Designing a GCP Landing Zone for a Healthcare Company with PHI and US-Only Data Residency

This is the design I would put in front of an architecture review board for a healthcare company moving to Google Cloud. The company handles protected health information (PHI), has engineering teams in the United States, India and the Philippines, and some customers contractually require that their data is stored in and accessed only from the US. The offshore teams still need to develop, test and support the platform, so they work in environments that hold only de-identified data.

This post assumes familiarity with the building blocks of a landing zone. If you need a refresher, start with GCP Landing Zone: Core Concepts and Google’s Recommendations.

Index

• Requirements
• Assumptions and decisions
• Design principles
• Architecture overview
• Resource hierarchy
• Identity and access
• Enforcing “US-only access” in layers
• Network architecture
• The de-identification pipeline
• Security and compliance controls
• Logging, monitoring and the SOC
• Cost management
• Infrastructure as code and operating model
• Residual risks and open decisions
• Rollout plan
• References

Requirements

#	Requirement	Source
R1	PHI is protected to HIPAA standards; a Business Associate Agreement (BAA) with Google is in place and only BAA-covered services process PHI	Regulation
R2	For strict-US customers, PHI is stored only in US regions and accessed only by people located in the US, including Google support staff	Customer contracts
R3	Teams in India and the Philippines can develop, test and troubleshoot using de-identified data, without any path to PHI	Business
R4	One customer’s PHI must not be reachable from another customer’s environment	Customer contracts, least privilege
R5	Every access to PHI is attributable to a named person and auditable for at least six years	HIPAA documentation retention, contracts
R6	The company’s US data center and offices connect privately; cloud-only (zero-trust) access is supported too	Business
R7	Spend is attributable by customer, environment and team	Finance

Assumptions and decisions

These were agreed with the stakeholders before the design started:

• All Google Cloud data stays in US regions, including the de-identified environments. Offshore engineers work remotely on de-identified projects hosted in the US. Nothing has to leave the US, so residency becomes a single organization-wide rule instead of a per-folder exception.
• Microsoft Entra ID is the identity provider, federated to Cloud Identity.
• Strict-US customers get dedicated folders, projects, encryption keys and service perimeters. Customers without the restriction share a separate US PHI zone.
• Both connectivity models are supported: Dedicated Interconnect from the US data center and HA VPN from offices, and cloud-only access through Identity-Aware Proxy, Chrome Enterprise Premium and Cloud Workstations.
• Primary region us-east4 (Northern Virginia), disaster recovery region us-central1 (Iowa).

Whether de-identified data derived from a strict-US customer’s PHI may be used offshore is a contract question, not a technical one. HIPAA treats properly de-identified data as no longer PHI, but a contract can still forbid it. The design keeps a per-customer flag. If it is off, that customer’s data never feeds the offshore environments, and offshore teams use synthetic data for that customer instead.

Design principles

1. Two worlds, one organization. A regulated zone (PHI, US-only people) and a general zone (de-identified data, global teams) share one organization, identity system and toolchain, but no network path, no perimeter and no data path except one controlled, one-way de-identification pipeline.
2. Defense in depth for the residency promise. No single control (IAM, network, geography, device) is trusted to keep non-US people away from PHI. Each layer assumes the one before it failed.
3. Isolation by customer where contracts demand it, by project and dataset everywhere else.
4. Guardrails over gatekeeping. Offshore teams get self-service in the general zone. The regulated zone is changed only through reviewed pipelines and just-in-time access.
5. Everything from code. The hierarchy, policies, perimeters and networks are Terraform, deployed by pipelines whose identities are themselves zoned.

Architecture overview

flowchart LR
    subgraph US["US-located people and systems"]
        USDC["US data center<br/>EHR feeds, HL7/FHIR"]
        USENG["US engineers, support<br/>managed devices"]
    end
    subgraph OFF["India and Philippines"]
        INENG["Offshore engineers<br/>managed devices"]
    end

    subgraph GCP["Google Cloud organization, all resources in US regions"]
        subgraph REG["Regulated zone: Assured Workloads, US-only personnel"]
            CUSTA["Strict-US customer A<br/>own perimeter, own keys"]
            CUSTB["Strict-US customer B<br/>own perimeter, own keys"]
            SHARED["Shared PHI zone<br/>other customers"]
            DEID["De-identification pipeline"]
        end
        subgraph GEN["General zone: de-identified data, global teams"]
            DEV["Development"]
            TEST["Test / QA / performance"]
        end
        COMMON["Common services<br/>logging, SCC, KMS, billing"]
    end

    USDC -- "Interconnect, regulated VLANs" --> REG
    USENG -- "IAP / Chrome Enterprise Premium<br/>access level: US + managed device" --> REG
    INENG -- "HA VPN or IAP" --> GEN
    INENG -. "blocked: IAM, perimeter,<br/>no routes, geo access level" .-x REG
    CUSTA --> DEID
    SHARED --> DEID
    DEID -- "one-way, validated,<br/>de-identified only" --> GEN
    REG -. "audit logs" .-> COMMON
    GEN -. "audit logs" .-> COMMON

Resource hierarchy

I start from Google’s environment-oriented blueprint (bootstrap, common, networking, environments) and add a data-classification split at the top: regulated or general. Data classification is what changes policy here: residency rules, perimeters, who may hold roles and which services are allowed. In Google’s terms this combines the environment-oriented and region/regulation-oriented patterns.

flowchart TB
    ORG["Organization: example-health.com<br/>gcp.resourceLocations = in:us-locations"]
    ORG --> BOOT["fldr-bootstrap"]
    ORG --> COM["fldr-common"]
    ORG --> NET["fldr-network"]
    ORG --> REG["fldr-regulated<br/>Assured Workloads: Healthcare and Life Sciences with Support"]
    ORG --> GEN["fldr-general"]
    ORG --> SBX["fldr-sandbox"]

    BOOT --> B1["prj-b-seed"]
    BOOT --> B2["prj-b-cicd-general"]
    BOOT --> B3["prj-b-cicd-regulated"]

    COM --> C1["prj-c-logging-general"]
    COM --> C2["prj-c-scc"]
    COM --> C3["prj-c-billing-export"]

    NET --> N1["prj-net-hub-general"]
    NET --> N2["prj-net-interconnect"]
    NET --> N3["prj-net-dns"]

    REG --> RC["fldr-reg-common<br/>prj-r-logging, prj-r-kms, prj-r-deid"]
    REG --> RS["fldr-reg-shared-phi<br/>prj-r-shared-svpc, prj-r-shared-prod, prj-r-shared-uat"]
    REG --> RA["fldr-reg-cust-acme<br/>prj-r-acme-svpc, prj-r-acme-prod, prj-r-acme-kms"]
    REG --> RB["fldr-reg-cust-globex<br/>prj-r-globex-svpc, prj-r-globex-prod, prj-r-globex-kms"]

    GEN --> GP["fldr-gen-production<br/>non-PHI corporate apps"]
    GEN --> GN["fldr-gen-nonproduction<br/>test, QA, perf on de-identified data"]
    GEN --> GD["fldr-gen-development<br/>dev on de-identified or synthetic data"]

Folder	Holds	Key policies set at this level
Organization	Everything	gcp.resourceLocations: in:us-locations, the Google baseline constraints, domain-restricted sharing, no SA keys, SCC, org log sinks
fldr-bootstrap	Seed project, Terraform state, separate pipelines for regulated and general	Only the platform team; regulated pipeline service account is the only identity with write access to fldr-regulated
fldr-common	Org-wide logging (non-PHI), SCC, billing export	Security team and finance only
fldr-network	Hub for the general zone, Interconnect project, DNS	Network team; regulated network hosts live inside fldr-regulated
fldr-regulated	All PHI	Assured Workloads folder; IAM only for US-only groups; gcp.restrictNonCmekServices; gcp.restrictServiceUsage limited to BAA-covered services; stricter VM, SQL and storage constraints
fldr-reg-cust-<name>	One strict-US customer: own Shared VPC host, workload projects, key project	Own VPC-SC perimeter, own CMEK key ring, IAM only for that customer’s US support group
fldr-reg-shared-phi	PHI for customers without the US-only clause	Shared perimeter; customer isolation by project, dataset and IAM
fldr-general	De-identified and non-PHI workloads	Global groups; standard blueprint constraints; Sensitive Data Protection discovery enabled
fldr-sandbox	Personal experiments	No data imports from other folders, budgets with hard caps, auto-deletion

Why the regulated network hosts sit inside fldr-regulated: a project can belong to only one regular VPC-SC perimeter, and a Shared VPC network’s traffic is attributed to its host project. Putting each strict-US customer’s network host in that customer’s folder and perimeter keeps the perimeter boundary, the IAM boundary and the network boundary the same. That makes them easy to reason about and easy to show to an auditor.

Why PHI environments are not split into dev/test/prod: there is no PHI in development. The regulated zone has only prod and a US-only uat for the rare case where validation against real data is unavoidable, such as reconciling a customer data feed. All other environments are in the general zone.

Assured Workloads

fldr-regulated is created as an Assured Workloads folder with the Healthcare and Life Sciences with Support control package. This adds controls that ordinary org policies cannot provide:

• Data residency in US regions, enforced and monitored by Google.
• Google support personnel who can access the workloads are limited to US persons located in the US. This is the part of R2 that applies to the cloud provider itself.
• Only services in scope for the package can be enabled.
• Violations are reported in the Assured Workloads monitoring view.

If a customer’s contract requires only residency and not the healthcare controls, the US Data Boundary and Support package is the lighter alternative. I keep one package for the whole regulated folder so there is only one set of rules to explain.

Identity and access

Federation

flowchart LR
    HR["HRIS<br/>work location, US person status"] --> ENTRA["Microsoft Entra ID"]
    ENTRA -- "SCIM: users + groups" --> CI["Cloud Identity"]
    ENTRA -- "SAML SSO<br/>Conditional Access" --> CI
    CI --> IAM["IAM bindings on folders and projects<br/>groups only"]

• Entra ID → Cloud Identity with SAML SSO and SCIM provisioning through the Google Cloud enterprise app in Entra. Only the groups prefixed grp-gcp- are provisioned.
• Entra Conditional Access on the Google Cloud app: phishing-resistant MFA (FIDO2 or Windows Hello for Business), compliant or hybrid-joined device, and sign-in risk policies.
• Four or five super admin accounts that exist only in Cloud Identity (super admins bypass SSO), held by US staff, protected with hardware security keys and alerted on every sign-in.
• No service account keys. Pipelines use Workload Identity Federation, and people use impersonation and Privileged Access Manager.

Group model

Group names encode zone, scope and role, so a binding can be audited by reading its name:

Group	Membership rule	Bound on
grp-gcp-reg-acme-support	Entra dynamic group: usageLocation == US AND extensionAttribute: usPerson == true AND assigned to customer Acme	fldr-reg-cust-acme (read and support roles)
grp-gcp-reg-shared-ops	Dynamic: US-located, US person, regulated operations team	fldr-reg-shared-phi
grp-gcp-reg-platform	Dynamic: US-located platform engineers	fldr-regulated (Privileged Access Manager eligible, not standing)
grp-gcp-gen-dev-<team>	Any location, team membership	fldr-gen-development projects
grp-gcp-gen-qa-<team>	Any location	fldr-gen-nonproduction projects
grp-gcp-sec-analysts	Security operations, any location	fldr-common, SCC (findings only, no data roles in regulated)

The dynamic membership rules matter. When an engineer transfers from the US to India, HR updates their work location, Entra removes them from every grp-gcp-reg-* group, and SCIM removes the group membership in Cloud Identity. Their access to PHI ends without anyone editing an IAM policy.

A deny policy on fldr-regulated adds a second check. It denies data-access permissions (for example bigquery.tables.getData, storage.objects.get, healthcare.fhirResources.get) to every principal except the regulated groups and the zone’s service accounts. Even a mistaken allow binding, for example someone granting roles/bigquery.dataViewer to a general-zone group, does not grant access.

Enforcing “US-only access” in layers

“Accessed only from the US” is the hardest requirement, because the cloud cannot see where a person really is. The design stacks independent controls so that defeating one is not enough:

Layer	Control	What it stops	Known gap covered by another layer
1. Who	IAM and deny policy: PHI roles only for dynamic US-only groups	Offshore staff holding roles at all	Wrong HR data, misconfigured group
2. Where (identity)	Entra Conditional Access: the regulated access path requires a US named location and a compliant device	Sign-in from non-US IPs	VPN or proxy that exits in the US
3. Where (Google)	VPC-SC ingress rules for the regulated perimeters require an Access Context Manager access level with regions: [US] + corporate-owned, encrypted device (Endpoint Verification)	API and console access from non-US public IPs or unmanaged devices	Same VPN caveat; geo checks do not work for private IPs
4. Network	Regulated VPCs have no routes from India or Philippines office networks; office VPNs terminate only in the general hub; a hierarchical firewall policy on fldr-regulated denies offshore office ranges	Network reachability from offshore offices	Remote access through a US machine
5. Workspace	Hands-on PHI work happens only in US-located VDI / Cloud Workstations inside the regulated perimeter, reached through IAP with the layer 3 access level; clipboard, download and print disabled	Copying PHI to an endpoint	Screen photography (policy and training)
6. Provider	Assured Workloads with Support, Access Approval, Access Transparency, Key Access Justifications	Non-US Google personnel	n/a
7. Detect	Data Access audit logs on every PHI service, alerts for access from unexpected IPs or ASNs, and quarterly access reviews per customer	Anything that slipped through	n/a

Access Context Manager’s geographic attribute only evaluates public source IPs, and access levels that require a region always deny requests from private IPs. Paths that arrive privately, over Interconnect from the US data center or from inside a US VDI subnet, are therefore authorized by network-based ingress rules (the specific VPC networks or IP ranges) rather than by the geo access level. Design the perimeter ingress rules with both kinds of path in mind.

Network architecture

Topology

The regulated and general zones get separate network estates that are never peered. Within each zone I follow Google’s guidance: Shared VPC hosts, private by default, centralized egress.

flowchart TB
    subgraph ONPREM["On-premises"]
        DC["US data center<br/>VRF-PHI and VRF-CORP"]
        INOFF["India offices"]
        PHOFF["Philippines offices"]
    end

    subgraph ICP["prj-net-interconnect"]
        IC["Dedicated Interconnect<br/>2 metros x 2 links, 99.99%<br/>MACsec"]
    end

    subgraph REGNET["Regulated networks, inside fldr-regulated"]
        RACME["vpc-r-acme<br/>us-east4 / us-central1"]
        RGLOB["vpc-r-globex"]
        RSHARED["vpc-r-shared"]
    end

    subgraph GENNET["General networks"]
        HUB["vpc-gen-hub<br/>Cloud NGFW, Secure Web Proxy"]
        GDEV["vpc-gen-dev"]
        GNP["vpc-gen-nonprod"]
        GPRD["vpc-gen-prod"]
    end

    DC --- IC
    IC -- "VLAN attachments per customer<br/>from VRF-PHI only" --> RACME
    IC -- "VLAN" --> RGLOB
    IC -- "VLAN" --> RSHARED
    IC -- "VLAN from VRF-CORP" --> HUB
    INOFF -- "HA VPN" --> HUB
    PHOFF -- "HA VPN" --> HUB
    HUB --- GDEV
    HUB --- GNP
    HUB --- GPRD

Regulated zone

• One Shared VPC host per strict-US customer (prj-r-<customer>-svpc) and one for the shared PHI zone, each with subnets in us-east4 and us-central1 only.
• Dedicated VLAN attachments from the Interconnect for each regulated VPC, terminating on the data center’s PHI VRF. The corporate VRF that carries office traffic, including traffic from the offshore offices, cannot route into these attachments. Cloud Router advertisements are filtered so offshore prefixes are never learned.
• No Cloud NAT. Egress to the internet goes through a Secure Web Proxy in each regulated VPC with an explicit allow-list (for example a clearinghouse API), and every request is logged.
• Google APIs are reached only through Private Service Connect endpoints for the vpc-sc bundle, with private DNS zones that resolve *.googleapis.com to them.
• Inbound partner traffic (HL7/FHIR from hospitals) arrives through an external Application Load Balancer with Cloud Armor (mTLS for partners, geo-restriction to the US, WAF rules) or over the Interconnect.

General zone

• Hub-and-spoke: vpc-gen-hub holds Cloud NGFW policies, Secure Web Proxy and Cloud NAT. The dev, nonprod and prod spokes connect through Network Connectivity Center, with spoke-to-spoke traffic controlled at the hub.
• India and Philippines offices connect with HA VPN (two tunnels per office, BGP) to the hub only.
• Developers reach workloads through IAP. Cloud Workstations in us-east4 give offshore engineers a US-hosted development environment close to the data.

Shared

• Hierarchical firewall policies: an org-level policy allows IAP and health-check ranges and denies common bad actors. A fldr-regulated policy denies all offshore office CIDRs and all general-zone ranges as defense in depth, even though no routes exist.
• Hybrid DNS: Cloud DNS in prj-net-dns for general zones, forwarding to on-prem. Each regulated VPC has its own private zones, so general-zone names never resolve regulated endpoints.
• IP plan: non-overlapping supernets per zone and per customer, sized for two active regions and room for new strict-US customers. Each new customer gets the next pre-allocated block.

Cloud-only access

For staff who are not on a corporate network, and as the default for offshore teams:

• Chrome Enterprise Premium (BeyondCorp) with Endpoint Verification provides device posture.
• IAP for consoles, SSH/RDP and internal web apps, with access levels per zone. Regulated access levels require regions: [US] and a corporate-owned, encrypted device.
• Cloud Workstations in the general zone for offshore developers, and US-only VDI inside the regulated perimeters for the small number of US staff who must handle PHI directly.

The de-identification pipeline

The pipeline is the only bridge between the zones. Its design decides whether the offshore model is safe.

flowchart LR
    subgraph REGP["Regulated perimeter: prj-r-deid"]
        SRC["PHI sources<br/>Healthcare API FHIR / DICOM,<br/>BigQuery, Cloud Storage"]
        JOB["De-identify<br/>Healthcare API de-identify,<br/>Sensitive Data Protection templates,<br/>Dataflow"]
        STAGE["Staging dataset<br/>de-identified copy"]
        VAL["Validate<br/>SDP inspection scan,<br/>re-identification risk analysis"]
        Q["Quarantine"]
    end
    subgraph GENP["General perimeter: prj-n-deid-data"]
        DST["De-identified datasets<br/>BigQuery, Cloud Storage"]
        DISC["SDP discovery<br/>continuous profiling"]
    end

    SRC --> JOB --> STAGE --> VAL
    VAL -- "pass" --> DST
    VAL -- "fail" --> Q
    DST --> DISC
    DISC -- "PHI found: alert + revoke" --> DST

1. Source selection. A pipeline configuration lists which customers’ data may be de-identified. Strict-US customers are included only if their contract allows it (the per-customer flag).
2. Transformation in the regulated zone. The Cloud Healthcare API de-identify operation handles FHIR and DICOM stores, including OCR redaction of text burned into images. It writes a copy to a destination dataset in the same location and never modifies the source. Structured data in BigQuery and files in Cloud Storage use Sensitive Data Protection de-identification templates: redaction, character masking, deterministic tokenization with a key held in prj-r-kms so joins still work, and date shifting so intervals between events are preserved. Templates are versioned in Git and approved by the privacy office.
3. De-identification standard. Templates implement HIPAA Safe Harbor (the 18 identifiers removed) by default. Datasets that need to keep more detail, such as exact dates for clinical analytics, go through Expert Determination with a documented risk analysis.
4. Validation before release. A Sensitive Data Protection inspection job scans the staged output for residual identifiers, and a risk analysis job (k-anonymity / l-diversity) checks re-identification risk. Failures go to quarantine and page the data engineering on-call.
5. One-way transfer. A VPC-SC egress rule on the regulated perimeter allows exactly one identity (sa-deid-publisher@prj-r-deid) to call exactly one method set (BigQuery and Cloud Storage writes) on exactly one project (prj-n-deid-data). A matching ingress rule on the general perimeter accepts it. Nothing is allowed in the other direction. The tokenization key never leaves the regulated zone, so tokens cannot be reversed offshore.
6. Continuous detection downstream. Sensitive Data Protection discovery profiles every BigQuery table and bucket in fldr-general. A high-sensitivity finding (for example an SSN pattern or names near diagnosis codes) creates an SCC finding and triggers automation that removes access to the table and opens an incident.

Treat the de-identification templates and the egress rule as production code with privacy-office approval. A one-line template change that stops masking a field is a reportable breach waiting to happen. Require two approvers, one from privacy, for changes to either.

Security and compliance controls

Organization policies

On top of the Google baseline from the concepts post:

Constraint	Scope	Value / purpose
gcp.resourceLocations	Organization	in:us-locations: every location-bound resource in the US, in both zones
gcp.restrictNonCmekServices	fldr-regulated	Listed services (BigQuery, Cloud Storage, Healthcare API, Cloud SQL, Compute) must use CMEK
gcp.restrictCmekCryptoKeyProjects	fldr-reg-cust-<name>	Only that customer’s prj-r-<name>-kms may supply keys, so no cross-customer key use
gcp.restrictServiceUsage	fldr-regulated	Allow-list of BAA-covered services in scope for the Assured Workloads package
iam.allowedPolicyMemberDomains	Organization	Only the company’s Cloud Identity customer ID
compute.vmExternalIpAccess	Organization	Deny all
compute.requireShieldedVm, compute.requireOsLogin	Organization	Enforced
sql.restrictPublicIp, storage.publicAccessPrevention	Organization	Enforced
iam.disableServiceAccountKeyCreation	Organization	Enforced, no exceptions in fldr-regulated
compute.restrictVpcPeering	fldr-regulated	Deny all, so no accidental peering to a general VPC
compute.restrictSharedVpcHostProjects	fldr-reg-cust-<name>	Service projects may attach only to that customer’s host

Service perimeters (VPC Service Controls)

• One perimeter per strict-US customer (sp-reg-acme, sp-reg-globex), one for the shared PHI zone (sp-reg-shared), one for regulated common services (sp-reg-common, containing de-identification, KMS and logging), and one broad perimeter for the general zone (sp-gen), following Google’s recommendation to apply VPC-SC broadly.
• Customer perimeters reach sp-reg-common only through narrow ingress and egress rules (for example the de-identification service account reading a customer’s FHIR store). No perimeter bridges, because a bridge opens all services between two perimeters.
• Every perimeter runs in dry-run mode for at least two weeks before enforcement. Violations are reviewed in Logs Explorer and in the VPC-SC troubleshooter.

Encryption and keys

• CMEK everywhere in the regulated zone, with a key ring per customer in that customer’s KMS project, using Cloud HSM keys. Key administrators (US platform security) are a different group from key users (the service agents of the customer’s projects).
• For customers that require it contractually, Cloud External Key Manager keys held in the customer’s or company’s external HSM, so access can be revoked outside Google.
• Key Access Justifications policies on regulated keys allow only justifications that correspond to customer-initiated access and approved support.
• Data in transit: TLS everywhere, mTLS for partner feeds, MACsec on the Interconnect.

Provider access

• Access Transparency enabled at the organization.
• Access Approval enrolled for fldr-regulated, so every Google support access requires approval by the US security on-call.

Detective controls

• Security Command Center Enterprise (or Premium) at the organization, with the HIPAA compliance standard assessed for fldr-regulated and CIS for everything else.
• Assured Workloads monitoring for residency and package violations.
• Cloud Asset Inventory feeds alerting on IAM changes in fldr-regulated, perimeter changes, new VLAN attachments and any org policy change.
• Sensitive Data Protection discovery across fldr-general (see the pipeline section).

Logging, monitoring and the SOC

Audit logs from PHI services can contain PHI, for example a FHIR resource ID or a query string. So logs follow the same zoning as data:

• Regulated logs go through a folder-level aggregated sink on fldr-regulated to prj-r-logging, into log buckets in us-east4 with six-year retention and bucket lock, encrypted with CMEK.
• General and org-level logs go to prj-c-logging-general.
• The organization’s default log storage location is set to a US region, so even _Default buckets in new projects stay in the US.
• Data Access audit logs (DATA_READ, DATA_WRITE) are enabled for the Healthcare API, BigQuery, Cloud Storage and Cloud SQL in fldr-regulated. This is the evidence for R5.
• The SOC has analysts in India. They work from SCC findings and a SIEM fed with a filtered, PHI-free log stream: log views and exclusion filters drop request payloads and resource names. Full regulated logs are readable only by the US security group. An incident that needs PHI-level investigation is escalated to US responders.
• Cloud Monitoring metrics scopes per zone. Alerts page US on-call for the regulated zone and the global rotation for the general zone.

Cost management

• One billing account, with billing export (standard and detailed) to BigQuery in prj-c-billing-export, and Looker Studio dashboards per customer, zone and team.
• Mandatory labels applied by the project factory: customer, dataclass (phi, deid, internal), env, costcenter, app, owner. The factory refuses to create a project without them.
• Budgets per strict-US customer folder (the basis for contract pricing), per general environment and per sandbox. Alerts at 50%, 90%, 100% and forecasted 100% go to Pub/Sub. A Cloud Run function posts them to the owning team’s channel and, for sandboxes, detaches billing at 120%.
• Known premium costs to plan for: Assured Workloads Premium (the with Support package), SCC Enterprise, Dedicated Interconnect ports, Cloud HSM keys, Sensitive Data Protection inspection and discovery volumes, and Data Access log volume. Exclude high-volume, low-value logs explicitly.
• Committed use discounts for the steady regulated production footprint once usage stabilizes (after about three months).

Infrastructure as code and operating model

• The foundation is built from terraform-example-foundation (or Cloud Foundation Fabric FAST), extended with stages for the regulated folder, per-customer folders, perimeters and the de-identification pipeline.
• Two pipelines with two identities: prj-b-cicd-general and prj-b-cicd-regulated. Only the regulated pipeline’s service account can change anything under fldr-regulated, and its repository requires approval from a US-based platform engineer.
• Offshore engineers can contribute Terraform modules and application code. Applying changes to the regulated zone is a US-only action, and the pipeline runs inside the US perimeter. Writing code is not accessing PHI. Approving and deploying into the zone is a controlled action.
• A customer onboarding module creates everything for a new strict-US customer in one pull request: folder, projects, Shared VPC host and IP block, VLAN attachments, KMS key ring, perimeter, groups and budget.
• Policy-as-code checks (gcloud terraform vet with custom constraints) reject plans that, for example, add a non-US region, add a general-zone group to a regulated folder, or loosen an egress rule.
• Break-glass: Privileged Access Manager entitlements on fldr-regulated, time-boxed to four hours, requiring a ticket ID and approval by a second US engineer. Every grant is logged and reviewed weekly.

Residual risks and open decisions

Risk / decision	Mitigation or owner
A determined insider abroad uses a US VPN exit and a stolen US credential	Phishing-resistant MFA, managed-device-only access levels, impossible-travel detection in Entra, and the identity is still not in any US-only group
A US employee shares a screen with an offshore colleague	Policy, training, VDI watermarking; legal and HR controls, not technical ones
De-identification misses an identifier in free text	SDP validation before release, discovery after release, Expert Determination for rich datasets
Contracts differ on whether de-identified data may go offshore	Per-customer flag in the pipeline; owner: legal and contracts
A Google service the team wants is not in the Assured Workloads package	Use it only in the general zone with de-identified data, or wait for it to be added to the package
Latency for offshore developers working on US-hosted environments	Cloud Workstations in us-east4, IDE-over-browser; measured during the pilot

Rollout plan

1. Weeks 1-3: foundation. Organization, super admins, Entra federation, bootstrap pipelines, common folder, org policies, logging and SCC.
2. Weeks 3-6: general zone. Hub network, HA VPN to the India and Philippines offices, dev and nonprod folders, Cloud Workstations, project factory. Offshore teams start on synthetic data.
3. Weeks 5-9: regulated zone. Assured Workloads folder, shared PHI zone, Interconnect and regulated VLANs, perimeters in dry run, CMEK, Access Approval.
4. Weeks 8-11: de-identification pipeline. Templates approved by privacy, validation jobs, one-way egress rule, SDP discovery in the general zone.
5. Weeks 10-12: first strict-US customer. Run the onboarding module, enforce perimeters, complete a penetration test and a mock audit, then migrate the customer’s data.
6. Ongoing: quarterly access reviews per customer, annual HIPAA risk assessment, and a landing zone backlog owned by the platform team.

References

• GCP Landing Zone: Core Concepts and Google’s Recommendations
• Landing zone design in Google Cloud
• Enterprise foundations blueprint
• Assured Workloads control packages
• Access Context Manager access level attributes
• VPC Service Controls overview
• Cloud Healthcare API de-identification
• Sensitive Data Protection de-identification
• HIPAA compliance on Google Cloud
• HHS guidance on de-identification of PHI
