X12 278: Prior Authorization Request and Response

The 278 is the transaction behind “we’re waiting on authorisation”. It carries a provider’s request for approval to the payer’s utilization management organisation (UMO), and carries the decision back. Request and response use the same transaction set, with most of the same segments, so reading one teaches you most of the other.

This post walks through the 278’s structure, the segments that differ between request and response, and a simplified example of each.

This post covers the X12 side. For the business process behind it, start with Prior Authorization: The Step-by-Step Workflow.

Request or response? Check BHT02

The 278 uses implementation guide 005010X217. Right after ST, the BHT (beginning of hierarchical transaction) segment says which way the file is going:

BHT02	Meaning
13	Request
11	Response

BHT01 is 0007 for the 278’s hierarchy. A tracking reference in BHT03 ties the response back to the request.

The hierarchy

The 278 has more hierarchical levels than most transactions, and each one has its own HL03 code:

Loop	Level	HL03	Holds
2000A	UMO (information source)	20	The payer or UMO that decides: NM1*X3
2000B	Requester (information receiver)	21	The provider asking: NM1*1P or NM1*FA
2000C	Subscriber	22	The member: NM1*IL
2000D	Dependent	23	The patient, only if they aren’t the subscriber: NM1*QC
2000E	Patient event	EV	The admission or service episode being reviewed
2000F	Service	SS	Line-level services within the event

If the subscriber is the patient, loop 2000D is simply left out, and the patient event hangs off the subscriber. When a dependent is the patient, their relationship to the subscriber is carried in the dependent loop (INS02: 01 spouse, 19 child, and so on).

The segments that matter

TRN (trace number) sits in the patient event loop. The requester assigns one when sending, and the payer echoes it in the response. It’s how you track a request end to end.

UM (health care services review information) describes what’s being reviewed, at the event level and again at each service:

• UM01: the request category: AR admission review, HS health services review, SC specialty care review;
• UM02: the certification type: I for initial, plus codes for extensions, revisions and appeals;
• UM03: the service type code;
• UM04: the facility or place of service code.

HI carries the diagnoses, DTP the proposed dates, and SV1/SV2/SV3 in the service loop carry the procedure codes and units, just like on a claim.

What’s different in the response

Two segments carry the payer’s answer.

HCR (health care services review) is the decision:

HCR01	Meaning
A1	Certified in total
A2	Certified, partially
A3	Not certified
A4	Pended
A6	Modified
C	Cancelled
CT	Contact the payer
NA	No action required

HCR02 holds the authorisation (certification) number that goes on the later claim, and HCR03 a reason code when the request isn’t fully approved.

AAA (request validation) appears when the request itself couldn’t be processed: an unknown member, a missing field, a provider the payer can’t identify. AAA01 is N (not valid), AAA03 gives the reject reason (for example 72 for an invalid member ID, or 15 for missing required information), and AAA04 suggests a follow-up action.

Line beats event. HCR and AAA can appear at the patient event level and at the service level. When both are present, the service-level answer wins for that line, because it’s more specific. A payer might approve an event overall but deny one of its services.

A simplified request

Here’s a request for a lumbar spine MRI for a patient who is also the subscriber. The envelopes are omitted and values are illustrative:

ST*278*0001*005010X217~
BHT*0007*13*REQ20251020001*20251020*0930~
HL*1**20*1~
NM1*X3*2*ACME HEALTH PLAN*****PI*12345~
HL*2*1*21*1~
NM1*1P*1*SMITH*JANE****XX*1234567893~
HL*3*2*22*1~
NM1*IL*1*DOE*JOHN****MI*W123456789~
DMG*D8*19800101*M~
HL*4*3*EV*1~
TRN*1*TRK0001*9012345678~
UM*HS*I*62*11:B~
DTP*AAH*D8*20251105~
HI*ABK:M5416~
HL*5*4*SS*0~
SV1*HC:72148**UN*1~
SE*17*0001~

The hierarchy goes UMO (1) → requester (2) → subscriber (3) → patient event (4) → service (5). There’s no HL*..*23, because the patient is the subscriber. The event asks for a health services review (HS) of an MRI (service type 62) in an office setting, for an event date of 5 November (DTP*AAH), for a diagnosis of lumbar radiculopathy. The service line asks for one unit of CPT 72148.

The matching response

The payer approves:

BHT*0007*11*REQ20251020001*20251020*1015~
...
HL*4*3*EV*1~
TRN*2*TRK0001*9012345678~
HCR*A1*AUTH998877~
UM*HS*I*62*11:B~
DTP*AAH*D8*20251105~
HL*5*4*SS*0~
HCR*A1*AUTH998877~
SV1*HC:72148**UN*1~

BHT02 is now 11. TRN01 changes to 2 (a referenced trace number) but keeps the requester’s number, and both levels return HCR*A1 with authorisation number AUTH998877. That number goes on the claim in REF*G1.

A rejected request

If the member ID doesn’t match anyone, the payer answers with AAA in the subscriber loop instead of a decision:

HL*3*2*22*1~
NM1*IL*1*DOE*JOHN****MI*W123456780~
AAA*N**72*C~

AAA03 = 72 means an invalid or missing member ID; AAA04 = C means “correct and resubmit”.

Notifications and inquiries

The same transaction set also handles:

• notifications, such as telling the payer a patient has been admitted;
• inquiries about an existing authorisation;
• acknowledgments confirming receipt.

They reuse the structure above with different BHT and UM values.

Common pitfalls

• Including loop 2000D when the subscriber is the patient. It’s a structural error.
• Reading only the event-level HCR. A service-level A3 can deny one line inside an approved event.
• Losing the trace number. Without the TRN, matching asynchronous responses to requests becomes guesswork.
• Assuming 278 coverage. Many payers still require portals or fax for prior auth, despite the 278 standard. CMS now requires a FHIR prior authorisation API from many government-program payers by January 2027, which may change that.

Conclusion

The 278 is one transaction set for both directions: BHT02 tells you if it’s a request (13) or response (11). Loops go from UMO to requester to subscriber, optional dependent, patient event (EV) and service (SS). The UM segment describes what’s being reviewed; HCR returns the decision and authorisation number; AAA flags requests that couldn’t be processed. Service-level answers override event-level ones.

The approved authorisation number goes on the claim, which is covered in 837 Part 2.
