k3d's load balancer ran out of connections, and DNS took the whole cluster down

I was refreshing a page of links for my homelab when four tiles went red at once. Keycloak, PowerDNS and the container registry, all in the same k3d cluster, all failing. The DNS lookups timed out, the HTTPS connections died mid-handshake, and kubectl against that cluster answered with EOF. The cluster itself was fine: its node had plenty of memory, and when I talked to it directly it answered every request. The thing in front of it had quietly run out of room. This post walks through how I found it, why less than one DNS query a second is enough to break k3d’s load balancer, and the small fix that keeps it up under more than 300 times that load.

The setup

My homelab runs several k3d clusters on one DGX Spark, all on a shared Docker network. One of them, core, holds the services everything else depends on: Keycloak for sign-in, OpenBao for secrets, a Zot registry mirror, and PowerDNS for the internal zone home.cloudutsuk.com.

k3d puts an nginx container (the “serverlb”) in front of every cluster. It’s how a host port reaches the cluster: k3d maps the port on the load balancer, and nginx forwards it to the node. For core that load balancer carries three very different kinds of traffic on the same host address:

• HTTPS (443) for Keycloak, OpenBao and the registry
• The Kubernetes API (6443) for kubectl and the automation
• DNS (53, UDP and TCP): the host resolves the internal zone through it, and so does every other cluster’s CoreDNS (on a second port, 1053)

%%{init: {"themeVariables": {"fontSize": "14px"}, "flowchart": {"useMaxWidth": false, "nodeSpacing": 30, "rankSpacing": 40, "padding": 8, "wrappingWidth": 150}}}%%
flowchart TB
  subgraph C["Clients"]
    direction LR
    H[Host resolver] ~~~ P[Other clusters' CoreDNS] ~~~ B[Browsers and kubectl]
  end
  subgraph L["k3d load balancer (nginx)"]
    direction LR
    U[UDP 53] ~~~ T[TCP 443] ~~~ A[TCP 6443]
  end
  subgraph N["core node"]
    direction LR
    D[PowerDNS] ~~~ K[Keycloak, OpenBao, Zot] ~~~ S[API server]
  end
  C --> L --> N

That shared middle box is the whole story.

Symptoms

From the outside it looked like three unrelated failures:

$ curl -s -o /dev/null -w "%{http_code} %{errormsg}\n" https://auth.core.home.cloudutsuk.com/
000 Resolving timed out after 6000 milliseconds

$ curl -s -o /dev/null -w "%{http_code} %{errormsg}\n" https://registry.core.home.cloudutsuk.com/v2/
000 OpenSSL SSL_connect: SSL_ERROR_SYSCALL in connection to registry.core.home.cloudutsuk.com:443

$ kubectl --context k3d-core get pods -A
error: client rate limiter Wait returned an error: context deadline exceeded - error from a previous attempt: EOF

A DNS timeout, a TLS connection cut before the handshake, and an API client getting EOF. If you start debugging each of those on its own, you can lose an afternoon. The useful question was: what do all three have in common? They all go through the same load balancer.

So I went around it. The node has its own address on the Docker network, and from there everything worked:

direct API: 401          # the API answers (no token sent)
direct 443: 302          # Keycloak answers

The node was healthy. The load balancer wasn’t.

The log that explains it

docker logs on the load balancer container was full of one line:

[alert] 66#66: *366626 1029 worker_connections are not enough while connecting to upstream,
udp client: 172.30.0.1, server: 0.0.0.0:53, upstream: "172.30.0.128:53"

483 of them in two minutes, every one for UDP port 53. nginx had run out of connections, and it was DNS that had used them up.

That surprised me, because the DNS load isn’t large. I measured it from the clusters’ CoreDNS: a few queries a second across everything. That can’t fill a thousand connections, unless each one stays open for a very long time.

Why a few queries a second fill a thousand slots

Here’s the server block k3d generated for DNS over UDP:

server {
    listen        53 udp;
    proxy_pass    53_udp;
    proxy_timeout 600;
    proxy_connect_timeout 2s;
}

Two things matter here.

First, UDP has no connection to close. nginx’s stream module handles UDP as a “session”: a client’s datagrams and the upstream’s replies, tracked together. Every session holds a connection in the worker, and for a proxied session that’s really two, one to the client and one to the upstream. nginx decides a UDP session is over in one of two ways: it has received the number of reply datagrams you told it to expect (proxy_responses), or nothing has moved for proxy_timeout.

Second, k3d sets neither in a way that suits DNS. The nginx docs on proxy_responses say it plainly: “By default, the number of datagrams is not limited.” So nginx never assumes the reply ended the session. And proxy_timeout 600 means it waits ten minutes of silence before giving up.

A DNS lookup is one datagram out and one back. Each new query comes from a new source port, so it’s a new session. Put those together:

	Value
Connections per worker (worker_connections)	1029
Connections per DNS session (client and upstream)	2
How long each DNS session is held	up to 600 s
Query rate that fills every connection	about 1029 / (2 × 600) ≈ 0.9 per second
What my clusters and host actually sent	a few per second

Less than one query a second is nothing. Probes, CoreDNS cache misses and image pulls get there easily, and they did as I added clusters and labs. It also explains why the failure came and went: when the query rate dipped, sessions timed out and freed up, and things recovered for a while.

There was a second, quieter limit. When I raised worker_connections, nginx warned:

[warn] 4096 worker_connections exceed open file resource limit: 1024

The container’s soft limit on open files was 1024, and every proxied connection needs two file handles. So nginx was really capped by the file limit, not by its own setting. The nginx docs mention this too: the number of connections “cannot exceed the current limit on the maximum number of open files”.

And the reason the whole cluster went down rather than just DNS: those connections are shared. Once a worker is full, it refuses new HTTPS and API connections just as it refuses DNS.

What k3d lets you change

k3d’s load balancer is nginx with a config rendered by confd from a template inside the container. The documented knobs are two values, set when you create the cluster:

# k3d config file
options:
  k3d:
    loadbalancer:
      configOverrides:
        - settings.workerConnections=2048
        - settings.defaultProxyTimeout=900

Neither fixes this properly. More connections only raise the threshold; at 600 seconds per session the same thing happens at a slightly higher query rate. And defaultProxyTimeout applies to every port. Cut it to a few seconds and you break the long-lived connections the Kubernetes API relies on, such as watches that sit idle between events.

What I actually wanted is to tell nginx to expect one reply, and let the session go as soon as it arrives. That’s what proxy_responses is for (“the number of datagrams expected from the proxied server in response to a client datagram… a hint for session termination”), and k3d’s template (as of v5.9.0) has no setting for it.

There was one more constraint. My infrastructure code treats any change to core’s cluster settings as a reason to rebuild core, and rebuilding the cluster that holds the secrets and the identity provider isn’t something I do to tune a proxy.

The fix

Inside the load balancer container, confd runs in watch mode against a values file (confd -watch -backend file -file /etc/confd/values.yaml). When that file changes, confd re-renders nginx.conf from the template, checks it with nginx -T, and reloads nginx gracefully. Open connections finish on the old workers, and new ones go to the new workers.

So the fix is to patch the template once and write the values file:

1. UDP servers only: proxy_responses 1 and proxy_timeout 10s. TCP keeps k3d’s 600 seconds.
2. worker_rlimit_nofile 16384, so the connection count is real.
3. settings.workerConnections 4096, for headroom.

The template change is a small edit around the proxy_timeout line:

  server {
    listen        {{ $port }} {{- if (eq $protocol "udp") }} udp{{- end -}};
    proxy_pass    {{ $upstream }};
    {{- if (eq $protocol "udp") }}
    proxy_responses 1;
    proxy_timeout 10s;
    {{- else }}
    proxy_timeout {{ getv "/settings/defaultProxyTimeout" "600" }};
    {{- end }}
    proxy_connect_timeout 2s;
  }

I wrapped it in an idempotent script that loops over every k3d load balancer and does the edit inside each container with docker exec. It only patches what isn’t patched yet, then rewrites the values file and waits until nginx -T shows the new settings. The rendered result for DNS:

server {
    listen        53 udp;
    proxy_pass    53_udp;
    proxy_responses 1;
    proxy_timeout 10s;
    proxy_connect_timeout 2s;
}

And a --check mode, so I can see the state of every load balancer at a glance:

$ lb-udp.sh --check
k3d-ai-serverlb: worker_connections 4096, worker_rlimit_nofile 16384, UDP servers 0, with proxy_responses 0
k3d-platform-serverlb: worker_connections 4096, worker_rlimit_nofile 16384, UDP servers 0, with proxy_responses 0
k3d-mon-serverlb: worker_connections 4096, worker_rlimit_nofile 16384, UDP servers 0, with proxy_responses 0
k3d-core-serverlb: worker_connections 4096, worker_rlimit_nofile 16384, UDP servers 2, with proxy_responses 1

The race I hit on the first try

My first version rewrote the values file with cat new > values.yaml. That truncates the file and then writes it, and confd noticed the truncation first. It read an empty file, failed with key does not exist: /settings/workerConnections, and never picked up the write that followed. Nothing broke, because nginx keeps running its last good config when confd fails. But the change didn’t apply either. The script now rewrites the file and checks nginx -T, and repeats a few times until the new config is live.

Making it stick

A docker restart keeps the patched template, because it’s the same container. But k3d recreates the load balancer when you create a cluster or edit its load balancer ports, and a new container starts from k3d’s defaults again. So my boot unit runs the script right after each cluster starts, and the cluster config carries a comment telling whoever edits the ports to run it afterwards.

Patching a file inside a container that a tool owns is a workaround, not a configuration. I’m fine with it here because it’s idempotent, it’s checked, and it runs on every boot. If k3d grows a setting for UDP sessions, that’s the better home for it.

Proving it

I didn’t want to trust “the alerts stopped”: the failure came and went on its own, so a quiet five minutes proved nothing. Instead I generated load that the old configuration couldn’t survive. A small Python script sends real DNS queries for an internal name, each from a fresh socket (and so a fresh source port, a new nginx session), alternating between the two DNS ports, at a fixed rate:

def query(port, name="auth.core.home.cloudutsuk.com"):
    s = socket.socket(socket.AF_INET, socket.SOCK_DGRAM)
    s.settimeout(2)
    qid = random.randint(0, 65535)
    q = (struct.pack(">HHHHHH", qid, 0x0100, 1, 0, 0, 0)
         + b"".join(bytes([len(p)]) + p.encode() for p in name.split("."))
         + b"\0" + struct.pack(">HH", 1, 1))          # type A, class IN
    try:
        s.sendto(q, (DNS_HOST, port))
        reply, _ = s.recvfrom(512)
        return struct.unpack(">H", reply[:2])[0] == qid  # answered, same query ID
    except OSError:
        return False
    finally:
        s.close()

At the old 600-second hold, 100 queries a second would fill 1029 connections in about five seconds. The results after the fix:

Test	Queries	Rate	Answered	Connection alerts	HTTPS during the test
1	5000	100/s	5000	0 after the reload	healthy
2	9000	300/s	9000	0	healthy

Three hundred a second is more than 300 times the rate that used to break it. Keycloak, OpenBao and the registry answered normally throughout.

Common pitfalls

• Debugging the symptoms one by one. A DNS timeout, a TLS error and an API EOF at the same time usually share a cause. Find what they pass through, then go around it.
• Raising the timeout instead of lowering it. k3d’s docs show defaultProxyTimeout=900 as an example override. For DNS over UDP that makes this worse.
• Lowering the timeout for everything. A short proxy_timeout on TCP cuts idle API watches and long-lived HTTPS connections. Set it per protocol.
• Forgetting the file limit. worker_connections above the open-file limit only produces a warning in the log, and the real ceiling stays where it was.
• Patching once and forgetting. A recreated container brings the defaults back. Put the fix somewhere that runs again (a boot unit, or the step after cluster creation).

What I’d do differently

I’d have kept DNS off a shared proxy from the start. The cleanest design is to publish DNS from something whose only job is DNS, so a burst of lookups can never take the identity provider down with it. I’ll make that change the next time I rebuild core anyway. Until then, the nginx settings above are the right ones for proxying DNS, and they’re what any UDP-over-nginx setup should have.

Conclusion

k3d’s load balancer is a plain nginx stream proxy, and its defaults suit TCP. For DNS over UDP, a 600-second idle timeout with no expected reply count turns every lookup into a ten-minute reservation of two connections, and at under one query a second the connections run out for every port behind it. If you run DNS through a k3d load balancer, check docker logs on it for worker_connections are not enough, and set proxy_responses 1 with a short timeout on the UDP servers.

References

• nginx stream proxy module: proxy_responses, proxy_timeout
• nginx core module: worker_connections, worker_rlimit_nofile
• k3d defaults: the load balancer and its config overrides
