WebSocket: Full-Duplex Real-Time Communication

WebSocket is a protocol that turns one HTTP request into a persistent, two-way connection. After a short handshake, client and server can each send messages at any moment, in both directions at once, with only a few bytes of framing per message. It is the standard way to build chat, multiplayer games, live dashboards, trading screens and collaborative editors on the web.

This post is part of the API communication protocols series.

At a glance

	WebSocket
Type	Application-layer protocol (IETF RFC 6455) plus the browser WebSocket API
Published	December 2011
Transport	TCP, upgraded from an HTTP/1.1 request; over HTTP/2 via RFC 8441
URL schemes	ws:// (port 80) and wss:// (TLS, port 443)
Payload	Text (UTF-8) or binary frames; the message format is up to you
Contract	None built in; subprotocols (Sec-WebSocket-Protocol) or AsyncAPI document it
Direction	Full duplex, either side may send at any time
Best for	Low-latency, high-frequency, two-way messaging

What WebSocket is

HTTP is request/response: the client asks, the server answers, and the server can never speak first. WebSocket keeps the TCP connection open after the first exchange and replaces HTTP with a lightweight framing protocol. There are no headers, cookies or status lines on each message, just a 2 to 14 byte frame header and the payload.

const ws = new WebSocket("wss://chat.example.com/rooms/42", ["chat.v1"]);

ws.onopen = () => ws.send(JSON.stringify({ type: "join", user: "asha" }));
ws.onmessage = (event) => render(JSON.parse(event.data));
ws.onclose = (event) => scheduleReconnect(event.code);

Why it was developed

Before WebSocket, browsers had no way to receive data the server wanted to send. Developers simulated it with polling (ask every few seconds), long polling and streaming hacks collectively called Comet (2006), hidden iframes and Flash sockets. Every message paid for HTTP headers, connections were constantly re-established and latency was poor.

In 2008, a TCPConnection API was proposed for HTML5; Ian Hickson and Michael Carter developed it further and named it WebSocket. After several incompatible drafts (and a security issue with early versions and transparent proxies, fixed with client-side masking), the IETF published RFC 6455 in December 2011, and all major browsers implemented it shortly after.

How it works

The animation shows a chat message: the handshake, the upgrade, then a message from client A to client B, who is connected to a different server:

1. Start with HTTP: Client A opens wss://chat.example.com with an ordinary GET carrying Upgrade: websocket and a random Sec-WebSocket-Key.
2. Through the load balancer: The balancer must allow the Upgrade header and long-lived connections; it pins the connection to one backend.
3. Server accepts: Server 1 checks Origin and auth, then computes Sec-WebSocket-Accept from the key to prove it speaks WebSocket.
4. Connection upgraded: 101 Switching Protocols: from now on the same TCP connection carries WebSocket frames in both directions, with no more HTTP.
5. A sends a message: A sends a small text frame such as {type: msg, room: 42, text: hi}. Frames have a 2 to 14 byte header, not a full HTTP request.
6. Publish to the room: B is connected to a different server, so server 1 publishes the message to a pub/sub backplane channel for room 42.
7. Other servers receive it: Every server with a member of room 42 is subscribed and gets the message.
8. Server pushes to B: Server 2 writes a frame on B's open connection. B did not ask for it; this server push is what WebSocket is for.
9. Full duplex: B replies on the same connection at any time, even while messages are flowing the other way. Ping and pong frames keep idle connections alive.

The opening handshake

The client starts with an ordinary HTTP/1.1 GET:

GET /rooms/42 HTTP/1.1
Host: chat.example.com
Upgrade: websocket
Connection: Upgrade
Sec-WebSocket-Key: dGhlIHNhbXBsZSBub25jZQ==
Sec-WebSocket-Version: 13
Sec-WebSocket-Protocol: chat.v1
Origin: https://app.example.com

The server agrees by switching protocols:

HTTP/1.1 101 Switching Protocols
Upgrade: websocket
Connection: Upgrade
Sec-WebSocket-Accept: s3pPLMBiTxaQ9kYGzzhZRbK+xOo=
Sec-WebSocket-Protocol: chat.v1

Sec-WebSocket-Accept is the Base64 of the SHA-1 of the client’s key concatenated with the fixed GUID 258EAFA5-E914-47DA-95CA-C5AB0DC85B11. It proves the server really understands WebSocket and is not a confused HTTP server or cache. From this point the connection carries frames, not HTTP.

Frames

Field	Size	Meaning
FIN	1 bit	Last fragment of a message
Opcode	4 bits	0x1 text, 0x2 binary, 0x0 continuation, 0x8 close, 0x9 ping, 0xA pong
MASK	1 bit	Set on every client-to-server frame
Payload length	7, 7+16 or 7+64 bits	Size of the payload
Masking key	0 or 4 bytes	XOR key for client frames, so proxies cannot be tricked into caching data
Payload	Variable	Your message

Ping and pong frames act as heartbeats and keep NAT and proxy idle timers from closing quiet connections. A close frame carries a status code such as 1000 (normal), 1001 (going away) or 1008 (policy violation), and both sides reply before closing TCP.

Message sequence

sequenceDiagram
    autonumber
    participant B as Browser
    participant S as WebSocket server
    B->>S: HTTP GET with Upgrade websocket
    S-->>B: 101 Switching Protocols
    Note over B,S: Same TCP connection, now WebSocket frames
    B->>S: text frame, join room 42
    S-->>B: text frame, history
    S-->>B: text frame, new message from another user
    B->>S: text frame, reply
    S->>B: ping
    B-->>S: pong
    B->>S: close 1000
    S-->>B: close 1000

Connection lifecycle

The browser API exposes the connection state as readyState. A UML state machine of the lifecycle, including the reconnect logic every production client needs:

stateDiagram-v2
    [*] --> CONNECTING : new WebSocket(url)
    CONNECTING --> OPEN : 101 Switching Protocols
    CONNECTING --> CLOSED : handshake failed
    OPEN --> OPEN : send and receive frames
    OPEN --> CLOSING : close() or close frame received
    OPEN --> CLOSED : network error
    CLOSING --> CLOSED : close handshake done
    CLOSED --> CONNECTING : reconnect with backoff and jitter
    CLOSED --> [*]

Designing the message protocol

WebSocket only moves bytes, so you define the messages yourself. A typical JSON envelope:

{ "type": "message", "id": "c1f7", "room": "42", "body": "hi", "ts": 1759740000 }

Common choices are a type field for routing, an id for acknowledgements and deduplication, and a sequence number so a reconnecting client can ask for what it missed. Higher-level options already exist: STOMP, MQTT over WebSocket, graphql-ws for GraphQL subscriptions, WAMP, and libraries such as Socket.IO and SignalR that add rooms, acknowledgements and fallbacks.

Scaling WebSocket servers

Every connection is long-lived state on one server, which changes the operational picture:

• Load balancers must support the Upgrade header and long idle timeouts (AWS ALB, NGINX, Envoy and Azure Application Gateway do). Use layer 7 balancing or sticky routing during the handshake.
• A pub/sub backplane (Redis, NATS, Kafka) is needed when users in the same room are connected to different servers, as in the animation.
• Capacity is counted in connections, not requests per second. Memory per connection, file descriptors and kernel limits matter.
• Deployments drop connections. Drain servers gradually and make clients reconnect with exponential backoff and jitter, or a restart turns into a thundering herd.
• Managed services such as AWS API Gateway WebSocket APIs, Azure Web PubSub and Cloudflare Durable Objects take care of the connection layer for you.

Where it is used

• Chat and messaging (Slack, WhatsApp Web, customer support widgets).
• Multiplayer games and real-time collaboration (Figma, Google Docs-style editors, whiteboards).
• Financial market data: crypto exchanges and brokers stream order books and trades.
• Live dashboards, sports scores, auctions, ride tracking.
• Developer tools: hot reload in dev servers, browser DevTools protocol, Jupyter kernels.

Real-life examples

Slack

Slack’s clients keep a WebSocket connection open to Slack’s edge to receive new messages, typing indicators and presence changes the moment they happen. Slack’s engineering blog describes how its real-time messaging infrastructure fans out a message to every connected client in a channel through a layer of gateway servers holding the WebSockets and channel servers that route messages between them, the same split as the pub/sub backplane in the animation. For apps, Slack’s Socket Mode delivers events to a bot over a WebSocket instead of public webhooks, which is useful behind a firewall.

Discord Gateway

Discord’s real-time API is a documented WebSocket service called the Gateway. A bot connects to wss://gateway.discord.gg, receives a Hello with a heartbeat interval, sends Identify with its token, and then receives events such as MESSAGE_CREATE as JSON frames. It must send a heartbeat at the given interval or be disconnected, and can Resume a dropped session with a sequence number so missed events are replayed. It is a textbook example of designing a message protocol on top of raw WebSocket.

Strengths and limitations

Strengths	Limitations
True server push and full duplex	Stateful connections complicate load balancing, scaling and deploys
Very low per-message overhead and latency	No built-in message format, acknowledgements, or replay
Supported natively by every browser	No HTTP caching; harder to observe with standard HTTP tools
Works through most proxies on port 443	Some corporate proxies still break long-lived connections
Text or binary payloads	Auth happens once at connect time; tokens can expire mid-connection

Best practices

• Always use wss:// and validate the Origin header to prevent cross-site WebSocket hijacking.
• Authenticate during the handshake (a short-lived token in a cookie or the first message, not a long-lived token in the URL, which ends up in logs) and re-check authorisation per action.
• Heartbeat with ping/pong and detect dead connections on both sides.
• Reconnect with exponential backoff and jitter, and resume from the last sequence number.
• Cap message size and rate per connection to protect the server.
• Version your message protocol via Sec-WebSocket-Protocol or a version field.
• Use SSE instead if data only flows from server to client.

When to use WebSocket, and when not

Use WebSocket when both sides send frequently and latency matters: chat, games, collaboration, live trading.

Prefer Server-Sent Events for one-way updates such as notifications or LLM token streaming, webhooks for server-to-server events, and REST for everything that is naturally request/response.
