State of DevOps: Technical Architecture

The whole architecture of State of DevOps follows from one decision: jobs write files, the dashboard reads files. There’s no database and no message bus, and no analyzer calls another one. Thirteen Kubernetes cronjobs collect, analyze and aggregate into dated JSON on one Azure File Share, and a FastAPI + React dashboard reads that share. It’s a boring design, and that’s why one person could build it and a team could take it over.

System context and component architecture

The components fall into four tiers:

Tier	Components	Job
Collectors	github-data-collector, github-new-repositories, github-stale-repositories, github-container-registry-scanner, github-package-registry-scanner	Pull raw data from GitHub REST, Container Registry and Packages APIs
Analyzers	devops-repo-analyzer, devops-pipeline-analyzer, devops-infra-analyzer, devops-enterprise-analyzer, devops-ghas-analyzer, devops-cost-analyzer	Inspect one domain and write structured JSON
Aggregators	devops-trends-analyzer, devops-summary-generator	Compute trends and pre-compute the Home page
UI	devops-state-dashboard (FastAPI + React, Redis cache)	Serve it to people

1. The outside world: GitHub (four orgs plus the enterprise), JFrog, Azure Cost Management and Key Vault feed the system; readers reach it from a browser.
2. Collect once, centrally: The central GitHub collector pulls repository data once a day, so every other job reuses it instead of calling the same APIs again.
3. Write and notify: Collectors write dated JSON to the Azure File Share and post a summary to a Microsoft Teams webhook.
4. Analyzers read and enrich: Each analyzer reads the shared cache, then fetches only the extra detail its domain needs from GitHub, JFrog or Azure.
5. One folder per domain: Analyzers write structured JSON under /data/devops-state/<domain>/<org>/<date>/. No analyzer calls another one.
6. Aggregators read results: The trends analyzer and summary generator read every domain's output for the day.
7. Pre-compute the Home page: They write trend series and one home-overview.json, so the dashboard never aggregates on a request.
8. Someone opens the dashboard: A stakeholder opens State of DevOps in the browser. One FastAPI service on port 8000 serves the React app and its read-mostly REST API.
9. Read files, cache in Redis: The API reads the share read-only and memoizes expensive aggregations in Redis. It never calls a job, so the UI stays up when jobs fail.
10. Secrets from Key Vault: Tokens and keys live in Azure Key Vault. The External Secrets Operator syncs them into the cluster.
11. Secrets in both namespaces: Kubernetes secrets land in the cronjobs and state-of-devops namespaces, so no credential is baked into an image or a Helm value.

Adding a domain means adding a component to a tier: a new cronjob folder, a new folder under /data/devops-state/, and a new tab. That property is what makes the enterprise scorecard phase realistic.

Technology and framework selection

Need	Choice	Why
Jobs	Python 3.11 / 3.12 slim images	The GitHub, JFrog and Azure SDKs and requests make API work quick; easy for a DevOps team to read
Retries	tenacity	Rate limits and flaky APIs are the normal case, not the exception
Scheduling	Kubernetes CronJobs	Already on the platform; no extra scheduler to run
Backend	FastAPI 0.109 + Uvicorn, Pydantic 2	Async file reads, typed models, free OpenAPI docs
Frontend	React 18, Create React App (react-scripts 5.0.1), React Router 6, Axios, Recharts	Familiar, enough for a tab-based internal UI
Cache	Redis (redis[hiredis])	Memoize expensive aggregations across requests
Packaging	Docker, Helm 3 with a shared library chart	One template for 13 similar CronJobs
Delivery	GitHub Actions, JFrog, ArgoCD	The organization’s standard path

One choice I’d revisit is Create React App. It still works, but it’s no longer maintained, so a move to Vite is worth planning before the next big frontend change (see Continuous Improvement).

API and integration architecture

The dashboard API is read-mostly REST, grouped by domain, with the same shape in each group:

GET /api/<domain>/organizations                         # orgs with latest analysis date
GET /api/<domain>/organizations/{org}/repositories      # ?date= for a past snapshot
GET /api/<domain>/organizations/{org}/repositories/{repo}
GET /api/<domain>/organizations/{org}/summary

<domain> is the repo analysis root (/api/organizations), pipeline, infra, ghas, compliance or trends. Around that sit GET /api/home-overview (one pre-computed file), GET /api/overview, the cost endpoints (/api/cost/{github,jfrog,azure}), applications mapped to Jira epics, GET /api/health, GET /api/sidebar-config, and the single write endpoint, POST /api/jira/create-story.

Outbound integrations live in the jobs, not the dashboard: GitHub REST and GraphQL, GitHub Enterprise, Container Registry and Packages APIs, JFrog Artifactory, Azure Cost Management and Teams webhooks. The dashboard’s only outbound call is to Jira. The backend never calls an analyzer; it reads their files. That keeps the UI up even if every job is failing.

Data architecture and data models

The “database” is a directory tree on Azure Files, partitioned by domain, org and UTC date:

/data/
├── github-data/{org}/organization_repos/          # collector cache, overwritten
├── devops-state/
│   ├── repo-analysis/{org}/{YYYY}/{MM}/{DD}/<sub-analyzer>/
│   ├── pipeline-analysis/…  infra-analysis/…  ghas-analysis/…
│   ├── enterprise/…  cost-analysis/…  trends/…
│   ├── summaries/{YYYY}/{MM}/{DD}/home-overview.json
│   └── github-{new,stale}-repositories/
└── weekly-routine/{container,package}-registry-scanner/

Filenames inside a dated folder are stable, so “today’s” data has a predictable path, and every analyzer writes a metadata.json with its version and generated_at. The full layout and retention rules are in Data and Integration.

Identity and access architecture

There are three identity paths, all without secrets baked into images:

1. GitHub: one GitHub App per org (plus one for the enterprise). A shared GitHubAppTokenManager signs a JWT, exchanges it for an installation token and caches it with a 5-minute pre-expiry buffer. A GITHUB_TOKEN PAT is the fallback.
2. Azure Files and Azure APIs: Azure Workload Identity on two ServiceAccounts, cron-jobs in the cronjobs namespace and state-of-devops for the dashboard. The storage client tries storage key, then service principal, then managed identity, then DefaultAzureCredential.
3. Secrets: External Secrets Operator syncs per-org GitHub App credentials, Jira, storage and Teams webhook secrets from Azure Key Vault into Kubernetes secrets.

How people sign in to the dashboard is covered in Security and Privacy.

Hosting and deployment model

	Local	Production
Cluster	k3d (k3s in Docker)	AKS
Registry	localhost:5000/k8cron/<component>	JFrog Artifactory
Ingress	traefik	nginx, SSL redirect
Storage	Host bind mount as /data	Azure File Share via PVCs
Secrets	values-local.yaml / kubectl create secret	External Secrets + Key Vault
Delivery	task state-of-devops-<component>	GitHub Actions → JFrog → ArgoCD

Each chart ships values.yaml (AKS) and values-local.yaml (k3d), kept in sync except for cloud-only fields. Cronjobs run in the cronjobs namespace; the dashboard in state-of-devops mounts the same share through its own PV and PVC. That mount is ReadWriteMany and not read-only, because the dashboard writes the dormant-users upload there.

Scalability and performance strategy

The jobs scale by time and partitioning, not replicas. Each run handles four orgs, and the heavy ones limit concurrency (max_concurrent_orgs: 2 in the GHAS analyzer) and throttle API calls. Adding orgs adds run time, so the schedule has headroom between 02:00 and 07:00 UTC.

The dashboard scales by doing less per request: the Home page reads one file, Redis memoizes expensive aggregations, and a background cache warmer starts with the app and re-warms popular endpoints on a timer. Large JSON reads are the weak spot: the trends endpoints move them off the event loop with asyncio.to_thread, but repo-analysis reads still call a blocking open() inside async handlers. Pagination and search happen in the browser (10 rows per page), so a big org still ships its whole list in one response.

The known gap is that the dashboard runs as one replica with no autoscaling. The chart already has an autoscaling block in values.yaml (enabled: false, 1 to 3 replicas, 80% CPU), but no HorizontalPodAutoscaler template uses it. The fix is designed in Operations and Observability.

Resilience and disaster recovery

The design is naturally forgiving:

• Jobs are idempotent per day: re-running an analyzer overwrites the same dated folder.
• The dashboard only reads analysis results (its one write to the share is the dormant-users upload) and degrades to “no data for today” rather than failing.
• Collection is incremental (ETags), so a missed day costs one run, not a backfill.
• Everything except the data can be rebuilt from Git: images, charts and ArgoCD apps.

The data is the one thing Git can’t rebuild. Trends depend on months of daily history, and that history lives on one Azure File Share. That share is protected by Azure Backup share snapshots, and a restore has been tested.

TODO: What RPO and RTO are agreed for trend history?

Architectural decision records

These are the decisions worth recording as ADRs, most important first:

ADR	Decision
001	Store results as dated JSON on Azure Files, not in a database
002	One cronjob per domain, independent and rerunnable
003	Centralize GitHub collection in one collector job
004	Pre-compute the Home page in a summary generator
005	Per-org GitHub Apps with a PAT fallback
006	FastAPI serves the built React app (one image, one ingress)
007	GitOps delivery through ArgoCD, with dev-pause / dev-push for iteration

ADR-003 is the one that came from experience, so it’s the one I’d write out in full:

# ADR-003: Centralize GitHub data collection

Status: Accepted
Context: Each cronjob originally collected its own GitHub data, and much of it was the same
  (repository lists and metadata). The duplicated calls cost API rate limit and run time, and
  each job had its own copy of the same collection logic.
Decision: A single job, github-data-collector, collects shared repository data for every org into
  /data/github-data/ with ETag-based incremental requests. Other cronjobs read that cache and call
  the API only for the extra detail their domain needs.
Consequences: Less redundant API traffic and faster jobs; collection logic in one place. Jobs that
  read the cache now depend on the collector having run, which the clock-based schedule doesn't
  enforce (see Continuous Improvement).

TODO: Are ADRs kept anywhere today (for example docs/adr/ in the repo)? If not, these seven are a good starting set.

Checklist

• Component map and tier table current in the repo docs
• Every new domain follows the pattern: one cronjob, one data folder, one tab
• The dashboard never calls an analyzer; it only reads /data
• No credentials in images: GitHub Apps, Workload Identity, External Secrets
• values.yaml and values-local.yaml in sync for every chart
• HPA template added and autoscaling.enabled switched on for the dashboard
• Azure Files backup and restore decided and tested

• ADRs 001-007 written down
