eBPF Lab: Set Up the Infrastructure

Running eBPF tools inside k3d means running them inside Docker containers that share one kernel with everything else on the machine. This part goes through the cluster definition, the storage that survives a rebuild, the app manifests, and how each eBPF tool is set up and scoped. Every k3d-specific workaround is called out where it appears. At the end you’ll know what make up is about to build, and why.

The Cluster

k3d/cluster.yaml creates one server and one agent on the homelab’s Docker network:

apiVersion: k3d.io/v1alpha5
kind: Simple
metadata:
  name: lab-ebpf
servers: 1
agents: 1
image: rancher/k3s:v1.35.5-k3s1
network: homelab
kubeAPI:
  hostIP: 127.0.0.1
  hostPort: "6450"
ports:
  - port: 127.0.0.1:8091:30091   # demo web app
    nodeFilters: [server:0]
  - port: 127.0.0.1:8092:30092   # Hubble UI
    nodeFilters: [server:0]
  - port: 127.0.0.1:8093:30093   # Falcosidekick UI
    nodeFilters: [server:0]
volumes:
  - volume: /srv/homelab/labs/ebpf-lab:/var/lib/lab-storage
    nodeFilters: [server:0]
  - volume: /srv/homelab/k3s/registries.yaml:/etc/rancher/k3s/registries.yaml
    nodeFilters: [server:*, agent:*]
options:
  k3s:
    extraArgs:
      - arg: --flannel-backend=none
        nodeFilters: [server:*]
      - arg: --disable-network-policy
        nodeFilters: [server:*]
      - arg: --disable-kube-proxy
        nodeFilters: [server:*]
      - arg: --disable=traefik
        nodeFilters: [server:*]
      - arg: --disable=servicelb
        nodeFilters: [server:*]
      - arg: --cluster-cidr=10.100.0.0/16
        nodeFilters: [server:*]
      - arg: --service-cidr=10.101.0.0/16
        nodeFilters: [server:*]
      - arg: --cluster-dns=10.101.0.10
        nodeFilters: [server:*]

What each part does:

• No CNI, no kube-proxy, no policy controller. --flannel-backend=none, --disable-kube-proxy and --disable-network-policy leave networking empty for Cilium. Until Cilium runs, the nodes stay NotReady. Traefik and ServiceLB are off too; the app is reached through NodePorts.
• Ports straight to NodePorts on the server node, all bound to 127.0.0.1. These mappings are fixed when the cluster is created; changing one means make rebuild.
• Two nodes so that some traffic crosses between nodes over VXLAN, which Hubble marks to-overlay.
• The PV folder: /srv/homelab/labs/ebpf-lab on the host is mounted into the server node only, at /var/lib/lab-storage. No pod mounts it directly (see Application Manifests).
• registries.yaml sends image pulls through the homelab’s Zot mirror. After the first pull, a rebuild pulls from the local mirror instead of the internet.
• Ranges 10.100/10.101, the first pair reserved for labs on the shared network.

A BPF filesystem in each node

make node-prep runs scripts/node-prep.sh after the cluster is created:

# Cilium pins its maps in a BPF filesystem at /sys/fs/bpf and needs it to be a *shared* mount so
# the pinned maps survive agent restarts and are visible to its other pods. A k3d node is a Docker
# container whose /sys has no bpffs, so we mount a fresh one inside each node (not the host's).
for n in $(docker ps --filter "label=k3d.cluster=$CLUSTER" --filter "label=k3d.role" --format '{{.Names}}' | grep -v serverlb); do
  docker exec "$n" sh -c '
    if [ "$(stat -f -c %T /sys/fs/bpf 2>/dev/null)" != "bpf_fs" ]; then
      mount bpffs /sys/fs/bpf -t bpf
    fi
    mount --make-shared /sys/fs/bpf
    # …
  '
done

Docker drops these mounts when a node container restarts, so run make node-prep again after a k3d cluster start.

Cilium

helm/cilium-values.yaml, installed by make cilium from the vendored 1.20.2 chart:

kubeProxyReplacement: true
k8sServicePort: 6443

socketLB:
  enabled: true
  hostNamespaceOnly: true

ipam:
  mode: kubernetes

routingMode: tunnel
tunnelProtocol: vxlan

hubble:
  enabled: true
  relay:
    enabled: true
  ui:
    enabled: true
    service:
      type: NodePort
      nodePort: 30092
  metrics:
    enabled:
      - dns
      - drop
      - tcp
      - flow
      - "httpV2:labelsContext=source_namespace,source_workload,destination_namespace,destination_workload"
    serviceMonitor:
      enabled: false

The settings that matter, and the reasons in the values file:

• kubeProxyReplacement: true makes Cilium’s eBPF programs do Service load balancing. The Makefile passes k8sServiceHost as the server node’s address on the homelab network: with no kube-proxy, nothing can translate the API server’s ClusterIP before Cilium itself is running.
• socketLB.hostNamespaceOnly: true is the nested-container setting. k3d nodes have a private cgroup namespace, so socket-level load balancing attached to the cgroup root never saw pod sockets: pods could reach the API server on its node IP but not on 10.101.0.1. With this set, pod traffic to Services is translated by the tc programs on each pod’s veth instead.
• routingMode: tunnel with VXLAN keeps pod-to-pod traffic between the two node containers independent of the Docker bridge’s routing.
• Hubble metrics are enabled, but nothing scrapes them: the ServiceMonitor is off, because Cilium installs before the monitoring pack brings the ServiceMonitor CRD. Flows are read through the UI and hubble observe.

DNS for pods on the homelab network

make dns applies k8s/dns/coredns-custom.yaml:

data:
  upstream.override: |
    forward . 1.1.1.1 8.8.8.8
  home.server: |
    home.cloudutsuk.com:53 {
      errors
      cache 30
      forward . 172.30.0.1:1053
    }

k3d points every node’s resolver at the network gateway, which inside a node is Docker’s embedded resolver, and pods can’t use it: lookups time out. That broke Falco’s rule download on the first build. So CoreDNS forwards public names to public resolvers and the internal zone to the homelab’s PowerDNS on port 1053.

Joining the platform

make monitoring registers the cluster with the platform:

monitoring: ## Join the homelab platform: monitoring pack from Argo CD, OTLP token (lab contract v2)
	$(HOMELAB_INFRA)/host/labs/lab.sh register $(CLUSTER) dashboards
	@# OBI sends straight to the gateway (helm/obi-values.yaml), so it needs the token in its namespace.
	$(KUBECTL) create namespace obi --dry-run=client -o yaml | $(KUBECTL) apply -f -
	$(KUBECTL) -n monitoring get secret otlp-token -o jsonpath='{.data.token}' | base64 -d \
	  | $(KUBECTL) -n obi create secret generic otlp-token --from-file=token=/dev/stdin --dry-run=client -o yaml \
	  | $(KUBECTL) apply -f -

lab.sh register (in infra-local) does four things: it adds the cluster to Argo CD on the platform cluster with the label homelab/addons=monitoring, copies the shared labs OTLP token into monitoring/otlp-token, loads dashboards/ebpf-lab.json into mon’s Grafana (folder Labs), and waits until Argo CD reports cert-manager and the four monitoring-pack apps Synced/Healthy.

Application Manifests

Storage that outlives the cluster

k8s/storage/storage.yaml defines a StorageClass with no provisioner and two PersistentVolumes:

apiVersion: storage.k8s.io/v1
kind: StorageClass
metadata:
  name: lab-local
provisioner: kubernetes.io/no-provisioner   # static only: nothing is created on demand
volumeBindingMode: WaitForFirstConsumer
reclaimPolicy: Retain
---
apiVersion: v1
kind: PersistentVolume
metadata:
  name: ebpf-lab-redis
  labels: {lab: ebpf-lab}
spec:
  capacity: {storage: 1Gi}
  accessModes: [ReadWriteOnce]
  persistentVolumeReclaimPolicy: Retain
  storageClassName: lab-local
  claimRef: {namespace: demo, name: redis-data}
  local:
    path: /var/lib/lab-storage/redis
  nodeAffinity:
    required:
      nodeSelectorTerms:
        - matchExpressions:
            - {key: kubernetes.io/hostname, operator: In, values: [k3d-lab-ebpf-server-0]}

The PV’s name, path and claimRef are fixed, and its node is pinned. After make rebuild, the new cluster gets a PV with the same name over the same folder, reserved for the same claim, so Redis finds its old append-only file. Retain means deleting the claim never deletes the folder. The second PV, ebpf-lab-falco-ui-redis, does the same for the Falcosidekick UI’s event store.

The app

k8s/app/app.yaml creates namespace demo and three Deployments. The claim names its PV explicitly:

apiVersion: v1
kind: PersistentVolumeClaim
metadata:
  name: redis-data
  namespace: demo
spec:
  storageClassName: lab-local
  volumeName: ebpf-lab-redis
  accessModes: [ReadWriteOnce]
  resources:
    requests: {storage: 1Gi}

Redis runs as the host user that owns /srv/homelab and writes every change to its append-only file:

    spec:
      securityContext: {runAsUser: 1000, runAsGroup: 1000, runAsNonRoot: true}
      containers:
        - name: redis
          image: redis:7.4.2-alpine
          args: ["--appendonly", "yes", "--dir", "/data"]
          readinessProbe: {exec: {command: [redis-cli, ping]}, periodSeconds: 5}
          resources: {requests: {cpu: 20m, memory: 32Mi}, limits: {memory: 128Mi}}

The Recreate strategy keeps a single writer on the ReadWriteOnce volume. That redis-cli ping probe runs every 5 seconds, and Tetragon sees each one as a process execution; the dashboard filters them out.

The API has two replicas spread across the nodes, so some requests cross nodes:

spec:
  replicas: 2                          # spread over both nodes, so some traffic crosses VXLAN
  template:
    spec:
      topologySpreadConstraints:
        - {maxSkew: 1, topologyKey: kubernetes.io/hostname, whenUnsatisfiable: ScheduleAnyway,
           labelSelector: {matchLabels: {app: api}}}
      containers:
        - name: api
          image: ebpf-lab/api:dev
          imagePullPolicy: Never
          env: [{name: REDIS_ADDR, value: "redis:6379"}]
          readinessProbe: {httpGet: {path: /healthz, port: 8080}, periodSeconds: 5}
          resources: {requests: {cpu: 20m, memory: 16Mi}, limits: {memory: 64Mi}}

web is one replica behind a NodePort Service on 30091. Its readiness probe also hits /healthz; those probes are the steady /healthz lines in the dashboard’s request panels.

Observability Stack

Two different paths leave the lab, plus two local UIs.

The monitoring pack (installed by Argo CD): the agent collector, a DaemonSet in namespace monitoring, tails every pod’s log file and scrapes the kubelet and cAdvisor on its node; the cluster collector scrapes kube-state-metrics and the API server. Both add k8s.cluster.name=lab-ebpf and send OTLP to the gateway on mon. Tetragon’s and Falco’s JSON events travel this way, as log lines.

OBI, straight to the gateway. OBI must run on the host network (its context propagation needs it). In this nested setup, Cilium translates neither Service addresses nor host ports for host-network sockets, so OBI can’t reach agent-collector.monitoring. It can’t resolve mon’s names either: the node’s resolver is Docker’s. So OBI sends OTLP/HTTPS to https://otlp.mon.home.cloudutsuk.com itself, with the labs token, and make obi adds a host alias for that name at mon’s fixed ingress address:

	$(KUBECTL) -n obi patch ds obi --type merge -p \
	  '{"spec":{"template":{"spec":{"hostAliases":[{"ip":"172.30.0.3","hostnames":["otlp.mon.home.cloudutsuk.com"]}]}}}}'

Tetragon and OBI hit the same API-server problem as Cilium, for the same reason: they run on the host network, where the API’s ClusterIP doesn’t answer. The Makefile sets KUBERNETES_SERVICE_HOST to the server node’s address for both. Without it, OBI has no pod metadata and its namespace rule matches nothing.

Scoping Tetragon and Falco to the lab

Both see every process on the host. helm/tetragon-values.yaml exports only the demo namespace:

tetragon:
  clusterName: lab-ebpf
  exportAllowList: |-
    {"namespace":["demo"], "event_set":["PROCESS_EXEC", "PROCESS_EXIT", "PROCESS_KPROBE", "PROCESS_TRACEPOINT", "PROCESS_LSM"]}
  enableProcessCred: true
  enableProcessNs: true
export:
  mode: stdout

Falco keeps its stock rules (they’re part of the comparison) and adds two lab rules in helm/falco-values.yaml, both limited to k8s.ns.name = "demo":

    - rule: Shell in demo pod
      condition: >
        spawned_process and container and k8s.ns.name = "demo"
        and proc.name in (sh, bash, ash, dash)
      output: >
        Shell in demo pod (user=%user.name uid=%user.uid cmdline=%proc.cmdline
        pod=%k8s.pod.name ns=%k8s.ns.name container=%container.name parent=%proc.pname)
      priority: WARNING
      tags: [ebpf_lab, shell, mitre_execution]

    - rule: Network tool in demo pod
      condition: >
        spawned_process and container and k8s.ns.name = "demo"
        and proc.name in (wget, curl, nc, ncat)
      # … priority: CRITICAL, tags: [ebpf_lab, network, mitre_command_and_control]

The stock rules are not scoped. They fire for processes anywhere on the host, which is why the Falcosidekick UI’s totals run into the tens of thousands while the lab’s own events are a handful. The Grafana panel keeps only lines tagged ebpf_lab. Falco uses the modern eBPF probe (driver.kind: modern_ebpf) and gets pod names from k3s’s containerd.

How each signal is collected

1. Four sources: OBI, Tetragon and Falco watch the kernel; the kubelet and cAdvisor expose container metrics. None of the eBPF tools is configured with an exporter to Loki.
2. Events are log lines: Tetragon writes JSON events on its export-stdout container, Falco on stdout. The container runtime stores both under /var/log/pods.
3. Falco's own UI: Falcosidekick receives each Falco alert over HTTP and keeps it in the UI's Redis, on a static PV.
4. The agent collects: The monitoring pack's agent collector tails every pod log on its node and scrapes the kubelet and cAdvisor every 30 s, adding pod labels and k8s.cluster.name.
5. OBI goes direct: OBI can't reach the agent from the host network here, so it pushes OTLP to the gateway itself: metrics every 60 s, spans in 15 s batches.
6. One token for labs: Everything else reaches the gateway through the agent, with the shared labs token. The gateway sets cluster=lab-ebpf from k8s.cluster.name.
7. Three stores: Metrics go to Mimir, logs (including Tetragon and Falco events) to Loki, spans to Tempo.
8. One dashboard: The eBPF lab dashboard queries all three, every query filtered on lab-ebpf.

The dashboard

dashboards/ebpf-lab.json (uid ebpf-lab) is loaded into mon by lab.sh register. Part 5 goes through it panel by panel. To change it, edit the JSON and run make monitoring again; Grafana’s sidecar on mon picks it up within a minute.

Ports and Endpoints

What	URL or port	How it’s exposed
The app	http://127.0.0.1:8091	k3d maps host 8091 to NodePort 30091 on the server node; Cilium forwards it to web
Hubble UI	http://127.0.0.1:8092	NodePort 30092
Falcosidekick UI	http://127.0.0.1:8093 (login admin / admin, the chart’s default)	NodePort 30093
Kubernetes API	127.0.0.1:6450, context k3d-lab-ebpf	k3d’s server load balancer
Grafana (mon)	https://grafana.mon.home.cloudutsuk.com, Dashboards › Labs › eBPF lab	The homelab’s mon cluster, Keycloak sign-in
OBI’s Prometheus endpoint	port 9090 on each node	make obi-metrics port-forwards it
OTLP gateway (outbound)	https://otlp.mon.home.cloudutsuk.com (172.30.0.3)	Used by OBI and the agent collector

All four host ports bind to 127.0.0.1, so nothing in the lab, including the Falcosidekick UI’s default login, is reachable from the network.

Check Your Understanding

Why does the cluster stay NotReady right after k3d cluster create?

k3s starts with --flannel-backend=none, so there’s no CNI until make cilium installs one. The kubelet reports the node not ready while the network plugin is missing.

What makes the rebuilt cluster's Redis find the old data, and what would break it?

The PV ebpf-lab-redis is recreated with the same name and path, with claimRef reserving it for demo/redis-data, and the claim names volumeName: ebpf-lab-redis. Change the folder, the PV name or the node name in its affinity (for example by renaming the cluster) and the new claim would bind to an empty folder or stay Pending.

Why does OBI send to the gateway's public name instead of to the agent collector like everything else?

OBI runs on the host network, and in this nested k3d setup Cilium doesn’t translate Service addresses for host-network sockets, so the collector’s Service is unreachable from OBI. It sends to the gateway directly, with a host alias because the node’s resolver doesn’t know the internal zone.

The Falcosidekick UI shows tens of thousands of Critical events. Is the lab under attack?

No. Falco’s stock rules aren’t limited to namespace demo, and its eBPF probe sees the whole host’s syscalls, including the other homelab clusters. The lab’s own rules are tagged ebpf_lab; filter on that.
