OpenTelemetry End to End: Set Up the Infrastructure

The code from Part 2 needs somewhere to run and somewhere to send its telemetry. This part covers the cluster, the Kubernetes manifests for the five application pods, the two-line change that makes Traefik part of every trace, and the Collector pipelines that turn three kinds of input into data Grafana can query.

The Cluster

# k3d/cluster.yaml
apiVersion: k3d.io/v1alpha5
kind: Simple
metadata:
  name: lab-otel
servers: 1
agents: 0
image: rancher/k3s:v1.35.5-k3s1
network: homelab
kubeAPI:
  hostIP: 127.0.0.1
  hostPort: "6451"
ports:
  - port: 127.0.0.1:8081:80      # site, via the bundled Traefik ingress
    nodeFilters: [loadbalancer]
volumes:
  - volume: /srv/homelab/k3s/registries.yaml:/etc/rancher/k3s/registries.yaml
    nodeFilters: [server:*]
options:
  k3s:
    extraArgs:
      - arg: --cluster-cidr=10.102.0.0/16
        nodeFilters: [server:*]
      - arg: --service-cidr=10.103.0.0/16
        nodeFilters: [server:*]
      - arg: --cluster-dns=10.103.0.10
        nodeFilters: [server:*]

One k3s server and no agents: a single-node cluster is enough, and it keeps the Collector DaemonSet at exactly one pod. The cluster follows the homelab’s lab contract v2:

• network: homelab. The cluster joins the Docker network every homelab cluster shares, so the platform’s Argo CD can reach its API and its pods can reach the mon cluster.
• Its own CIDR pair. Pods get 10.102.0.0/16 and Services 10.103.0.0/16, so they never overlap another cluster’s on the shared network.
• The registry mirror. registries.yaml sends public image pulls through the homelab’s Zot mirror.
• Ports on localhost only. 8081 goes to k3d’s load balancer, which forwards to Traefik on port 80; the API is on 6451. There is no Grafana port any more: Grafana is in mon.

The mappings are baked in when the cluster is created, which is why make cluster is a no-op for an existing cluster:

cluster: ## Create the k3d cluster (no-op if it already exists)
	@k3d cluster list $(CLUSTER) >/dev/null 2>&1 || k3d cluster create --config k3d/cluster.yaml

Pods resolve the homelab’s internal names (*.mon.home.cloudutsuk.com) through one CoreDNS addition, applied by make dns. Inside a k3d node the usual resolver doesn’t know the internal zone, so CoreDNS forwards just that zone to the homelab’s PowerDNS:

# k8s/dns/coredns-custom.yaml (data)
home.server: |
  home.cloudutsuk.com:53 {
    errors
    cache 30
    forward . 172.30.0.1:1053
  }

Joining the Platform

make monitoring runs the homelab’s registration script, then hands the lab its two tokens:

monitoring: ## Join the homelab platform: monitoring pack, OTLP token, dashboard, Trace Lab token
	$(HOMELAB_INFRA)/host/labs/lab.sh register $(CLUSTER) dashboards
	# ...copies the OTLP token into observability/otlp-token and writes demo/grafana-proxy

lab.sh register lab-otel dashboards does four things:

1. Registers the cluster with the platform’s Argo CD (label homelab/addons=monitoring), which installs cert-manager and the monitoring pack: OpenTelemetry collectors for the cluster’s own Kubernetes metrics and every pod’s raw logs, and kube-state-metrics.
2. Puts the shared labs OTLP token in Secret monitoring/otlp-token.
3. Loads every JSON file in dashboards/ into mon’s Grafana, folder Labs.
4. Waits until the monitoring pack is healthy.

The Makefile then copies the OTLP token for the lab’s own Collector, and asks lab.sh grafana-token for a read-only Grafana token for the Trace Lab page (see below). make down runs lab.sh unregister first, which removes all of it.

Application Manifests

Everything for the app lives in the demo namespace, applied by Kustomize (k8s/app/):

Workload	Image	Port	Probes	Notes
static-site	static-site:dev + nginx/nginx-prometheus-exporter:1.5.3	80, 9113	GET /healthz	Two containers: nginx, and a sidecar reading stub_status on loopback
api	trace-lab-api:dev	8000	GET /healthz	BACKEND_URL=http://backend:8000/data
backend	trace-lab-backend:dev	8000	GET /healthz	REDIS_URL=redis://redis:6379/0, SQLite at /tmp/trace-lab.sqlite3
redis	redis:7.4-alpine	6379	redis-cli ping	--save "" --appendonly no: no persistence at all

Each Deployment has a Service of the same name, so the API reaches the backend at http://backend:8000 through cluster DNS. One Ingress splits the traffic by path:

# k8s/app/static-site.yaml (Ingress)
spec:
  ingressClassName: traefik
  rules:
    - http:
        paths:
          - path: /api
            pathType: Prefix
            backend:
              service:
                name: api
                port:
                  name: http
          - path: /
            pathType: Prefix
            backend:
              service:
                name: static-site
                port:
                  name: http

Because the page and the API share one origin (localhost:8081), the browser’s fetch('/api/demo') needs no CORS and the trace header goes along with it.

Traefik joins the trace. k3s installs Traefik itself, so the lab doesn’t deploy it; it reconfigures it with a HelmChartConfig, which k3s merges into its own chart values:

# k8s/traefik/helmchartconfig.yaml
spec:
  valuesContent: |-
    additionalArguments:
      - "--tracing=true"
      - "--tracing.serviceName=state-site-traefik"
      - "--tracing.otlp=true"
      - "--tracing.otlp.http.endpoint=http://otel-collector.observability.svc.cluster.local:4318/v1/traces"
      - "--metrics.otlp=true"
      - "--metrics.otlp.serviceName=state-site-traefik"
      - "--metrics.otlp.http.endpoint=http://otel-collector.observability.svc.cluster.local:4318/v1/metrics"

Tracing and metrics are separate switches: with only --tracing, Traefik appears in waterfalls but there are no traefik_* metrics, and the reverse. The lab turns on both.

Observability Stack

The observability namespace has one workload, the Collector (a DaemonSet running otel/opentelemetry-collector-contrib:0.162.0). There is no storage or Grafana in the lab: the Collector sends everything to the homelab’s mon cluster. Step through what happens inside it:

1. Four ways in: otlp takes pushed spans and Traefik metrics; two file_log receivers tail nginx and API pod logs; prometheus scrapes the nginx exporter every 15 s.
2. memory_limiter first: Every pipeline starts with memory_limiter, which refuses data instead of crashing when the Collector nears 200 MiB.
3. Traces and metrics: The traces and metrics pipelines go straight on to batch.
4. Logs get a service name: Log lines read from files carry no service.name, so a resource processor inserts state-site-nginx or state-site-api.
5. Then batching: batch groups records into larger sends, which is cheaper and kinder to the backend than one request per span.
6. One exporter for everything: All five pipelines share one otlp_http exporter pointing at the homelab's gateway on mon, after resource/cluster stamps k8s.cluster.name=lab-otel.
7. Stored by signal: On mon, traces land in Tempo, logs in Loki and metrics in Mimir, next to every other homelab cluster's.

The receivers, from k8s/observability/otel-collector-config.yaml:

receivers:
  otlp:
    protocols:
      grpc:
        endpoint: 0.0.0.0:4317
      http:
        endpoint: 0.0.0.0:4318

  file_log:
    include:
      - /var/log/pods/demo_static-site-*/nginx/*.log
    include_file_path: true      # the container operator reads pod metadata from the path
    start_at: beginning
    operators:
      - type: container          # CRI format + k8s.* resource attributes from the path
      - type: json_parser        # access log lines are JSON; error log lines are not
        if: body startsWith "{"
        parse_to: attributes
        on_error: send_quiet
        trace:
          trace_id:
            parse_from: attributes.trace_id
          span_id:
            parse_from: attributes.span_id

  # file_log/api: the same, for /var/log/pods/demo_api-*/api/*.log

  prometheus:
    config:
      scrape_configs:
        - job_name: state-site-nginx
          scrape_interval: 15s
          static_configs:
            - targets: [static-site.demo.svc.cluster.local:9113]

Three details make the lab work:

• Why a DaemonSet with runAsUser: 0. Pod logs are files on the node, under /var/log/pods. The Collector mounts that path read-only from the host, and it must run on every node that has pods (here, one) and as root to read them.
• The trace block in json_parser. It copies the trace_id and span_id fields from each JSON line into the log record’s own trace context. That is what makes a Loki line belong to a trace, rather than just mention one.
• Five pipelines, one exporter. traces and metrics take OTLP (and the scrape); logs takes OTLP; logs/nginx and logs/api take the two file readers, each with a resource processor that inserts service.name (a file has no idea which service wrote it). All five also run resource/cluster and send to one exporter, the homelab’s gateway:

processors:
  resource/cluster:
    attributes:
      - key: k8s.cluster.name
        value: lab-otel
        action: upsert

exporters:
  otlp_http/mon:
    endpoint: https://otlp.mon.home.cloudutsuk.com
    headers:
      Authorization: "Bearer ${env:OTLP_TOKEN}"   # Secret observability/otlp-token

mon holds every homelab cluster’s data, and the gateway turns k8s.cluster.name into a cluster label. So every query in this lab filters on the lab: cluster="lab-otel" in PromQL (where the service name becomes the job label), k8s_cluster_name="lab-otel" in LogQL and resource.k8s.cluster.name = "lab-otel" in TraceQL.

The dashboard. dashboards/static-site.json is a plain Grafana dashboard whose queries use mon’s data sources (mimir, loki, tempo) and the lab’s cluster filter. lab.sh register loads it into mon’s Grafana as OpenTelemetry lab: static site signals in the Labs folder, so it’s there as soon as the lab is up, and removes it when the lab goes.

The Trace Lab proxy. The page’s This request in Grafana panel calls /grafana-api/loki/, /grafana-api/tempo/ and /grafana-api/prometheus/ on the site itself. nginx forwards those to mon’s Grafana data source API and adds a Viewer token from Secret demo/grafana-proxy, so the browser never sees it. That token can query data but change nothing, and the site listens on localhost only.

Ports and Endpoints

URL or address	What it is	Exposed by
http://localhost:8081/	The page	k3d load balancer → Traefik → static-site Service
http://localhost:8081/api/demo	The API (JSON with trace_id)	Traefik → api Service (Ingress path /api)
https://grafana.mon.home.cloudutsuk.com/d/lab-otel-signals	The lab’s dashboard in the homelab’s Grafana (Keycloak sign-in)	the mon cluster
otel-collector.observability.svc:4317 / :4318	OTLP gRPC / HTTP into the Collector	ClusterIP Service
/v1/traces on the site	The browser’s OTLP endpoint, proxied by nginx to :4318	nginx location
static-site.demo.svc:9113/metrics	nginx metrics in Prometheus format	exporter sidecar
https://otlp.mon.home.cloudutsuk.com	OTLP into mon (Tempo, Loki, Mimir), labs token	the homelab’s gateway
/grafana-api/* on the site	Read-only queries to mon’s Grafana, for the Trace Lab page	nginx locations

Check Your Understanding

Why is the Collector a DaemonSet and not a Deployment?

It reads pod log files from the node’s filesystem (/var/log/pods). A DaemonSet guarantees one Collector on every node, so every pod’s logs are local to some Collector.

What would you lose if the trace block were removed from the file_log receivers?

The log lines would still arrive in Loki with trace_id as an ordinary attribute, but the log records wouldn’t carry trace context, so Grafana couldn’t link them to traces natively. You’d be back to copying IDs by hand.

If you changed the site's host port from 8081 to 9090 in cluster.yaml, what else must you do?

Recreate the cluster (make rebuild), because k3d applies port mappings only at creation, and change deploy.ports on the lab card so the lab runner knows. The telemetry already in mon stays.
