gRPC: Contract-First RPC over HTTP/2 and Protocol Buffers

gRPC is a high-performance remote procedure call (RPC) framework. You define a service and its messages once in a .proto file, generate client and server code for each language, and then call remote methods as if they were local functions. Messages are encoded as compact binary Protocol Buffers and travel over HTTP/2, which gives gRPC streaming, multiplexing and low latency.

This post is part of the API communication protocols series.

At a glance

	gRPC
Type	RPC framework with a wire protocol
Created by	Google (open-sourced 2015, 1.0 in 2016); a CNCF incubating project since 2017
Transport	HTTP/2 (one long-lived connection, many concurrent streams)
Payload	Protocol Buffers (binary) by default; JSON possible but rare
Contract	Required: .proto file, with generated client stubs and server skeletons
Call types	Unary, server streaming, client streaming, bidirectional streaming
Browser support	Needs gRPC-Web (or Connect) plus a proxy such as Envoy
Best for	Internal microservice calls, polyglot systems, streaming, mobile-to-backend

What gRPC is

gRPC has three parts:

1. An interface definition language: Protocol Buffers (proto3) describe services, methods and messages.
2. Code generation: protoc with language plugins produces typed clients and server interfaces for Go, Java, C#, Python, C++, Node.js, Kotlin, Swift, Rust, Dart and more.
3. A runtime and wire protocol: channels, load balancing, deadlines, cancellation, metadata, interceptors and status codes, all mapped onto HTTP/2.

syntax = "proto3";
package orders.v1;

service OrderService {
  rpc GetOrder (GetOrderRequest) returns (Order);                        // unary
  rpc WatchOrders (WatchOrdersRequest) returns (stream OrderEvent);      // server streaming
  rpc UploadItems (stream OrderItem) returns (UploadSummary);            // client streaming
  rpc Chat (stream SupportMessage) returns (stream SupportMessage);      // bidirectional
}

message GetOrderRequest { int64 id = 1; }

message Order {
  int64 id = 1;
  string status = 2;
  double total = 3;
  repeated OrderItem items = 4;
}

message OrderItem { string sku = 1; int32 quantity = 2; }
message WatchOrdersRequest { int64 customer_id = 1; }
message OrderEvent { int64 order_id = 1; string status = 2; }
message UploadSummary { int32 accepted = 1; }
message SupportMessage { string text = 1; }

The numbers (= 1, = 2) are field tags. On the wire, a field is identified by its tag, not its name, which is why Protobuf messages are small, and why you can add new fields without breaking old clients, as long as you never reuse or renumber a tag.

Why it was developed

Google has connected its services with an internal RPC system called Stubby since around 2001, handling billions of calls per second across its data centres. Protocol Buffers, Stubby’s serialisation format, was open-sourced in 2008, but Stubby itself was tied to Google’s infrastructure. When HTTP/2 (derived from Google’s SPDY) was being standardised, Google rebuilt the ideas of Stubby on top of it and open-sourced the result as gRPC in February 2015. Version 1.0 followed in August 2016, and gRPC joined the Cloud Native Computing Foundation in 2017.

The goals were the problems REST and JSON leave open for internal traffic: a strict contract shared by many languages, efficient binary encoding, streaming in both directions, and built-in deadlines, cancellation and load balancing for large microservice fleets.

How it works

A gRPC call passes through a generated stub, becomes an HTTP/2 stream, and is dispatched to a typed handler on the server. Switch modes to compare a unary call with server streaming:

1. Call a local method: Client code calls a method on a stub generated from the .proto file, as if it were a local function, with a deadline attached.
2. Serialize with protobuf: The stub encodes the request message to compact binary using the field numbers from the contract.
3. Open a stream: The call becomes a new HTTP/2 stream: a HEADERS frame with :path /orders.v1.OrderService/GetOrder and content-type application/grpc.
4. Send the message: The request travels as a length-prefixed DATA frame. Many calls share one TCP connection without blocking each other.
5. Dispatch to the handler: The server stub decodes the bytes back into a typed object and invokes the implementation of GetOrder.
6. Unary response (unary): One response message, then trailers carry grpc-status 0 (OK). The client stub decodes it and returns a typed Order.
7. First streamed message (stream): For a server-streaming method such as WatchOrders, the server writes the first message on the same stream.
8. More messages (stream): It keeps writing messages as events happen; the client reads them in a loop. Flow control stops a slow client from being flooded.
9. Close with a status (stream): The server ends the stream with trailers holding grpc-status. Client and bidirectional streaming work the same way in the other direction.

On the wire

Each call is one HTTP/2 stream on a shared connection:

HTTP/2 frame	Content
HEADERS	:method POST, :path /orders.v1.OrderService/GetOrder, content-type: application/grpc, grpc-timeout: 300m, custom metadata such as authorization
DATA	One or more messages, each prefixed with a 1-byte compression flag and a 4-byte length
HEADERS (trailers)	grpc-status: 0 and optional grpc-message

Because HTTP/2 multiplexes streams, hundreds of concurrent calls share one TCP connection without head-of-line blocking at the HTTP level, and headers are compressed with HPACK.

The four kinds of method

sequenceDiagram
    participant C as Client
    participant S as Server
    Note over C,S: Unary: GetOrder
    C->>S: GetOrderRequest
    S-->>C: Order, status OK
    Note over C,S: Server streaming: WatchOrders
    C->>S: WatchOrdersRequest
    S-->>C: OrderEvent
    S-->>C: OrderEvent
    S-->>C: status OK
    Note over C,S: Client streaming: UploadItems
    C->>S: OrderItem
    C->>S: OrderItem
    C->>S: half-close
    S-->>C: UploadSummary, status OK
    Note over C,S: Bidirectional streaming: Chat
    C->>S: SupportMessage
    S-->>C: SupportMessage
    C->>S: SupportMessage
    S-->>C: SupportMessage

Generated code as UML

Code generation produces a typed client and an abstract server class for each service. This is roughly what protoc generates in an object-oriented language:

classDiagram
    class OrderServiceClient {
        +GetOrder(GetOrderRequest, deadline) Order
        +WatchOrders(WatchOrdersRequest) stream of OrderEvent
        +UploadItems() client stream
        +Chat() bidirectional stream
    }
    class OrderServiceBase {
        <<abstract>>
        +GetOrder(GetOrderRequest, context) Order
        +WatchOrders(WatchOrdersRequest, writer)
        +UploadItems(reader) UploadSummary
        +Chat(reader, writer)
    }
    class OrderServiceImpl {
        +GetOrder(GetOrderRequest, context) Order
    }
    class Channel {
        +target
        +credentials
        +loadBalancingPolicy
    }
    OrderServiceClient --> Channel : sends calls over
    OrderServiceImpl --|> OrderServiceBase : implements

Using it

A Go server and client for GetOrder:

// server
type server struct{ ordersv1.UnimplementedOrderServiceServer }

func (s *server) GetOrder(ctx context.Context, req *ordersv1.GetOrderRequest) (*ordersv1.Order, error) {
    o, err := store.Find(ctx, req.GetId())
    if errors.Is(err, store.ErrNotFound) {
        return nil, status.Errorf(codes.NotFound, "order %d not found", req.GetId())
    }
    return o, err
}

// client
conn, _ := grpc.NewClient("orders:50051", grpc.WithTransportCredentials(creds))
client := ordersv1.NewOrderServiceClient(conn)
ctx, cancel := context.WithTimeout(context.Background(), 300*time.Millisecond)
defer cancel()
order, err := client.GetOrder(ctx, &ordersv1.GetOrderRequest{Id: 42})

For debugging, grpcurl is the gRPC equivalent of curl: grpcurl -d '{"id": 42}' orders:50051 orders.v1.OrderService/GetOrder (it needs server reflection or the .proto files).

Deadlines, cancellation and status codes

• Deadlines travel with the call (grpc-timeout). When a deadline passes, the client gets DEADLINE_EXCEEDED and the server’s context is cancelled, so downstream calls stop too.
• Status codes replace HTTP status codes: OK, INVALID_ARGUMENT, NOT_FOUND, ALREADY_EXISTS, PERMISSION_DENIED, UNAUTHENTICATED, RESOURCE_EXHAUSTED, UNAVAILABLE, DEADLINE_EXCEEDED, INTERNAL and others, 17 in all.
• Metadata is the equivalent of HTTP headers, used for auth tokens and tracing context.
• Interceptors are middleware for logging, metrics, auth and retries.

Load balancing

Because one HTTP/2 connection carries many calls, a layer 4 (TCP) load balancer sends all of a client’s calls to the same backend. gRPC needs either client-side load balancing (the client resolves all backends through DNS or xDS and spreads calls) or a layer 7 proxy that understands HTTP/2, such as Envoy, Linkerd or Istio.

gRPC in the browser

Browsers do not expose HTTP/2 frames or trailers to JavaScript, so they cannot speak native gRPC. gRPC-Web uses a slightly different wire format that a proxy (Envoy) translates. The Connect protocol from Buf is another option that serves gRPC, gRPC-Web and a simple JSON-over-HTTP protocol from the same handlers.

Where it is used

• Microservice back ends where many services in different languages call each other.
• Infrastructure and control planes: container runtimes, service meshes, databases.
• Mobile to backend where bandwidth and battery matter.
• Streaming: telemetry, logs, real-time updates between services.
• Machine learning serving: TensorFlow Serving and NVIDIA Triton Inference Server offer gRPC endpoints.

Real-life examples

Kubernetes Container Runtime Interface

The kubelet on every Kubernetes node does not talk to containerd or CRI-O through a custom API: it calls them through the Container Runtime Interface, a gRPC service defined in .proto files (RuntimeService with methods such as RunPodSandbox, CreateContainer and StartContainer, and ImageService with PullImage). The call goes over a local Unix socket. Any runtime that implements the gRPC contract can be plugged into Kubernetes, which is the point of contract-first design.

etcd and Envoy

etcd, the key-value store that holds all Kubernetes cluster state, exposes its v3 API over gRPC; the Watch method is a bidirectional stream that pushes key changes to the API server. Envoy proxies receive their configuration through the xDS APIs, which are gRPC streaming services, so a control plane such as Istio can push new routes and endpoints to thousands of proxies instantly.

Strengths and limitations

Strengths	Limitations
Small binary messages, fast to serialise	Not human-readable; needs grpcurl or reflection to debug
Strict, versionable contract with code generation	Browsers need gRPC-Web or Connect and a proxy
Four call types including bidirectional streaming	Load balancing needs L7 proxies or client-side balancing
Deadlines, cancellation and metadata built in	HTTP caching and CDNs do not apply
HTTP/2 multiplexing over one connection	Shared .proto files must be managed (registry, linting, breaking-change checks)

Best practices

• Always set deadlines on the client and propagate the context downstream.
• Version packages (orders.v1) and never reuse or change field numbers; reserve removed ones with reserved.
• Lint and check for breaking changes in CI with buf lint and buf breaking, and keep .proto files in a shared repository or schema registry.
• Return rich status codes, not UNKNOWN for everything.
• Use TLS or mTLS (a service mesh can do this transparently) and pass auth tokens in metadata.
• Enable health checking (grpc.health.v1) and retries with backoff only for idempotent methods.
• Keep messages small; the default maximum received message size is 4 MB. Stream large data.

When to use gRPC, and when not

Use gRPC for internal service-to-service traffic, polyglot systems, low-latency or high-throughput paths, and anything that needs streaming in both directions.

Prefer REST for public APIs and browser clients, GraphQL for flexible front-end data fetching, and AMQP when the caller should not wait for the callee at all.
