DGX Spark to Azure Private Endpoint: Set Up the Infrastructure

This part goes through every az command the lab runs, in order, and the two config files that turn a stock Ubuntu VM and your DGX into the two ends of a tunnel. There’s no Kubernetes here. The “cluster” is an Azure VNet and the “manifests” are a cloud-init file and a wg0.conf. By the end of it you’ll know what each resource is for and which settings the experiments depend on.

The Cluster

In this lab the role of the cluster is played by one resource group, rg-pe-lab, holding one VNet. Everything is created by infra/up.sh with the names and address ranges from infra/lib.sh:

LOCATION="${LOCATION:-eastus}"
RG="${RG:-rg-pe-lab}"
VNET="${VNET:-vnet-pe-lab}"
VNET_CIDR="${VNET_CIDR:-10.60.0.0/16}"
PE_SUBNET="${PE_SUBNET:-snet-pe}"
PE_SUBNET_CIDR="${PE_SUBNET_CIDR:-10.60.1.0/24}"
VPN_SUBNET="${VPN_SUBNET:-snet-vpn}"
VPN_SUBNET_CIDR="${VPN_SUBNET_CIDR:-10.60.2.0/28}"

Pick a VNet range that doesn’t overlap your home network or anything else the DGX routes. wg-quick will add a route for the whole /16. On my DGX the only private routes were 192.168.1.0/24 (home) and Docker’s 172.17-19.0.0/16, so 10.60.0.0/16 was free (ip route shows yours).

1. Resource group and VNet.

az group create -n "$RG" -l "$LOCATION" -o none
az network vnet create -g "$RG" -n "$VNET" --address-prefixes "$VNET_CIDR" \
  --subnet-name "$PE_SUBNET" --subnet-prefixes "$PE_SUBNET_CIDR" -o none

2. The Foundry account, then public access off.

az cognitiveservices account show -g "$RG" -n "$ACCOUNT" -o none 2>/dev/null ||
  az cognitiveservices account create -g "$RG" -n "$ACCOUNT" -l "$LOCATION" \
    --kind AIServices --sku S0 --custom-domain "$ACCOUNT" --yes -o none
ACCOUNT_ID=$(az cognitiveservices account show -g "$RG" -n "$ACCOUNT" --query id -o tsv)
az resource update --ids "$ACCOUNT_ID" --set properties.publicNetworkAccess=Disabled -o none

--custom-domain gives the account its own names (<account>.cognitiveservices.azure.com and the other two), which private endpoints require. The name gets a random suffix (pelab-3d07e659 in my run) because it must be globally unique. The show || guard is there because running create again on an account whose public access is already disabled fails with PublicNetworkAccess is required for this resouce (sic). I hit that on my second run.

3. The private endpoint and one DNS zone.

az network private-endpoint create -g "$RG" -n "$PE" \
  --vnet-name "$VNET" --subnet "$PE_SUBNET" \
  --private-connection-resource-id "$ACCOUNT_ID" --group-id account \
  --connection-name "$PE-conn" -o none
ZONE=privatelink.cognitiveservices.azure.com
ensure_zone "$ZONE"
az network private-endpoint dns-zone-group create -g "$RG" --endpoint-name "$PE" -n default \
  --private-dns-zone "$ZONE" --zone-name cognitiveservices -o none

ensure_zone (in lib.sh) creates the zone and links it to the VNet:

ensure_zone() {
  az network private-dns zone show -g "$RG" -n "$1" -o none 2>/dev/null ||
    az network private-dns zone create -g "$RG" -n "$1" -o none
  az network private-dns link vnet show -g "$RG" -z "$1" -n "link-$VNET" -o none 2>/dev/null ||
    az network private-dns link vnet create -g "$RG" -z "$1" -n "link-$VNET" \
      -v "$VNET" --registration-enabled false -o none
}

Two things here are easy to get wrong, and the second one is left wrong on purpose:

• The VNet link. A private DNS zone with no virtual network links is invisible to everything. Azure DNS (168.63.129.16) consults a private zone only for queries coming from a VNet linked to it. If your zones show virtual_network_links: [], no forwarder in that VNet can ever return a private answer.

• One zone is not enough for Foundry. The account sub-resource of an AIServices account serves three names, and the endpoint gets one private IP per name. In my run:

  $ az network nic show --ids $PE_NIC --query "ipConfigurations[].{ip:privateIPAddress, fqdns:join(',',privateLinkConnectionProperties.fqdns), member:privateLinkConnectionProperties.requiredMemberName}" -o table
  Ip         Fqdns                                       Member
  ---------  ------------------------------------------  ---------
  10.60.1.4  pelab-3d07e659.cognitiveservices.azure.com  default
  10.60.1.5  pelab-3d07e659.openai.azure.com             secondary
  10.60.1.6  pelab-3d07e659.services.ai.azure.com        third


  up.sh puts only the cognitiveservices zone in the zone group, which is how I found many real setups (mine included). The OpenAI SDK calls <account>.openai.azure.com, which then still resolves to the public IP. Experiment 4 fixes it with infra/fix-zones.sh.

1. A query reaches the VNet: The DGX's query for <account>.openai.azure.com came through the tunnel. dnsmasq has one upstream: Azure DNS.
2. Forward to Azure DNS: 168.63.129.16 resolves public names like any resolver, but also checks the private zones linked to this VNet.
3. The public record is a CNAME: Since the private endpoint exists, the public record says <account>.openai.azure.com is an alias for <account>.privatelink.openai.azure.com.
4. Is that zone linked here?: Azure DNS answers a privatelink name from a private zone only if a zone with that exact name is linked to the asking VNet.
5. The private zone answers (linked): privatelink.openai.azure.com is linked, and the zone group wrote the A record: 10.60.1.5, the endpoint's openai IP.
6. Private IP, call succeeds (linked): The DGX connects to 10.60.1.5 through the tunnel and the account answers 200.
7. No zone, keep resolving publicly (missing): No linked zone has that name, so the privatelink CNAME is followed on the internet: Traffic Manager, API Management, a regional host.
8. Public IP, call blocked (missing): The chain ends at 20.232.91.180. The DGX connects over the internet and the account answers 403 Public access is disabled.

The zone group is what writes the A record into the zone and keeps it right if the endpoint’s IP ever changes. Without it you’d add pelab-3d07e659 A 10.60.1.4 by hand.

4. NSG, public IP and the VM.

az network nsg rule create -g "$RG" --nsg-name "$NSG" -n allow-wireguard --priority 100 \
  --direction Inbound --access Allow --protocol Udp \
  --source-address-prefixes "$MYIP/32" --destination-port-ranges "$WG_PORT" -o none
az network nsg rule create -g "$RG" --nsg-name "$NSG" -n allow-ssh --priority 110 \
  --direction Inbound --access Allow --protocol Tcp \
  --source-address-prefixes "$MYIP/32" --destination-port-ranges 22 -o none
az network vnet subnet create -g "$RG" --vnet-name "$VNET" -n "$VPN_SUBNET" \
  --address-prefixes "$VPN_SUBNET_CIDR" --nsg "$NSG" -o none
az network public-ip create -g "$RG" -n "$PIP" --sku Standard --allocation-method Static -o none

$MYIP is your public IPv4 from api.ipify.org. My DGX’s default route to the internet is IPv6, which is why the lookup forces curl -4: WireGuard connects to the VM’s IPv4 address, so the NSG sees your IPv4 address as the source. If your ISP changes it, re-run make azure-up to update the rules.

  az vm create -g "$RG" -n "$VM" --image "$VM_IMAGE" --size "$VM_SIZE" \
    --vnet-name "$VNET" --subnet "$VPN_SUBNET" --private-ip-address "$VM_PRIVATE_IP" \
    --public-ip-address "$PIP" --nsg "" \
    --storage-sku StandardSSD_LRS --os-disk-size-gb 32 \
    --admin-username azureuser --ssh-key-values "$STATE/ssh.pub" \
    --custom-data "$STATE/cloud-init.yaml" -o none

--nsg "" stops az vm create from making a second NSG on the NIC; the subnet’s one is enough. The Standard static public IP matters for Experiment 6: it keeps its address when the VM is deallocated, so the DGX’s Endpoint = line stays valid.

The size is Standard_B1s because that’s the B-series family my subscription had quota for. My first az vm create with Standard_B2pts_v2 failed with QuotaExceeded ... standardBpsv2Family Cores quota ... Current Limit: 0. If you hit an unreadable RuntimeError: The content for this response was already consumed from az vm create, add --validate --debug and look for the inner QuotaExceeded.

No IP forwarding on the NIC. The brief I started from enabled IP forwarding on the VM’s NIC. With MASQUERADE you don’t need it: every packet the VM sends into the VNet has the VM’s own address as its source, and every reply comes back to that address. Azure’s NIC setting is needed only when a VM sends or receives packets for addresses that aren’t its own, for example if you dropped the NAT and used a route table pointing 10.200.0.0/24 at the VM. The lab never enables it, and the probe gets its 200s anyway.

Application Manifests

Two files configure the two ends of the tunnel.

The VM: infra/cloud-init.yaml

up.sh fills in the keys and addresses and passes the file as custom data, so the VM is configured on first boot without anyone logging in:

packages:
  - wireguard-tools
  - dnsmasq
  - iptables

write_files:
  # Route traffic arriving from the tunnel on to the VNet.
  - path: /etc/sysctl.d/99-wg-forward.conf
    content: |
      net.ipv4.ip_forward = 1

  - path: /etc/wireguard/wg0.conf
    permissions: "0600"
    content: |
      [Interface]
      Address    = __WG_VM_IP__/24
      ListenPort = __WG_PORT__
      PrivateKey = __VM_PRIVATE_KEY__
      PostUp     = iptables -t nat -A POSTROUTING -s __WG_NET__ -o eth0 -j MASQUERADE
      PostDown   = iptables -t nat -D POSTROUTING -s __WG_NET__ -o eth0 -j MASQUERADE

      [Peer]
      # the DGX Spark
      PublicKey  = __DGX_PUBLIC_KEY__
      AllowedIPs = __WG_DGX_IP__/32

  - path: /etc/dnsmasq.d/pe-lab.conf
    content: |
      listen-address=__WG_VM_IP__
      bind-dynamic
      except-interface=lo
      no-resolv
      server=168.63.129.16
      log-queries
      log-facility=/var/log/dnsmasq.log

Setting	Why
net.ipv4.ip_forward = 1	Lets the kernel pass packets from wg0 out of eth0
MASQUERADE for 10.200.0.0/24 out of eth0	The private endpoint sees 10.60.2.4 as the source, so replies need no route back to the tunnel network. Tying it to PostUp/PostDown keeps the rule in step with the tunnel
AllowedIPs = 10.200.0.2/32 on the VM	The VM accepts packets from the DGX only if they come from its tunnel address
listen-address + bind-dynamic + except-interface=lo	dnsmasq answers only on the tunnel address and leaves 127.0.0.53 to the VM’s own systemd-resolved (Ubuntu’s default would make the two fight over port 53)
no-resolv + server=168.63.129.16	One upstream, Azure DNS, the only resolver that sees the linked zones

runcmd enables wg-quick@wg0 and restarts dnsmasq. There’s deliberately no ordering between the two units: bind-dynamic makes dnsmasq bind 10.200.0.1 whenever wg0 appears. My first version added After=wg-quick@wg0.service to dnsmasq, which creates an ordering cycle through nss-lookup.target, and systemd silently skipped WireGuard on every boot after the first (Experiment 6). The WireGuard keys come from infra/keys.sh, which makes both pairs on the DGX with Python’s cryptography (the same Curve25519 keys wg genkey makes) before wireguard-tools is installed anywhere.

You can check the result over SSH (make vm-ssh). From my run:

$ sudo iptables -t nat -S POSTROUTING
-P POSTROUTING ACCEPT
-A POSTROUTING -s 10.200.0.0/24 -o eth0 -j MASQUERADE
$ sudo ss -lunp | grep ':53 '
UNCONN 0      0          10.200.0.1:53         0.0.0.0:*    users:(("dnsmasq",pid=2686,fd=4))
UNCONN 0      0          127.0.0.54:53         0.0.0.0:*    users:(("systemd-resolve",pid=487,fd=16))
UNCONN 0      0       127.0.0.53%lo:53         0.0.0.0:*    users:(("systemd-resolve",pid=487,fd=14))

The DGX: wg0.conf

dgx/render.sh writes .state/wg0.conf from lab.env. The tunnel-only version, used in experiment 2:

[Interface]
PrivateKey = <dgx private key>
Address    = 10.200.0.2/32

[Peer]
PublicKey  = OWcvAw0eW83wZR08sN8GT7F2ZAGdSqTnOqGApKFzimE=
Endpoint   = 20.102.50.119:51820
AllowedIPs = 10.200.0.1/32, 10.60.0.0/16
PersistentKeepalive = 25

AllowedIPs lists only the VM’s tunnel address and the VNet, so wg-quick adds two routes and everything else stays on your home connection. PersistentKeepalive = 25 sends a packet every 25 seconds, which keeps your home router’s NAT entry open so the VM can always reach the DGX.

There’s no DNS = line on purpose. With one, wg-quick would make the VM the DNS server for every name. render.sh --dns (used by make dgx-persist) adds split DNS instead:

PostUp     = resolvectl dns %i 10.200.0.1; resolvectl domain %i ~cognitiveservices.azure.com ~openai.azure.com ~services.ai.azure.com; resolvectl default-route %i false

resolvectl settings belong to the link, so they vanish whenever wg0 goes away. Running them in PostUp reapplies them every time the tunnel comes up, including at boot with systemctl enable wg-quick@wg0. default-route false says explicitly that wg0 is not a place to send names that match no routing domain.

This is the setup to keep once the experiments are done. From my run, after make dgx-persist:

$ make dgx-persist
bash dgx/render.sh --dns
sudo install -m 600 -D .state/wg0.conf /etc/wireguard/wg0.conf
sudo wg-quick down wg0 2>/dev/null || true
sudo systemctl enable --now wg-quick@wg0
Created symlink /etc/systemd/system/multi-user.target.wants/wg-quick@wg0.service → /usr/lib/systemd/system/wg-quick@.service.
resolvectl status wg0
Link 116 (wg0)
    Current Scopes: DNS
         Protocols: -DefaultRoute -LLMNR -mDNS -DNSOverTLS DNSSEC=no/unsupported
       DNS Servers: 10.200.0.1
        DNS Domain: ~cognitiveservices.azure.com ~openai.azure.com ~services.ai.azure.com
$ make dgx-status
pelab-3d07e659.cognitiveservices.azure.com       10.60.1.4
pelab-3d07e659.openai.azure.com                  10.60.1.5
pelab-3d07e659.services.ai.azure.com             10.60.1.6

-DefaultRoute and the three routing domains came from PostUp, not from a manual resolvectl. With the tunnel up, all three names returned 200 from their private IPs, while github.com still resolved through the home router to its public address.

Observability Stack

There’s no OpenTelemetry Collector in this lab. The probe pushes OTLP straight into grafana/otel-lgtm 0.35.0, whose built-in collector fans it out to Prometheus, Loki and Tempo:

  lgtm:
    image: grafana/otel-lgtm:0.35.0
    ports:
      - "3012:3000"     # Grafana (anonymous admin)
      - "14318:4318"    # OTLP/HTTP in, for the probe on the host network
    volumes:
      # Mounted as a directory so Grafana's file provider picks up edits without a restart.
      - ./dashboards:/otel-lgtm/lab-dashboards:ro
      - ./dashboard-provider.yaml:/otel-lgtm/grafana/conf/provisioning/dashboards/lab-dashboard.yaml:ro

The OTLP port is published on the host as 14318, not 4318, so it can’t collide with another collector on the DGX. The probe, on the host network, sends to http://localhost:14318. The dashboard (uid: azure-pe-lab) is provisioned from a file into the Labs folder and reloaded every 10 seconds.

The stat panels in the top row use instant queries. My first capture used range queries, and the “after” screenshots showed the old value: a probe value that flipped five seconds before the screenshot fell just outside the last 15-second step. Instant queries are evaluated at the exact moment the dashboard asks.

The two timeline panels (Where each name resolves, HTTP status over time) use a fixed colour mode, so each value mapping supplies its own colour and label. With the default threshold colouring, Grafana’s state timeline labelled every bar with its threshold range (“-∞+”), drew it grey and ignored the mappings. That ruined my first timelapse of experiment 4.

Ports and Endpoints

What	Address	Exposed how
Grafana	http://localhost:3012/d/azure-pe-lab/	Docker port 3012 → 3000, anonymous admin, DGX only
OTLP/HTTP into LGTM	localhost:14318	Docker port 14318 → 4318
WireGuard on the VM	<VM public IP>:51820/udp	Standard static public IP, NSG allows your IPv4 only
SSH to the VM	<VM public IP>:22	Same NSG; key in .state/ssh (make vm-ssh)
dnsmasq	10.200.0.1:53	Tunnel address only
Azure DNS	168.63.129.16:53	From inside the VNet only
Private endpoint	10.60.1.4 / .5 / .6 :443	Through the tunnel, NATed by the VM
Foundry data plane	https://<account>.{cognitiveservices,openai,services.ai}.azure.com	Public names, private answers

Check Your Understanding

You see your zone in the portal with the right A record, but nothing in the VNet resolves it privately. What do you check first?

The zone’s virtual network links. Azure DNS answers from a private zone only for VNets linked to it, and a zone with no links is never consulted, however correct its records are.

Why doesn't the lab need a route table (UDR) in the VNet?

MASQUERADE rewrites the source of everything from the tunnel to the VM’s own 10.60.2.4. The private endpoint replies to 10.60.2.4, which the VNet already knows. Without NAT, the replies would go to 10.200.0.2, which the VNet has no route for. You’d then need a UDR pointing 10.200.0.0/24 at the VM, and IP forwarding enabled on its NIC.

What breaks if you put DNS = 10.200.0.1 in the DGX's wg0.conf?

wg-quick would make the VM the resolver for every name the DGX looks up. All your DNS would cross the tunnel, slower than your router and dead whenever the VM is off. Routing domains (~domain) send only the three Azure AI suffixes there.

Why is the public IP Standard and static rather than dynamic?

A dynamic IP is released when the VM is deallocated and usually comes back different, which would break the Endpoint = line on the DGX after every stop and start. Basic SKU public IPs are also retired, so Standard is the only choice for a new one anyway.
