Y-IaC: Requirements Gathering

A requirement for Y-IaC has a twist: it isn’t for one deployment, it’s a contract that a few dozen repositories will lean on at once. “The azurerm provider is pinned” sounds like a detail until a bump replaces a resource group in a consumer nobody on the platform team has heard of. So I write Y-IaC requirements as reusable contracts and keep each consumer’s incidental config out of them.

Functional requirements

What the platform must do, per provider and module where it applies:

#	Requirement	Where it lives today
F1	Declare resources in YAML and generate Terragrunt from it	generators/stack_generator.py writes terragrunt.stack.hcl
F2	Run init, plan, apply, destroy, import, state, taint, stack and DAG commands	handlers/terragrunt/
F3	Validate modules: fmt, init, provider schema, validate, TFLint, README, HCL format	tools/validate_terraform_module.py
F4	Conditional dependencies: a module works with or without a dependency’s output	Terragrunt mock_outputs in unit templates
F5	Provider version selection, with per-resource overrides	config/providers.yaml + override_versions in common_vars.yaml
F6	Validate repo, subscription, environment and provider before running	cli/arg_validation.py, validation/repository.py
F7	Security, policy and cost gates with configurable enforcement	validation/opa.py, trivy.py, wiz.py, infracost.py
F8	Plan summaries, error reports, notifications, drift detection, ticketing	reporting/, drift and Jira workflows
F9	Safe state-lock recovery with age and retry limits	handlers/statelock/
F10	Ansible playbooks and resource inventory visualization	handlers/ansible.py, --python visualize

Two of these deserve a sentence each. F4 matters because a stack’s first plan runs before its dependencies exist; without mocks, a brand-new stack can never plan. F9 matters because a lock left by a killed CI job blocks every later run on that state file, and releasing the wrong lock corrupts state.

Non-functional requirements

• Reproducible and reviewable. The same YAML at the same Y-IaC ref produces the same generated files and the same plan.
• Backward-compatible module inputs wherever practical. A renamed variable is a breaking change for every consumer that sets it.
• Clear failures. Every error says what failed, where and what to do next. config/error_message_and_solutions.yaml is the start of a failure catalog for exactly this.
• Deterministic validation that doesn’t modify the module it’s validating.
• No secrets in committed config. Credentials only arrive as environment variables.
• Reasonable performance for the stack sizes we support.
• Testable without production. Module and CLI behavior can be tested without live credentials.
• Versioned, searchable docs. The generated module reference is published to GitHub Pages.

The target I’d set (an estimate, not yet measured): under 10 minutes for a 30-unit stack on a GitHub-hosted runner, and under 3 minutes for a single-unit change. That makes “reasonable performance” testable in Performance and load testing.

User journeys and use cases

The five representative use cases from the guide, each as a journey I’d want to demo end to end:

1. Add a resource. A consumer adds an aws_vpc entry to environments/aws/dev/hello-world/resources.yaml, runs python entrypoint.py --cloud aws --environment dev --stack hello-world --terragrunt plan, reviews the plan and opens a PR. CI plans again; after merge and approval, it applies.
2. Add a module. A contributor creates cloud/azure/terraform/<type>/ and the matching cloud/azure/terragrunt/<type>/terragrunt.hcl, documents inputs and the import path, runs the module validator and the relevant tests.
3. Import an existing resource. An operator imports it, the provider path is normalized (for example microsoft.insights to Microsoft.Insights via import_id_normalization), and the next plan shows no changes.
4. Change shared behavior. A maintainer changes Python or a workflow, runs the tests, then checks the compatibility workflow against representative consumers.
5. Review a blocked plan. A security owner sees an OPA or Wiz failure in the summary, reads the evidence, and either rejects the change or grants a time-boxed exception.

Acceptance criteria

Written so a reviewer can tick them off, using use case 1 as the example:

Given infra-aws has an aws_vpc entry in hello-world/resources.yaml
When I run entrypoint.py with --terragrunt plan for aws/dev/hello-world
Then terragrunt.stack.hcl contains one unit "aws_vpc"
And .terragrunt-stack/aws_vpc/ contains a generated provider.tf pinning aws to the providers.yaml version
And the plan shows 1 to add, 0 to change, 0 to destroy
And the OPA and scanner gates report a result in the summary
And a second plan after apply shows no changes

General criteria for any platform change: plans succeed for the affected consumers, validation output is as expected, existing resources are not replaced or destroyed unless the change says so, failure behavior is documented, audit evidence (plan, gate results, approval) exists, and changes that touch state or deployments have a rollback or recovery procedure.

Business rules

The rules the platform enforces or must make easy to enforce:

• Subscription allow-lists. A repo may only target subscriptions mapped to it (validation/repository.py checks the repo-subscription mapping).
• Backend per repo. Every consumer has exactly one backend entry, matched on the repo folder name, in its own config.yaml or the shared one. No entry, no run: root.hcl fails with an explicit message.
• Required tags. common_tags in common_vars.yaml are merged into every resource, and stack-level tags merge key by key so they never drop an environment tag. OPA has a tag compliance policy.
• Provider version constraints come from config/providers.yaml, with per-resource overrides only through override_versions.
• Approval before apply. Apply jobs wait on GitHub environment protection rules.
• Ownership metadata. Repos carry custom properties (cloud, cost centre, portfolio, tech stack), as infra-github shows for its own repositories.

Reporting and analytics requirements

Reports exist for three audiences:

Audience	Report	Produced by
Reviewer on a PR	Per-unit add/change/destroy table, gate outcomes, links to plan artifacts	reporting/plan_summary.py, terragrunt-summary-report.yaml
Operator after a failure	Error report with matched catalog entry and suggested fix	reporting/error_report.py, error_catalog.py
Platform owner	Drift findings, gate trends, validation status, release info	Drift workflows, Jira tickets; trends not yet aggregated

The gap is the third row. Individual runs report well; nothing yet rolls them up across consumers. I’d add that before promising any of the KPIs in Vision.

Accessibility and localization requirements

Y-IaC’s interface is a CLI, YAML, Markdown and workflow summaries, so accessibility is about readable output rather than screen-reader support for a UI. In practice: clear headings and tables in docs, descriptive link text, diagrams with text alternatives, and CLI and summary output that never carries meaning by colour or emoji alone (every ✅ or ❌ sits next to a word like “passed” or “failed”).

Localization is not a platform requirement; everything is in English. A consumer whose workload needs localized content handles that in the workload.

Regulatory, legal, and compliance requirements

The platform doesn’t hold workload data, but it does produce artifacts that reveal infrastructure: state files, plan JSON and logs contain resource names, addresses, tags and provider attributes. So:

• Regulatory controls are mapped per subscription, resource type, workload and data classification, not once for the platform.
• Plan JSON is redacted before scanning (sensitive provider config removed), and that redaction is a requirement, not a nice-to-have.
• Audit evidence (PR, plan, gate results, approval, apply log) must be retained for whatever period the strictest consumer needs.

The baseline I’d plan for: treat the strictest consumers as falling under HIPAA (the module catalog includes FHIR and healthcare workspace modules) and SOC 2, with ISO 27001-style controls for access and change management. That sets evidence retention at six years for plan summaries, approvals and apply records (the HIPAA documentation period), exported to long-term storage, while raw plan files stay short-lived.

Prioritization and release scope

The guide sets a risk-based order, and I’d hold every backlog conversation to it:

1. State safety, identity, security and policy enforcement.
2. Correct module contracts and non-destructive plans.
3. Consumer onboarding and CI/CD reliability.
4. Observability, reporting, drift, cost and support efficiency.
5. Convenience features and visualization.

This order means a nice visualization improvement waits behind a lock-recovery bug, every time. It also means Infracost (currently disabled by default) only becomes a priority once the first two levels are solid. The MVP is cut from levels 1 to 3.

Checklist

• Functional requirements F1 to F10 each have an owner and a test reference
• A plan-time target exists for the largest supported stack
• Each of the five use cases has a scripted demo in a scratch consumer
• Gherkin-style acceptance criteria exist for “add a resource” and “import a resource”
• Repo-subscription mappings are complete for every consumer
• Cross-consumer reporting requirements are agreed with the platform owner
• Applicable regulatory frameworks and evidence retention periods are recorded

• The risk-based priority order is written into the backlog guidelines
