GraphQL: Ask for Exactly the Data You Need

GraphQL is a query language for APIs and a runtime that answers those queries. Instead of calling several fixed endpoints, a client sends one query to one endpoint, describing exactly the fields it needs, and receives a JSON response with exactly that shape. A strongly typed schema defines everything that can be asked for.

This post is part of the API communication protocols series.

At a glance

	GraphQL
Type	Query language plus server runtime, with a specification
Created by	Facebook (internal 2012, open-sourced 2015); now the GraphQL Foundation (Linux Foundation)
Transport	HTTP, almost always POST /graphql; WebSocket or SSE for subscriptions
Payload	JSON request (query, variables, operationName) and JSON response (data, errors)
Contract	Required: a typed schema written in SDL, discoverable through introspection
Operations	query (read), mutation (write), subscription (server push)
Caching	Not HTTP-native; done by clients (normalised caches) or persisted queries
Best for	Front ends with varied, nested data needs; aggregating many back ends

What GraphQL is

A GraphQL API is described by a schema of types and fields. Some fields are scalars (String, Int, ID), others point to other types, so the schema is a graph. The Query and Mutation types are the entry points.

type User {
  id: ID!
  name: String!
  orders(last: Int = 10): [Order!]!
  reviews: [Review!]!
}

type Order {
  id: ID!
  total: Float!
  status: OrderStatus!
}

type Review {
  stars: Int!
  text: String
}

enum OrderStatus { PENDING PAID SHIPPED }

type Query {
  user(id: ID!): User
}

type Mutation {
  cancelOrder(id: ID!): Order
}

type Subscription {
  orderStatusChanged(userId: ID!): Order
}

The client chooses a path through that graph:

query UserSummary($id: ID!) {
  user(id: $id) {
    name
    orders(last: 3) { total status }
    reviews { stars }
  }
}

and gets back the same shape:

{
  "data": {
    "user": {
      "name": "Asha",
      "orders": [
        { "total": 129.9, "status": "PAID" },
        { "total": 42.0, "status": "SHIPPED" },
        { "total": 15.5, "status": "PENDING" }
      ],
      "reviews": [{ "stars": 5 }, { "stars": 4 }]
    }
  }
}

With REST, the same screen might need GET /users/7, GET /users/7/orders?limit=3 and GET /users/7/reviews, three round trips, each returning fields the screen never shows.

Why it was developed

In 2012 Facebook was rewriting its iOS app as a native app. The News Feed needed deeply nested data (stories, authors, comments, likes, friends) and the existing REST-style endpoints and FQL either returned too much, too little or needed many round trips on slow mobile networks. Lee Byron, Nick Schrock and Dan Schafer designed GraphQL so that the app could describe the data it needed in one request, and product teams could change what a screen showed without waiting for new back-end endpoints.

Facebook presented GraphQL publicly in 2015 and released the specification and the graphql-js reference implementation. In 2018 the project moved to the GraphQL Foundation under the Linux Foundation. GitHub, Shopify, Netflix, Airbnb and many others have since adopted it.

How it works

Every operation goes through the same pipeline: parse, validate against the schema, execute resolvers, shape the result. This animation follows one query whose fields come from three different back ends:

1. Client writes a query: The client asks for exactly the fields it needs: user(id: 7) { name orders(last: 3) { total } reviews { stars } }.
2. One endpoint: Every operation is an HTTP POST to /graphql with the query and variables in a JSON body.
3. Parse and validate: The query is parsed into an AST and checked against the typed schema. Unknown fields or wrong argument types are rejected before any data is touched.
4. Resolvers fan out: Each field has a resolver. Independent fields run in parallel, and each resolver can call a different backend. DataLoader batches calls to avoid N+1 queries.
5. Results come back: The executor waits for every resolver. A failing resolver returns null for its field plus an entry in errors; the rest of the data still arrives.
6. One shaped response: The JSON mirrors the shape of the query, with no extra fields and no second round trip.

Resolvers

Each field in the schema has a resolver, a function that returns its value. The executor walks the query tree and calls resolvers level by level, passing each parent’s result to its children:

const resolvers = {
  Query: {
    user: (_parent, { id }, ctx) => ctx.usersApi.getUser(id),          // REST call
  },
  User: {
    orders: (user, { last }, ctx) => ctx.db.ordersFor(user.id, last),  // SQL
    reviews: (user, _args, ctx) => ctx.reviewsClient.list(user.id),   // gRPC call
  },
};

This is why GraphQL is often used as an aggregation layer: the client sees one graph, while the fields are backed by databases, REST services and gRPC services.

Operation lifecycle

sequenceDiagram
    autonumber
    participant C as Client
    participant G as GraphQL server
    participant U as Users service
    participant O as Orders DB
    C->>G: POST /graphql, query and variables
    G->>G: parse to AST
    G->>G: validate against schema
    alt invalid query
        G-->>C: 200 with errors array, no data
    else valid query
        G->>U: user resolver
        U-->>G: user 7
        par children run in parallel
            G->>O: orders resolver
            O-->>G: 3 orders
        and
            G->>G: reviews resolver
        end
        G-->>C: 200 with data shaped like the query
    end

GraphQL over HTTP usually returns 200 OK even when some fields failed. Errors are reported in an errors array next to partial data, so clients must check both.

Schema as UML

The schema above, drawn as a UML class diagram. Each arrow is a field that a query can follow:

classDiagram
    class Query {
        user(id) User
    }
    class Mutation {
        cancelOrder(id) Order
    }
    class Subscription {
        orderStatusChanged(userId) Order
    }
    class User {
        ID id
        String name
        orders(last) Order list
        reviews() Review list
    }
    class Order {
        ID id
        Float total
        OrderStatus status
    }
    class Review {
        Int stars
        String text
    }
    Query --> User
    Mutation --> Order
    Subscription --> Order
    User "1" --> "*" Order : orders
    User "1" --> "*" Review : reviews

Mutations and subscriptions

Mutations are writes. They run sequentially, in the order written, and return the changed object so the client can update its cache:

mutation { cancelOrder(id: "42") { id status } }

Subscriptions are server push. The client subscribes once, and the server sends a result every time the event fires. The transport is usually WebSocket (the graphql-ws protocol) or Server-Sent Events:

subscription { orderStatusChanged(userId: "7") { id status } }

The N+1 problem and DataLoader

A naive orders resolver runs once per user. Asking for 100 users and their orders produces 1 query for the users plus 100 queries for orders. DataLoader collects all the keys requested during one tick of execution and loads them with one batched call (WHERE user_id IN (...)), with a per-request cache.

Federation

In large organisations a single schema is owned by many teams. Apollo Federation (and the open GraphQL Composite Schemas work) lets each team publish a subgraph, and a router composes them into one supergraph that clients query as if it were one API.

Where it is used

• Mobile and web front ends with many screens that need different slices of the same data.
• Backend-for-frontend (BFF) layers that aggregate microservices for one client type.
• Public developer platforms where consumers want flexible access to a rich data model.
• Content and commerce platforms (headless CMSs such as Contentful, commerce such as Shopify).

Real-life examples

GitHub GraphQL API

GitHub announced its GraphQL API (API v4) in 2016 because integrators were making many REST calls to assemble one view. A single query can fetch a repository, its last 10 pull requests, each one’s reviews and labels. GitHub limits cost rather than requests: each query is scored by the number of nodes it may return, and the score is deducted from a points-per-hour budget, which is how it protects itself from expensive nested queries.

query {
  repository(owner: "cotes2020", name: "jekyll-theme-chirpy") {
    pullRequests(last: 5, states: OPEN) {
      nodes { title author { login } reviews(first: 3) { nodes { state } } }
    }
  }
}

Shopify Storefront and Admin APIs

Shopify exposes its commerce platform through GraphQL. Custom storefronts (for example built with Shopify’s Hydrogen framework) query products, variants, prices and inventory in one request per page, and apps manage orders through the Admin GraphQL API. Shopify also uses calculated query cost for rate limiting and offers bulk operations for large exports, two answers to GraphQL’s main operational risks.

Strengths and limitations

Strengths	Limitations
No over-fetching or under-fetching; one round trip per screen	HTTP caching does not work for POST to one URL
Strong, introspectable schema; great tooling (GraphiQL, codegen)	Resolver performance: N+1 queries without batching
Front ends evolve without new endpoints; fields deprecate gracefully	Malicious or accidental expensive queries need depth and cost limits
One graph over many back ends	Errors return with 200 OK; monitoring needs GraphQL awareness
Subscriptions for real-time updates	File uploads and binary data are awkward

Best practices

• Use persisted queries (allow-listed query hashes) in production: smaller requests, GET caching becomes possible and arbitrary queries are blocked.
• Limit depth, complexity and cost, and set timeouts per operation.
• Batch with DataLoader in every resolver that loads by key.
• Disable introspection in public production endpoints unless the API is meant to be explored.
• Design the schema for the client, not as a mirror of database tables. Use @deprecated rather than breaking changes; GraphQL APIs are usually versionless.
• Authorise in the business layer, per field or per object, not only at the endpoint.
• Paginate with connections (first, after, edges, pageInfo).

When to use GraphQL, and when not

Use GraphQL when many clients need different shapes of related data, when a front-end team wants to move without back-end changes, or when you need a single graph over many services.

Prefer REST for simple CRUD, public resources that benefit from CDN caching, or file-heavy APIs. Prefer gRPC for internal service-to-service calls where the shape of data is fixed and latency matters.
