REST vs GraphQL vs gRPC vs WebSocket vs SSE vs SOAP vs Webhooks vs MQTT vs AMQP

REST and GraphQL are styles for client-facing request/response APIs, gRPC is a high-performance RPC framework mostly used between services, WebSocket is a transport for persistent two-way messaging, SSE and long polling push data over plain HTTP, SOAP is the contract-heavy XML predecessor, webhooks are HTTP callbacks between systems, and MQTT and AMQP are broker-based messaging protocols. This post puts them side by side: how they differ, where each one fits and how they are combined in a real system.

This post concludes the API communication protocols series. Each protocol links to its own deep dive.

Index

• The three families
• The master comparison table
• Operational comparison
• Head to head
• The same operation in each protocol
• Decision tree
• Using them together
• Where each one is used
• Common mistakes
• Summary

The three families

Comparing every protocol with every other only makes sense once you notice they solve three different problems:

Family	Question it answers	Members
Request/response APIs	“Client, ask me for something and wait for the answer.”	REST, GraphQL, gRPC, SOAP
Push and real-time	“Server, tell me when something changes.”	WebSocket, SSE and long polling, webhooks, GraphQL subscriptions, gRPC streaming
Brokered messaging	“Deliver this reliably to whoever needs it, even if they are not ready.”	MQTT, AMQP

flowchart LR
    subgraph RR["Request/response"]
        REST
        GraphQL
        gRPC
        SOAP
    end
    subgraph PUSH["Push and real-time"]
        WebSocket
        SSE["SSE / long polling"]
        Webhooks
    end
    subgraph MSG["Brokered messaging"]
        MQTT
        AMQP
    end
    GraphQL -. subscriptions .-> PUSH
    gRPC -. streaming .-> PUSH
    MQTT -. over WebSocket .-> WebSocket

The master comparison table

	REST	GraphQL	gRPC	SOAP	WebSocket	SSE	Long polling	Webhooks	MQTT	AMQP
What it is	Architectural style	Query language and runtime	RPC framework	XML messaging protocol	Full-duplex protocol	Streaming format and browser API	HTTP technique	HTTP callback pattern	Pub/sub protocol	Messaging protocol
Origin	Fielding, 2000	Facebook, 2012 / 2015	Google, 2015	Microsoft and partners, 1998	IETF RFC 6455, 2011	WHATWG, Opera 2006	Comet, 2006	Jeff Lindsay, 2007	IBM and Arcom, 1999	JPMorgan Chase, 2003
Model	Resources, URLs, verbs	One endpoint, client-written queries	Methods on services	Operations in an envelope	Message channel	Event stream	Held request	Provider calls your URL	Topics through a broker	Exchanges, bindings, queues
Transport	HTTP/1.1, 2, 3	HTTP	HTTP/2	HTTP (also JMS, SMTP)	TCP via HTTP upgrade	HTTP	HTTP	HTTP	TCP (or WebSocket)	TCP
Payload	JSON (any media type)	JSON	Protobuf (binary)	XML	Text or binary	UTF-8 text	Any	JSON	Any bytes	Any bytes plus properties
Contract	Optional (OpenAPI)	Required schema	Required .proto	Required WSDL	None	None	None	Provider docs	None	None
Code generation	Optional	Common	Built in	Built in	No	No	No	No	No	No
Direction	Request/response	Request/response plus subscriptions	Unary and three streaming types	Request/response	Full duplex	Server to client	Server to client	Provider to consumer	Pub/sub	Pub/sub and queues
Connection	Short or keep-alive	Short or keep-alive	Long-lived, multiplexed	Short	Long-lived, stateful	Long-lived	Repeated	Short	Long-lived to broker	Long-lived to broker
Coupling	Client knows URL	Client knows schema	Client knows contract	Client knows WSDL	Both know message format	Client knows stream	Client knows endpoint	Provider knows URL	Only topic names	Only exchange and key
Delivery guarantee	Per request (retry if idempotent)	Per request	Per call, with deadlines	Per request (WS-ReliableMessaging)	None beyond TCP	Resume with Last-Event-ID	Cursor based	At least once, retries	QoS 0, 1 or 2	At least once with acks
HTTP caching	Native	Hard (persisted queries help)	No	No	No	No	No	No	No (retained messages)	No
Browser	Native	Native	gRPC-Web proxy	Possible, rare	Native	Native	Native	Not applicable	Over WebSocket	Not directly
Human-readable	Yes	Yes	No	Yes, verbose	Depends	Yes	Yes	Yes	Depends	Depends

Operational comparison

	REST	GraphQL	gRPC	SOAP	WebSocket	SSE	Webhooks	MQTT	AMQP
Message overhead	Medium (HTTP headers + JSON)	Medium	Low (HPACK + Protobuf)	High (XML)	Very low (2 to 14 B frames)	Very low	Medium	Very low (2 B fixed header)	Low
Latency	Good	Good, one round trip	Excellent	Fair	Excellent	Excellent	Seconds (event driven)	Excellent	Good
Load balancing	Easy (stateless)	Easy	Needs L7 or client-side	Easy	Hard (sticky, long-lived)	Medium	Easy	Broker cluster	Broker cluster
Scaling concern	Request rate	Query cost, N+1	Connection spread	XML CPU	Open connections, fan-out	Open connections	Receiver bursts	Connections, fan-out	Queue depth
Debugging	curl, browser	GraphiQL	grpcurl, reflection	SoapUI	Browser DevTools	curl, DevTools	Delivery logs, tunnels	MQTT Explorer	Management UI
Security model	TLS, OAuth 2.0, API keys	Same as REST plus cost limits	TLS or mTLS, metadata tokens	TLS plus WS-Security	TLS, Origin check, token at connect	Same as HTTP	HMAC signatures, TLS	TLS, client certs, topic ACLs	TLS, SASL, vhost permissions
Learning curve	Low	Medium	Medium	High	Low to start, high to scale	Low	Low	Low	Medium

Head to head

REST vs GraphQL

	REST	GraphQL
Endpoints	Many, one per resource	One
Who shapes the response	Server	Client
Round trips for nested data	Often several	One
Caching	HTTP and CDN	Client-side normalised cache, persisted queries
Versioning	/v1, /v2	Evolve the schema, deprecate fields
Errors	HTTP status codes	200 with an errors array
Main risk	Over-fetching and chatty clients	Expensive queries, N+1 resolvers

Choose REST for public, cacheable, resource-oriented APIs. Choose GraphQL when many screens need different views of a connected data model, usually behind a BFF. Many companies, GitHub among them, offer both.

REST vs gRPC

	REST	gRPC
Contract	Optional	Mandatory, with generated code
Encoding	JSON text	Protobuf binary
Streaming	No (use SSE or WebSocket)	Four call types
Browser	Native	Needs gRPC-Web
Speed	Good	Better: smaller messages, multiplexing, no JSON parsing
Ecosystem	Universal	Strong in cloud-native and polyglot back ends

Choose REST at the edge and for partners. Choose gRPC for internal east-west traffic, especially with many languages, high call rates or streaming.

GraphQL vs gRPC

Both have a typed schema, but they optimise for different consumers. GraphQL lets the client decide the shape of each response, which suits front ends. gRPC fixes the shape in the contract and optimises the wire, which suits services. A common architecture uses GraphQL at the edge and gRPC behind it.

SOAP vs REST

SOAP offers formal contracts, message-level security and WS-* transactions at the cost of verbose XML and complexity. REST trades those features for simplicity and the web’s infrastructure. Use SOAP when a partner or regulator requires it; build new APIs as REST or gRPC and wrap legacy SOAP services behind a facade.

WebSocket vs SSE vs long polling

	WebSocket	SSE	Long polling
Direction	Both ways	Server to client	Server to client
Protocol	Own framing after HTTP upgrade	Plain HTTP response	Plain HTTP requests
Reconnect and resume	You build it	Built in	You build it (cursor)
Binary data	Yes	No (text only)	Yes
Proxy friendliness	Good on 443, some proxies break it	Very good (watch buffering)	Excellent
Per-message overhead	2 to 14 bytes	A few bytes	A full HTTP exchange
Typical uses	Chat, games, collaboration, trading	Notifications, progress, LLM tokens	Fallback, bot APIs, restrictive networks

Rule of thumb: if the client also sends a lot, use WebSocket; if only the server sends, use SSE; use long polling only when streaming is blocked.

Webhooks vs polling vs SSE

All three answer “how do I learn about changes in another system?”. Polling is simple but slow and wasteful. Webhooks are instant and cheap but need a public endpoint and careful verification. SSE or long polling work when the consumer cannot accept inbound connections (a laptop, a mobile app, a locked-down network). Many providers, such as Telegram, offer both webhooks and long polling for exactly this reason.

MQTT vs AMQP (and Kafka)

	MQTT	AMQP 0-9-1	Kafka (for reference)
Designed for	Constrained devices and unreliable networks	Reliable business messaging between services	High-throughput, replayable event streams
Routing	Topic hierarchy with + and # wildcards	Exchanges (direct, fanout, topic, headers) and bindings	Topics and partitions
Storage	Retained message and session queues only	Queues until acknowledged	Log retained for days or forever
Consumers	Every subscriber gets a copy (shared subscriptions in MQTT 5)	Competing consumers per queue, copies per queue	Consumer groups, each can replay
Client footprint	Tiny	Moderate	Heavier
Typical scale	Millions of device connections	Thousands of service connections	Millions of messages per second

Choose MQTT at the device edge, AMQP for commands, jobs and business events inside the platform, and Kafka when many consumers need to replay a stream. They are often chained: MQTT from devices, bridged into AMQP or Kafka in the cloud.

gRPC streaming vs WebSocket

Both provide bidirectional streams. gRPC streams are typed by a contract, multiplexed over HTTP/2 and best between services. WebSocket is untyped but native in every browser and best between a browser and a server.

The same operation in each protocol

“Get order 42” makes the differences concrete.

REST

GET /v1/orders/42 HTTP/1.1
Accept: application/json

GraphQL

query { order(id: "42") { id status total } }

gRPC

grpcurl -d '{"id": 42}' orders.internal:50051 orders.v1.OrderService/GetOrder

SOAP

<soap:Envelope xmlns:soap="http://www.w3.org/2003/05/soap-envelope" xmlns:o="urn:orders">
  <soap:Body><o:GetOrder><o:Id>42</o:Id></o:GetOrder></soap:Body>
</soap:Envelope>

WebSocket (a message on an already open connection; the format is your own)

{ "type": "order.get", "id": "req-17", "orderId": 42 }

SSE (you do not ask; updates to order 42 arrive on the stream)

event: order
data: {"id": 42, "status": "shipped"}

Webhook (the provider calls you when order 42 changes)

POST /webhooks/orders HTTP/1.1
Content-Type: application/json

{"type": "order.updated", "data": {"id": 42, "status": "shipped"}}

MQTT and AMQP (publish an event; whoever is subscribed receives it)

mosquitto_pub -t 'shop/orders/42/status' -m 'shipped' -q 1
rabbitmqadmin publish exchange=orders routing_key=order.shipped payload='{"id": 42}'

Decision tree

flowchart TD
    A["What do you need?"] --> B{"Does the caller need<br/>an answer right now?"}
    B -- "Yes" --> C{"Who is the caller?"}
    C -- "Public or partner client" --> D["REST"]
    C -- "Front end with varied,<br/>nested data needs" --> E["GraphQL"]
    C -- "Internal service,<br/>latency matters" --> F["gRPC"]
    C -- "Legacy system with a WSDL" --> G["SOAP"]
    B -- "No, it is an event<br/>or a notification" --> H{"Who receives it?"}
    H -- "A browser or app,<br/>server to client only" --> I["SSE<br/>(long polling as fallback)"]
    H -- "A browser or app,<br/>both directions" --> J["WebSocket"]
    H -- "Another company's server" --> K["Webhooks"]
    H -- "IoT devices" --> L["MQTT"]
    H -- "Your own back-end services,<br/>must not be lost" --> M["AMQP<br/>(or Kafka for replayable streams)"]

Using them together

Real systems mix protocols, each where it is strongest. This animation follows one order from a mobile app through six of them:

1. Customer taps Pay: The app has one screen to render and wants one round trip for everything it shows.
2. GraphQL at the edge: A placeOrder mutation goes to the backend-for-frontend, which asks for exactly the fields the screen needs.
3. gRPC inside: The BFF calls OrderService.CreateOrder over gRPC with a deadline. Typed, binary and fast on the internal network.
4. Service to service: The Order service reserves stock with another gRPC call. Generated clients mean no hand-written HTTP code.
5. REST to a third party: Card payment goes to an external provider's public REST API, the lingua franca between organisations.
6. Webhook back: Seconds later the provider POSTs a signed payment-succeeded event to a webhook endpoint instead of being polled.
7. Publish an event: The handler verifies the signature and publishes order.paid to an AMQP exchange. Billing, shipping and analytics can all subscribe.
8. Consume asynchronously: The notification service consumes the message from its queue at its own pace and acknowledges it.
9. Push to the device: The app holds an open WebSocket, so the confirmation appears instantly. Mobile push or SSE would also fit a one-way update.

Hop	Protocol	Why this one
Mobile app to BFF	GraphQL	One round trip with exactly the fields the screen needs
BFF to Order service, Order to Inventory	gRPC	Fast, typed, internal calls with deadlines
Order service to payment provider	REST	The provider’s public API; universal and well documented
Payment provider to webhook handler	Webhook	The provider notifies you; no polling
Webhook handler to other services	AMQP	Durable, decoupled fan-out to billing, shipping and notifications
Notification service to app	WebSocket (or SSE, or mobile push)	Instant update on an open connection

Add MQTT if warehouse scanners or delivery vans report events, bridged into the same broker.

Where each one is used

Protocol	Industries and products	Well-known examples
REST	Every industry; public APIs, cloud control planes	GitHub, Stripe, Twilio, Kubernetes API, Azure Resource Manager
GraphQL	E-commerce, social, media, developer platforms	GitHub API v4, Shopify Storefront API, Netflix and Airbnb internal graphs
gRPC	Cloud-native infrastructure, microservices, ML serving	Kubernetes CRI, etcd, Envoy xDS, TensorFlow Serving
SOAP	Banking, insurance, telecom, government, ERP	EU VIES VAT check, Salesforce SOAP API, carrier and payment gateways
WebSocket	Messaging, gaming, trading, collaboration	Slack, Discord Gateway, exchange market-data feeds
SSE / long polling	AI products, notifications, feeds; bots	LLM streaming APIs (Anthropic, OpenAI), Telegram getUpdates
Webhooks	SaaS, payments, DevOps, e-commerce	Stripe events, GitHub webhooks, Shopify, Slack apps
MQTT	IoT, manufacturing, energy, automotive, smart home	AWS IoT Core, Azure IoT Hub, Home Assistant, Facebook Messenger (2011)
AMQP	Finance, e-commerce back ends, enterprise integration	RabbitMQ with Celery, Azure Service Bus

Common mistakes

• Using WebSocket for everything “real-time”, when SSE would be simpler and work with existing HTTP infrastructure.
• Exposing gRPC to browsers or partners directly instead of putting REST or GraphQL at the edge.
• Using GraphQL as a thin proxy over REST without batching, cost limits or schema design.
• Calling services synchronously in long chains (REST or gRPC) where an AMQP event would decouple them and survive outages.
• Trusting webhooks without verifying signatures, or doing slow work before returning 2xx.
• Treating MQTT QoS 2 or AMQP acks as end-to-end exactly-once; consumers still need idempotency.
• Building new SOAP services where REST or gRPC would do.
• Forgetting the infrastructure: long-lived connections (WebSocket, SSE, gRPC, MQTT) need load balancers, timeouts and capacity planning designed for them.

Summary

• REST: the universal default for public and CRUD APIs; cacheable and simple, but can be chatty.
• GraphQL: client-shaped queries for rich front ends; flexible, but moves complexity to the server.
• gRPC: fast, typed, streaming RPC between services; not for browsers without help.
• SOAP: formal contracts and WS-Security for enterprise and legacy integration; heavy for new work.
• WebSocket: full-duplex real time; powerful, but stateful and you design the protocol.
• SSE and long polling: one-way push over plain HTTP; the simplest way to stream to a browser.
• Webhooks: event callbacks between systems; verify, deduplicate and acknowledge fast.
• MQTT: tiny, reliable pub/sub for devices on bad networks.
• AMQP: durable, acknowledged messaging that decouples services in time.

Pick per interaction, not per system: most architectures use three or four of these at once.
