MQTT: Lightweight Publish/Subscribe for IoT

MQTT is a lightweight publish/subscribe messaging protocol. Devices connect to a central broker, publish messages to hierarchical topics such as plant/1/temp, and receive messages on topics they subscribe to. The fixed header is only two bytes, connections survive flaky networks, and three Quality of Service levels let each message choose between speed and guaranteed delivery. That makes MQTT the default protocol of the Internet of Things.

This post is part of the API communication protocols series.

At a glance

	MQTT
Type	Binary publish/subscribe protocol through a broker
Created	1999 by Andy Stanford-Clark (IBM) and Arlen Nipper (Arcom, now Cirrus Link)
Standards	MQTT 3.1.1 (OASIS 2014, ISO/IEC 20922 in 2016), MQTT 5.0 (OASIS 2019)
Name	Originally “MQ Telemetry Transport”; today simply MQTT
Transport	TCP on port 1883, TLS on 8883; MQTT over WebSocket for browsers
Payload	Opaque bytes: JSON, Protobuf, CBOR or raw sensor values
Contract	None; topic names and payloads are a convention (AsyncAPI can document them)
Delivery	QoS 0 at most once, QoS 1 at least once, QoS 2 exactly once (between client and broker)
Best for	Sensors, vehicles, smart homes, industrial telemetry, mobile apps on poor networks

What MQTT is

Publishers and subscribers never talk to each other directly. They only know the broker and topic names, so a sensor does not know who reads its data, and a dashboard does not know which sensors exist.

Topics are UTF-8 strings with levels separated by /. Subscribers can use wildcards:

Filter	Matches	Does not match
plant/1/temp	exactly plant/1/temp	plant/2/temp
plant/+/temp (+ = one level)	plant/1/temp, plant/7/temp	plant/1/line/3/temp
plant/# (# = all remaining levels)	plant/1/temp, plant/1/line/3/alarm	factory/1/temp

# Subscribe to every temperature in plant 1's lines (Mosquitto command-line clients)
mosquitto_sub -h broker.example.com -p 8883 --cafile ca.pem -t 'plant/+/temp' -q 1 -v

# Publish a reading, retained so new subscribers get the last value immediately
mosquitto_pub -h broker.example.com -p 8883 --cafile ca.pem -t 'plant/1/temp' -m '21.7' -q 1 -r

Why it was developed

In 1999, Phillips 66 needed to monitor oil pipelines from remote stations in the desert. The data went over satellite links that were slow, expensive per byte and often interrupted, and the field devices had very little power and memory. Andy Stanford-Clark of IBM and Arlen Nipper of Arcom designed a protocol with a tiny header, a persistent connection with keep-alive, and delivery guarantees that survive lost links. It became part of IBM’s MQSeries (WebSphere MQ) family as “MQ Telemetry Transport”.

IBM published the specification royalty-free in 2010, and the Eclipse Foundation’s Paho (clients) and Mosquitto (broker) projects made it widely available. OASIS standardised version 3.1.1 in 2014, and MQTT 5.0 in 2019 added features learned from large deployments: reason codes, session and message expiry, shared subscriptions, user properties and request/response correlation.

How it works

The animation shows topic-based routing through a broker. Switch on the offline mode to see the Last Will and Testament in action:

1. Clients connect: Devices open a TCP connection to the broker on port 1883, or 8883 with TLS, with a client ID, a keep-alive interval and a Last Will message.
2. Publish a reading: The sensor publishes 21.7 to plant/1/temp with QoS 0: fire and forget, no acknowledgement. Subscribers registered topic filters earlier.
3. Broker routes by topic: The broker matches the topic against every subscription and forwards a copy to the dashboard and the time-series store. Alerting is not subscribed to temp.
4. Publish an alarm (normal): The pump controller publishes to plant/1/alarm with QoS 1, so the broker must acknowledge with PUBACK and the controller resends until it does.
5. Alarm fans out (normal): Alerting and the time-series DB both match plant/1/alarm. A retained flag would also keep the last value for subscribers that join later.
6. Broker publishes the will (lwt): The sensor loses power. After 1.5 times the keep-alive with no packet, the broker publishes its Last Will (plant/1/alarm = sensor offline) for it.

Packets

Packet	Direction	Purpose
CONNECT / CONNACK	Client to broker / back	Client ID, credentials, keep-alive, clean start flag, Last Will
PUBLISH	Both	Topic, QoS, retain flag, payload
PUBACK	Both	Acknowledges QoS 1
PUBREC, PUBREL, PUBCOMP	Both	Four-step handshake for QoS 2
SUBSCRIBE / SUBACK	Client to broker / back	Topic filters and the maximum QoS for each
UNSUBSCRIBE / UNSUBACK	Client to broker / back	Remove subscriptions
PINGREQ / PINGRESP	Client to broker / back	Keep-alive when there is no other traffic
DISCONNECT	Both	Clean disconnect; the Last Will is not sent

Quality of Service

sequenceDiagram
    participant P as Publisher
    participant B as Broker
    Note over P,B: QoS 0, at most once
    P->>B: PUBLISH
    Note over P,B: QoS 1, at least once
    P->>B: PUBLISH packet id 7
    B-->>P: PUBACK 7
    Note right of P: resent with DUP flag if no PUBACK
    Note over P,B: QoS 2, exactly once
    P->>B: PUBLISH packet id 8
    B-->>P: PUBREC 8
    P->>B: PUBREL 8
    B-->>P: PUBCOMP 8

QoS	Guarantee	Cost	Typical use
0	At most once; may be lost	One packet	Frequent sensor readings where the next value replaces the last
1	At least once; may be duplicated	Two packets, stored until acknowledged	Alarms, commands, most business data
2	Exactly once	Four packets	Billing or metering where duplicates are unacceptable

QoS applies to each hop separately: publisher to broker, and broker to each subscriber. A subscriber receives at the lower of the publish QoS and its subscription QoS.

Features that make MQTT fit devices

• Retained messages: the broker keeps the last message on a topic and sends it to every new subscriber, so a dashboard sees the current state immediately.
• Last Will and Testament (LWT): a message the client registers at connect time; the broker publishes it if the client disappears without a clean DISCONNECT.
• Keep-alive: if the broker hears nothing for 1.5 times the keep-alive interval, it closes the session.
• Persistent sessions: with a clean start flag of false, the broker remembers subscriptions and queues QoS 1 and 2 messages while the device sleeps or is offline.
• Shared subscriptions (MQTT 5, $share/group/topic): load-balance messages across a group of backend consumers.

Client session state

A device’s view of its connection as a UML state machine:

stateDiagram-v2
    [*] --> Disconnected
    Disconnected --> Connecting : open TCP or TLS, send CONNECT
    Connecting --> Connected : CONNACK success
    Connecting --> Disconnected : CONNACK refused or timeout
    Connected --> Connected : PUBLISH, SUBSCRIBE, PINGREQ
    Connected --> Disconnected : DISCONNECT sent, will discarded
    Connected --> Lost : no traffic for 1.5 x keep-alive
    Lost --> Disconnected : broker publishes Last Will
    Disconnected --> Connecting : reconnect with backoff, session resumed

Where it is used

• Industrial IoT: factories, oil and gas, energy grids, often with the Sparkplug B specification that defines topic names and payloads for SCADA systems.
• Smart home: Home Assistant, Zigbee2MQTT, Tasmota and many devices talk MQTT.
• Connected vehicles and fleets: telemetry and remote commands over mobile networks.
• Cloud IoT platforms: AWS IoT Core, Azure IoT Hub and Azure Event Grid’s MQTT broker, HiveMQ Cloud, EMQX Cloud.
• Mobile messaging and notifications on unreliable networks.
• Brokers to know: Eclipse Mosquitto (small, single node), EMQX, HiveMQ, VerneMQ and RabbitMQ’s MQTT plugin (clustered, millions of connections).

Real-life examples

AWS IoT Core and Azure IoT Hub

On AWS IoT Core, every device connects with an X.509 certificate over MQTT on port 8883 and publishes telemetry to topics such as factory/line1/temp. Rules written in an SQL-like language subscribe to topics and route messages to Lambda, DynamoDB, Kinesis or S3. Device Shadows use reserved topics ($aws/things/<name>/shadow/update) to sync the desired and reported state of a device that is often offline. Azure IoT Hub follows the same pattern: devices publish to devices/{deviceId}/messages/events/ and receive cloud-to-device messages and device twin updates on reserved topics.

Facebook Messenger

When Facebook built its Messenger app in 2011, its engineers chose MQTT to deliver messages to phones. Their engineering post explained why: keeping a persistent MQTT connection open used less battery and bandwidth than repeated HTTP polling, and messages arrived in a fraction of a second even on poor mobile networks. It is a well-known example of MQTT outside classic IoT: any client on a constrained or unreliable link benefits from the same design.

Strengths and limitations

Strengths	Limitations
Very small overhead; good for low bandwidth and battery-powered devices	The broker is a central component that must be highly available and scaled
Publishers and subscribers fully decoupled	No payload schema, no built-in request/response before MQTT 5
Three QoS levels, retained messages, Last Will, persistent sessions	Not designed for large payloads or long message retention
Handles intermittent connectivity well	Topic design and ACLs need care to stay secure
Huge ecosystem of clients, brokers and cloud services	Exactly-once is per hop, not end to end

Best practices

• Always use TLS (8883) and per-device credentials, ideally X.509 client certificates.
• Enforce topic ACLs so each device can only publish and subscribe under its own prefix.
• Design topics hierarchically, from general to specific (site/area/device/measurement), and never start them with / or $ (reserved for the broker).
• Pick the lowest QoS that is acceptable; QoS 2 is rarely needed.
• Use retained messages for state, not for events, and clear them with an empty retained payload.
• Set a Last Will with a status topic for every device.
• Use unique client IDs: a second connection with the same ID disconnects the first.
• Bridge to a stream platform (Kafka, Event Hubs, Kinesis) for analytics and long-term storage.

When to use MQTT, and when not

Use MQTT for many devices sending small messages over unreliable or metered networks, for telemetry and commands, and when you want producers and consumers fully decoupled.

Prefer AMQP for back-end business messaging with complex routing and work queues, Kafka for high-volume event streams that must be replayed, and WebSocket or REST for browser applications that do not need a broker.
