X12 837 Part 1: Submitter, Receiver, Provider, Subscriber and Patient Loops

The 837 is the most important X12 transaction in healthcare, and the most complicated. It’s the electronic claim: everything the payer needs to decide what to pay, for professional (837P), institutional (837I) and dental (837D) services. Before you can read the clinical and billing detail, you need the frame around it: who sent the file, who receives it, who’s billing, who’s insured and who’s the patient.

This is part 1 of a three-part series, following the structure of the HealthTech Decoded 837 videos. It covers the envelopes and loops 1000A to 2000C, across all three claim types.

Part	Covers
1 (this post)	Envelopes, BHT, loops 1000A–1000B and 2000A–2000C
2	Loop 2300: claim information
3	Loop 2400: service lines, and the trailers

Three claim types, one transaction set

Variant	Submitted by	Implementation guide (GS08)
837P	Physicians and other practitioners	005010X222A1
837I	Hospitals and other facilities	005010X223A2
837D	Dentists	005010X224A2

GS08 reads as version (005010), guide (X222) and addendum (A1, the first published fix to that guide). All three share the structure covered in this post; they differ mostly in loop 2300 and 2400.

The envelopes

ISA*00*          *00*          *ZZ*SUBMITTERID    *ZZ*PAYERID        *251020*0930*^*00501*000000001*0*T*:~
GS*HC*SUBMITTERID*PAYERID*20251020*0930*1*X*005010X222A1~
ST*837*0001*005010X222A1~
BHT*0019*00*BATCH0001*20251020*0930*CH~

• ISA: ISA05/ISA07 are ID qualifiers (ZZ means a mutually defined ID) for the sender and receiver IDs in ISA06/ISA08. ISA15 marks the file as test (T) or production (P).
• GS: GS01 = HC (health care claim) and GS08, the guide version.
• ST: ST01 = 837, ST02 a control number of your choice, repeated in SE02; ST03 repeats the guide version.
• BHT: announces the hierarchy. BHT01 = 0019 means the file will contain information source, subscriber and dependent levels. BHT02 = 00 is an original transmission, BHT03 the batch reference, and BHT06 = CH a chargeable claim (vs RP for reporting-only encounters).

The EDI introduction explains the envelopes and delimiters in more detail.

1000A and 1000B: submitter and receiver

NM1*41*2*ACME BILLING SERVICES*****46*SUB12345~
PER*IC*CLAIMS DESK*TE*5551234567~
NM1*40*2*ACME HEALTH PLAN*****46*PAYERID~

• 1000A, the submitter: NM101 = 41. NM102 is 1 for a person or 2 for a non-person entity. NM108 = 46 means the ID in NM109 is an electronic transmitter ID. The PER segment gives a contact (PER01 = IC, information contact), with PER03 = TE marking PER04 as a phone number.
• 1000B, the receiver: NM101 = 40, usually the payer or the clearinghouse.

These loops are about the file, not the claim. The submitter is often a billing company or clearinghouse, not the provider.

2000A: the billing provider

HL*1**20*1~
NM1*85*2*CITY MEDICAL GROUP*****XX*1234567893~
N3*100 MAIN STREET~
N4*SPRINGFIELD*IL*627010000~
REF*EI*123456789~

The first hierarchical level (HL03 = 20, information source) is always the billing provider, the entity that will be paid.

• 2010AA, billing provider name: NM101 = 85. NM108 = XX says NM109 is the National Provider Identifier (NPI). N3 and N4 hold the address, and in 5010 the ZIP must be nine digits and a street address, not a PO box. REF*EI gives the tax ID.
• 2010AB, pay-to address: NM101 = 87, used only when payment should go to a different address from the billing provider’s.

2000B: the subscriber

HL*2*1*22*1~
SBR*P**GRP1001******CI~
NM1*IL*1*DOE*JOHN****MI*W123456789~
N3*12 OAK AVENUE~
N4*SPRINGFIELD*IL*627040000~
DMG*D8*19800101*M~
NM1*PR*2*ACME HEALTH PLAN*****PI*PAYERID~

The second level (HL03 = 22) is the subscriber, the person who holds the insurance.

SBR carries the coverage details:

• SBR01: this payer’s responsibility for the claim: P primary, S secondary, T tertiary. It matters when a patient has more than one plan.
• SBR02: 18 (self) if the subscriber is the patient, otherwise blank.
• SBR03: the group or policy number.
• SBR09: the claim filing indicator, such as CI (commercial), MB (Medicare Part B) or MC (Medicaid).

Then two child loops:

• 2010BA, subscriber name: NM101 = IL (insured). NM108 = MI puts the member ID in NM109. Address in N3/N4, and DMG (date of birth and gender) is required when the subscriber is the patient.
• 2010BB, payer name: NM101 = PR, always NM102 = 2 because a payer is never a person. NM108 = PI puts the payer ID in NM109. (XV is the CMS national plan ID, which is rarely used in practice.)

A PAT segment can also appear in 2000B, but only for specific patient details (such as a date of death or pregnancy indicator) when the subscriber is the patient.

2000C: the dependent patient

When the patient isn’t the subscriber, a third level appears:

HL*3*2*23*0~
PAT*19~
NM1*QC*1*DOE*EMMA~
N3*12 OAK AVENUE~
N4*SPRINGFIELD*IL*627040000~
DMG*D8*20150315*F~

• HL03 = 23 is the dependent, and HL02 = 2 points to the subscriber as parent.
• PAT01 is the relationship to the subscriber: 01 spouse, 19 child, 20 employee, G8 other relationship.
• 2010CA, patient name: NM101 = QC (patient), NM102 = 1 because a patient is always a person. Address and DMG follow.

When the subscriber is the patient, there’s no 2000C at all: SBR02 = 18 and the subscriber’s HL has HL04 = 0 (no children).

Why there’s no HL 21

Other transactions, such as the 270 and 278, have an information-receiver level (HL03 = 21). The 837 doesn’t: the receiver is already in loop 1000B, and the payer in loop 2010BB.

Putting it together

%%{init: {"themeVariables": {"fontSize": "14px"}, "flowchart": {"useMaxWidth": false, "nodeSpacing": 30, "rankSpacing": 40, "padding": 8, "wrappingWidth": 150}}}%%
flowchart TB
  subgraph H["File header"]
    direction LR
    A[ISA / GS / ST<br/>envelopes] --> B[BHT<br/>0019] --> C[1000A submitter<br/>1000B receiver]
  end
  subgraph L["Hierarchy"]
    direction LR
    D[2000A · HL 20<br/>billing provider] --> E[2000B · HL 22<br/>subscriber + payer] --> F[2000C · HL 23<br/>dependent patient]
  end
  H --> L

Below whichever level holds the patient, the claim itself begins with loop 2300.

Common pitfalls

• SBR02 = 18 and a 2000C together. If the subscriber is the patient, there’s no dependent level.
• The wrong NPI. The billing provider NPI in 2010AA must be the one enrolled with the payer for this tax ID.
• PO boxes in the billing address. 5010 requires a physical address in 2010AA; use 2010AB for a payment address.
• Short ZIP codes. The billing provider ZIP needs all nine digits.

Conclusion

The top of an 837 says who’s sending (1000A) and receiving (1000B), then builds the hierarchy: billing provider (2000A, HL 20), subscriber and payer (2000B, HL 22) and, if needed, the dependent patient (2000C, HL 23). SBR02 = 18 is the quickest tell that the subscriber is the patient.

Continue with Part 2: The Claim Information Loop (2300).
