OpenTelemetry End to End: Write the Code

This part walks through the code that produces every signal you’ll look at later. There’s less of it than you might expect: most of the tracing comes from configuration and auto-instrumentation, and the few lines written by hand are there to teach something specific. By the end you’ll know which file creates which span.

Repository Layout

otel-static-site-k3d/
  Makefile                    up, build, deploy, status, down, traffic + exp-*/verify-* targets
  EXPERIMENTS.md              the experiments from this lab (generated from the blog's lab card)
  app/
    Dockerfile                two stages: Node bundles otel.js, then nginx:1.30-otel serves the site
    nginx.conf                otel module, JSON access log, /v1/traces and /grafana-api proxies
    site/index.html           the page, its "Call /api/demo" button and its own Grafana lookups
    site/ping.json            a static JSON file
    web/otel.js               browser tracing setup (bundled into /otel.js)
    web/package.json          OpenTelemetry JS packages + esbuild
    api/main.py               FastAPI: GET /api/demo calls the backend, logs a JSON line
    api/Dockerfile            python:3.12-slim + opentelemetry-instrument
    backend/main.py           FastAPI: GET /data, Redis cache-aside over SQLite
    backend/Dockerfile        same base, Redis auto-instrumentation disabled (added by hand instead)
  k3d/cluster.yaml            lab-otel: one k3s server on the homelab network; 127.0.0.1:8081 → ingress
  k8s/
    app/                      static-site (nginx + exporter sidecar), api, backend, redis, ingress
    traefik/                  HelmChartConfig: Traefik tracing + OTLP metrics
    observability/            Collector DaemonSet + config (exports to the homelab's mon cluster)
    dns/                      CoreDNS forwarding for the homelab's internal zone
  dashboards/static-site.json the dashboard, loaded into mon's Grafana (folder Labs)
  scripts/signal.sh           asks mon's Grafana whether a metric, log or trace has arrived

The Application

The application is deliberately boring, so the telemetry stands out. The API has one real endpoint. It calls the backend, and if that call fails it answers 502 (experiment 6 depends on this):

# app/api/main.py
BACKEND_URL = os.getenv("BACKEND_URL", "http://backend:8000/data")


@app.get("/api/demo")
async def demo():
    """Call the backend so one browser request crosses both application tiers."""
    try:
        async with httpx.AsyncClient(timeout=5.0) as client:
            response = await client.get(BACKEND_URL)
            response.raise_for_status()
    except httpx.HTTPError as error:
        raise HTTPException(status_code=502, detail="Backend request failed") from error

The backend implements cache-aside: look in Redis; on a miss, read the database and put the result in the cache for 60 seconds.

# app/backend/main.py
CACHE_TTL_SECONDS = 60
CACHE_KEY = "record:demo"


@app.get("/data")
def data():
    """Use Redis cache-aside; load the seeded record from SQLite on a miss."""
    current_span = trace.get_current_span()
    try:
        cached = _cache.get(CACHE_KEY)
    # …
    if cached is not None:
        return {"tier": "backend", "record": json.loads(cached), "source": "redis"}
    # … SQLite SELECT (below), then:
    _cache.setex(CACHE_KEY, CACHE_TTL_SECONDS, json.dumps(record))
    return {"tier": "backend", "record": record, "source": "database"}

The database is a SQLite file created at startup with one row, ("demo", "Hello from the database"). Calling the API twice in a row shows both paths. This is real output from the running lab:

$ kubectl -n demo exec deploy/redis -- redis-cli DEL record:demo
$ curl -s localhost:8081/api/demo
{"tier":"api","backend":{"tier":"backend","record":{"id":"demo","message":"Hello from the database"},"source":"database"},"trace_id":"b81d488a4fa6592f755714ffbbe23461"}
$ curl -s localhost:8081/api/demo
{"tier":"api","backend":{"tier":"backend","record":{"id":"demo","message":"Hello from the database"},"source":"redis"},"trace_id":"ddb21b6ca807c1cbc67a3902333089be"}

source flips from database to redis, and every response hands you its trace_id.

Instrumentation

Each tier gets its telemetry a different way. That’s typical of real systems, so it’s worth seeing all four.

Browser: the Web SDK, configured in code. otel.js creates a tracer provider with a stable service name, batches spans for two seconds, and sends them to a same-origin path:

// app/web/otel.js
const OTLP_PATH = '/v1/traces';

const provider = new WebTracerProvider({
  resource: resourceFromAttributes({ 'service.name': 'state-site-browser' }),
  spanProcessors: [
    new BatchSpanProcessor(new OTLPTraceExporter({ url: OTLP_PATH }), {
      scheduledDelayMillis: 2000,
    }),
  ],
});
provider.register();

const ignoreUrls = [/\/v1\/traces$/, /\/grafana-api\//];
registerInstrumentations({
  instrumentations: [
    getWebAutoInstrumentations({
      '@opentelemetry/instrumentation-fetch': { ignoreUrls },
      '@opentelemetry/instrumentation-xml-http-request': { ignoreUrls },
    }),
  ],
});

The auto-instrumentations cover document load, user interactions, fetch and XHR. For same-origin requests the fetch instrumentation adds the traceparent header, which starts the distributed trace. ignoreUrls matters: without it, exporting spans (a fetch to /v1/traces) would create more spans to export, forever.

nginx: a module and five directives.

# app/nginx.conf
load_module modules/ngx_otel_module.so;
# …
  log_format json escape=json
    '{"time":"$time_iso8601","remote_addr":"$remote_addr",'
    '"method":"$request_method","uri":"$request_uri","status":"$status",'
    '"bytes":"$body_bytes_sent","request_time":"$request_time",'
    '"user_agent":"$http_user_agent",'
    '"trace_id":"$otel_trace_id","span_id":"$otel_span_id"}';

  otel_exporter {
    endpoint otel-collector.observability.svc.cluster.local:4317;
  }
  otel_service_name state-site-nginx;
  otel_trace on;
  otel_trace_context propagate;   # continue the browser's trace when it sends traceparent
# …
    location = /v1/traces {
      otel_trace off;
      access_log off;
      proxy_pass http://otel-collector.observability.svc.cluster.local:4318;
    }

$otel_trace_id in the log format is what lets you jump from an access-log line to its trace. The /v1/traces location is the browser’s export path, proxied to the Collector with tracing and logging switched off (the same recursion guard, server-side). The page’s own Grafana lookups under /grafana-api/ are excluded the same way.

Python services: zero-code auto-instrumentation. Neither main.py sets up a tracer provider. The Dockerfile does it by starting Uvicorn through opentelemetry-instrument and configuring it with environment variables:

# app/api/Dockerfile
ENV PYTHONDONTWRITEBYTECODE=1 \
    PYTHONUNBUFFERED=1 \
    OTEL_SERVICE_NAME=state-site-api \
    OTEL_EXPORTER_OTLP_ENDPOINT=http://otel-collector.observability.svc.cluster.local:4318 \
    OTEL_EXPORTER_OTLP_PROTOCOL=http/protobuf \
    OTEL_TRACES_SAMPLER=parentbased_always_on
# …
CMD ["opentelemetry-instrument", "uvicorn", "main:app", "--host", "0.0.0.0", "--port", "8000"]

opentelemetry-instrument loads every installed instrumentation package (opentelemetry-instrumentation-fastapi and -httpx in the API) before the app starts. parentbased_always_on means “keep a trace if the caller kept it, otherwise sample everything”, so a browser-started trace is never cut in half.

Backend: two pieces by hand. The backend’s Dockerfile sets OTEL_PYTHON_DISABLED_INSTRUMENTATIONS=redis and instruments its one Redis client explicitly instead, so it can attach a response hook that names the cache result:

# app/backend/main.py
def _redis_response_hook(span, _instance, response):
    """Label Redis GET spans so cache hits and misses are obvious in Tempo."""
    if span.name == "GET":
        result = "hit" if response is not None else "miss"
        span.set_attribute("app.cache.result", result)
        span.update_name(f"GET (cache {result})")


RedisInstrumentor.instrument_client(_cache, response_hook=_redis_response_hook)

And because nothing instruments sqlite3 here, the query gets a manual span with the standard database attributes:

with trace.get_tracer(__name__).start_as_current_span(
    "sqlite SELECT records"
) as db_span:
    db_span.set_attribute("db.system", "sqlite")
    db_span.set_attribute("db.operation", "SELECT")
    db_span.set_attribute("db.statement", "SELECT id, message FROM records WHERE id = ?")

A log line that knows its trace. The API prints one JSON line per completed request, reading the trace and span IDs from the current span:

span_context = trace.get_current_span().get_span_context()
trace_id = f"{span_context.trace_id:032x}" if span_context.is_valid else None
request_log = {
    "event": "api.demo.completed",
    "service_name": "state-site-api",
    "route": "/api/demo",
    "http_status_code": response.status_code,
    "trace_id": trace_id,
    "span_id": f"{span_context.span_id:016x}" if span_context.is_valid else None,
    "cache_source": backend.get("source"),
}
print(json.dumps(request_log, separators=(",", ":")), flush=True)

Note what’s not here: the app doesn’t send logs anywhere. It prints to stdout and the Collector picks the line up from the node (Part 3).

Build the Image

make build produces three images and imports them into the cluster, with no registry involved:

build: ## Build the site, API, and backend images and import them into the cluster
	docker build -t $(IMAGE) app
	docker build -t $(API_IMAGE) app/api
	docker build -t $(BACKEND_IMAGE) app/backend
	k3d image import $(IMAGE) $(API_IMAGE) $(BACKEND_IMAGE) -c $(CLUSTER)

The site image is a two-stage build. Node exists only in the first stage; the final image is nginx plus files:

# app/Dockerfile
FROM node:22-alpine AS web
WORKDIR /src
COPY web/package.json web/package-lock.json ./
RUN npm ci
COPY web/otel.js ./
RUN npm run build

FROM nginx:1.30-otel
COPY nginx.conf /etc/nginx/nginx.conf
COPY site/ /usr/share/nginx/html/
COPY --from=web /src/dist/otel.js /usr/share/nginx/html/otel.js
EXPOSE 80

Line	Why
FROM node:22-alpine AS web	A throwaway build stage with npm
COPY package.json package-lock.json then npm ci	Install exact versions; this layer is cached until the lockfile changes
npm run build	esbuild otel.js --bundle --minify --target=es2020 --outfile=dist/otel.js: npm imports become one browser file
FROM nginx:1.30-otel	A fresh stage with the OTel module; nothing from Node carries over
COPY --from=web …/otel.js	Only the bundle crosses stages

The Python images are single-stage: python:3.12-slim, pip install -r requirements.txt, copy main.py. The images are tagged static-site:dev, trace-lab-api:dev and trace-lab-backend:dev, and the manifests use imagePullPolicy: IfNotPresent so Kubernetes uses the imported copies.

Check Your Understanding

What would happen if ignoreUrls were removed from otel.js?

Every export to /v1/traces is itself a fetch, so it would be traced, producing a new span that needs exporting, which is another fetch… The browser would generate telemetry about sending telemetry in a loop.

The API's main.py never creates a tracer provider. Where do its spans come from?

From opentelemetry-instrument, the command the container starts with. It configures the SDK from the OTEL_* environment variables and loads the FastAPI and HTTPX instrumentations before Uvicorn imports the app.

Why does the backend disable Redis auto-instrumentation and then instrument Redis by hand?

To attach a response hook. Instrumenting the client explicitly lets the backend see each GET’s result and rename the span GET (cache hit) or GET (cache miss), which makes the two paths obvious in a waterfall.
