Job Hunter Agent: Technical Architecture

The architecture fits in one pod because the hard parts aren’t scale. They’re trust (an LLM that wants to please will invent experience), a website that doesn’t want to be automated, and a local model that’s slower than a cloud API. So the design spends its complexity on deterministic checks and careful integration, and keeps the runtime simple: one process, one sidecar, one database.

System context and component architecture

Step through one scheduled run for one search profile:

1. A profile's time comes: At 08:00 India time on a weekday the scheduler fires the Cloud Architect profile's job. The run is recorded as running; other profiles have their own times.
2. Ask the sidecar: The app calls the LinkedIn MCP server on loopback port 8080 over streamable HTTP. Its client allows only read-only tools, so it can't apply or message anyone.
3. A signed-in browser: Chromium, signed in as me, runs the search and opens up to 5 new postings per keyword. Jobs already stored are skipped before any page loads.
4. Filter and hand over: Duplicates, excluded companies and reposts are dropped; new postings are stored with the profile that found them and passed to the agents.
5. Research the company: The company's LinkedIn About page, then Wikidata for revenue and headcount by year and Google News for headlines. Cached for a week; figures only when published.
6. The local model writes: Every agent call goes through LiteLLM to a local model with a JSON schema. It scores the fit, returns line edits to my resume, writes a letter and re-scores the result.
7. Check the claims: Numbers, tools and phrases the draft adds that my resume doesn't have are flagged. Any flag blocks approval until I've looked at it.
8. Saved for review: Drafts, scores, research and the run's counts go to Supabase over its HTTPS API. The application waits as pending review; nothing is sent.
9. Tell me: When the run finishes, the app posts a summary to a Slack incoming webhook. A failed post never fails the run.
10. Sign in: I open the app and Keycloak signs me in with OpenID Connect. Only members of platform-admins get in; the app checks the group too.
11. The review queue: A signed cookie holds the session for 8 hours. The review page leads with skills required vs. mine and the shortlist confidence; drafts are collapsed.
12. My decision: I approve or reject. After approving I apply on the employer's site myself and mark it applied. The agent never does that step.

Component	What it is	Runs where
Job Hunter app	FastAPI service: API, review UI (static HTML/JS), pipeline, agents, scheduler	app container, port 8000
LinkedIn MCP server	mcp-server-linkedin: a Chromium browser signed in as me, exposed as MCP tools	linkedin sidecar, loopback 8080 only
LiteLLM gateway	OpenAI-compatible gateway in front of the local model qwen3.5-35b-a3b	Homelab ai cluster
Supabase	Postgres with a REST API, free tier	Supabase cloud
Keycloak	OIDC provider, realm homelab	Homelab core cluster
Wikidata, Google News	Public company facts and headlines	Internet
Slack	Run reports through an incoming webhook	Slack

Inside the app, the pieces are deliberately few: pipeline.py (discover, score, draft, evaluate one job, status transitions), agents/ (one base class, six agents), truthfulness.py, sources.py (LinkedIn, Indeed, company intel), company_facts.py, scheduler.py, runs.py (history), notify.py (Slack) and db/ (Supabase and an in-memory store with the same interface).

Technology and framework selection

Choice	Why	Alternative I passed on
Python + FastAPI	Async I/O for slow LLM and browser calls; Pydantic models double as the LLM’s JSON schemas	Node: fewer good PDF/DOCX libraries
Pydantic v2	One model per agent output; validation catches malformed LLM answers before they’re stored	Hand-written JSON parsing
OpenAI SDK against LiteLLM	Any OpenAI-compatible backend; structured output with json_schema	A provider-specific SDK
Local qwen3.5-35b-a3b	My resume stays home; free to run	A frontier cloud model: better prose, but my data leaves the house
mcp-server-linkedin	Maintained, read-only tools, real signed-in browser	Writing my own Playwright scraper
Supabase	The articles used it; Postgres + REST + row-level security on a free tier	SQLite in a PVC: simpler, but no off-cluster copy
Vanilla JS UI	No build step, ~800 lines, served by FastAPI	React: more structure than one user needs
APScheduler	In-process cron, one job per profile	A Kubernetes CronJob per profile: needs the sidecar’s browser session

API and integration architecture

A REST API under the same origin as the UI (OpenAPI at /docs). The groups:

Group	Main endpoints
Profiles and resumes	GET/POST /profiles, PUT/DELETE /profiles/{id}, POST /resumes/upload, PUT /resumes/{id}
Jobs	GET /jobs (with each job’s evaluation), POST /jobs, POST /jobs/{id}/evaluate
Pipeline	POST /pipeline/discover?profile_id=, POST /pipeline/draft, POST /pipeline/run, GET /runs, GET /stats, GET /schedule
Review	GET /applications, GET /applications/{id}, POST /applications/{id}/approve (and reject, reopen, applied)
Research	GET /research, POST /research/{id}/refresh

Integrations, each behind a small interface so tests can swap in fakes:

• LinkedIn: MCP over streamable HTTP; the client refuses any tool not on a read-only list.
• LLM: one structured(system, user, schema) call; JSON schema output, thinking disabled, one repair retry when validation fails.
• Company facts: Wikidata wbsearchentities / wbgetentities, Google News RSS.
• Slack: a POST of {"text": …} to an incoming webhook.

Data architecture and data models

Every row carries user_id, created_at and updated_at. The core of the model:

erDiagram
  search_profiles ||--o{ jobs : finds
  resume_templates ||--o{ job_scores : "scored with"
  jobs ||--o{ job_scores : has
  jobs ||--o| applications : "drafted as"
  applications }o--|| optimized_resumes : uses
  applications }o--|| cover_letters : uses
  resume_templates ||--o{ optimized_resumes : "tailored from"
  jobs ||--o{ contacts : suggests
  company_research }o--o{ jobs : "same company"
  runs }o--o{ search_profiles : covers
  agent_results ||--o{ job_scores : produced

Two stores I’d call out: agent_results keeps every LLM call’s input, output and error (the audit trail for “why did it write that?”), and company_research is a per-company cache keyed by the lower-cased company name. More in Data and Integration.

Identity and access architecture

• People: Keycloak OIDC, authorization code flow with PKCE and a confidential client. The app validates the ID token, then checks membership of platform-admins itself, so a misconfigured client still can’t let others in. The session is a signed jh_session cookie, 8 hours, SameSite=Lax, Secure.
• App to services: a LiteLLM virtual key limited to one model; a Supabase service-role key (server only, bypasses row-level security); a Slack webhook URL. All from OpenBao through External Secrets.
• App to LinkedIn: my own signed-in browser session, stored on a persistent volume. It’s the most sensitive credential here, and it never leaves the pod.

Hosting and deployment model

One Argo CD application on the homelab platform k3d cluster, namespace job-hunter:

Object	Notes
Deployment	1 replica, Recreate (single writer of the browser profile); app + linkedin containers; an init container prepares the browser’s home folder
PVC linkedin	2 GiB, holds the LinkedIn browser profile; backed up by Velero
Service + Ingress	jobs.platform.home.cloudutsuk.com, Traefik, Let’s Encrypt via cert-manager DNS-01
NetworkPolicy	Ingress only from Traefik, only port 8000; the sidecar has no Service port
ExternalSecret	kv/platform/job-hunter → env vars

The image is built by the platform’s reusable workflow, signed with cosign and pinned by digest; Kyverno refuses unsigned or unpinned images. Details in CI/CD.

Scalability and performance strategy

Scale isn’t the goal; LinkedIn’s patience is the ceiling. The numbers that matter:

• At most 5 postings per keyword per run, past week only, sorted by date.
• One run per profile per weekday, profiles 4 hours apart, and a lock so two scheduled runs never share the browser.
• Each draft costs about five LLM calls (score, tailor, re-score, letter, contacts) plus research once per company. With a local model that’s minutes per job, which is fine unattended.
• Resume tailoring returns line edits, not a rewritten resume: rewriting a 28,000-character resume timed out at 180 s; edits finish well inside the 300 s timeout.

Horizontal scaling isn’t possible as built (one browser session, an in-process scheduler) and isn’t needed.

Resilience and disaster recovery

Failure	Behaviour
LinkedIn errors or blocks	That keyword’s error is recorded; other keywords and profiles continue
LLM times out or returns junk	One repair retry; then that job is listed under failed and the run goes on
Company research, facts, news, contacts or apply-link fail	Recorded as warnings; the draft still completes
Slack is down	Logged; the run is unaffected
Pod restarts	Browser session survives on the PVC; the scheduler’s jobs live in memory, so a run whose time passed while the pod was down is skipped until the next slot
Supabase unavailable	Runs and the UI fail visibly; nothing is lost that isn’t regenerable

Recovery is mostly re-running: postings and drafts can be regenerated. What can’t be regenerated is my review history and the LinkedIn session. See Backup and restore.

Architectural decision records

The decisions live as MADR files in job-hunter-agent/docs/adr and are published in full on the Architecture Decision Records page:

#	Decision	Status
1	Manual approval only; the agent never submits, connects or messages	Accepted
2	Local LLM through LiteLLM instead of a cloud API	Accepted
3	Resume tailoring as line edits applied by code, not a regenerated resume	Accepted
4	Deterministic truthfulness checks block approval	Accepted
5	LinkedIn through an MCP sidecar with a read-only tool allow-list	Accepted
6	Company figures only from published sources (Wikidata), never the model	Accepted
7	One scheduled job per profile, spread through the day	Accepted
8	Six-month retention, and our own nightly export because the Supabase free plan has no backups	Accepted
9	Service level objectives for scheduled runs, and alerts on the platform	Accepted

ADR	Decision	Status
0001	Manual approval only: the agent never submits, connects or messages	Accepted
0002	Local LLM through the homelab's LiteLLM gateway, not a cloud API	Accepted
0003	Resume tailoring as line edits applied by code, not a regenerated resume	Accepted
0004	Deterministic truthfulness checks block approval	Accepted
0005	LinkedIn through an MCP sidecar with a read-only tool allow-list	Accepted
0006	Company figures only from published sources, never the model	Accepted
0007	One scheduled job per search profile, spread through the day	Accepted
0008	Six-month retention, and our own nightly export because Supabase's free plan has no backups	Accepted
0009	Service level objectives for scheduled runs, and alerts on the platform	Accepted

Checklist

• System diagram matches the deployed pod (containers, ports, volumes)
• Every external integration has a fake used in tests
• Read-only tool allow-list reviewed when the MCP server is upgraded
• LinkedIn volume limits written down next to the scheduler settings
• Backup covers the browser session and Supabase data

• The seven decisions above written as ADRs
