected through a token from OpenBao. M3 passed from the portal: Deploy of the OpenTelemetry lab ran its make up in 8 min 48 s, registered lab-otel in Argo CD with its monitoring pack Healthy, and the lab’s metrics, logs and traces checks passed in mon. Destroy ran make down in 2 s and removed the cluster, its registration and its dashboard. Admission control refused a deploy whose ports were taken. Follow-ups: reconcile labs started outside the runner through their status target; turn Deploy off on the card when ports are taken; the runner’s records move to platform-db later)
4a	Lab hostnames: a labs gateway (Traefik on the host, bridge address 172.30.0.5, reachable over the tailnet), one wildcard DNS record *.labs.home.cloudutsuk.com, a Let’s Encrypt wildcard certificate per lab, and routes that lab.sh register writes for each Service a lab publishes, so lab UIs open by name from anywhere on the tailnet	infra-local, this blog	https://hubble-ui.ebpf.labs.home.cloudutsuk.com opens the eBPF lab’s Hubble UI from a tailnet device with a valid certificate, and the route goes away with make down	In progress (2026-10-15)
4b	Sign Argo CD’s webhook: a GitHub webhook secret for Argo CD (webhook.github.secret in argocd-secret, its value from OpenBao, never in git), and the build workflow’s promote job signs its push event with it (X-Hub-Signature-256). Today the endpoint accepts unsigned events, which can only trigger a refresh	infra-local, homelab-gitops	An unsigned or wrongly signed event to Argo CD’s webhook is refused, and a portal or hello-world build still refreshes Argo CD right after its digest commit	Planned (2026-10-15)
5	deploy: blocks on the lab cards	this blog	Every deployable lab card has one and the lab runner reads it	Done (2026-10-11: both lab cards have one and the runner’s card loader accepts them; the learning-lab skill scaffolds and checks it)
6	Argo CD plugin in the portal, with the application groups of step 6a as tabs	self-service-portal	Each app’s sync and health status shows in the portal, one tab per group	Not started
6a	Application groups (ADR 0047): one Argo CD AppProject per area (platform, monitoring, security, ai, labs), each allowing only its own sources and clusters, mirrored as the label homelab/group on every Application; a Group variable and a Groups row on Grafana’s Argo CD dashboard. Codefresh’s Application Groups were considered and rejected: they show only in Codefresh’s hosted UI and need an account, a tunnel and a non-expiring admin token	homelab-gitops	Every Application except the app-of-apps is in its group’s project and Synced; the Argo CD UI filters by group; the dashboard’s Groups row shows each group	Done (2026-10-15: 54 Applications in five groups (monitoring 20, security 12, platform 11, ai 6, labs 5), all Synced with no spec errors; the app-of-apps stay in default; Grafana’s Group variable and Groups row show the same counts from Mimir)
7	Dashboard tab on the blog	this blog	TODO: decide what the tab shows	Not started
8	Lab-deploy sequence and portal user-journey diagrams	this blog	Both are drawn and in the Diagrams lane	Not started
8a	Monitoring the monitoring: ServiceMonitors for Mimir (with its ruler and Alertmanager), Loki, Tempo and Grafana in mon; their upstream mixin dashboards in a Monitoring folder; and an Alerts overview dashboard (rules configured, normal, pending and firing, alerts by group, severity and cluster, notifications sent and failed)	homelab-gitops	The Monitoring folder has no unexplained empty panels and the Alerts overview’s counts match Grafana’s alert rule list	Done (2026-10-15: ServiceMonitors for Mimir, Loki, Tempo and Grafana (about 12,000 series); 22 mixin dashboards pointed at the single binaries, plus Alerts overview and LGTM health, in a Monitoring folder; an alert-rule inventory makes 118 rules = normal + pending + firing + Watchdog; panel_check.py lists a reason for every empty panel. The mixins’ alerts aren’t used: they assume microservices)
8b	Hermes Agent (Nous Research) on platform: the gateway and its dashboard at hermes.platform.home.cloudutsuk.com, signed in through Keycloak for platform-admins only, with the chat model through LiteLLM (gpt-oss-20b at 64k, then qwen3.5-35b-a3b at 128k, ADR 0048, ADR 0049)	homelab-gitops, infra-local	A platform admin signs in and chats with Hermes; anyone else is refused	In progress (2026-10-16: deployed. Hermes v0.21.5 runs as uid 10000 without its s6 init, Synced and Healthy; vllm-chat at 64k; Keycloak client hermes behind the browser platform-admins only flow (infra-local #12); the URL serves a Let’s Encrypt certificate and redirects to Keycloak; a chat through Hermes, LiteLLM and vLLM answered in 6 s. Left: a platform admin signs in from a browser)
9	Phase 3 exit (MVP): ADRs synced, Security, Infrastructure, CI/CD and Operations areas brought up to date, roadmap ticked	this blog	M3’s exit check passes	Not started

Phase 3a steps

Step	Does	Repos	Done when	Status
1	Playwright journeys for the portal	self-service-portal	The journeys run in CI and pass	Not started
2	Schemathesis on every service	homelab-services	Every service’s PR gate runs it against its OpenAPI spec	Not started
3	Nightly OWASP ZAP scan	homelab-gitops	The nightly scan runs and its findings reach the Security dashboards	Not started
4	Locust load scenarios and the first performance baseline	homelab-services	The baseline is recorded and SLO targets are set from it (ADR 0020 accepted)	Not started
5	Performance and Security dashboard folders	homelab-gitops	Both folders are provisioned in mon with data	Not started
5a	Central findings store: open-source DefectDojo (OWASP, BSD-3) in platform, so the scan results outlive the 30-day security-reports-<image> artifact (ADR 0032 names it as the gap). build-image.yaml re-imports every report (Gitleaks, Semgrep, Bandit, Trivy, Checkov, Hadolint, the CycloneDX SBOM) through the API, one product per repo; sign-in through Keycloak; its token and database password in OpenBao. Its own database or platform-db is decided in the step’s ADR	homelab-gitops, infra-local	Every CI run, pull requests included, lands its findings in DefectDojo, de-duplicated across runs, and platform-admins can open them with SSO	Not started (2026-10-16: version 3.4.101 checked: the django and nginx images are built for arm64, Helm chart 1.9.57)
5b	SBOM inventory: OWASP Dependency-Track (Apache-2.0) in platform. Today the signed CycloneDX SBOMs sit in Zot as attestations and nothing shows their contents. build-image.yaml uploads each main build’s SBOM (the attested one) through the API, one project per image with the git SHA as the version; Dependency-Track re-checks every SBOM against new CVEs daily, applies licence and component policies, and sends its findings to DefectDojo (step 5a). Sign-in through Keycloak; it needs PostgreSQL (its own or platform-db, decided in the step’s ADR)	homelab-gitops, infra-local	Every main image’s components, licences and open CVEs are visible in one dashboard, and a new CVE in a running image shows up without a rebuild	Not started (2026-10-16: version 5.2.0 checked: the apiserver and frontend images are built for arm64, Helm chart 2.8.0, PostgreSQL only)
6	Phase 3a exit: QA area written, roadmap ticked	this blog	Every step above is done	Not started

Phase 4 steps

Step	Does	Repos	Done when	Status
1	Azure, AWS and GCP collectors (GCP through the billing export), every 6 hours plus “Sync now”	homelab-services	Each provider’s resources and cost land in the inventory database	Not started
2	DGX collector with a power-based cost estimate	homelab-services	The DGX has its own cost line (needs the electricity tariff)	Not started
3	lab tag convention and AWS cost allocation tag activation	cloud IaC repos	A lab-tagged resource is attributed to its lab	Not started
4	Inventory & Cost plugin in the portal	self-service-portal	Portal cost matches each provider’s console within a day; Sync now refreshes the data	Not started
5	Budget alerts	homelab-gitops	A budget threshold fires an alert (TODO: thresholds)	Not started
6	Phase 4 exit: ADRs synced, playbook updated, roadmap ticked	this blog	M4’s exit check passes	Not started

Phase 5 steps

Step	Does	Repos	Done when	Status
1	ai workloads: vLLM chat and embeddings behind the LiteLLM gateway; first chat model and its licence chosen in an ADR	homelab-gitops	The gateway answers an authenticated client and the model ADR is accepted	In progress (2026-10-15: ADR 0046 proposes gpt-oss-20b, Apache 2.0, in a 0.17 slice of unified memory, about 21 GB, because the DGX had 39 GB free rather than the 81 GB planned. Tested in ai on the exact manifest: weights 13.8 GiB, KV cache 113,900 tokens, answers in 2 s, tool calls work, about 50 tokens a second. Every request first failed on a tokenizer file the non-root pod couldn’t download (L069). LiteLLM v1.103.1, ai-db, vllm-chat and their Argo CD apps are written; LiteLLM was tested read-only and non-root against Postgres, with 401 without a key and a virtual key limited to its models. JWT auth is Enterprise-only, so callers get virtual keys (ADR 0029). Left: seed the OpenBao secrets, sync, call the gateway with a virtual key over HTTPS, accept ADR 0046. 2026-10-16: secrets seeded, LiteLLM and ai-db running, Hermes Agent called the gateway with its own virtual key over HTTPS. gpt-oss-20b then broke long tool-calling runs on malformed Harmony output, so ADR 0049 replaces it with Qwen3.5-35B-A3B (FP8, Apache 2.0, 3B active, 128k context, about 44 GB) in the same vllm-chat app; ADR 0046 is superseded)
2	Qdrant and the Redis cache	homelab-gitops	Both are Healthy in ai	In progress (2026-10-15: Qdrant 1.19.1 (API key, UI at qdrant.ai.home.cloudutsuk.com) and Redis 8.10.2 (password; its plain image includes the Query Engine RedisVL needs) are written, each on a static PV and with a NetworkPolicy admitting only the rag namespace. Left: seed their secrets and sync)
3	rag-ingest: incremental indexing every 6 hours plus “Re-index now”	homelab-services	Re-index now picks up a new post	Not started
4	rag-api: semantic cache, hybrid retrieval, citations	homelab-services	The same question asked twice hits the cache	Not started
5	Chat plugin with citations and “View trace”	self-service-portal	The chat cites the new post and “View trace” opens its trace	Not started
6	Arize Phoenix	homelab-gitops	Phoenix shows the full trace for a cache miss and a cache hit	Not started
7	Golden question set and evaluation runs: a scheduled job scores the chat model and the RAG pipeline on a fixed question set and publishes the scores to Mimir for an “Evaluations” row in Grafana. Text quality against reference answers (exact match, BLEU, ROUGE-N and ROUGE-L, BERTScore, COMET; perplexity from the model’s log-probabilities) and RAG quality with a judge model (faithfulness and hallucination rate, answer relevancy, context recall, context precision). Speed and efficiency (TTFT, inter-token latency, throughput, latency, tokens and cost) come from serving metrics on AI / Model performance and usage (done 2026-10-16)	homelab-services, homelab-gitops	An eval run scores every golden question and the scores show in Grafana per model and run	Not started (serving metrics done 2026-10-16)
8	rag-chat data-flow diagram	this blog	It’s drawn and in the Diagrams lane	Not started
9	Phase 5 exit: ADRs synced, playbook updated, roadmap ticked	this blog	M5’s exit check passes	Not started

Phase 6 steps

Step	Does	Repos	Done when	Status
1	Alertmanager webhook into the sre-agent	sre-agent, homelab-gitops	A firing alert reaches the agent	Not started
2	Read-only multi-cluster access with short-lived tokens	sre-agent, homelab-gitops	The agent’s Kubernetes token expires after 15 minutes and it can’t change anything	Not started
3	RAG and mon tools for the agent	sre-agent	An RCA cites the right lab doc and the metrics behind it	Not started
4	Eval suite built from lab experiments	sre-agent	The evals pass	Not started
5	Alert-agent incident diagram	this blog	It’s drawn and in the Diagrams lane	Not started
6	Phase 6 exit: ADRs synced, playbook updated, card moved to Live	this blog	M6’s exit check passes	Not started

MVP definition

The MVP is phases 0 to 3. At that point I can:

• sign in from anywhere with SSO
• see every lab
• deploy or destroy one with a click
• watch it in one Grafana
• ship changes to the platform itself through CI and Argo CD

Cost, chat and the agent are valuable, but they’re layers on top. The MVP is also the point where this playbook gains its Security, Infrastructure, CI/CD and Operations posts, because by then there’s something real to describe.

Release milestones

Each phase ends with the same exit steps:

1. Its verification passes.
2. New decisions are written as ADRs and synced to the blog.
3. The playbook posts are updated, and the card’s status moves on (Planning, then In progress, then Live).

Milestone	Exit check
M0 Design approved	The three animated diagrams are approved; nvidia-smi works in a test pod (or the plain-container fallback is accepted); cloudutsuk.com still serves after the DNS move
M1 Commit to deploy	A commit to a hello-world service ends with an Argo CD app Synced and Healthy on the new SHA
M1a One placement	A new cluster labelled lab gets the shared add-ons from Karmada with no other change; Argo CD shows them Healthy through Karmada; removing the cluster removes them. If the trial fails, the ApplicationSets stay and this milestone is dropped
M2 One Grafana	A lab’s signals appear in mon without changing the lab; killing a pod fires an alert
M2a Chaos	A pod-delete experiment from ChaosCenter in core runs on a lab, its probe passes, and the fault and its alert show side by side in Grafana; no experiment can target a node
M3 MVP	Deploy and Destroy from the portal create and delete a cluster and register it in Argo CD
M4 Cost	Portal cost matches each provider’s console within a day; a lab-tagged resource rolls up under its lab; every k3d cluster’s OpenCost reports, and a lab’s DGX cost and cloud cost show together
M5 Chat	A new post is cited after “Re-index now”; the same question again hits the cache
M6 Agent	An injected lab fault produces an RCA in Slack that cites the right doc; evals pass

TODO: Target dates per milestone. Dates aren’t set yet; add them once phase 0 shows how fast the work goes.

Backlog structure

Epics map one to one to phases, and each epic lives in the repo that does most of the work:

Epic	Main repo	Example stories
Foundation	infra-local, infra-github	Create repos; k3d clusters via k3d_config_cluster; GPU spike
GitOps + CI/CD	homelab-gitops	App-of-apps; ARC runner scale sets (homelab for builds, homelab-iac for infra-local); image tag write-back
Monitoring	homelab-gitops	LGTM values; ApplicationSet for lab collectors; Watchdog heartbeat
Multi-cluster management	homelab-gitops, homelab-services	Karmada trial; control plane values; propagation and override policies per add-on; lab runner register and unregister
Chaos engineering	homelab-gitops	ChaosCenter Helm values in core; agent ApplicationSet; experiment library with probes; game-day runbook
Portal + labs	self-service-portal, homelab-services	Auth providers; Labs plugin; lab-runner lock and admission control
Inventory + cost	homelab-services, homelab-gitops	Azure collector; AWS collector; GCP billing export; DGX power estimate; OpenCost in the monitoring pack with custom DGX prices; daily OpenCost allocation into COST_DAILY
RAG + chat	homelab-services, homelab-gitops	Incremental ingest; semantic cache; Chat plugin with citations; KEDA ScaledObject for each on-demand model
Alert agent	sre-agent	Alertmanager webhook; RAG tool; eval cases from lab experiments
Later (deferred)	a new lab repo, then infra-local	Cilium on k3d as a lab first; the long-lived clusters only if the lab passes (why deferred)
Playbook	this blog	Area posts per phase; ADR sync; diagrams

Issues live on GitHub in each repo, labelled by epic.

Prioritization approach

Dependencies come first, then whatever removes the most risk. That’s why phase 0 includes a GPU-in-k3d spike before anything is built on top of it. If vLLM can’t see the GB10 inside k3d, ADR 0010 switches to running it as a plain container on the shared Docker network. Better to learn that in week one than in phase 5. Inside a phase, I pick the story that makes the phase’s exit check pass soonest, and polish waits.

Budget and resource planning

Item	Cost
Platform hosting (DGX, Cloudflare free plan, GitHub free self-hosted runner minutes)	$0
Backups (Velero to an Azure Blob container, Cool tier, under 1 GB)	a few cents a month
Dead-man’s switch (healthchecks.io free plan)	$0
AWS Cost Explorer API (about one call a day)	about $0.30 a month
GCP billing export to BigQuery	Inside the free tier, expected
Cloud labs	Only while deployed, capped by the TTL
Electricity for the DGX	TODO

The real constraint isn’t money. It’s memory on the DGX (see Scalability) and my evenings.

TODO: What’s the electricity tariff per kWh? It’s needed for the DGX’s own line in the cost dashboard, and for OpenCost’s custom prices on every k3d cluster.

Risk and dependency management

Risk	Likelihood	Impact	Mitigation
GPU not usable inside k3d on arm64	Closed 2026-10-11		The test passed: vLLM runs inside k3d on the GB10
Some images have no arm64 build	Medium	Delays	Check every chart’s images in phase 0; build our own where needed
DNS move breaks the blog	Low	The blog goes offline	DNS-only records for GitHub Pages; check curl -I before and after
Memory exhaustion	Medium	Monitoring or the portal starves	Budget table, limits, PriorityClasses, lab admission control
A chaos experiment hits the whole DGX (node stress on k3d, a fault in core)	Low	Every cluster, and the desktop, at once	Pod-level faults only; annotation check; core only in a planned game day; ChaosCenter LAN-only and admins only
ChaosCenter adds memory and a MongoDB to core	Medium	core is less small and stable (ADR 0025)	Measure it in the spike; if it doesn’t fit, ChaosCenter moves to mon and only the agents stay
Karmada duplicates what Argo CD already does and costs ~2.5 GB	Medium	Two tools to learn and debug for the same fan-out	Narrow role (shared add-ons only); a trial with an exit check; ApplicationSets stay as the fallback; first to go if memory is tight
Self-hosted runners abused	Low	Code execution on the DGX	Private repos only; ephemeral runners
Prompt injection through logs reaches the agent	Medium	A bad change proposed	Read-only RBAC; approval for every change; fixes as PRs
Scope creep	High	Nothing ships	MVP is phases 0–3; new ideas go to the backlog via change control

Change-control process

There’s one decider, so this stays light:

1. A change that alters a decision gets a new ADR in homelab-gitops that supersedes the old one, in the same PR as the code.
2. A new feature becomes a backlog issue tagged with its phase. It doesn’t join the current phase unless it unblocks the exit check.
3. A change to the diagrams is made in the same change as its ADR, so the blog never shows the old design.
4. At the end of each phase, the playbook is updated, and that’s the point where changes become public.

Checklist

• Phase 0 exit check passed and status moved in the roadmap table (2026-10-11)
• Milestone dates added once phase 0 is done
• Electricity tariff recorded
• Epics created as GitHub issues in each repo
• GPU spike result written into ADR 0010
• arm64 image check done for every planned chart, including LitmusChaos and its MongoDB
• Every step added to its phase’s table before work on it starts, and its status updated with the work
• ADR for LitmusChaos in core written in homelab-gitops and synced
• ADR for OpenCost on every k3d cluster written in homelab-gitops and synced
• ADR for KEDA (on-demand models in ai) written in homelab-gitops and synced
• ADR for Karmada written in homelab-gitops, and accepted or dropped after the phase 1a trial

• This post and the project card status updated at the end of every phase
