Cloudutsuk Platform: Requirements Gathering

The requirements for this platform came from one long message, and the hard part wasn’t collecting them. It was noticing which ones pull against each other. “Public with SSO” and “no hosting cost” meet in Cloudflare’s free plan. “Run a local LLM” and “run several lab clusters” compete for the same 121 GB of memory. Those tensions shaped the non-functional requirements more than any feature did.

Living playbook. These requirements are the planning baseline. Changes go through the change-control process and this post is updated at the end of each phase.

Functional requirements

ID	Requirement
F1	Sign in with Entra ID (Google later) through Keycloak; only my devices reach the platform, over Tailscale
F2	List every resource on the DGX (k3d clusters, containers, GPU use), in Azure, AWS and GCP
F3	Show cost per resource, grouped by lab, repo and environment, with a “last synced” time
F4	Refresh inventory and cost every 6 hours, plus a manual “Sync now”
F5	List every lab from the blog’s lab cards, with status, links and estimated cost
F6	Deploy or destroy a lab with one click, with streamed logs; cloud labs ask for confirmation
F7	Every lab cluster sends traces, metrics and logs to one central monitoring cluster
F8	Dashboards and alert rules in that monitoring cluster cover every cluster
F9	A chatbot answers questions about my setup from the repos and live data, with citations
F10	The knowledge base re-indexes every 6 hours, plus a manual “Re-index now”
F11	Answers to repeated questions come from a semantic cache
F12	The chatbot runs on a local model served on the DGX
F13	An alert triggers an agent that investigates with the LLM and the knowledge base and posts an RCA
F14	Any change the agent proposes needs my approval and goes through GitOps
F15	A commit to a platform repo builds an image locally and Argo CD deploys it
F16	Architecture decisions are recorded as ADRs and published on the blog
F17	Planned faults can be injected into any cluster from one open-source chaos tool (LitmusChaos, run from the core cluster), with experiments kept in git and each run scored by probes
F18	The add-ons every cluster needs are placed by one policy per add-on (Karmada), by cluster label, so a new cluster gets them without any per-cluster change
F19	Every k3d cluster reports what it costs on the DGX, by namespace and pod (OpenCost), and that cost appears in the portal next to the cloud costs, per cluster and per lab

Non-functional requirements

The platform runs on one machine, so these requirements aim at recovery and visibility rather than redundancy. The reasoning is in Resilience and disaster recovery.

Attribute	Requirement
Cost	$0 a month to host the platform; cloud labs have a TTL (default 4 hours)
Availability	Portal 99% monthly (proposed); I’m alerted from outside the DGX when it’s down
Recovery	RTO 1 hour, RPO 24 hours; clusters restart on their own after a reboot
Capacity	Fits in ~121 GB unified memory; a deploy that would exceed the budget is refused
Performance	Chat time to first token under 3 s at p95 (proposed); alert to RCA under 5 minutes
Security	Two SSO gates; read-only credentials for inventory and the agent; no inbound ports
Freshness	Inventory and knowledge at most 6 hours old, shown in the UI
Degradation	Stale data shows a badge instead of an error; chat works without the LLM in retrieval-only mode
Operability	Every platform component sends OTEL signals to the mon cluster
Maintainability	Everything rebuilds from git; chart and image updates come as PRs

User journeys and use cases

“What’s costing me money?” I open the portal on my phone. Cloudflare asks for my Google login, and Backstage opens on the Inventory page. The cost view grouped by lab shows the Azure private endpoint lab still running from yesterday. I click Destroy, confirm, and watch the logs stream until it’s gone.

“Try a lab from the blog.” I open the Labs tab and pick the OpenTelemetry lab. The tile shows it needs about 4 GB and there’s room. One click runs make up, and the lab runner registers the new cluster with Argo CD. A minute later its traces show up in the central Grafana.

“Where did I set that?” I ask the chatbot which subnet the Azure dev VNet uses. It answers from the infra-azure YAML and links the file.

“Something broke at night.” A lab pod crash-loops and Alertmanager fires. The SRE agent reads the pod’s events and logs, finds the lab’s runbook in the knowledge base and posts a root cause in Slack, with a proposed fix waiting for my approval.

(These are target journeys, not things that have happened yet.)

Acceptance criteria

• F1: Given a Tailscale user who isn’t me, when it tries any platform address, the tailnet policy drops it; and given someone on my network without a Keycloak account in the homelab realm, every tool’s own sign-in refuses them.
• F3: Given a resource tagged lab=azure-private-endpoint-lab, when costs sync, its cost appears under that lab within one sync cycle of the provider publishing it.
• F6: Given a lab is deploying, when Deploy is clicked again, the second request is refused (per-lab lock).
• F6: Given less free memory than the lab’s declared size plus headroom, when Deploy is clicked, the deploy is refused with the reason shown.
• F7: Given a new lab cluster, when it’s registered, its signals appear in mon without changing the lab’s own code.
• F10: Given a new post is pushed, when “Re-index now” runs, the chatbot can cite it.
• F13: Given an injected fault from a lab experiment, an RCA citing the right lab doc is posted within 5 minutes.
• F14: No change is made to any cluster without an approval record.
• F17: Given a pod-delete experiment from homelab-gitops, when it runs on a lab from ChaosCenter, its probe result and resilience score are recorded, and the fault shows in Grafana next to its effect.
• F17: Given an experiment that targets a node, or a workload without the chaos annotation, when it’s started, it doesn’t run.
• F18: Given a new lab cluster registered with the lab role, when it joins, the monitoring pack and the other shared add-ons are running on it without a change to homelab-gitops.
• F19: Given a lab that ran for a day, when the daily cost sync runs, the portal shows that lab’s DGX cost from OpenCost next to its cloud cost, and the DGX costs of all clusters add up to the DGX’s own hourly cost for that day.

Business rules

• Cloud labs always show their estimated cost before deploy, and destroying one always needs a confirmation.
• A cloud lab past its TTL warns 30 minutes before, then is destroyed (with confirmation, or automatically if enabled).
• Only one deploy or destroy runs per lab at a time.
• The agent never writes to a cluster directly. Fixes become PRs to homelab-gitops.
• _posts/private/ and .env* files are never indexed.
• Self-hosted CI runners only serve private repos.
• Chaos experiments are pod-level only and start on lab clusters. The core cluster is a target only in a planned game day, and ChaosCenter is never published to the internet.

Reporting and analytics requirements

The reports I want are views over the inventory store and mon, not a separate BI tool:

• Cost: by cloud, by lab, by repo, by day, for the last 30 days, with a running month-to-date total.
• Labs: deploys, destroys, failures and average deploy time per lab.
• Platform health:
  • SLO burn rate
  • vLLM tokens per second
  • semantic cache hit rate
  • ingest lag (newest commit not yet indexed)
  • sync failures per provider
• Agent: alerts received, RCAs posted, approvals given or rejected.
• RAG pipeline: a trace per question in Arize Phoenix (cache hit or miss, retrieved chunks and scores, prompt, tokens, latency per step), an embeddings map, and retrieval-relevance and hallucination evals.

Accessibility and localization requirements

There’s one user and one language, so localization is out of scope. Accessibility still matters a little: Backstage’s Material UI components are keyboard navigable, and custom plugins should keep that. The animated diagrams on this blog already have a text fallback for readers without JavaScript.

Regulatory, legal, and compliance requirements

There’s no regulated data here, so no formal compliance regime applies. Two rules come close:

• Public repo hygiene. This blog’s repo is public. Subscription and tenant IDs, Cloudflare account and tunnel IDs, email allowlists and private repo URLs stay out of it.
• Provider terms. Cloud APIs are used with read-only roles, and the local model is used under its licence.

Resolved 2026-10-16: Apache 2.0. The chat model is Qwen3.5-35B-A3B (ADR 0049), after gpt-oss-20b (ADR 0046), also Apache 2.0; the embeddings model, Qwen3-Embedding-0.6B, is Apache 2.0 too (ADR 0010).

Prioritization and release scope

The order follows dependencies, not wish-list priority:

1. Must first: F1 (SSO), F15 (CI/CD and GitOps) and F16 (ADRs). Everything else ships through them.
2. Then: F7 and F8 (central monitoring), so every later piece is observable from day one.
3. Then: F5 and F6 (labs), then F2 to F4 (inventory and cost).
4. Then: F9 to F12 (local LLM, RAG, chat).
5. Last: F13 and F14 (the alert agent), because it needs monitoring, RAG and the LLM.

The phases are in Product Planning.

Checklist

• F1–F16 reviewed and each mapped to a phase
• Proposed NFR targets (99% portal, 3 s first token, 5 min RCA) confirmed or replaced
• Every lab card has a deploy: block with its memory size
• TTL default for cloud labs agreed
• Acceptance criteria turned into tests as each phase is built
• Model licence recorded in ADR 0010

• This post updated at the end of each phase
